LH280 Manual
TM

What’s in the Box
Your LH280 Headset
Spare Eartips
205mAh 3.75v
Lithium-Ion Battery
Battery
Compartment Cover
8.5v AC Adaptor
RJ-9 Phone Cord
Type A-to-Mini
USB Cord

3
Contents
1. Product diagrams ..........................................................4
2. Setup .......................................................................6
2.1 Connecting to a telephone with a headset port...............................6
2.2 Connecting to a telephone without a headset port ...........................6
2.3 Connecting with a Leitner Handset Lifter .....................................6
2.4 Connecting a Leitner Electronic Hookswitch (EHS) cable ......................7
2.5 Connecting to your computer USB port ......................................7
2.6 Replacing the eartip .........................................................7
3. Operation ..................................................................7
3.1 Making an outgoing call in telephone mode..................................7
3.2 Receiving an incoming call in telephone mode ...............................8
3.3 Making an outgoing call in USB/PC mode.....................................8
3.4 Making a call using UniBase® Mode...........................................8
3.5 Adjusting the ring volume ...................................................9
3.6 Muting the headset microphone .............................................9
3.7 Headset microphone volume setting .........................................9
3.8 Adjusting headset listening volume ..........................................9
3.9 Out of range and reconnection...............................................9
3.10 Battery level indication .....................................................10
3.11 Training mode and making a conference call ................................10
3.12 Overview of audio signals ...................................................11
3.13 Registering a new headset to the base. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.14 Controlling the Automatic Answer feature for calls...........................12
3.15 Permanently register an additional headset .................................12
4. Troubleshooting ............................................................. 13
5. Health and safety instructions ............................................13

3
1. Receive volume up/down
2. Mute
3. Headset ON/OFF
4. Noise cancelling boom
5. Replaceable earplug
6. Battery (note position of
arrow when replacing)
4
5
6
1
3
2
B. WL1240 Headset
Manual W9xx_03.pdf 1 6/23/2016 10:18:40 AM
2
A. Base station
1. Battery indicator
2. PC button
3. Telephone (TEL) button
4. Online indicator
5. USB connector (PC port)
6. Power socket
7. EHS port
8. Telephone connector (‘Tel’ port)
9. Handset connector
10. EHS Selection switch
11. Microphone volume up/down
12. Wiring switch
5
7
6
9
8
10
11 12
1
4
3
2
Manual W9xx_02.pdf 1 6/23/2016 10:17:51 AM
Headset
1. Incoming volume up/down
2. Mute
3. Headset ON/OFF
(and online indicator)
4. Noise cancelling boom
5. Replaceable eartip
6. Battery (note position of
arrow before replacing)
7. Battery door
Noise-canceling boom
4 5 7
4
Base Station
1. Battery indicator
2. Computer Mode button
3. Telephone (TEL) Mode button
4. Online indicator
5. USB connector port
6. Power socket
7. AUX port
8. Telephone connector (TEL port)
9. Handset connector port
10. Accessory selection switch
11. Microphone volume up/down
12. Compatibility switch
1
2
34
5
6
7
8
9
10
11 12

3
1. Receive volume up/down
2. Mute
3. Headset ON/OFF
4. Noise cancelling boom
5. Replaceable earplug
6. Battery (note position of
arrow when replacing)
4
5
6
1
3
2
B. WL1240 Headset
Manual W9xx_03.pdf 1 6/23/2016 10:18:40 AM
2
A. Base station
1. Battery indicator
2. PC button
3. Telephone (TEL) button
4. Online indicator
5. USB connector (PC port)
6. Power socket
7. EHS port
8. Telephone connector (‘Tel’ port)
9. Handset connector
10. EHS Selection switch
11. Microphone volume up/down
12. Wiring switch
5
7
6
9
8
10
11 12
1
4
3
2
Manual W9xx_02.pdf 1 6/23/2016 10:17:51 AM
Headset
1. Incoming volume up/down
2. Mute
3. Headset ON/OFF
(and online indicator)
4. Noise cancelling boom
5. Replaceable eartip
6. Battery (note position of
arrow before replacing)
7. Battery door
Noise-canceling boom
4
57
5

6
2. Setup
• Plug in the included power adaptor to the base unit. The light on your base
will light up
NOTE: Charge your headset for at least 4 hours before you use it the rst time
2.1 Connecting to a telephone with a headset port
• Using the included connector cord, connect the TEL port on the back of the
headset base to the headset port on your desk phone
• You may need to adjust the compatibility switch located on the bottom of the base
to nd the correct setting for your phone model. The most common setting is 1*
2.2 Connecting to a telephone without a headset port
• Unplug the curly cord of your handset from your desk phone
• Using the included connector cord, connect the TEL port on the back of
headset base to the handset port on your desk phone
• Connect the other end of handset curly cord to the handset port on the headset base
• You may need to adjust the compatibility switch located on the bottom of the base
to nd the correct setting for your device. The most common setting is 1*
2.3 Connecting with a Leitner Handset Lifter
• Follow instructions in section 2.2 before moving onto next step
• Fit the handset lifter to your telephone as indicated in its user guide
• Connect the handset lifter to the AUX port located on the back of the headset base
• Ensure that the Accessory switch on the bottom of your base is set to RHL
• Want to see the setup video? Go to headsets.com/LifterSetup
*We’d love to help you get set up! Call us at 1-800-432-3738, Mon-Fri 6:00-4:30 Pacic Time

7
2.4 Connecting a Leitner Electronic Hookswitch (EHS) cable
• Connect the EHS cable to your telephone as indicated in its user guide
• Connect the EHS cable to the AUX and TEL ports on the back of the headset base
Refer to the user guide for the EHS cable for the correct setting of the Accessory
selection switch
With the handset lifter or EHS cable connected, you will be able to answer and end calls
using the ON/OFF button located on the headset — up to 350 feet away from your desk
2.5 Connecting to your computer USB port
• Connect the included USB cable to the USB port on the back of the
headset base and the other end to an available USB port on your computer
• Your computer will automatically recognize the device and install the correct
drivers. Wait a few seconds before using the headset
2.6 Replacing the eartip
To replace the eartip of your LH280, twist the eartip 90 degrees and pull the eartip towards
you
3. Operation
3.1 Making an outgoing call in telephone mode
• Ensure that the TEL button on top of the headset base is selected
• Press the headset’s ON/OFF button. The base’s Online Indicator will light
• If a handset lifter or electronic hookswitch device is connected to the headset base,
the line will be engaged automatically. Otherwise, you will need to lift the handset
of your telephone or activate the headset button on your telephone

8
• Dial the number you’re calling
• After nishing the call, press the headset ON/OFF button to end the call if you have a
handset lifter or EHS cable. Otherwise, just hang up the phone manually
3.2 Receiving an incoming call in telephone mode
• If there is an incoming call and the headset base is connected to a handset lifter or
electronic hookswitch device, the TEL light and headset light will ash, and a ring
tone will be heard on the headset
• Press the headset’s ON/OFF button. The base’s Online Indicator LED will light
• If a handset lifter or electronic hookswitch device is connected to the headset base,
the line will be engaged automatically. Otherwise, you will need to lift the handset of
your telephone or activate the headset button on your telephone
• To end the call, replace the headset on the base or press the ON/OFF button. If you do
not have an EHS cable or a handset lifter, you will need to manually disconnect the line
3.3 Making an outgoing call in USB/PC mode
• Ensure that the PC button on the top of the headset base is selected
• Press the headset’s ON/OFF button and the base’s Online Indicator will light
• After nishing your call, press the ON/OFF button to disconnect. The base’s
Online Indicator will turn o
• You may also need to click your softphone’s disconnect button to end the call
3.4 Making a call using UniBase® Mode
Your Leitner LH280 is equipped with UniBase technology that allows you to conference your
oce phone and softphone calls together. To activate UniBase mode, start with the base in
phone mode with a call on the phone line. Press and hold the PC button for 4 seconds. Both
phone and computer mode lights will light up. You can now conference a softphone call with
the existing telephone call. To exit UniBase mode, press the phone mode button.
Note: all computer sounds will be shared with the conference call.

9
3.5 Adjusting the ring volume
When the headset is ringing to indicate an incoming call, you can adjust the ring volume
using the volume control buttons located on the headset
3.6 Muting the headset microphone
To mute the headset microphone when on a call, press the mute button on the headset (in
between the volume buttons). While the headset is in mute mode, a short beep will be heard
on the headset every 8 seconds. Press the mute button again to end
3.7 Headset microphone volume setting
You can adjust your speaking volume by using the two buttons located on the bottom of the
headset base
3.8 Adjusting headset listening volume
Use the volume control buttons on the headset to adjust the listening volume. You will
hear a beep for each volume step up or down
3.9 Out of range and reconnection
You will hear warning beeps in the headset when you walk out of range of the base. If the
headset disconnects due to being out of range, the call will not drop. The headset will
automatically reconnect when you are back in range and the call will be active again
NOTE: If you do not move back inside the base range within 5 minutes, the call will be
disconnected

10
3.10 Battery level indication
The four LEDs on the top of the headset base indicate the battery level of your headset
battery
3.11 Training mode and making a conference call
Your Leitner LH280 headset allows a second headset to be temporarily connected to the base
for training or conference calls.
• Set up the call using the primary headset
• Once on the call, place the second headset on the base charger*
• After about one second, the Online Indicator on the secondary headset will turn on
and the primary base’s 2nd LED light will ash to indicate that the headset is registering
with the base unit
• Once the registering has completed, the LED light on the base will stop ashing
• Immediately remove the second headset from the base. Wait 6 seconds and then press
the 2nd headset’s ON/OFF button to join it to the call
NOTE: The additional headset will only remain registered to the base for the duration of the
call. After the primary headset has ended the call, the second headset will return to its normal
state. Returning either headset to its original base will also end conference mode
*Your Leitner LH280 headset can only be conferenced with another LH280 headset
Indication Battery level
One LED ashing < 20%
One LED on 20%-40%
Two LEDs on 40%-60%
Three LEDs on 60%-80%
Four LEDs on 80%-100%

11
3.12 Overview of audio signals
3.13 Registering a new headset to the base
You can register a new primary headset unit to your LH280 base using the following
procedure:
• Press and hold the TEL button on the base for ve seconds to make the base
enter registration mode. The TEL light will ash showing the base is in registration mode
• Press and hold the mute button on the headset for ve seconds to make the headset
enter the registration mode
• The headset will now be registered to the base which will take around 30 seconds.
When the registration has completed, the base TEL light will stop ashing
NOTE: The LH270 and LH275 model cannot register to the LH280 base
Sound Indication
2 rapid beeps (60 sec repeat) Low battery
2 beeps Nearly out of range
2 pitch tone Out of range
4 rapid beeps Back in range
1 beep Receiver volume up/down
2 pitch tone (8 sec repeat) Mute is on
1 beep Mute o/on
Multi tone (2 sec repeat) Ringer (EH device)

12
3.14 Controlling the Automatic Answer feature for calls
When you take your LH280 o of the base, your call will not be answered by
default. If you’d like to turn this feature on, simply hold the ”+” and “–“ buttons on your
headset together for 3 seconds. You’ll know this feature is activated when the LED light
slowly ashes.
To turn this feature back o, follow the same steps again. This time the LED light will quickly
ash, letting you know this feature has been turned back o.
3.15 Permanently register an additional headset
• With the original headset out of the base, press and hold the Volume Up button
undereath the base for about 5 seconds to enter registration mode. The TEL light on
the base will begin to ash to indicate you’re in registration mode
• Press and hold the ON/OFF button on the 2nd headset until the light on the headset
begins to ash
• Wait until the ON/OFF light on the headset stops ashing (about 30 seconds)
• The 2nd headset is now permanently registered to the new base
• You can charge this headset on its original base without ending the permanent
registration mode
• To end the permanent registration, follow the instructions in 3.13
*The rst headset to turn on will become the primary headset. Only the primary headset can
answer and end calls

13
4. Troubleshooting (For live support call 1-800-432-3738, Mon-Fri 6:00-4:30 Pacic Time)
Q. I have connected my headset base to my phone but the headset is not working
A. Make sure that the battery has been properly charged. Your headset requires an initial
4-hour charge before its rst use
Q. The headset is working but I cannot hear telephone calls correctly
A. Ensure that you have the correct compatibility setting by adjusting the switch on the
bottom of your headset base. The most common compatibility is 1. Cisco telephones
should be set to 4 when using the headset jack
Q. When the headset’s ON/OFF button is pressed, the handset lifter lifts the handset but
I cannot hear the call on the headset
A. Ensure that the headset base is connected to the telephone’s handset port and not the
headset port (if the telephone has one)
5. Health and safety instructions
Please read the following safety and operational instructions before using your Leitner
LH280. Please keep these instructions for your reference. When using this product, these
basic safety precautions and warnings should be followed to reduce the risk of re, electric
shock, injury to persons and damage to property.
General
Operating, charging and storage temperature is 0°C to 40°C (32°F to 104°F).
Warnings
• Never allow children to play with the product - small parts may be a
choking hazard
• Plug the AC adaptor into the outlet nearest the equipment that is easily accessible
• To reduce the risk of electric shock, explosion or re, use only the supplied charger or
Class 2 AC adaptor to charge the headset. Ensure that the voltage rating
(e.g. 120V, 60 Hz) corresponds to the power supply you intend to use

14
• Do not disassemble the product or AC adaptor as this may expose you to dangerous
voltages or other risks. Incorrect reassembly can cause electric shock or re when the
product is subsequently used
• Do not insert anything into the product because this may cause damage to the internal
components or cause injury to you
• Avoid contact with liquids. Do not locate this product near water, for example, near a
bathtub, or sink, in a wet basement, or near a swimming pool
• Discontinue use of product if the product overheats, has a damaged cord or plug, if the
product has been dropped or damaged, or if the product has come into contact
with liquids
• This product should never be placed over or near a heat source and should not be
placed in locations which do not have proper ventilation
• If you experience skin irritation after using this product, discontinue use
• Exposure to high volume sound levels or excessive sound pressure may cause
temporary or permanent damage to your hearing. Although there is no single volume
setting that is appropriate for everyone, you should always use your headset with the
volume set at moderate levels and avoid prolonged exposure to high volume sound
levels. The louder the volume, the less time is required before your hearing could be
aected. You may experience dierent sound levels when using your headset with
dierent devices. The device you use and its settings aect the level of sound you
hear. If you experience hearing discomfort, you should stop listening to the device
through your headset and have your hearing checked by your doctor.
To protect your hearing, some hearing experts suggest you:
1. Set the volume control in a low position before putting your headset on your ear and
use as low volume as possible
2. Avoid turning up the volume to block out noisy surroundings. Whenever possible,
use your headset in a quiet environment with low background noise
3. Limit the amount of time you use headsets at high volume levels
4. Turn the volume down if the sound from the headset prevents you from hearing
people speaking near you

15
To avoid the risk of electric shock, explosion, re or leakage of corrosive or toxic chemicals,
please observe the following charging and battery warnings:
Charging warnings
• Use only the charger provided with your headset to charge the product. Do not use
the charger for any other purpose. Ensure that the voltage rating corresponds to the
power supply you intend to use
• Charge the headset according to the instructions supplied with the unit
• Plug the AC adaptor or charger into an outlet that is near the equipment and will be
easily accessible
Headset battery warnings
The headset is equipped with a replaceable battery. To reduce the risk of re or injury to
persons read and follow these instructions
Do not dispose of the battery in a re. The battery may explode. Check your local laws for
disposal instructions
Do not open or mutilate the battery. There may be corrosive materials which can cause
damage to eyes or skin and may be toxic if swallowed
Never charge the battery where the temperature may fall below 0°C (32°F) or rise
above 40°C (104°F)
RECYCLING: the battery used in your headset must be recycled or disposed of properly.
Contact your local recycling center for proper disposal of your headset battery

®
© Leitner Headsets
