Leica iCB50 User manual

Leica iCB50/iCB70
User Manual
Version 2.0
English

Introduction
Congratulations on the purchase of the Leica iCB50/iCB70.
This manual contains important safety directions as well as instructions for
setting up the product and operating it. Refer to "1 Safety Directions" for fur-
ther information.
Read carefully through the User Manual before you switch on the product.
The content of this document is subject to change without prior notice. Ensure
that the product is used in accordance with the latest version of this docu-
ment.
Updated versions are available for download at the following Internet address:
https://myworld.leica-geosystems.com > myDownloads.
The model and serial number of your product are indicated on the type plate.
Always refer to this information when you need to contact your agency or
Leica Geosystems authorised service centre.
•Windows is a registered trademark of Microsoft Corporation in the United
States and other countries
•Bluetooth® is a registered trademark of Bluetooth SIG, Inc.
All other trademarks are the property of their respective owners.
This manual applies to all iCB50/iCB70 instruments. Where there are differ-
ences between the various models they are clearly described.
Name Description/Format
iCB50/70
Quick Guide
Provides an overview of the product together
with technical data and safety directions. Inten-
ded as a quick reference guide.
ü ü
iCB50/70
User Manual
All instructions required in order to operate the
product to a basic level are contained in the User
Manual. Provides an overview of the product
together with technical data and safety direc-
tions.
-ü
iCON build
How-To
Guide
Overall comprehensive guide to the product and
application functions. Included are detailed
descriptions of special software/hardware set-
tings and software/hardware functions intended
for technical specialists.
-ü
Refer to the following resources for all iCB50/70 documentation/soft-
ware:
•the supplied data storage device
•https://myworld.leica-geosystems.com
Purchase
☞
Product identication
Trademarks
Validity of this
manual
Available documenta-
tion
2

On the last page of this manual, you can nd the address of Leica Geosystems
headquarters. For a list of regional contacts, please visit
http://leica-geosystems.com/contact-us/sales_support.
myWorld@Leica Geosystems (https://myworld.leica-geosystems.com)
offers a wide range of services, information and training material.
With direct access to myWorld, you are able to access all relevant services
whenever it is convenient for you.
Service Description
myProducts Add all products that you and your company own
and explore your world of Leica Geosystems: View
detailed information on your products and update
your products with the latest software and keep up-
to-date with the latest documentation.
myService View the current service status and full service his-
tory of your products in Leica Geosystems service
centres. Access detailed information on the services
performed and download your latest calibration cer-
ticates and service reports.
mySupport Create new support requests for your products that
will be answered by your local Leica Geosystems
Support Team. View the complete history of your
support requests and view detailed information on
each request in case you want to refer to previous
support requests.
myTraining Enhance your product knowledge with Leica Geosys-
tems Campus - Information, Knowledge, Training.
Study the latest online training material on your
products and register for seminars or courses in
your country.
myTrustedServices Add your subscriptions and manage users for Leica
Geosystems Trusted Services, the secure software
services, that assist you to optimise your workow
and increase your efciency.
Leica Geosystems
address book
3

Table of Contents
1 Safety Directions 6
1.1 General 6
1.2 Denition of Use 7
1.3 Limits of Use 7
1.4 Responsibilities 7
1.5 Hazards of Use 8
1.6 Laser Classication 11
1.6.1 General 11
1.6.2 Distancer, Measurements with Reectors 12
1.6.3 Distancer, Measurements without Reectors 12
1.6.4 Red Laser Pointer 14
1.6.5 Laser Plummet 16
1.7 Electromagnetic Compatibility (EMC) 17
1.8 FCC Statement, Applicable in U.S. 19
1.9 ISED Statements (EN/FR), Applicable in Canada 21
2 Description of the System 22
2.1 System Components 22
2.2 Container Contents 23
2.3 Instrument Components 24
3 User Interface 26
3.1 Keyboard 26
3.2 Operating Principles 26
4 Operation 30
4.1 Instrument Setup 30
4.2 Batteries 33
4.2.1 Operating Principles 33
4.2.2 Battery for the iCB Instrument 33
4.3 Data Storage 34
4.4 Distance Measurements - Guidelines for Correct Results 34
5 Check & Adjust 36
5.1 Overview 36
5.2 Preparation 37
5.3 Combined Adjustment (l, t, i and c) 38
5.4 Adjusting the Circular Level of the Instrument and Tribrach 40
5.5 Adjusting the Circular Level of the Prism Pole 41
5.6 Inspecting the Laser Plummet of the Instrument 41
5.7 Servicing the Tripod 42
6 Care and Transport 43
6.1 Transport 43
6.2 Storage 43
6.3 Cleaning and Drying 44
7 Technical Data 45
7.1 Angle Measurement 45
7.2 Distance Measurement with Reectors 45
7.3 Distance Measurement without Reectors
(Non-Prism mode)
46
7.4 LOC8 Theft Deterrence and Location Device (optional) 47
7.5 Conformity to National Regulations 47
7.5.1 iCB50/iCB70 47
7.5.2 LOC8 Theft Deterrence and Location Device (optional) 48
7.5.3 Dangerous Goods Regulations 49
4 Table of Contents

7.6 General Technical Data of the Product 50
7.7 Scale Correction 53
7.8 Reduction Formulas 54
8 Software Licence Agreement 56
Appendix A Directory Structure 57
Table of Contents 5

1 Safety Directions
1.1 General
The following directions enable the person responsible for the product, and
the person who actually uses the equipment, to anticipate and avoid opera-
tional hazards.
The person responsible for the product must ensure that all users understand
these directions and adhere to them.
Warning messages are an essential part of the safety concept of the instru-
ment. They appear wherever hazards or hazardous situations can occur.
Warning messages...
•make the user alert about direct and indirect hazards concerning the use
of the product.
•contain general rules of behaviour.
For the users‘ safety, all safety instructions and safety messages shall be
strictly observed and followed! Therefore, the manual must always be available
to all persons performing any tasks described here.
DANGER, WARNING, CAUTION and NOTICE are standardised signal words for
identifying levels of hazards and risks related to personal injury and property
damage. For your safety, it is important to read and fully understand the fol-
lowing table with the different signal words and their denitions! Supplement-
ary safety information symbols may be placed within a warning message as
well as supplementary text.
Type Description
DANGER Indicates an imminently hazardous situation
which, if not avoided, will result in death or
serious injury.
WARNING Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
may result in minor or moderate injury.
NOTICE
Indicates a potentially hazardous situation or
an unintended use which, if not avoided,
may result in appreciable material, nancial
and environmental damage.
☞Important paragraphs which must be
adhered to in practice as they enable the
product to be used in a technically correct
and efcient manner.
Description
About warning
messages
6 Safety Directions

1.2 Denition of Use
•Measuring horizontal and vertical angles
•Measuring distances
•Recording measurements
•Visualising the aiming direction and vertical axis
•Data communication with external appliances
•Computing with software
•Use of the product without instruction.
•Use outside of the intended use and limits.
•Disabling safety systems.
•Removal of hazard notices.
•Opening the product using tools, for example screwdriver, unless this is
permitted for certain functions.
•Modication or conversion of the product.
•Use after misappropriation.
•Use of products with recognisable damage or defects.
•Use with accessories from other manufacturers without the prior explicit
approval of Leica Geosystems.
•Deliberate dazzling of third parties.
•Controlling of machines, moving objects or similar monitoring application
without additional control and safety installations.
•Aiming directly into the sun.
•Inadequate safeguards at the working site.
1.3 Limits of Use
Suitable for use in an atmosphere appropriate for permanent human habita-
tion: not suitable for use in aggressive or explosive environments.
WARNING
Working in hazardous areas, or close to electrical installations or sim-
ilar situations
Life Risk.
Precautions:
▶Local safety authorities and safety experts must be contacted by the per-
son responsible for the product before working in such conditions.
1.4 Responsibilities
Leica Geosystems AG, CH-9435 Heerbrugg, hereinafter referred to as Leica
Geosystems, is responsible for supplying the product, including the User
Manual and original accessories, in a safe condition.
Intended use
Reasonably
forseeable misuse
Environment
Manufacturer of the
product
Safety Directions 7

The person responsible for the product has the following duties:
•To understand the safety instructions on the product and the instructions
in the User Manual.
•To ensure that it is used in accordance with the instructions.
•To be familiar with local regulations relating to safety and accident pre-
vention.
•To inform Leica Geosystems immediately if the product and the applica-
tion becomes unsafe.
•To ensure that the national laws, regulations and conditions for the oper-
ation of the product are respected.
1.5 Hazards of Use
NOTICE
Dropping, misusing, modifying, storing the product for long periods or
transporting the product
Watch out for erroneous measurement results.
Precautions:
▶Periodically carry out test measurements and perform the eld adjust-
ments indicated in the User Manual, particularly after the product has
been subjected to abnormal use as well as before and after important
measurements.
DANGER
Risk of electrocution
Because of the risk of electrocution, it is dangerous to use poles, levelling
staffs and extensions in the vicinity of electrical installations such as power
cables or electrical railways.
Precautions:
▶Keep at a safe distance from electrical installations. If it is essential to
work in this environment, rst contact the safety authorities responsible
for the electrical installations and follow their instructions.
WARNING
Lightning strike
If the product is used with accessories, for example masts, staffs, poles, you
may increase the risk of being struck by lightning.
Precautions:
▶Do not use the product in a thunderstorm.
Person responsible
for the product
8 Safety Directions

WARNING
Distraction/loss of attention
During dynamic applications, for example stakeout procedures, there is a
danger of accidents occurring if the user does not pay attention to the envir-
onmental conditions around, for example obstacles, excavations or trafc.
Precautions:
▶The person responsible for the product must make all users fully aware of
the existing dangers.
WARNING
Inadequate securing of the working site
This can lead to dangerous situations, for example in trafc, on building sites
and at industrial installations.
Precautions:
▶Always ensure that the working site is adequately secured.
▶Adhere to the regulations governing safety, accident prevention and road
trafc.
CAUTION
Pointing product toward the sun
Be careful when pointing the product toward the sun, because the telescope
functions as a magnifying glass and can injure your eyes and/or cause damage
inside the product.
Precautions:
▶Do not point the product directly at the sun.
CAUTION
Not properly secured accessories
If the accessories used with the product are not properly secured and the
product is subjected to mechanical shock, for example blows or falling, the
product may be damaged or people can sustain injury.
Precautions:
▶When setting up the product, make sure that the accessories are correctly
adapted, tted, secured, and locked in position.
▶Avoid subjecting the product to mechanical stress.
Safety Directions 9

WARNING
Inappropriate mechanical inuences to batteries
During the transport, shipping or disposal of batteries it is possible for inap-
propriate mechanical inuences to constitute a re hazard.
Precautions:
▶Before shipping the product or disposing it, discharge the batteries by the
product until they are at.
▶When transporting or shipping batteries, the person in charge of the
product must ensure that the applicable national and international rules
and regulations are observed.
▶Before transportation or shipping, contact your local passenger or freight
transport company.
WARNING
Exposure of batteries to high mechanical stress, high ambient temper-
atures or immersion into uids
This can cause leakage, re or explosion of the batteries.
Precautions:
▶Protect the batteries from mechanical inuences and high ambient tem-
peratures. Do not drop or immerse batteries into uids.
WARNING
Short circuit of battery terminals
If battery terminals are short circuited e.g. by coming in contact with jewellery,
keys, metallised paper or other metals, the battery can overheat and cause
injury or re, for example by storing or transporting in pockets.
Precautions:
▶Make sure that the battery terminals do not come into contact with
metallic objects.
10 Safety Directions

WARNING
Improper disposal
If the product is improperly disposed of, the following can happen:
•If polymer parts are burnt, poisonous gases are produced which may
impair health.
•If batteries are damaged or are heated strongly, they can explode and
cause poisoning, burning, corrosion or environmental contamination.
•By disposing of the product irresponsibly you may enable unauthorised
persons to use it in contravention of the regulations, exposing themselves
and third parties to the risk of severe injury and rendering the environ-
ment liable to contamination.
•Improper disposal of silicone oil may cause environmental contamination.
•The product does include parts of Beryllium inside. Any modication of
some internal parts can release Beryllium dust or fragments, creating a
health hazard.
Precautions:
▶The product must not be disposed with household waste.
Dispose of the product appropriately in accordance with
the national regulations in force in your country.
Always prevent access to the product by unauthorised
personnel.
Product-specic treatment and waste management information can be
received from your Leica Geosystems distributor.
WARNING
Improperly repaired equipment
Risk of injuries to users and equipment destruction due to lack of repair
knowledge.
Precautions:
▶Only authorised Leica Geosystems Service Centres are entitled to repair
these products.
1.6 Laser Classication
1.6.1 General
The following chapters provide instructions and training information about
laser safety according to international standard IEC 60825-1 (2014-05) and
technical report IEC TR 60825-14 (2004-02). The information enables the per-
son responsible for the product and the person who actually uses the equip-
ment, to anticipate and avoid operational hazards.
☞According to IEC TR 60825-14 (2004-02), products classied as laser
class 1, class 2 and class 3R do not require:
•laser safety ofcer involvement,
•protective clothes and eyewear,
•special warning signs in the laser working area
if used and operated as dened in this User Manual due to the low
eye hazard level.
General
Safety Directions 11

☞National laws and local regulations could impose more stringent
instructions for the safe use of lasers than IEC 60825-1 (2014-05)
and IEC TR 60825-14 (2004-02).
1.6.2 Distancer, Measurements with Reectors
Depending on instrument model.
The EDM module built into the product produces a visible laser beam which
emerges from the telescope objective.
The laser product described in this section is classied as laser class 1 in
accordance with:
•IEC 60825-1 (2014-05): “Safety of laser products”
These products are safe under reasonably foreseeable conditions of operation
and are not harmful to the eyes provided that the products are used and
maintained in accordance with this User Manual.
Description Value
Wavelength 658 nm
Pulse duration 800 ps
Pulse repetition frequency 100 MHz
Maximum average radiant power 0.34 mW
Beam divergance 1.5 mrad x 3 mrad
18382_001
a
a Laser beam
1.6.3 Distancer, Measurements without Reectors
Depending on instrument model.
The EDM module built into the product produces a visible laser beam which
emerges from the telescope objective.
The laser product described in this section is classied as laser class 3R in
accordance with:
•IEC 60825-1 (2014-05): “Safety of laser products”
Direct intrabeam viewing may be hazardous (low eye hazard level), in particu-
lar for deliberate ocular exposure. The beam may cause dazzle, ash-blindness
Applicability
General
Applicability
General
12 Safety Directions

and after-images, particularly under low ambient light conditions. The risk of
injury for laser class 3R products is limited because of:
a)unintentional exposure would rarely reect worst case conditions of (e.g.)
beam alignment with the pupil, worst case accommodation,
b)inherent safety margin in the maximum permissible exposure to laser radi-
ation (MPE)
c)natural aversion behaviour for exposure to bright light for the case of vis-
ible radiation.
Description Value
(R500)
Wavelength 658 nm
Maximum average radiant power 4.8 mW
Pulse duration 800 ps
Pulse repetition frequency (PRF) 100 MHz
Beam divergence 0.2 mrad × 0.3 mrad
NOHD (Nominal Ocular Hazard Distance) @ 0.25 s 44 m / 144 ft
CAUTION
Class 3R laser products
From a safety perspective, class 3R laser products should be treated as poten-
tially hazardous.
Precautions:
▶Prevent direct eye exposure to the beam.
▶Do not direct the beam at other people.
CAUTION
Reected beams aimed at reecting surfaces
Potential hazards are not only related to direct beams but also to reected
beams aimed at reecting surfaces such as prisms, windows, mirrors, metallic
surfaces, etc.
Precautions:
▶Do not aim at areas that are essentially reective, such as a mirror, or
which could emit unwanted reections.
▶Do not look through or beside the optical sight at prisms or reecting
objects when the laser is switched on, in laser pointer or distance meas-
urement mode. Aiming at prisms is only permitted when looking through
the telescope.
Safety Directions 13

18383_001
Pav = 4.8mW λ= 658nm tp = 800ps
IEC 60825-1:2014
Complieswith 21 CFR 1040.10and 1040.11 except for conformance with
IEC 60825-1 Ed. 3., asdescribed in Laser Notice No. 56, dated May 8,2019.
This devicecomplies withpart 15of the FCC Rules.
Operation is subjectto thefollowingtwo conditions:
(1)Thisdevice may not cause harmfulinterference, and
(2)Thisdevice must accept anyinterferencereceived,includinginterference
thatmaycauseundesiredoperation.
Equip.No.:1234567
Power: 12-15V 16W max
Leica Geosystems AG
CH-9435 Heerbrugg
Manufactured:XX.20XX
Made in Singapore
Model: iCBX0
S.No.:
123456
Art.No.:
123456
18384_002
1.6.4 Red Laser Pointer
Depending on instrument model.
The laser pointer built into the product produces a visible red laser beam
which emerges from the telescope objective.
The laser product described in this section is classied as laser class 3R in
accordance with:
•IEC 60825-1 (2014-05): “Safety of laser products”
Direct intrabeam viewing may be hazardous (low eye hazard level), in particu-
lar for deliberate ocular exposure. The beam may cause dazzle, ash-blindness
and after-images, particularly under low ambient light conditions. The risk of
injury for laser class 3R products is limited because of:
a)unintentional exposure would rarely reect worst case conditions of (e.g.)
beam alignment with the pupil, worst case accommodation,
b)inherent safety margin in the maximum permissible exposure to laser radi-
ation (MPE)
c)natural aversion behaviour for exposure to bright light for the case of vis-
ible radiation.
Labelling
Applicability
General
14 Safety Directions

Description Value
(R500)
Wavelength 658 nm
Maximum average radiant power 4.8 mW
Pulse duration 800 ps
Pulse repetition frequency (PRF) 100 MHz
Beam divergence 0.2 mrad × 0.3 mrad
NOHD (Nominal Ocular Hazard Distance) @ 0.25 s 44 m / 144 ft
CAUTION
Class 3R laser products
From a safety perspective, class 3R laser products should be treated as poten-
tially hazardous.
Precautions:
▶Prevent direct eye exposure to the beam.
▶Do not direct the beam at other people.
CAUTION
Reected beams aimed at reecting surfaces
Potential hazards are not only related to direct beams but also to reected
beams aimed at reecting surfaces such as prisms, windows, mirrors, metallic
surfaces, etc.
Precautions:
▶Do not aim at areas that are essentially reective, such as a mirror, or
which could emit unwanted reections.
▶Do not look through or beside the optical sight at prisms or reecting
objects when the laser is switched on, in laser pointer or distance meas-
urement mode. Aiming at prisms is only permitted when looking through
the telescope.
18383_001
Labelling
Safety Directions 15

Pav = 4.8mW λ= 658nm tp = 800ps
IEC 60825-1:2014
Complieswith 21 CFR 1040.10and 1040.11 except for conformance with
IEC 60825-1 Ed. 3., asdescribed in Laser Notice No. 56, dated May 8,2019.
This devicecomplies withpart 15of the FCC Rules.
Operation is subjectto thefollowingtwo conditions:
(1)Thisdevice may not cause harmfulinterference, and
(2)Thisdevice must accept anyinterferencereceived,includinginterference
thatmaycauseundesiredoperation.
Equip.No.:1234567
Power: 12-15V 16W max
Leica Geosystems AG
CH-9435 Heerbrugg
Manufactured:XX.20XX
Made in Singapore
Model: iCBX0
S.No.:
123456
Art.No.:
123456
18384_002
1.6.5 Laser Plummet
The laser plummet built into the product produces a visible red laser beam
which emerges from the bottom of the product.
The laser product described in this section is classied as laser class 2 in
accordance with:
•IEC 60825-1 (2014-05): “Safety of laser products”
These products are safe for momentary exposures but can be hazardous for
deliberate staring into the beam. The beam may cause dazzle, ash-blindness
and after-images, particularly under low ambient light conditions.
Description Value
Wavelength 640 nm
Maximum average radiant power 0.95 mW
Pulse duration 0.1 ms - cw
Pulse repetition frequency (PRF) 1 kHz
Beam divergance <1.5 mrad
CAUTION
Class 2 laser product
From a safety perspective, class 2 laser products are not inherently safe for
the eyes.
Precautions:
▶Avoid staring into the beam or viewing it through optical instruments.
▶Avoid pointing the beam at other people or at animals.
General
16 Safety Directions

18388_001
a
b
18495_001
a Laser beam
bExit for laser beam
1.7 Electromagnetic Compatibility (EMC)
The term Electromagnetic Compatibility is taken to mean the capability of the
product to function smoothly in an environment where electromagnetic radi-
ation and electrostatic discharges are present, and without causing electro-
magnetic disturbances to other equipment.
WARNING
Electromagnetic radiation
Electromagnetic radiation can cause disturbances in other equipment.
Precautions:
▶Although the product meets the strict regulations and standards which
are in force in this respect, Leica Geosystems cannot completely
exclude the possibility that other equipment may be disturbed.
CAUTION
Use of the product with accessories from other manufacturers. For
example eld computers, personal computers or other electronic equip-
ment, non-standard cables or external batteries
This may cause disturbances in other equipment.
Precautions:
▶Use only the equipment and accessories recommended by Leica Geosys-
tems.
▶When combined with the product, they meet the strict requirements stip-
ulated by the guidelines and standards.
▶When using computers, two-way radios or other electronic equipment,
pay attention to the information about electromagnetic compatibility
provided by the manufacturer.
Labelling
Description
Safety Directions 17

CAUTION
Intense electromagnetic radiation. For example, near radio transmit-
ters, transponders, two-way radios or diesel generators
Although the product meets the strict regulations and standards which are in
force in this respect, Leica Geosystems cannot completely exclude the possib-
ility that function of the product may be disturbed in such an electromagnetic
environment.
Precautions:
▶Check the plausibility of results obtained under these conditions.
CAUTION
Electromagnetic radiation due to improper connection of cables
If the product is operated with connecting cables attached at only one of their
two ends, for example external supply cables, interface cables, the permitted
level of electromagnetic radiation may be exceeded and the correct function-
ing of other products may be impaired.
Precautions:
▶While the product is in use, connecting cables, for example product to
external battery, product to computer, must be connected at both ends.
WARNING
Use of product with radio or digital cellular phone devices
Electromagnetic elds can cause disturbances in other equipment, in installa-
tions, in medical devices, for example pacemakers or hearing aids and in air-
crafts. Electromagnetic elds can also affect humans and animals.
Precautions:
▶Although the product meets the strict regulations and standards which
are in force in this respect, Leica Geosystems cannot completely exclude
the possibility that other equipment can be disturbed or that humans or
animals can be affected.
▶Do not operate the product with radio or digital cellular phone devices in
the vicinity of lling stations or chemical installations, or in other areas
where an explosion hazard exists.
▶Do not operate the product with radio or digital cellular phone devices
near to medical equipment.
▶Do not operate the product with radio or digital cellular phone devices in
aircrafts.
▶Do not operate the product with radio or digital cellular phone devices for
long periods with the product immediately next to your body.
Radios or digital cel-
lular phones
18 Safety Directions

CAUTION
Exceeding the RF radiation exposure limits for general population
Health risk
Precautions:
▶The antennas used for this transmitter must be installed such that a min-
imum separation distance of at least 23 cm is always maintained between
the radiator (antenna) and all persons.
▶The antennas used for this transmitter must not be co-located or oper-
ated with any other antenna or transmitter.
1.8 FCC Statement, Applicable in U.S.
☞The greyed paragraph below is only applicable for products without
radio.
WARNING
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guaran-
tee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Changes or modications not expressly approved by Leica Geosystems for
compliance could void the user's authority to operate the equipment.
Safety Directions 19

Pav = 4.8mW λ= 658nm tp = 800ps
IEC 60825-1:2014
Complieswith 21 CFR 1040.10and 1040.11 except for conformance with
IEC 60825-1 Ed. 3., asdescribed in Laser Notice No. 56, dated May 8,2019.
This devicecomplies withpart 15of the FCC Rules.
Operation is subjectto thefollowingtwo conditions:
(1)Thisdevice may not cause harmfulinterference, and
(2)Thisdevice must accept anyinterferencereceived,includinginterference
thatmaycauseundesiredoperation.
Equip.No.:1234567
Power: 12-15V 16W max
Leica Geosystems AG
CH-9435 Heerbrugg
Manufactured:XX.20XX
Made in Singapore
Model: iCBX0
S.No.:
123456
Art.No.:
123456
18384_002
Pav = 0.95mW λ= 640nm tp = 0.1ms-cw
IEC 60825-1:2014
ComplieswithFDAperformance standards forlaserproductsexceptfor
deviationspursuant toLaserNotice No.50, dated June 24, 2007.
This devicecomplies withpart 15of the FCC Rules.
Operation is subject to thefollowing twoconditions:
(1)This device may not cause harmful interference, and
(2)Thisdevice must accept anyinterferencereceived,includinginterference
thatmaycauseundesiredoperation.
123456
S.No.:
123456
Art.No.:
Equip.No.: 1234567
Power:..V ..Wmax
LeicaGeosystemsAG
CH-9435Heerbrugg
Manufactured:20XX
Made in Singapore
iCBX0
Model:
18874_001
8469_007
XXXXXXXX-XXXXXX
A/S:[phone]
전지
Type: GEB361
Li-Ion Battery
11.1 V / 5.6 Ah
15 A / 62 Wh
Leica Geosystems AG, CH-9435 Heerbrugg
Art.No.: 799191
S.No.: XXXXX
Made in China
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Manufactured by Huizhou Longji Electronics Co., Ltd.
0016141_001
Labelling iCB50/iCB70
Laser Class 3R
Labelling iCB70
Laser Class 2
Labelling GEB331
Labelling GEB361
20 Safety Directions
