Welcome to clean air with TruSens. Thank you for allowing
us to join you on your journey towards wellness.
The air you breathe shouldbe clean, no matter where
you are in the room. TruSensSensorPod™, PureDirect™
Technology & 360 degree filtration ensure the whole
room benefits from cleaner air.

4
SAFETY INFORMATION
PLEASE READ AND SAVE THESE INSTRUCTIONS
Unplug or disconnect the appliance from the power
supply before replacingfilters or UV-C emitter, or when
appliance is not in use.
WARNING: To reduce the risk offire or electric shock,
do not use this fan with any solid-state speed control
device.
Do not operate any purifier with a damaged cord or
plug, or if the wall socket is loose. If the supply cord is
damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to
avoid a hazard.
Do not run cord under carpeting, throw rugs, runners,
or similar coverings. Do not run cord under furniture
or appliances. Arrange cord away from trac area and
where it will not be tripped over.
WARNING: Skin or eye damage may result from
directly viewing the light produced by the UV-C
emitter in this apparatus. Unintended use of the
appliance or damage to the housing may result in the
escape of dangerous UV-C radiation. UV-C radiation
may, even in little doses, cause harm to the eyes and
skin. Always disconnect power before relamping or
servicing. Replace UV-C emitter with 2415108 (for
Z-2000), or 2415111 (for Z-3000), Manufactured by
ACCO Brands.
• Remove all packaging, including thefilter bag,
before use.
• Appliances that are obviously damaged must not be
operated.
• This appliance must only be connected to a wall
socket outlet matching the supply plug type and
rating stated on the rating plate.
• Locate air purifier near the outlet wall socket and do
not use extension cords.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
• Children shall not play with, clean, or try to maintain
the appliance.
• Replace the UV-C emitter with the model specified
within this manual.
• Do not attempt to service or repair this product
yourself.
• Only use the purifier and SensorPod™ with the
power cable provided.
• Only clean this machine with a damp cloth, do not
use solvents or bleach.
• Ensure appliance is always placed onfirm level
surface before operation.
• Do not block or obstruct the air intake or outlet vents.
• Do not insertfingers or other items into the air intake
or outlet vents.
• When the air purifier is in standby mode the
SensorPod™ is still transmitting a signal/data.

5
Operating Frequency
Wireless: 2462 MHz
Maximum Transmit Power (EIRP)
Wireless: 0 dBm
Antenna Gain
Wireless: 2 Dbi
Hereby, ACCO UK Ltd declares that the radio
equipment types, Leitz TruSens Air Purifier
Z-2000/Z-3000 are in compliance with
Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following internet address:
https://declarations.accobrands.com/
A minimum separation distance of 0.2m must be
maintained between the user’s body and the device,
to comply with RF exposure requirements.
Waste Electrical and Electronic Equipment (WEEE)
At the end of its useful life, your product is considered to
be WEEE. As such, it is important to note that: WEEE is
not to be disposed of as unsorted municipal waste. It is to
be collected separately such that it can be disassembled
so its components and materials can be recycled, re-
used, and recovered (burned for energy content in the
production of electricity).
Public collection points have been set up by
municipalities for the collection of WEEE, free of charge
to you. Please return your WEEE to the collection facility
nearest your home or oce.
If you have diculty locating a collection facility, the
retailer that sold you the product should accept your
WEEE. If you are no longer in contact with your retailer,
please contact ACCO for assistance with this matter.
Recycling of WEEE is geared toward protecting the
environment, protecting human health, preserving raw
materials, improving sustainable development, and
ensuring a better supply of commodities in the European
Union. This will be achieved by retrieving valuable
secondary raw materials and reducing the disposal of
waste. You can contribute to the success of these goals by
returning your WEEE to a collection facility.
Your product is marked with the WEEE symbol
(wheelie bin with an X through it). This symbol is to
inform you that the WEEE is not to be disposed of as
unsorted municipal waste
Leitz TruSens air purifiers also come equipped with a
UV-C emitter. Upon replacement of this item (during the
lifetime of the product), these must also be returned and
disposed of at your local WEEE collection facility.
Further information and installation guides / videos for
the UV-C emitter can be found at www.leitz.com

6
FEATURE HIGHLIGHTS
SensorPod™
Remote air quality monitor that ensures cleaner air,
right where you need it.
PureDirect™ Technology
Independent lab testing confirms that two airflow streams are
better than one, moving air eectively and more comfortably
throughout the room.
Informs and Adapts
Colour-coded illuminated ring provides additional
information by communicating air quality in real-time.
360° Purification
HEPA filter captures pollutants and VOC gases/odours
from all directions. UV-C light kills germs and bacteria
that can get trapped in the filter.
Thoughtful Execution
Exceptional functionality wrapped in a contemporary
design that fits any environment.
AQI

PRODUCT OVERVIEW
Easy-carry handle
Power & signal
indicator Washable Prefilter
Air quality indicator display
Air outlet
Power cord
Carbon Filter
Simple touch control panel
Air inlet HEPA Filter
360° air intake
Easy-access door UV-C Lamp
Filter cover & knob (underneath)
Air Purifier
SensorPod ™Filter & UV-C Lamp

8
GETTING STARTED
1. Remove plastic bag from filter
Unscrew the bottom cover and remove the plastic bag from the filter.
2. Re-attach filter
Secure filter on the bottom cover and replace inside the purifier.

9
3. Set up
Plug-in your SensorPod
™, and place upright on tabletop or counter across the
room, within line of sight of the purifier.
Plug-in your air purifier unit and power on. Place the purifier on a flat surface, free
from obstructions.
Signal strength may vary by location. In the rare occasion that it doesn’t work –
see page 18.
4. Start living with cleaner air!
The purifier will automatically adjust fan speeds based on the air quality readings
from SensorPod, and proprietary PureDirect
™technology will deliver purified air
throughout the room!
up to 15m
room coverage 70 m 2

10
CONTROL PANEL
Fan Speed Settings
Select fan speed or AUTO mode. In AUTO mode,
purifier automatically adjusts fan speed based on air
quality readings from SensorPod
™.
Timer Mode
hours. To cancel this countdown, simply press button
until no timer setting is displayed.
UV Mode
UV-C lamp within the purifier’s filter chamber is on when
the symbol is white. The symbol will glow red
when it is time to replace the UV-C lamp.
Filter and UV Indicator Reset
HEPA, Carbon and UV indicators glow red when it is
time for each to be replaced.
When 1 indicator is on, simply hold Reset button for 3
seconds to reset that indicator.
When 2+ indicators are on, tap the Reset button to
select the correct indicator (selected indicator will blink)
before holding 3 seconds to reset that indicator.
Dimmer Mode
Display illumination turns o – for use while sleeping –
without sacrificing the eectiveness of the purifier.
Simply press the button again to bring back all
display features.
Power Button
(AUTO mode only available when purifier is paired with
SensorPod and receiving signal)
(See page 15 for replacement instructions)
(See pages 13-15 for replacement instructions. Follow above Reset

11
AIR QUALITY DISPLAY
Real-time Feedback
The revolutionary SensorPod
™evaluates the condition of your air by measuring
both small (PM2.5) and larger (PM10) particulate matter. It calculates the overall
air quality using a proprietary algorithm that is reactive to genuine increases in
pollutants without overreacting to someone entering the room or settling into
the couch.
The illuminated, colour-coded display communicates good, moderate or poor
air quality and a numeric value provides a greater level of detail.
In AUTO mode, the purifier automatically adjusts the fan speed in response to
these air quality readings.
TruSens utilises the Air Quality Index (1-500) created by the U.S. Environmental Protection Agency (EPA).
GOOD
BLUE | 0 - 50
MODERATE
YELLOW | 50 - 100
POOR
RED | 100 - 500

12
Air Inlet 360°
Air changed 2 times per hr 70 m²
Air Delivery Type PureDirect
™
Sensor SensorPod™, works up to 15 m from purifier
Fan Speed Settings Whisper, 1, 2, 3, Turbo
Purification Levels Washable Prefilter, Carbon, HEPA, UV-C Lamp
Timer Settings 2, 4, 8, 12 hr
Filter Change Indicators Carbon, HEPA, UV
Noise 32 - 66 dB
Dimensions 263 x 263 x 726 mm
Weight 5.7 kg
Motor Type DC motor
Power Requirements 220-240v 50/60H 0.5A
Power Consumption 68 W
Warranty 2 years
Replacement Filters & UV-C Lamp
3-in-1 HEPA drum filter 2415110
Carbon filter (3-pack) 2415109
UV-C Lamp 2415111
SPECIFICATIONS

13
CARE &MAINTENANCE
Accessing the filter chamber
1. Always power o the purifier by pressing the Power
Button and unplugging the power cord.
2. Gently place the unit on its side on the floor so that
the filter chamber cover and knob are exposed.
3. Turn the knob counter-clockwise and remove the
filter cover and 360° HEPA filter drum (Fig. A).
Fig. A
Fig. B
Fig. C
Fig. D
REPLACING HEPA FILTER
1. The HEPA indicator will glow red when it is time to
change the entire HEPA drum filter.
2. Gently pull the HEPA drum filter away from its place
secured to the filter cover (Fig. B).
3. Secure the replacement HEPA filter onto the filter
cover (Fig. C).
4. Gently replace the filter cover with filter drum into
the filter chamber and onto the threading, and turn
the knob clockwise until the knob and filter chamber
cover are securely tightened (Fig. D).
5. Plug-in and power on your purifier, and hold the
Reset button until the red HEPA indicator turns o.
Note: HEPA drum filter (on page 12) will include 3 layers: Washable
Prefilter, Carbon and HEPA

14
WASHING THE PREFILTER
1. The Carbon indicator will glow red when it is time to replace
the Carbon layer.
2. Gently peel away the Prefilter from the fastener strips (Fig. E).
3. Gently peel away the used Carbon layer from the fastener
strips (Fig. F).
4. Wrap a new Carbon layer around the filter drum and attach
to the same fastener strips (Fig. G).
5. Replace the Prefilter by wrapping it around the Carbon layer
and attach to the fastener strips (Fig. H).
6. Once the purifier is powered-on, hold the Reset button until
the red Carbon indicator turns o.
1. We recommend that you visually inspect the Prefilter every
month, and clean as needed. At minimum, you should
hand wash the Prefilter every time you change the Carbon
filter.
2. Gently peel away the Washable Prefilter from the fastener
strips (Fig. E).
3. Gently rinse with running water – allow Prefilter to air dry
before re-installing.
4. Replace the Prefilter by wrapping it around the filter drum
and attach to the fastener strips (Fig. H).
Note: Carbon filter 3-pack (on page 12) will cover 3 Carbon changes
between replacing the entire HEPA drum filter assembly (on page 13).
Fig. E
Fig. F
Fig. G
Fig. H
REPLACING CARBON FILTER

15
REPLACING UV-C LAMP
1. The indicator will glow red when it is time to
replace the UV-C lamp.
2. Remove HEPA filter drum (Fig. A), and use a
screwdriver to remove the 4 screws securing the UV
housing (Fig. I).
3. Gently remove the UV housing (Fig. J).
4. Disconnect the UV-C lamp from the socket within
the purifier (Fig. K).
5. Your replacement UV-C lamp (on page 12) will plug
directly into the same socket (Fig. L).
6. Replace the UV housing and use a screwdriver to
tighten the fastening screws.
7. Once the purifier is powered-on, hold the Reset
button until the indicator turns white.
Fig. I
Fig. K
Fig. J
Fig. L
Note: Upon replacement of the UV-C emitter please dispose of at your local WEEE collection facility.

16
Cleaning the air quality sensor
The SensorPod™uses an infrared light to detect particulate
matter, so it is important that you clean the viewing
chamber every 1-2 months to remove any dust or particles
that may aect the accuracy of the sensor’s readings.
1. Turn-o the SensorPod by unplugging the power cord.
2. Open the easy-access door on the front side by pulling
the door up at a 90° angle.
3. Use a damp cotton swab to wipe the lens and intake
area of the dust sensor (Fig. M).
4. Use a dry cotton swab to wipe away any remaining
moisture.
5. Close the cover by rotating the door back down and
sliding it back into place until you hear a click.
CLEANINGTHE SENSORPOD ™
Fig. M

17
Where do I place the SensorPod ™?Anywhere you want to measure the air quality within the room!
For optimal results, place the SensorPod
™up to 15 m away from the air
purifier on a counter or table, within line of sight of the purifier. In Auto
Mode, the purifier will work to distribute clean air until the SensorPod reads
an acceptable level of air quality.
filters?
That’s easy! The purifier’s replacement indicators will notify you when it is
time to replace the Carbon or HEPA filters, or the UV-C lamp.
Plan on replacing the Carbon every 3-4 months, HEPA every 12-15 months,
and UV-C lamp every 1-3 years.
Prefilter?
The Prefilter captures larger particles and preserves the eciency of the
other filters, so we recommend that you visually inspect the prefilter every
month and wash as needed. Another good habit is to wash the prefilter
every time you replace the Carbon filter.
dust sensor within SensorPod ™?
For the most accurate measurement of your air quality, we’d recommend
you clean the surface of the dust sensor every 1-2 months.
Purifier won’t turn on. Check that the power cord is connected securely to both the wall outlet and
the purifier. Check if there is a power outage in the outlet by trying a nearby
light or device, or by trying a working device in the same outlet.
Check that the HEPA filter is fitted properly into filter chamber.
Please contact us if you’re still having a problem! (page 19)
FAQ & TROUBLESHOOTING

18
Pairing SensorPod ™and Purifier
The SensorPod communicates with the purifier using
radio frequency signals, and will be paired on the
production line and ready for use when you open the
box. In the rare event that the signal is interrupted, the
purifier’s sensor indicator light will blink. You can
repair the connection in just a few easy steps.
1. Unplug the SensorPod.
2. HOLD the Power Button on the purifier for 3
seconds, when you should hear two chimes.
3. Plug-in the SensorPod and use an item with a small
point (paper clip) to press and HOLD the pairing
button underneath the SensorPod for 5-7 seconds
(Fig. N).
4. The connection is established when the purifier’s
sensor indicator light is lit with no blinking, and the
air quality indicators turn on.
Purifier won’t go into Auto Mode.
OR
Air quality indicators are o.
OR
Purifier’s sensor signal indicator is
blinking.
First, check that the SensorPod is plugged-in and that its light is solid.
Next, check that the SensorPod is within range of the purifier (up to 15m).
If both are true and the connection is still failing, see below instructions on
repairing the SensorPod’s connection.
I’ve lost my SensorPod ™!Don’t worry! Please contact our customer support team and you can order
a replacement SensorPod. Follow the easy pairing instructions below to pair
your replacement SensorPod with your existing air purifier!
FAQ & TROUBLESHOOTING
Fig. N

19
GUARANTEE
Operation of this machine is guaranteed for two years from date of purchase, subject to normal use.
Within the guarantee period, ACCO will at its own discretion either repair or replace the defective
machine free of charge. Defects due to misuse or use for inappropriate purposes are not covered
under the guarantee. Proof of date of purchase will be required. Repairs or alterations made by
persons not authorized by ACCO will invalidate the guarantee. It is our aim to ensure that our products
perform to the specifications stated. This guarantee does not aect the legal rights which consumers
have under applicable national legislation governing the sale of goods.
SUPPORT
Thank you for welcoming TruSens™ into your home. Our customers
are at the heart of what we do, and we strive to design products that fit
your lifestyle. If you have any questions or feedback, please reach out!
Visit our website atwww.leitz.com/trusens
Email us [e-mail]
Call us at0800 279 5102
Ireland: [phone]
M-Th 09:00 - 16:30
F 09:00-16:00
To register and activate your warranty go towww.leitz.com/register
