English

1 Important Information about your Instrument
Read and follow the User Manual on the accompanying USB card or on
myWorld@Leica Geosystems before using the product.
Direct link to
DD120/DD130/DD175:
Direct link to
DD220/DD230:
•This Quick Start Guide contains rst use directions as well as initial, basic instruc-
tions for setting up the product and operating it.
•Keep all documentation for future reference!
The products are intended to be used for the following applications:
•Detection, localisation and estimation of the depth of underground utilities with the
use of approved accessories
•Localisation, recording and storage of product usage
•Data transfer with Bluetooth
•Data communication with external appliances
The product must not be disposed with household waste.
Intended use
6 Important Information about your Instrument
en

1.1 Conformity to National Regulations
Valid for DA175/DA220/DA230 in EU:
Hereby, Leica Geosystems AG declares that the product/s is/are in com-
pliance with the essential requirements and other relevant provisions of
the applicable European Directives.
The full text of the EU declaration of conformity is available at the fol-
lowing Internet address:
http://www.leica-geosystems.com/ce.
Valid for DA175/DA220/DA230 in EU:
Hereby, Leica Geosystems AG declares that the radio equipment
type DD120/DD130/DD175/DD220/DD230 is in compliance with Direct-
ive 2014/53/EU and other applicable European Directives.
The full text of the EU declaration of conformity is available at the fol-
lowing Internet address: http://www.leica-geosystems.com/ce.
Valid for DD120/DD130 in USA/Canada:
FCC Part 15, Part 15 B/C
CAN ICES-003 B/NMB-003 B
EU
EU
USA
Canada
7 Important Information about your Instrument
en

Valid for DD175/DD220/DD230 and DA175 in USA/Canada:
For DD175 only:
Contains FCC ID: XPYNINAW15
FCC Part 15, Part 15 B
For DA175 only:
FCC ID: RFD-DA175
3177A-DA175
For DD220/DD230 only:
Contains FCC ID: T7VPAN10
FCC Part 15, Part 15 B/C
For DD175 only:
CAN ICES-003 B/NMB-003 B
Contains IC (DD175): 8595A-NINAW15
For DD220/DD230 only:
CAN ICES-003 B/NMB-003 B
Contains IC (DD220/DD230): 216Q-PAN10
Valid for all products in USA/Canada:
USA
Canada
8 Important Information about your Instrument
en

Changes or modications not expressly approved by Leica Geosystems for compliance
could void the user's authority to operate the equipment.
The conformity for countries with other national regulations has to be approved prior to
use and operation.
Others
9 Important Information about your Instrument
en

2 Instrument Components
0016742_001
a
b
c
d
e
f
aDisplay panel
Contains the operational controls.
bSpeakers
(mounted internally left and right)
Active at power on and when a signal is detected.
cOn/Off trigger
Press and hold the trigger to activate the Locator.
Release the trigger to deactivate.
dBattery hatch release
Pressing the release button unlocks the battery hatch
allowing access to the battery compartment.
eBattery compartment
6 x LR6 (AA) alkaline batteries are used. Replace all
batteries when indicated.
fCase foot
The case foot can be replaced if it is worn.
Contact your agency or Leica Geosystems authorised
service workshop.
Description of
components DD120/
DD130/DD175 locators
10 Instrument Components
en

0016598_003
Function key
Press and release to change the search mode.
i key
Used to access the user settings and to provide a depth readout for depth
locators.
DD120/DD130/DD175
locator keyboard
11 Instrument Components
en

a
b
d
e
f
c
13300_002
a Display
b Locator keyboard
c USB port
d Trigger
e Battery compartment
f Locator foot (wear part)
Description of
components DD220/
DD230 locators
12 Instrument Components
en

13302_001
Function key
Press and release to change the search mode.
Depth Estimation key
Press and release to take a depth reading.
Menu key
Press and hold to display the Locator main menu or to return back to the
locate screen.
Press and release to select a menu option.
Left navigation key
Press and release to select the previous menu option.
Right navigation key
Press and release to select the next menu option.
DD220/DD230 locator
keyboard
13 Instrument Components
en

013301_001
b
c
a
d
e
f
a Accessory compartment
b Connection socket
c Battery compartment and USB
port
d Signal transmitter keyboard
e Speaker
f Induction arrow
13192_001
ab e fc d
a Power key
b Power Output key and LED indic-
ators
c Low Battery LED indicator
d Connection Mode LED indicator
e Frequency key and LED indicators
f Mute key
Description
of transmitter
components
Transmitter keyboard
14 Instrument Components
en

•Refer to Technical Data for information about storage temperature range.
•Protect batteries from damp and wetness. Wet or damp batteries must be dried
before storing or use.
•Before storing the product for a long time, remove batteries from the product in
order to avoid the danger of leakage.
The Li-Ion battery pack is delivered with an energy content as low as possible and needs
to be woke up prior to use.
To wake up the Li-Ion battery pack, do the following:
1. Connect the charger plug into the charge jack
on the battery pack.
14479_001
2. Plug the connector into a suitable power
source.
14480_001
12/24 V
100-240 V
Alkaline batteries
Li-Ion battery pack
15 Instrument Components
en

☞The battery pack should be fully charged before use.
☞Result:
The small LED next to the charge jack ashes at a fast rate to indicate the
wake up process, then ashes at a slower rate to indicate that the battery
pack is active and charging.
☞Applicable to the DD220/DD230 locators and DA Signal Transmitters.
16 Instrument Components
en

3 Technical Data
For locator and transmitter:
Temperature
Operating temperature [°C] Operating temperature [°F]
-20 to +50 -4 to +122
Protection against water, dust and sand
Protection
DD120/DD130/DD175 Locator IP54 (IEC 60529)
DD220/DD230 Locator IP65 (IEC 60529)
DA175 Transmitter Opened: IP65 (IEC 60529)
Closed: IP67 (IEC 60529)
DA220/DA230 Transmitter Opened: IP67 (IEC 60529)
Closed: IP67 (IEC 60529)
Humidity
Protection
Max 95 % RH non condensing
The effects of condensation are to be effectively counteracted by periodically drying
out the instrument.
Environmental
specications
17 Technical Data
en

4 Care and Transport
Never carry the product loose in a road vehicle, as it can be affected by shock and
vibration. Always carry the product in its container and secure it.
For products for which no container is available use the original packaging or its equival-
ent.
Transport in a road
vehicle
18 Care and Transport
en

5 Operation
Only at the rst use to start the locator:
1. Press and hold the trigger until the word SET
appears on the display.
0016786_002
2. Then press and hold the Function key for ve
seconds.
The locator can be operated now.
0023089_001
5 sec.
Turning on and off the
DD120/DD130/DD175
19 Operation
en

Normal use:
1. Press and hold the trigger to turn on and operate
the locator.
0016786_002
2. Release the trigger to turn off the locator.
Press and hold the trigger to turn on and operate the locator.
Release the trigger to turn off the locator.
13303_001
Turning on and off the
DD220/DD230
20 Operation
