LEGRAND CHIEF CSPBPTA User manual

I N S T A L L A T I O N I N S T R U C T I O N S
(inside TA500)
In-Wall Box Back Plane Accessory
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
CSPBPTA

CSPBPTA Installation Instructions
2
DISCLAIMER
Legrand | AV and its affiliated corporations and subsidiaries
(collectively “Legrand | AV”), intend to make this manual
accurate and complete. However, Legrand | AV makes no claim
that the information contained herein covers all details,
conditions or variations, nor does it provide for every possible
contingency in connection with the installation or use of this
product. The information contained in this document is subject
to change without notice or obligation of any kind. Legrand | AV
makes no representation of warranty, expressed or implied,
regarding the information contained herein. Legrand | AV
assumes no responsibility for accuracy, completeness or
sufficiency of the information contained in this document.
Chief® is a registered trademark of Legrand AV Inc.
DEFINITIONS
MOUNTING SYSTEM: A MOUNTING SYSTEM is the
primary Chief product to which an accessory and/or component
is attached.
ACCESSORY: AN ACCESSORY is the secondary Chief
product which is attached to a primary Chief product, and may
have a component attached or setting on it.
COMPONENT: A COMPONENT is an audiovisual item
designed to be attached or resting on an accessory or mounting
system such as a video camera, CPU, screen, display,
projector, etc.
WARNING: A WARNING alerts you to the possibility of
serious injury or death if you do not follow the instructions.
CAUTION: A CAUTION alerts you to the possibility of
damage or destruction of equipment if you do not follow the
corresponding instructions.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: Failure to read, thoroughly understand, and
follow all instructions can result in serious personal injury,
damage to equipment, or voiding of factory warranty! It is the
installer’s responsibility to make sure all accessories are
properly assembled and installed using the instructions
provided.
WARNING: Failure to provide adequate structural strength
for this accessory can result in serious personal injury or
damage to equipment! It is the installer’s responsibility to
make sure the structure to which this accessory is attached
can support five times the combined weight of all equipment.
Reinforce the structure as required before installing the
accessory.
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components attached to this accessory does not exceed
20 lbs (9.07 kg).
WARNING: Use this accessory only for its intended use as
described in these instructions. Do not use attachments not
recommended by the manufacturer.
WARNING: Never operate this accessory if it is damaged.
Return the accessory to a service center for examination and
repair.
WARNING: Do not use this accessory outdoors.
WARNING: RISK OF INJURY TO PERSONS! Do not use
this accessory to support video equipment such as
televisions or computer monitors.
--SAVE THESE INSTRUCTIONS--

Installation Instructions CSPBPTA
3
DIMENSIONS
LEGEND
.48
2.05
18.25
17.00
1.13
A
18.75
13.75
.75
28.30
B
.75
1.50
.75
.25
DETAIL A
SCALE 1 : 4
HOLE FOR CABLE
TIE CLIP, 8 PROVIDED
4.00 .90
DETAIL B
SCALE 1 : 4
CABLE TIE POINT
14 PLACES
Tighten Fastener
Apretar elemento de fijación
Befestigungsteil festziehen
Apertar fixador
Serrare il fissaggio
Bevestiging vastdraaien
Serrez les fixations
Loosen Fastener
Aflojar elemento de fijación
Befestigungsteil lösen
Desapertar fixador
Allentare il fissaggio
Bevestiging losdraaien
Desserrez les fixations
Phillips Screwdriver
Destornillador Phillips
Kreuzschlitzschraubendreher
Chave de fendas Phillips
Cacciavite a stella
Kruiskopschroevendraaier
Tournevis à pointe cruciforme
Pencil Mark
Marcar con lápiz
Stiftmarkierung
Marcar com lápis
Segno a matita
Potloodmerkteken
Marquage au crayon
Drill Hole
Perforar
Bohrloch
Fazer furo
Praticare un foro
Gat boren
Percez un trou
Security Wrench
Llave de seguridad
Sicherheitsschlüssel
Chave de segurança
Chiave di sicurezza
Veiligheidssleutel
Clé de sécurité

CSPBPTA Installation Instructions
4
TOOLS REQUIRED FOR INSTALLATION
PARTS
3/32" (2.38mm)
#2
5/32" (security)
(included)
A (1)
[Accessory plate]
B (8)
C (16)
[Cable tie]
[Cable clip]

Installation Instructions CSPBPTA
5
Assembly And Installation
1. Mount TA500/501 enclosure box to wall following TA500/
501 installation instructions.
2. Install four attachment brackets to inside of TA500/501
following TA500/501 installation instructions.
3. Attach accessory plate (A) to top two attachment brackets
while also attaching top plate of Thinstall mount to two
attachment brackets following TA500/501 installation
instructions. (See Figure 1)
Figure 1
4. Slide Thinstall mount onto top plate as described in Thinstall
mount installation instructions.
5. Attach Thinstall mount and accessory plate (A) to two lower
attachment brackets following TA500/501 installation
instructions. (See Figure 2)
Figure 2
Component Installation
WARNING: Exceeding the weight capacity can result in
serious personal injury or damage to equipment! It is the
installer’s responsibility to make sure the combined weight of
all components attached to this accessory does not exceed
20 lbs (9.07 kg).
1. Install components to accessory plate (A) as desired using
cable clips (B) and cable ties (C) for each component.
(A)
3
x 2
installation
spacers
5
x 2
installation
spacers

CSPBPTA Installation Instructions
6

Installation Instructions CSPBPTA
7

CSPBPTA Installation Instructions
