Lennox Hearth Products B-Vent Series EBVCL Manual

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 1
LOG PLACEMENT GUIDE
LOG PLACEMENT GUIDE FOR LENNOX DIRECT VENT AND B-VENT SERIES
MULIT-OPEN GAS FIREPLACE HEATERS
EDVPF, EDVST, EDVCL, EDVCR, EBVPF,
EBVST, EBVCL AND EBVCR SERIES
750,161M
REV. B 10/2004
GENERAL INFORMATION
This log placement guide has been prepared to present detailed log
placement illustrations and provide instruction to assist in the place-
ment of logs at the initial (new appliance) setup and after the annual
cleaning and inspection cycles. The information provided here is to
be used in conjunction with the Homeowner's Care and Operation In-
structions provided together with this document in the appliance lit-
erature packet. Please read the Homeowner's Care and Operation In-
structions completely before completing the procedures detailed in
this placement guide.
INITIAL INSTALLATION CONSIDERATIONS
If the logs are being installed for the first time, the following para-
graphs apply:
DO NOT attempt to install the logs until the appliance installation has
been completed, the gas line connected and tested for leaks and the
initial burner operation has been checked out.
Step 1. Remove the appliance front door.
Step 2. Remove the foamed log set from the interior of the firebox.
Remove the logs from their packaging. Handle logs carefully to pre-
vent breakage.
CERAMIC FLOOR PANELS, LOGS AND GLOWING EMBER
PLACEMENT
Step 1. Install the Ceramic Floor Panels as shown in Figure 3 (for
Direct Vent fireplaces only).
Note: This appliance is provided with enough Glowing Embers for sev-
eral applications, do not feel compelled to use all that is in a new bag.
For best glowing effect, replace the ember material annually. Replace-
ment Glowing Embers are available (Catalog Number 88L53).
Step 2. Position the individual logs as shown in Figures 4A and 4B
on pages 3 and 4 .Logs should be placed in the order shown. All logs
that have notches to fit over the grate tines should be positioned with
these notches directly against the grate. Proper log placement is criti-
cal to encourage outstanding flame appearance and prevent sooting.
When positioned properly as shown, logs will be positioned between
flame peaks and will not impinge any flames.
Note: Do Not place Glowing Embers (Rockwool) over burner slots.
Step 3. Separate the Glowing Ember (Rockwool) into pieces about
the size of a quarter Figure 1 . Keep the pieces fluffed up, not matted.
Distribute these pieces over the front surface of the burner, as shown
in Figure 2 . Do not use more than is necessary. When properly posi-
tioned, the Glowing Embers will cover approximately 65% of the front
burner and with no appreciable gaps or openings. Ensure that the
main burner ports remain uncovered by the ember material.
Figure 1
Figure 2
Glowing Embers

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
2
CERAMIC FLOOR PANEL PLACEMENT (Direct Vent Fireplaces Only)
Figure 3
Catalog Number for the Ceramic Floor Panel set: 55M4901 (For EDVPF), 55M5101 (For EDVCL),
55M5501 (For EDVST) And 55M7601 (For EDVCR).
1 1/4" Dia. Through Holes (4 Places)
Ceramic Floor Panel
Burner
EDVST Shown
Burner
Ceramic Floor Panel
EDVCL Shown*
*NOTE: EDVCR & EDVPF Are Installed In Similar Fashion
With Chamfer End Pointing Toward Small Door Opening
Chamfer Corner Pointing Toward
Small Door Opening
Small Door Opening
Place The Four Legs Of The Grate
Assembly In The Four Holes Of The
Ceramic Floor Panel
Log Support
1 1/4" Dia. Through Holes (4 Places)

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 3
EDVPF, EDVST, EDVCL, EDVCR, EBVPF, EBVST, EBVCL & EBVCR LOG PLACEMENT
Figure 4A
Catalog Number for the entire log set: 55M0401
Log Part
Number Description Number
1 Log, Corner 55M1801
2 Log, Rear/Left 55M1901
3 Log, Front/Left 55M2001
4 Log, Rear/Right 55M2101
5 Log, Front/Center 55M2201
6 Log, Center/Top 55M2301
26
5
4
1
3
Position Groove At The
Bottom Of Log (1) Over
The Burner Log Support
Bracket
Position The Groove At The
Bottom Of Log (1) Over The
Grate And Slide It Forward
Against The Grate Here
Position Log (2) Over The Grate
Bar And Slide It Against The
Back Of The Grate Here
Position Groove At The Bottom Of Log (2)
Over The Grate Here And Slide It Against
The Back Of The Grate
Place Bottom Hole Of Log (3) On Pin In Log (2). Position
Grooves At The Bottom Of Log (3) Over The Grate.
1
Position And Slide Log (4)
Against The Back Of The Grate
2
Log (3) Lays Over
Logs 1 And 2
STEP 1
STEP 2
STEP 3
STEP 4
3
4
1
Place Log (4) Over
The Flat Spot On
Log (1) Here

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
4
Printed in U.S.A. © 2003 by Lennox
P/N 750,161M REV. B 10/2004
Lennox reserves the right to make changes at any time, without notice, in design,
materials, specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for fireplace code information.
1110 West Taft Avenue • Orange, CA 92865
EDVPF, EDVST, EDVCL, EDVCR, EBVPF, EBVST, EBVCL & EBVCR LOG PLACEMENT (CONTINUED)
Catalog Number for the entire log set: 55M0401
Log Part
Number Description Number
1 Log, Corner 55M1801
2 Log, Rear/Left 55M1901
3 Log, Front/Left 55M2001
4 Log, Rear/Right 55M2101
5 Log, Front/Center 55M2201
6 Log, Center/Top 55M2301
26
5
4
1
3
Figure 4B
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
3
Grate
Assembly
5
Position Small End Of Log (6)
On The Notch Of Log (3) Here 6
4
Position The Round End Of Log (6)
Against The Notch Of Log (4) Here.
Two Charred Spots Face The Front
Position The Groove In The Back
Of Log (3) Against The Grate
Rest Log (5) Against
The Grate Here
Log (5) Sits In Front
Of The Grate
STEP 5
