Thermostat with screen
User manual
1 Thermostat with screen 4
1.1 Function 4
1.2 What type of installation is it? 4
2 Description 5
2.1 Meaning of icons and buttons 5
2.2 Summary of functions and operating modes 6
3 Using the thermostat 8
3.1 Setting the temperature 8
3.2 Frost protection 8
3.3 Changing the heating/air conditioning function 9
3.4 Setting the fan in the fan coil unit 10
4 Programming 12
4.1 Open programming mode 12
4.2 Creating the network 12
4.3 Associating products 14
4.4 Closing programming mode 16
4.5 Conrming association 17
5 Different system configurations 18
5.1 1 fan coil unit with 2 tubes, and 1 ON/OFF valve 18
5.2 1 fan coil unit with 4 tubes, and 2 ON/OFF valves 19
5.3 2 tubes with 2 pumps 20

Thermostat with screen
User manual 1 Thermostat with screen
1.1 Function
The thermostat with screen is used to control the temperature (heating and/or air conditioning)
in rooms where it is installed, and can be congured for various applications according to need.
1.2 What type of installation is it?
Installation in hotel room (section 3)
Hotel Thermostat
In the hotel room conguration, customers can easily set the temperature and get the comfort
they want by operating the thermostat. For the hotel manager, it oers the option of integrating
the thermostats in the various rooms into a system which can be managed via a software
program, allowing consumption to be monitored and preventing waste of energy.
4

Thermostat with screen
User manual
2 Description
2.1 Meaning of icons and buttons
1 - Heating function.
2 - Air conditioning function.
3 - Operating mode icons (see table in section 2.2).
4 - MODE button: pressing briefly changes the device mode; pressing and holding down
changes the heating/air conditioning function. This function can be disabled for hotel
thermostat modes with a tool.
5 - + button: increases the programmed value.
6 - – button: decreases the programmed value.
7 - FAN button: sets the fan speed (3 levels + automatic).
8 - Heating/air conditioning enabled indicator (see table in section 2.2).
9 - Fan speed indicator (3 levels).
10 - Fan operating in automatic mode indicator.
11 - Measured temperature (thermometer symbol on)/set temperature (thermometer symbol
o) or setpoint indicator. Conguration with a tool.
12 - Unit of measurement °C or °F, modiable with a tool.
7
4
5
6
3
910
11
12
1 2
8
5

Thermostat with screen
User manual
Heating function
If the measured temperature is lower than the setpoint value, the heating
system is active and the symbol is displayed.
Air conditioning function
If the measured temperature is higher than the setpoint value, the air
conditioning system is active and the symbol is displayed.
Automatic switching function (no icon)
Should the temperature exceed certain preset thresholds, either the heating
symbol or air conditioning symbol will be displayed.
( * )
Comfort mode
The installation operates according to the ideal setting value programmed in
the heating and air conditioning functions.
( * )
Eco mode
The installation operates according to the energy eciency value
programmed in the heating and air conditioning functions.
( * )
Frost protection/Thermal protection/Off mode
Frost protection: minimum safe temperature.
Thermal protection: maximum safe temperature.
O: zone switched o.
Automatic mode
( * )
Mode which mimics the remote setting (control unit or control &
management software) .
2.2 Summary of functions and operating modes
2 Description
NB: Some functions can be modied with the tool.
6

Thermostat with screen
User manual
Setting the fan in the fan coil unit
By pressing the FAN button, the fan speed is set to
the desired level.
If the thermostat is managing a load such as a fan
coil unit, the fan speed can be set using the relevant
button.
Comfort, Eco and Frost protection mode
One of these modes is selected by pressing the MODE button.
NB : During setting, the fan symbol and the seg-
ment relating to speed ash.
OFF (configurable via radio)
Speed 1
Speed 2
Speed 3
Automatic operating
7

Thermostat with screen
User manual 3 Using the thermostat
Hotel thermostat
This section describes how to use the thermostat when it is installed in an hotel room.
3.1 Setting the temperature
3.2 Frost protection
Use the + and – buttons to change the existing
temperature setting.
Once the desired value has been set, wait a few
seconds for the new setting to be stored.
The setpoint remains displayed.
(“Hotel” tool cong.)
Default settings
Heating Air conditioning
Setting interval 7 – 30 °C 7 – 30 °C
The symbol and the value 7 °C are displayed on
screen.
8

Thermostat with screen
User manual
3.3 Changing the heating/air conditioning function (locked locally if congured as
“hotel”, modication with a tool).
To switch from the heating function to auto function
and then air conditioning, hold down the MODE
button for at least 7 seconds.
7 seconds
The switch to AUTO mode is indicated by the
absence of an icon.
The switch to AIR CONDITIONING mode is indicated
by the corresponding icon being displayed on
screen.
3 Using the thermostat
Repeating this operation runs cyclically from the Heating function to Auto function and then Air
conditioning.
7 seconds
9

Thermostat with screen
User manual
By pressing the FAN button, the fan speed can be set
to the desired level.
FAN OFF possible if congured with a tool.
If the thermostat is managing a load such as a fan
coil unit, the fan speed can be set using the relevant
button.
OFF (if congured with a tool)
Speed 1
Speed 2
Speed 3
Automatic operating
3.4 Setting the fan in the fan coil unit
10
3 Using the thermostat

Thermostat with screen
User manual
The guarantee is automatically rendered null and
void in the event of negligence, improper use
and/or modication carried out by unauthorised
personnel.
Some of the functions described in this manual can be congured with a tool.
11
3 Using the thermostat

Thermostat with screen
User manual
4 seconds
4 seconds ~10 seconds
Long press on + (NETW). The network is created.
4 Programming
4.1 Open programming mode
4.2 Creating the network
OFF
ON
SLOW FLASHING
QUICK FLASHING
1s Constant ashing. Once a second.
Constant ashing. Twice a second.
1s 1s
1s
2 PULSES 2 quick ashes 5 seconds apart.
5s
12

Thermostat with screen
User manual
The network is closed and both devices are in the same network.
The device which created the network ashes twice every 5 seconds.
The LED goes o.Brief press on NETWORK.
The LED comes on with
a steady light and then
ashes.
Brief press on NETWORK.
13
4 Programming

Thermostat with screen
User manual
Short press on - (LEARN).
Short press on FAN (ACTION).
4.3 Associating products
14
4 Programming

Thermostat with screen
User manual
Short press on LEARN.The LEARN LED ashes
slowly.
Short press on the
ACTION button.
The ACTION LED ashes
slowly.
The LEARN LED ashes
quickly.
15
4 Programming

Thermostat with screen
User manual
Everything goes o.
The LEDs ash and then go o.
The 2 devices are associated.
Simultaneous short presses
on MODE and FAN.
Short press on - LEARN
or 4 seconds automatic closure +
4.4 Closing programming mode
16
4 Programming

Thermostat with screen
User manual
Everything goes o.
17
4 Programming
4.5 Confirming association
To conrm association between the 2 devices, we recommend following the sequence below:
Press the FAN button on the thermostat and see that the FAN LEDs on the HVAC actuator
come on (not the FAN AUTO function):

Thermostat with screen
User manual
18
5.1 1 fan coil unit with 2 tubes, and 1 ON/OFF valve
a) Wiring example
b) Configuration
5 Different system configurations
0 884 00
FAN 1
FAN 2
FAN 3
COOL
HEAT
M
L
N
240 Vac
b1) If the installation is in WINTER version, icon, congure
the thermostat as « heating » function, symbolised by
(refer to the conguration pages at the beginning of the guide).
Si
Si
b2) If the installation is in SUMMER version, icon, congure
the thermostat as « air conditioning » function, symbolised by
(refer to the conguration pages at the beginning of the guide)

Thermostat with screen
User manual
19
5 Different system configurations
a) Wiring example
5.2 1 fan coil unit with 4 tubes, and 2 ON/OFF valves
M
N
FAN 1
FAN 2
FAN 3
N
COOL
HEAT
L
240 VAC
b) Configuration
In this example of reversible installations, congure the
thermostat as “automatic” function (refer to the conguration
pages at the beginning of the guide). The thermostat will
manage activation of the heating or air conditioning by
comparing the ambient temperature with the setpoint
temperature.
Depending on whether or not people are present, the mode
should alternate between COMFORT (presence) or ECO
(absence), or even FROST PROTECTION (long absence).

Thermostat with screen
User manual
20
5 Different system configurations
a) Wiring example
N
2
KEY
1 actuator
2 boiler
3 chiller
4 heating circulating pump
5 cooling circulating pump
6 radiator
7 fan coil unit
4
35 7
0 884 00
COOL HEAT
COOLING
HEATING
L
N
240 Vac
6
1
b) Configuration
In this example of reversible installations, congure the thermostat
as “automatic” function (refer to the conguration pages at the
beginning of the guide). The thermostat will manage activation
of the heating or air conditioning by comparing the ambient
temperature with the setpoint temperature. The dierence from
paragraph 5.2 is that activating the fan outputs will have no impact
on the installation. Depending on whether or not people are
present, the mode should alternate between COMFORT (presence)
or ECO (absence), or even FROST PROTECTION (long absence).
5.3 2 tubes with 2 pumps
