1. Introduction
This manual is an addendum to the installation manual for Keor MOD.
It describes only the procedure to finalize the installation of the seismic basement of the Keor MOD with Seismic Kit 3 111 19
and 3 111 20.
For all the other information related to the installation and the use, consult the installation and user/manual for Keor MOD.
For the technical electrical data:
- 3 111 19 is equivalent to 3 104 80.
- 3 111 20 is equivalent to 3 104 81.
1.1 Content of the kit
a9
a10
a11
a5
a8 a5
a6
a7
b3
b2
b1
B
a1
A
POS. TORQUING MOMENT
a9 18 Nm
b1 36 Nm
TAG DESCRIPTION QTY
ALateral mount subassembly 1+1
a1 Base Plate Draw.6087 4
a9 Screws M8X20 Cl.8.8 4
a10 Safety washer for M8 DIN 128 Cl.8.8 4
a11 Flat Washer for M8 ISO 7092 Cl.8.8 4
BExternal shoulder Draw.5849 2
b2 Screws M10X20 Cl 8.8 6+6
b3 Safety washer for M10 DIN 128 Cl.8.8 6+6
b4 Washer for M10 DIN 125 Cl.8.8 6+6
a5 Nut UNI5587 C.L.8.8Cl.8.8 2
a7 Washer 12X36X2.5 UNI6593 1
a8 Washer for UNI1751Cl.8.8 1

Keor MOD
5
Additional installation instructions
2. Installation procedure
2.1 Step 1
Remove the UPS cabinet from the pallet by following the unpackaging instructions in the installation manual.
Do not proceed with step 2 until the unpackaging has been completed.
2.2 Step 2
Install the lateral mounts (A) to the ground keeping them aligned and with each other.
Use 6 (3+3) M16 certied seismic fasteners to install the subassemblies, following the indications provided by the supplier.
Install the lateral mounts in the nal placement of the unit.
Torquing moment for M16 provided by seismic anchor producer.
a3
A

6
2. Installation procedure
2.3 Step 3
Align the unit with the guides anchored to the ground, refer to the image below to align the side holes, it is necessary
to keep a distance of 16 mm.
16mm

Keor MOD
7
Additional installation instructions
2.4 Step 4
• Assemble the ns (a2) with the support feet using grub screws (a3), nuts (b3) M12 and at washers.
• Mount the assembly of the four ns on the front brackets using the respective M8X20 screws and washers.
a2

8
2. Installation procedure
2.5 Step 5
• Adjust the support feet one by one until the machine has reached the height of the xing holes on the side shoulder (A).
• Fix the side shoulders (A) with the preassembled shoulders (B) using the 12 (6 + 6) screws M10X20 (a4).
a4

Keor MOD
9
Additional installation instructions
2.6 Step 6 (only for 3 111 19)
Only for the 3 111 19 (Keor MOD 125 kVA), in addition to the seismic basement, there are also ten metal bars and
twenty M4x8 screws to keep stable the battery packs in the drawers. For each battery drawer, after having followed
the instructions in the Keor MOD installation manual to install the battery packs, mount a metal bar with two relative
screws as shown in the picture:

10
The following picture shows the UPS with the seismic basement mounted:
2. Installation procedure

Keor MOD
11
