Lennox Hearth Products EBVI25 Service manual

neighbor’s phone. Follow your gas suppliers
instructions.
• If your gas supplier cannot be reached, call
the fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas sup-
plier.
INSTALLATION INSTRUCTIONS
MANUAL
B-VENT GAS FIREPLACE HEATER INSERT
WARNING:IFTHEINFORMATIONINTHISMANUAL
IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO-
SIONMAYRESULTCAUSINGPROPERTYDAMAGE,
PERSONAL INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY: Do not store or use gasoline
or other flammable vapors or liquids in the vicinity
of this or any other appliance.
FOR YOUR SAFETY: What to do if you smell gas:
• DO NOT light any appliance.
• DO NOT touch any electrical switches.
• Do not use any phone in your building.
• Immediately call your gas supplier from a
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE
LES INSTRUCTIONS DONNÉ DANS CETTE NOTICE
POURRÉDUIREAUMINIMUMLERISQUED’INCENDIE
OUPOURÉVITERTOUTDOMMAGEMATÉRIEL,TOUTE
BLESSURE OU LA MORT.
POUR VOTRE SÉCURITÉ: Que faire si vous sentez une
odeur de gaz:
• Ne pas tenter d’allumer d’appareil.
• Ne touchez à aucun interrupteur. Ne pas vous servir
des téléphones se trouvant dans le batiment où vous
vous trouvez.
• Evacuez la piéce, le bâtiment ou la zone.
• Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du fournis-
seur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L’installation et service doit être exécuté par un qualifié
installeur, agence de service ou le fournisseur de gaz.
Report No. 116-F-15-5
Elite™ Series, Model: EBVI25 & EBVI30
Suitable for installation into masonry or factory built fireplaces.
RETAIN THIS MANUAL FOR FUTURE REFERENCE
P/N 775,154M B, 7/2004
POUR VOTRE SÉCURITÉ: Ne pas entreposer ni utiliser
d’essence ni d’autre vapeurs ou liquides inflammables
dans le voisinage de cet appareil ou de tout autre
appareil.
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
2
INTRODUCTION
This appliance complies with National
Safety Standards and is tested and listed
by OMNI-Test Laboratories Inc.; Beaverton,
Oregon (Report No. 116-F-15-5) to ANSI
Z21.88-2002 (in Canada, CSA-2.33-2002),
and CAN/CGA-2.17-M91 in both USA and
Canada, as vented gas fired room heater.
TABLE OF CONTENTS
Packaging List page 2
Introduction page 2
General Information page 3
Questions/Building Officials page 4
High Altitude page 4
Fireplace Requirements page 4
Specifications page 5
Clearance to Combustibles page 7
Step 1 Preparation page 8
Step 2 Clean Fireplace page 8
Step 3 Unpack the insert. page 9
Step 4 Lift Insert into Position page 9
Step 5 Remove Glass Door page 9
Step 6 Remove Firebox Contents page 9
Step 7 Install LP Conv. (if necessary) page 9
Step 8 Install Venting page 9
Step 9 Connect Gas Line page 12
Step 10 Purge Air page 12
Step 11 Install Log Set page 13
Step 12 Reinstall Front Glass Door page 14
Step 13 Perform Leak Test page 14
Step 14 Install Surround Assembly page 14
Step 15 Install Wall Thermostat page 14
Step 16 Check Appliance Operation page 14
Step 17 Perform Spillage Test page 16
Step 18 Check Blower Operation page 16
Step 19 Adjust Burner page 17
Step 20 Install Louver Kit page 17
Rating Plates page 18
PLEASEREAD ANDUNDERSTAND THESE
INSTRUCTIONS BEFORE BEGINNING
YOUR INSTALLATION.
This installation manual will help you obtain
a safe, efficient, dependable installation for
your appliance and vent system.
CONGRATULATIONS ON THE PURCHASE OF YOUR NEW GAS APPLIANCE MANU-
FACTURED BY LENNOX HEARTH PRODUCTS.
When you purchased your new gas fired heater, you joined the ranks of thousands of
concerned individuals whose answer to their home heating needs reflects their concern for
aesthetics, efficiency and our environment. We extend our continued support to help you
achieve the maximum benefit and enjoyment available from your new gas fired heater. It
is our goal at Lennox Hearth Products to provide you, our valued customer, with an appli-
ance that will ensure you years of trouble free warmth and pleasure.
Thank you for selecting a Lennox Hearth Products gas fired heater as the answer to
your home heating needs.
Sincerely,
All of us at Lennox Hearth Products
PACKAGING LIST
Theassembledventedgasfireplaceheater
is packaged with:
• One accessory package containing a
literaturepackage(installationandoperation
instruction manuals) is located on top of the
appliance.
• One log set, onebag of embers, one bagof
vermiculite, one propane conversion kits.
• One Warranty Certificate.
• One Fireplace Warning Label.
• One Draft Hood Sliding Tool.
This gas fireplace heater is a natural con-
vection, heat circulating gas fireplace insert
designed for residential applications.This
heaterisdesigned to be installedintoan exist-
ingmasonry or factory built solid fuelburning
fireplace only - Masonry fireplace must be
built to UBC 37 or ULC S628 standards and
factory built(zeroclearance) fireplacemust be
listed to UL 127 or ULC S610. Units must use
a 4” listed B-Vent or listed liner (conforming
to UL 1777) from the appliance outlet to the
chimney termination. The venting system
must be routed through the existing fireplace
flue system to the vent termination.
Thismillivoltapplianceisdesignedtooper-
ate on natural gas or propane gas only.
A millivolt gas control valve with piezo igni-
tionsystemprovides safe, efficient operation.
External electrical poweris required to operate
the blower.
This appliance may be used with a thermo-
stat (see Optional Wall Thermostat). This
appliance is certified for use in bedrooms.
If installed in a bedroom in Canada, a ther-
mostat IS required.
This appliance requires an adequate supply
of combustion and ventilation air. As an
aid in determining whether or not these
requirements have been satisfied, follow the
procedure indicated in the section entitled
Spill Test Procedure (see page 16).
The millivolt appliance is manually con-
trolled and features a spark igniter (piezo)
that allows the appliance's pilot gas to be
lit without the use of matches or batteries.
This system provides continued service in
the event of a power outage.
This unit is factory set for use with Natural
Gas and will require a field conversion for use
with Propane (other fuels are NOT allowed).
The use of other fuels or combination of fuels
will degrade the performance of this system
and may be dangerous.
DO NOT ATTEMPT TO ALTER OR MODIFY
THECONSTRUCTIONOFTHEAPPLIANCEORITS
COMPONENTS.ANYMODIFICATIONORALTERA-
TIONMAYVOIDTHEWARRANTY,CERTIFICATION
AND LISTINGS OF THIS UNIT.
Installation must conform to local codes. In
the absence of local codes, installation must
comply with the current National Fuel Gas
Code, ANSI Z223.1. (In Canada, the current
CAN-1 B149 installation code.) Electrical
wiring must comply with the National Elec-
trical Code ANSI/ NFPA 70 - latest edition.
In Canada, the current CSA C22-1 Canadian
Electrical Code - latest edition.
MODEL: EBVI30
SKS-30, Surround Kit, Small
(40 1/4" W x 27 1/2" H)
SKM-30, Surround Kit, Medium
(45 3/4" W x 30 1/4" H)
SKL-30, Surround Kit, Large
(49 1/4" W x 30" H)
MODEL: EBVI25
SKS-25, Surround Kit, Small
(41 1/16" W x 26 1/16" H)
SKM-25, Surround Kit, Medium
(44 1/8" W x 27 5/8" H)
SURROUND ASSEMBLY SOLD SEPA-
RATELY
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 3
This appliance uses a millivolt type control
system consisting of a gas control valve with
regulator (control to adjust for flame appear-
ance and heat output), astanding pilot burner
assembly, a thermopile, thermocouple, a
piezo igniter, and ON/OFF switch. All exhaust
gases must be vented outside the structure.
Combustion air isdrawn from the room where
appliance is installed. THE GAS BURNER
SYSTEM ON THIS APPLIANCE DOES NOT
REQUIRE 120 VOLT POWER TO OPERATE.
However, the heat circulation blower requires
120 Volt power (the appliance can be safely
used with the blower turned off). The blower
operation is controlled by a variable speed
rheostat located on the left side surround
panel (if optional surround is installed)
and temperature switch located beneath of
firebox bottom on the front left side.
Table 1 shows the BTU input:
Test gauge connections are provided on the
front of the millivolt gas control valve (identi-
fied IN for the inlet and OUT for the manifold
side). See Figures 32 & 33.
Tables 2 and 3 show the gas pressure
requirements for this appliance:
GENERAL INFORMATION
The appliance installation, repair and annual
inspection should be performed by a quali-
fied service person. It is imperative that the
control compartment, burners and circulat-
ing air passage ways of the appliance be
kept clean.
S'assurer que le brùleur et le compartiment
des commandes sont propres. Voir les
instructions d'installation et d'utilisation qui
accompagnent l'appareil.
Provide adequate clearances and adequate
accessibility clearance for service and proper
operation.
THISAPPLIANCEMUSTNOTBECONNECTED
TO A CHIMNEY OR FLUE SERVING A SEPA-
RATE SOLID FUEL BURNING APPLIANCE.
WARNING: FAILURE TO COMPLY WITH
THE INSTALLATION AND OPERATING
INSTRUCTIONSPROVIDEDINTHISDOCU-
MENT WILL RESULT IN AN IMPROPERLY
INSTALLED AND OPERATING APPLI-
ANCE, VOIDING ITS WARRANTY. ANY
CHANGETOTHISAPPLIANCEAND/ORITS
OPERATINGCONTROLS ISDANGEROUS.
IMPROPER INSTALLATION OR USE OF
THIS APPLIANCE CAN CAUSE SERIOUS
INJURY OR DEATH FROM FIRE, BURNS,
EXPLOSION OR CARBON MONOXIDE
POISONING.
CARBON MONOXIDE POISONING: EARLY
SIGNSOFCARBONMONOXIDEPOISONING
ARE SIMILAR TO THE FLU WITH HEAD-
ACHES, DIZZINESS AND/OR NAUSEA. IF
YOU HAVE THESE SIGNS, OBTAIN FRESH
AIR IMMEDIATELY. TURN OFF THE GAS
SUPPLY TO THE APPLIANCE AND HAVE
IT SERVICED BY A QUALIFIED PROFES-
SIONAL, AS IT MAY NOT BE OPERATING
PROPERLY.
WARNING: CHILDREN AND ADULTS
SHOULD BE ALERTED TO THE HAZARDS
OFHIGHSURFACETEMPERATURES.USE
CAUTION AROUND THE APPLIANCE TO
AVOID BURNS OR CLOTHING IGNITION.
YOUNG CHILDREN SHOULD BE CARE-
FULLY SUPERVISED WHEN THEY ARE IN
THE SAME ROOM AS THE APPLIANCE.
AVERTISSEMENT: SURVEILLER LES
ENFANTS. GARDER LES VÊTEMENTS,
LES MEUBLES, L'ESSENCE OU AUTRES
LIQUIDES À VAPEUR INFLAMMABLES À
COTE DE L'APPAREIL.
Table 4 shows the gas orifice size for the
elevations indicated.
WARNING: THIS APPLIANCE MUST BE
PROPERLY CONNECTED TO A VENTING
SYSTEM. OPERATION OF THIS GAS
APPLIANCE WHEN NOT CONNECTED TO A
PROPERLY INSTALLED AND MAINTAINED
VENTINGSYSTEMCANRESULTINCARBON
MONOXIDE(CO)POISONINGANDPOSSIBLE
DEATH.
NE PAS SE SERVIR DE CET APPAREIL S'IL A
ÉTÉPLONGÉDANSL'EAU,COMPLÈTEMENT
OU EN PARTIE. APPELER UN TECHNICIEN
QUALIFIÉPOURINSPECTERL'APPAREILET
REMPLACER TOUTE PARTIE DU SYSTÈME
DE CONTRÔLE ET TOUTE COMMANDE QUI
ONT ÉTÉ PLONGÉS DANS L'EAU.
WARNING: DO NOT PLACE CLOTHING
OR OTHER FLAMMABLE MATERIALS ON
OR NEAR THIS APPLIANCE.
DO NOT USE THIS APPLIANCE IF ANY PART
HAS BEEN UNDER WATER. IMMEDIATELY
CALL A QUALIFIED, PROFESSIONAL
SERVICE TECHNICIAN TO INSPECT THE
APPLIANCE AND TO REPLACE ANY PARTS
OF THE CONTROL SYSTEM AND ANY GAS
CONTROLS WHICH HAVE BEEN UNDER
WATER.
Millivolt Models with
Manually-Modulated Gas Valves
Nat. Gas Propane
Model No. Input Rate
(BTU / HR)
Input Rate
(BTU / HR)
EBVI25 17,000 to
25,000
19,500 to
25,000
EBVI30 21,500 to
30,000
22,000 to
28,000
Table 1
Inlet Gas Supply Pressure (all models)
Fuel # Minimum Maximum
Natural Gas 4.5" WC
(1.12 kPa)
10.5" WC
(2.61 kPa)
Propane 11.0" WC
(2.73 kPa)
13.0" WC
(3.23 kPa)
Table 2
Manifold Gas Supply Pressure (all models)
Fuel # Low High
Natural
Gas
(Lo) 1.6" WC
(.40 kPa)
(Hi) 3.5" WC
(.87 kPa)
Propane (Lo) 6.3" WC
(1.57 kPa)
(Hi) 10.0" WC
(2.49 kPa)
Table 3
Model
No.
Orifice Size Elevation
Feet
(meters)
Nat.
Gas
Prop.
Gas
EBVI25 #41
(.096")
#53
(.0595")
0-4500
(0-1372)
EBVI30 #37
(.104")
1/16"
(.0625")
0-4500
(0-1372)
Table 4
This appliance must be isolated from the
gas supply piping system (by closing it's
individual manual shut-off valve) during any
pressure testing of the gas supply piping
system at test pressures equal to or less
than 1/2 psig (3.5 kPa).
This appliance and it's individual shut-off
valve must be disconnected from the gas
supply piping system during any pressure
testing of that system at pressures greater
than 1/2 psig (3.5 kPa).
fire-parts.com

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
4
WARNING
THIS FIREPLACE HAS BEEN ALTERED TO
ACCOMMODATE A FIREPLACE INSERT AND
SHOULD BE INSPECTED BY A QUALIFIED
PERSON PRIOR TO RE-USE AS A
CONVENTIONAL FIREPLACE.
Installations at Altitudes of 0 to 4500 feet:
This appliance has been tested and approved
for elevations of 0 to 4500 feet (0 to 1370
meters).
Installations at Altitudes above 4500 feet:
For elevations above 4500 feet (1370
meters), install this appliance according to
the regulations of the local authorities having
jurisdiction and, in the USA, the latest edition
of the National Fuel Gas Code (ANSI Z223.1)
or, in Canada, the latest edition of the CAN-
B149.1 and CAN-B149.2 codes.
HIGH ALTITUDE
6. Maximum amount of gas pipe without a
pressure test - type of test required?
7. Are below grade penetrations of the gas
line allowed?
8. Is concealed gas piping allowed?
9. Specific requirements of concealed
fittings?
10. Is rigid pipe to appliance required?
11. Allowed piping materials?
12. Shut-off valve required within 4 feet
of the firebox?
13. May the shut-off valve be concealed?
14. Rooms where the installation is not
allowed?
15. This appliance is NOT approved for
installation into a manufactured (mobile)
home.
In the absence of local codes, installation
should conform to National Fuel Gas Code,
ANSI Z223.1 / NFPA 54-Latest Edition in the
USA or National Fuel Gas Code, CAN/CGA-
B149-Latest Edition in Canada.
QUESTIONS TO ASK LOCAL BUILDING
OFFICIAL
This appliance must be installed per
manufacturers’ instructions. Installations
mustconformto appropriate local codes and
applicable state and federal requirements.
Familiarity with these requirements before
installation is essential. Some important
considerations to discuss with local building
officials include:
1. Applicable codes (i.e. Uniform Mechanical
Code, State or Regional Gas Codes, National
Fuel Gas Code).
2. Local amendments.
3. Recognizedlisting/testingagency: OMNI-
Test Laboratories Inc.; Beaverton, Oregon
4. Is a permit required - cost?
5. In some states or municipalities, a
licensed gas fitter or plumber may be
required to install this appliance. Check with
your local building official for requirements
in your area (i.e. Is a license required for
installation of gas supply line)?
FIREPLACE REQUIREMENTS
IMPORTANT: When installing this appliance
into a factory built fireplace or heatform, the air
flow within and around the fireplace shall not
be altered by the installation of the insert (i.e.
DO NOT BLOCK louvers or cooling air inlet or
outlet ports, circulating air chambers in a steel
fireplace liner or metal heat circulator).
CAUTION: The factory built firebox must
accept the insert without modification other
than removing bolted or screwed together
pieces such as smoke shelf / deflectors,
ash lips, screen or door tracks and damper
assemblies. Any fireplace component, which
is removed, must be retained so they can be
reinstalled to restore the fireplace to its
original operating condition. The removal of
any part must not alter the integrity of the
outer shell of the pre-engineered fireplace
cabinet in any way.
If any components are removed from (or
altered) from the existing fireplace, a Warning
Label (see below) must be affixed inside the
fireplace firebox, so that it shall be visible
upon removal of the fireplace insert. Note:
RTV high temperature silicone is an approved
adhesive.
Fireplace Warning Label
(Provided in Accessory Package)
fire-parts.com

5
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
SPECIFICATIONS - Model EBVI25
Figure 1
A
B
C
D
E
L
M
F
G
H
K
J
I
Front View Side View
Top View
DIMENSIONS
inches (millimeter) inches (millimeter)
A 26 5/8” (675 mm) H 11 1/8” (282 mm)
B 20 1/2” (520 mm) I 1 1/4” (31 mm)
C 13 3/8” (340 mm) J 17 5/16” (439 mm)
D SM - 41 1/16” (1043 mm)
MED. = 44 1/8” (1121 mm)
K 15 1/4” (388 mm)
E SM.- 26 1/16” (662 mm)
MED. - 27 5/8” (702 mm)
L **10 7/8” (276 mm)
F 19 3/8” (493 mm) M **24 7/8” (632 mm)
G 1 15/16” (49 mm)
** The total glass viewing area equals approx. 270 1/2 Sq. In
SPECIFICATIONS
Natural Gas BTU Input 17,000 to 25,000
Propane Gas BTU Input 19,500 to 25,000
B-Vent Size 4” Dia. Liner
Room Blower CFM 110 cfm
EFFICIENCIES
64 % Nat. Gas; 68 % Prop. Gas
Steady State Efficiency * 79 % Nat. Gas; 81 % Prop. Gas
NOTES
* The Steady State Efficiency numbers based on maximum vent configuration.
Note: Due to Lennox' ongoing commitment to quality, all specifications, ratings
and dimensions are subject to change without notice.
fire-parts.com
