LenelS2 5000 Series User manual
Contact info
For all local contact details, please consult the
UTC Fire Security webpage:
Product Warnings and Disclaimers
Quick Installation Guide
LenelS2 Readers - 5000 Series
UTC Fire & Security BV
UTC Fire & Security EMEA
Carrier Fire & Security EMEA
Kelvinstraat 7 6003 DH – Weert,
The Netherlands
Tel: +31 (0)495 58 30 00
Fax: +31 (0)495 55 00 42
Email: cs.edc@carrier.com
For all local contact details, please consult
the Carrier Fire & Security webpage:
https://resecurityproducts.com/en/contact.php
Contact info
Carrier Fire & Security EMEA
Kelvinstraat 7 6003 DH – Weert,
The Netherlands
Tel: +31 (0)495 58 30 00
Fax: +31 (0)495 55 00 42
Email: cs.edc@carrier.com
For all local contact details, please consult
the Carrier Fire & Security webpage:
https://resecurityproducts.com/en/contact.php
Contact info
Options for the tamper alarm
The reader has a tamper alarm support for both break off from a wall and opening protection. To disable
the tamper alarm when dismounted from the wall, the red tray in the accessories bag has to be mounted
on the base plate.
To open the reader: Use the reader opening tool (LNL-RS0000-OT) to avoid any damage to the front
cover and/or mounting plate, remove the front cover from the mounting plate as shown on the picture
to the right.
1. Mount the base plate on the wall using supplied screws.
2. Insert the tamper alarm red tray as shown in the picture.
3. Remove the spring from the reader tamper alarm switch.
4. Close the reader. The Tamper alarm will be in a normal
state as long as the reader is closed. If the reader is opened
the tamper alarm is activated.
Contact info
For all local contact details, please consult the
UTC Fire Security webpage:
Product Warnings and Disclaimers
Quick Installation Guide
LenelS2 Readers - 5000 Series
UTC Fire & Security BV
UTC Fire & Security EMEA
Carrier Fire & Security EMEA
Kelvinstraat 7 6003 DH – Weert,
The Netherlands
Tel: +31 (0)495 58 30 00
Fax: +31 (0)495 55 00 42
Email: cs.edc@carrier.com
For all local contact details, please consult
the Carrier Fire & Security webpage:
https://resecurityproducts.com/en/contact.php
Contact info
Tamper
GPO1
GPO2
GND
B/RX
A/TX
GND
DC+
CP
D1 Clock
D0 Data
GND
G-LED
R-LED
BZ CTRL
K-LED
Tamper output
General purpose I/O
General purpose I/O
Ground
RS485 - / OSDP
RS485 + / OSDP
Power supply
Power supply 9 to 30 VDC
Card Present
Wiegand Data1/Clock/Data
Wiegand Data0/Clock/Data
Ground
External Green LED control
External Red LED control
External Buzzer control
External keypad LED control
PIN Description
Description
Wiegand
Wiegand
x
-
-
-
-
-
x
x
-
x
x
-
x
x
x
x
Terminal description
RS485/
OSDP
RS485/
OSDP
Clock/
Data
Clock/
Data
-
-
-
-
x
x
x
x
-
-
-
-
-
-
-
-
-
-
-
-
x
x
x
x
x
-
-
-
-
-
-
-
P2
P1
PIN
K-LED
BZ CTRL
R-LED
G-LED
GND
D0 Data
D1 Clock
CP
Tamper
GPO1
GPO2
GND
B/RX
A/TX
GND
DC+
P1
P2
Tamper
GPO1
GPO2
GND
B/RX
A/TX
P1 P2
CP
D1 Clock
D0 Data
GND
G-LED
R-LED
BZ CTRL
K-LED
Quick Installation Guide
LenelS2 Readers - 5000 Series Standard 13.56 MHz
LenelS2 Readers - 5000 Series Standard 13.56 MHz/125 kHz
GND
DC+
Quick Installation Guide
LenelS2 Readers - 5000
Series Slimline 13.56 MHz
Please note that this is only a quick installation guide.
Information regarding recommendations, measurements and accessories are
available in the full version of the LenelS2 Readers - 5000 Series installation
guide.
1 Current draw does not include heater consumption.
2 LED settings; LED Bar = Low, Back Light = Low
Please consult table in full installation manual for more information on heater
consumption settings and how the LED-settings will aect current draw.
Power consumption:
Notes
1. Maximum Wiegand cable length is 150 meters and requires a high quality
shielded cable with minimum AWG18 dimension (=0.8231 mm2) in an environment
free from electrical noise. A cable with smaller dimension or an installation
environment with electrical disturbances will reduce the maximum cable length.
2. Wiegand & Clock/Data requires dedicated wires for external control of Green
LED, Red LED, Buzzer and Keypad backlight.
3. When utilizing the GPI/O’s, each respective GPO1 or GPO2 must be connected
to each respective pin and also to GND. The general purpose input/output will only
be activated if so applied in the reader configuration.
4. RS485/OSDP requires twisted pair cable.
Model Current draw (idle1) Current draw (peak1,2)
12 V 24 V 12 V 24 V
Standard 13.56 MHz 50 mA 40 mA 147 mA 99 mA
Standard 13.56 MHz/125 kHz 90 mA 60 mA 187 mA 119 mA
Slimline 13.56 MHz 50 mA 40 mA 164 mA 108 mA
Please note that this is only a quick installation guide.
Information regarding recommendations, measurements and QR code modules and other
accessories are available in the full version of the LenelS2 Readers - 5000 Series installation
guide.
Please consult table in the full installation manual for more information on heater
consumption settings and how the LED-settings will aect current draw.
12 VDC 12 VDC24 VDC 24 VDC
