English
COMPONENTS :
1. Power cord
2. Main switch on/off
3. Steam ready pilot light
4. Coffee ready pilot light
5. Coffee switch
6. Steam group main switch
7. Manometer
8. Cover for water tray
9. Steam switch
10. Steam tube with safety protection
11. Hot water tube
12. Filter holder (2 ways)
13. Support for filter holder connection
14. Removable tray/grill for espresso cup
15. Drip grill / grill for mug
16. PID coffee boiler temperature controller
17. Water missing pilot light
18. Cup warming on top of the machine
19. Removable cover for water tank
20. Hot water switch
21. Hot water pilot light
22. Tamper
23. Coffee doser
24. \
25. Filter 1 cup
26. Filter 2 cups
27. Filter for pods
28. Resin filter (inside water tank)
USER INSTRUCTIONS:
Starting the machine:
1. Remove the machine from its packing and make sure all packing parts have been taken off (including the protection
bags).
2. Lay the machine on a flat and steady surface far away from hot places and from the water taps.
3. Remove the water tank cover (19) on the top of the machine; extract the plastic tube that has a resin filter (28)
attached; extract the water tank.
4. Fill the tank with cold water.
5. Replace the water tank back in the machine; insert the plastic tube and pay attention not to bend it; replace the cover
(19) in its right position.
6. Insert the power cord (1) in the mains. Make sure that the wall socket is of the right voltage.
7. Place the filter holder (12) under the brewing group (13) and turn it from the left to the right. Leave it there so that it
can get warm and it gets ready for use.
8. Turn on the machine by pressing the main switch (2); the build-in pilot light confirms that the machine is on. The coffee
group and the steam boiler recharge go on automatically. Press the hot water toggle switch (20) up: once water will
flow out of the water tube (11) press the toggle switch (20) down.
9. Press the steam group main switch (6) in order to turn on the boilers’ heating element: the coffee ready pilot light (4)
and the steam ready pilot light (3) will come on confirming that the machine is ready for use.
10. The PID (16) will visualize the degrees inside the boiler and will control the boiler’s heating.
11. The PID is already set from the producer on 95°C, i.e. the ideal temperature for a good cup of coffee. (If you want
to change the PID’s temperature, please follow the instructions written under How to set the temperature inside
the boiler by means of the PID).
Making an espresso with ground coffee:
12. Check that the tank contains water. ATTENTION: the internal tank has a special floating device that controls the water
level. In case of lack of water, the water missing pilot light (17) comes on automatically and at the same time the sound
alarm buzzes. Please fill the water tank with water (as described under Starting the machine, points 3-5): this will shut
off the pilot light (17) and the buzzer, confirming that the water level is suitable. NB: the water tank must be filled in
with water till the MAX level indicated on the appliance body.
13. Follow the instruction at point 9 in case the above written operations have not been yet done.
14. As soon as the PID’s (16) display shows the set temperature and the coffee ready pilot light (4) goes on, the machine is
ready for use.
15. Place the filter (25-26) in the filter holder (12). Lock the filter holder (12) in the brewing group (13) turning it from the
left to the right, after having poured the desired quantity of ground coffee (1 doser (23) corresponds to 1 coffee dose;
to get 2 coffee cups pour 2 dozers of ground coffee in the filter holder (12) ) and after having pressed it properly with
the pressing tool/tamper (22).
16. Place the espresso cup/s on the cup rest (14). NB: this machine has a removable tray (14) for espresso cups and a drip
grill (15) for cups/mug of max. 11cm height.
17. NB: The coffee switch (5) has 2 positions: up it’s on, down it’s off. Turn the coffee switch on (5) to start brewing
and once you have reached the desired quantity of coffee press the toggle switch (5) down to stop dispensing the
coffee.
18. Remove the filter holder (12) from its support (13) and throw away the coffee grounds. NB: Place the filter holder (12)
empty (without coffee) back in its support (13) in order to maintain the entire coffee group at the suitable temperature.
Steam:
19. Check that the tank contains water. ATTENTION: the internal tank has a special floating device that controls the water
level. In case of lack of water, the water missing pilot light (17) comes on automatically and at the same time the sound
allarm buzzes. Please fill the water tank with water (as described under Starting the machine, points 3-5): this will shut
off the pilot light (17) and the buzzer, confirming that the water level is suitable. NB: the water tank must be filled in
with water till the MAX level indicated on the appliance body.
20. Switch on the steam group by pressing the steam main switch (6) (only if it has not been yet done): the pilot light (3)
gets on. The machine is at the right temperature, ready to make steam.
21. Place the cup/mug with the drink to be heated under the steam tube (10).
