LEGRAND 4 306 32 User manual

USER MANUAL
Indoor Dome IP 720p
4 306 32
LE05639AB

2
Contents
1General introduction....................................................................................................................3
1.1 Accessories.......................................................................................................................................3
1.2 Specifications ...................................................................................................................................4
1.3 Default network configuration .........................................................................................................5
2Structure .......................................................................................................................................6
2.1 Dimensions .......................................................................................................................................6
2.2 System...............................................................................................................................................6
3Installation ....................................................................................................................................7
4Connection to the camera and opening the Web application ..................................................8
4.1 IE configuration options: iE configuration tools ............................................................................8
4.1.1 Connect with the Config Tool..............................................................................................................................9
4.1.2 Connect with Internet Explorer............................................................................................................................9
4.2 Connect with Mozilla Firefox or Google Chrome............................................................................9
5Rapid Config Tool ......................................................................................................................10
5.1 Presentation....................................................................................................................................10
5.2 Search/Connection.........................................................................................................................10
5.2.1 Connect to the camera's Web interface............................................................................................................10
5.2.2 Modifying the network parameters....................................................................................................................11
6Resetting the camera.................................................................................................................13
7Smartphone and tablet applications.........................................................................................13
7.1 Apple (iOS)......................................................................................................................................13
7.2 Android............................................................................................................................................14

3
1 General introduction
1.1 Accessories
Accessory name:
Quantity
IP Camera
1
Bag for accessories (screws
and assembly diagram)
1
Quick start guide
1
CD
1

4
1.2 Specifications
Parameters
IP Camera
System
Processor
TI Davinci
Operating system
LINUX incorporated
Video parameters
Sensor
CMOS 1/3’’ Sony Exmor
Resolution
HD 720p : 1280 (H) x 960 (V)
Compression
H264/MJPEG
Maximum image
frequency
Main flow (1280 x 720 at 25 fps)
Secondary flow (704 x 576 at 25 fps)
Speed
H.264 64 to 8 192 Kbps
MJPEG : 64 to 10 240 Kbps
Adjustable speed
Capture
1 f/s (JPEG)
Privacy mask
4 zones
Lens
2.8 mm Megapixel
Lens interface
M12
Day/Night
Yes, automatic
Backlight
compensation
Yes (BLC)
Mirror and Rotation
Yes
Event
Motion detection
396 detection zones (18 x 22): sensitivity level from 1 to 6
(level 6 being the most sensitive).
Video recording, image capture, diary,
e-mail, etc… activated by event.
Video loss/Masking
Video recording, image capture, diary,
e-mail, etc… activated by event.
Recording
Recording priority
"Manual" > "Video detect" > "Schedule"
Local storage
No
Network
Cable network
Ethernet 10/100 Base-T
Network protocol
HTTP standard, TCP/IP, IPv4/IPv6, ARP, IGMP, ICMP, RTSP, RTP,
UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP,
Bonjour, SNMP.

5
Parameters
IP Camera
Network
Standard
ONVIF 2 / Profil S
Web access
Live, recording, system configuration, diary, maintenance, update,
etc.
Number of
simultaneous
connections
10
General settings
Reset
Integrated "RESET" button
Power supply
12 V DC ; PoE 802.5af.
Power consumption
2.5 W MAXIMUM
Operating temperature
-10 ℃to+55 ℃
Operating humidity
10–90%
Dimensions (mm)
110 × 54
Weight
0.25 Kg
Mounting
Wall or ceiling
Protection index
IP 30
1.3 Default network configuration
Network settings
Default configuration
TCP/IP
Mode
Static
IP address
192.168.1.108
Subnet mask
255.255.255.0
Default gateway
192.168.1.1
Connection
TCP port
37777
UDP port
37778
HTTP port
80
RTSP port
554
Authentication
Username
admin
Password
admin

6
2 Structure
2.1 Dimensions
2.2 System
X-Y-Z rotation module
Lens
Casing
Power supply 12 VDC
RJ45 (PoE)
Insert an Allen key to adjust the position

7
3 Installation
Step 1
Use the Allen key to loosen the three casing fixing screws
Step 2
Attach the template which is found in the box to help you drill the fixing holes
Step 3
Place the camera as shown in the diagram and fix it
Step 4
Loosen the 2 M3 fixing screws of the lens rotation module (you can turn it) Adjust the position of the module depending
on the desired angle of surveillance, then tighten the 2 rotation module screws
The following lens angles are possible: inclination (0° to +75°), panoramic rotation (-15° to +15°), rotation angle (-
15° to +15°).
Step 5
Replace the cover and use the Allen key to fix it.
Wall or ceiling
Expansion peg
Body of the camera
Screw
Camera casing
Casing fixing screws:

8
4 Connection to the camera and opening the Web application
4.1 IE configuration options: iE configuration tools
This camera is accessible via the web browser Internet Explorer.
If the system shows a warning message asking you if you want to install the application webrec.cab. Click "OK" so that
the system installs it automatically.
If you cannot install the file, you can lower the security level of Internet Explorer (see example below) or deactivate the
anti-phishing filter. Ensure that you have administrator rights for your Windows session.

9
4.1.1 Connect with the Config Tool
Refer to section 5.2.1 "Connect with the camera's Web interface"
4.1.2 Connect with Internet Explorer
The default IP parameters for the camera are as follows.
- IP address: 192.168.1.108
- Username: admin
- Password: admin
Open Internet Explorer 32 Bits in administrator mode
Enter the camera's IP address in the address bar.
If the IP address of your camera is 192.168.1.108, enter "http:// 192.168.1.108" in the address bar.
4.2 Connect with Mozilla Firefox or Google Chrome
Go to the Apple website, then download and install QuickTime (www.apple.com/quicktime/download).
Then open Firefox or Chrome, and enter the IP address of your camera in the browser URL.
Note: With these browsers, the appearance of the interface might be different and some buttons may not appear. If
necessary, you can use the IE extensions tab for your browsers.

10
5 Rapid Config Tool
5.1 Presentation
The rapid config tool allows you to search for or modify an IP address. It also allows you to modify the parameters. You
will find this tool on the CD supplied with your camera.
Before using the rapid config tool, please make sure that you have the latest version.
5.2 Search/Connection
In the list of applications, select "ConfigTool.exe" and double-click.
You must have at least version 1.07.0.R.121203 of the config tool.
5.2.1 Connect to the camera's Web interface
Click the "Refresh" button to show the list of devices connected to the network segment. The tool will then search for
connected devices and show the list of results with the corresponding IPv4 and IPv6 versions.
In the "Device list" interface, you can consult the IP addresses (IPv4 and IPv69 of the devices, the port number, the
subnet mask, the default gateway and the MAC address.
1 - Select the Ipv4 addresses (the IPv6 addresses disappear) and right-click on the highlighted line

11
2 - Select "Open Device Web" to access the camera's web interface:
If you cannot connect, check the Internet Explorer security settings as indicated in section4.
5.2.2 Modifying the network parameters
1 - Select the Ipv4 addresses (the IPv6 addresses disappear) and click to select your camera.

12
2 - Click on the "Login" button or double click on the highlighted line. The following page opens:
The connection parameters are already filled in.
3 - Click on the "Login" button and the main interface appears.
Functions
Description
DHCP
Enable
Allows the activation or disactivation
of the DHCP function
IPv4/IPv6
Allows a choice between IPv4 and
IPv6 in the menu. IP addresses can
be modified.
IP Address
Device IP address
Subnet
Mask
Device subnet mask
Gateway
Device gateway
Mac
Address
Device MAC address
Save
Allows the user to save any changes.
Return
Allows a return to the previous
interface.

13
6 Resetting the camera
Hold down the "Reset" button inside the camera for 10 seconds.
Wait for the camera to restart automatically.
The default parameters for the camera are reset.
7 Smartphone and tablet applications
7.1 Apple (iOS)
The "Legrand Camera Viewer" app, available on Appstore, allows you to consult your videosurveillance system locally or
remotely via an EDGE, 3G or Wi-Fi connection.
It includes live viewing, snapshot and recording functions.
An installation wizard, tutorials and help pages are available in the app.
The app is compatible with:
- iPhone 4 or higher (iOS 5 minimum)
- iPad 2 or higher, iPad mini (iOS 5 minimum)

14
7.2 Android
The "Legrand Camera Viewer" app, available on Google Play, allows you to consult your videosurveillance system locally
or remotely via an EDGE, 3G or Wi-Fi connection.
It includes live viewing, snapshot and recording functions.
An installation wizard, tutorials and help pages are available in the app.
The app is compatible with the following Smartphones:
Samsung Galaxy S 2 (Android 2.3 minimum)
Samsung Galaxy S (Android 2.3 minimum)
Samsung Galaxy Note (Android 4.0 minimum)
Samsung Galaxy S 3 (Android 4.0 minimum)
Samsung Galaxy Ace (Android 2.3 minimum)
Samsung Galaxy Nexus (Android 4.0 minimum)
Sony Xperia ray (Android 2.3 minimum)
Sony Xperia mini pro (Android 2.3 minimum)
Sony Xperia Arc S (Android 2.3 minimum)
Sony Xperia X10 (Android 2.3 minimum)
Sony Xperia mini (Android 2.2 minimum)
Google Nexus S (Android 2.3 minimum)
Google Nexus One (Android 2.1 minimum)
HTC Desire (Android 2.2 minimum)
HTC Sensation (Android 2.3 minimum)
HTC Hero (Android 2.1 minimum)
Motorola Defy (Android 2.3 minimum)
Motorola Atrix (Android 2.3 minimum)
Acer Liquid Gallant (Android 4.0 minimum)
The app is compatible with the following tablets:
Samsung Galaxy Tab (Android 3.1 minimum)
Samsung Galaxy Tab 2 (Android 4.0 minimum)
Amazon Kindle Fire (Android 2.3 minimum)
Asus Transformer Pad (Android 3.1 minimum)
Asus EEEPad (Android 4.0 minimum)
Google Nexus 7 (Android 4.1 minimum)
Acer Iconia Tab (Android 4.0 minimum)
