Lenovo ThinkPad TopSeller User manual

Personal Systems Reference
Lenovo®ThinkPad
®TopSeller™Notebooks
February 2013 - Version 431
Visit www.lenovo.com/psref for the latest version

Ultraslim Plus Wireless Keyboard and Mouse
0A34032
Lenovo®Essential Notebook Stand 45J9292
with notebook, keyboard and mouse
ThinkVision®LT1421 with ThinkPad X1
90W Ultraslim AC/DC Combo Adapter
41R4493
ThinkPad Mini Dock Plus Series 3 with USB 3.0 - 90W
433815U
USB 3.0 Secure 1TB Hard Drive
0A65621

Lenovo ThinkPad Tablet 2 with
ThinkPad Tablet 2 Dock
0B47109
Lenovo ThinkPad Tablet 2 with
ThinkPad In-Ear Headphones with microphone
57Y4488
Lenovo ThinkPad Tablet 2 with
ThinkPad Tablet 2 Digitizer Pen
0A33899
Lenovo ThinkPad Tablet 2 with
ThinkPad Tablet 2 Dock
0B47109
Lenovo ThinkPad Tablet 2
Lenovo®ThinkPad Tablet 2

ThinkPad Tablet 2 Dock
0B47109
Lenovo ThinkPad Tablet 2 with
ThinkPad Tablet 2 VGA Adapter
0B47084
Lenovo®ThinkPad Tablet 2 with
ThinkPad Tablet 2 Bluetooth Keyboard with Stand
0B47270
Lenovo ThinkPad Tablet 2 with
ThinkPad Tablet 2 Bluetooth Keyboard with Stand
0B47270
Lenovo ThinkPad Tablet 2 with
ThinkPad Tablet 2 Fitted Sleeve
0A33902
Lenovo ThinkPad Tablet 2 with
ThinkPad Tablet 2 Fitted Sleeve
0A33902

Touchscreen tablet for on-the-go business
Intel®Atom™Processor Z2760 (2 cores, 1.80GHz, 1MB cache),
LPDDR2 memory controller (800MHz), HT technology
2GB / 800MHz LPDDR2, mobile DDR / soldered to systemboard, no sockets
32GB or 64GB / eMMC (embedded Multi Media Card) flash memory on board
one microSD Card slot
PowerVR™SGX545 graphics in Intel Atom SoC,
supports 1080p video out via mini-HDMI™connector, HDCP-compliant
10.1" (256.5mm) HD (1366x768) TFT color,
anti-reflective display with infinity AGC Dragontrail™Glass,
LED backlight, 400 nits, 16:9 aspect ratio, 500:1 contrast ratio, IPS,
WideView (170° viewing), MultiTouch screen supports five-finger gesture
Some: ThinkPad Tablet 2 Digitizer Pen (0A33899), supports hover, tip, and pressure modes /
a button for selection / no batteries required
*The models without Tablet Pen can not support pen input function via
ThinkPad Tablet 2 Digitizer Pen (0A33899)
Front camera: 2.0-megapixel, fixed focus
Rear camera: 8.0-megapixel, auto focus, flash LED
720p video capture
Realtek®ALC5642 codec / stereo speakers, 0.5 watt x 2 /
dual array digital microphone, combo audio/microphone jack
Audio formats: MP3, AAC, AAC+, eAAC+, WAV, PCM, WMA
Video formats: MPEG-4, H.263, H.264, VC-1, WMV9, Xvid
Windows button, Power button, volume control button, rotation lock switch, reset switch
Some: ThinkPad Tablet 2 Bluetooth Keyboard with Stand (0B47270),
6-row, TrackPoint®pointing device w/ three mouse buttons, landscape stand included,
connects system via bluetooth, sealed battery with 30-day battery life,
chargeable via micro-USB (one USB to micro-USB cable included)
Ambient Light Sensor, Capella CM3218
3D accelerometer and 3D magnetometer module,
STMicroelectronics LSM303DLHC
3-axis gyroscope, STMicroelectronics L3G4200D
Intel Atom Z2760 SoC (System on Chip) platform
One USB 2.0, one micro-USB 2.0 (only for power supply / charging), one mini-HDMI,
headphone/microphone combo jack, one ThinkPad Tablet 2 Dock connector
11a/b/g/n28 wireless,
ThinkPad 11a/ b/g/n, 1x1, WiFi + Bluetooth combo chip
Some:
Wireless WAN, Qualcomm
®
Gobi™4000 chipset, LTE (4G), WCDMA/HSPA/HSPA+
Some: AT&T
®
LTE (4G), contract required with service provider
Global Navigation Satellite System
Bluetooth 4.0 wireless, integrated in WiFi + Bluetooth combo chip
None
10.34" x 6.48" x 0.39"; 262.6mm x 164.6mm x 9.8mm
WiFi only: from 1.26 lb (0.57kg);
WiFi + Digitizer Pen: from 1.30 lb (0.59kg);
WiFi + Digitizer Pen + WWAN: from 1.35 lb (0.61kg)
Black
Magnesium frame, PolyCarbonate/Acrylonitrile-Butadiene-Styrene (PC/ABS) cover
Lithium Polymer, 30Whr
up to 25 days (standby); up to 150 hr (MP3 playback);
up to 10 hr (web browsing with flash); up to 10 hr (local video playback)
1-year - depot repair service / service upgrades22 available
Positioning
Processor
Memory
Storage
Storage extension
Graphics
Display
Tablet pen
Camera
Video capture
Audio support
Media capable
Control buttons
Bluetooth
Keyboard
with Stand
Light sensor
G-sensor/
eCompass
Gyroscope
Platform
Ports
WLAN4
WWAN
Carrier
GNSS
Bluetooth™
NFC
Dimensions3
Weight
2
Case color
Case material
Battery - type
Battery - life10
Limited Warranty12
ThinkPad®Tablet 2 (3679) - TopSeller
10-watt AC adapter (via micro-USB)
GREENGUARD®certified
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
Personal Systems Reference (PSREF)
© Lenovo
(CLT1-1) February 2013
Preloaded operating system20
- Some: Windows®8 32-bit
- Some: Windows 8 Pro 32-bit
Preloaded applications14 (only some
listed)
•Lenovo®Settings
•Lenovo Support
•Lenovo Companion
•Lenovo QuickSnip
•AT&T®All Access
•Lenovo Cloud Storage
by SugarSync
•Password Manager
•Norton™Internet Security 2012
(30 days of virus definitions)
•ThinkVantage System Update
•AccuWeather
•Evernote®
•Nitro PDF
•Skype™
•Amazon Kindle
See footnotes for more detailed information
US model(s) announced October 23 or December 18, 2012
•Small and medium business (SMB) model(s), part of the US TopSeller
™Program
For compatible accessories, please
go to O-Tablet-2 sheet;
For Lenovo service22 upgrade options,
please go to S-Tablet sheet
3679-23U Atom Z2760 2GB 10.1" HD 64G No 2.0/8.0 None 11a/b/g/n28 None None None BT Win8 32 10/12
3679-26U Atom Z2760 2GB 10.1" HD 64G Pen 2.0/8.0 None 11a/b/g/n None None None BT Win8 32 10/12
3679-27U Atom Z2760 2GB 10.1" HD 64G Pen 2.0/8.0 None 11a/b/g/n None None None BT Win8 Pro32 10/12
3679-28U Atom Z2760 2GB 10.1" HD 64G No 2.0/8.0 None 11a/b/g/n None None None BT Win8 Pro32 10/12
3679-4JU Atom Z2760 2GB 10.1" HD 64G No 2.0/8.0 None 11a/b/g/n Gobi 4000 AT&T None BT Win8 Pro32 12/12
Type-model
Widescreen
displayMemory Preload
Blue-
toothProcessor Storage
Camera
Front/
Rear (MP)
Tablet
Pen
PCIe
Mini Card
WWAN
WLAN
802.11
Bluetooth
Keyboard
w/ Stand Carrier NFC
Ann
Date
(mm/yy)

ThinkPad Tablet Expansion
ThinkPad Tablet 2 Dock 0B47109 ann 10/23/12
Keyboard
ThinkPad Tablet 2 Bluetooth Keyboard with Stand 0B47270 ann 10/23/12
Multimedia
ThinkPad In-Ear Headphones with microphone 57Y4488 ann 01/07/10
Tablet
ThinkPad Tablet 2 Digitizer Pen 0A33899 ann 10/23/12
73
The ThinkPad Tablet 2 models without Tablet Pen can not support
pen input function via ThinkPad Tablet 2 Digitizer Pen (0A33899)
Security
3M ThinkPad Tablet 2 Privacy Filter (landscape) 0C33167 ann 10/23/12
3M ThinkPad Tablet 2 Privacy Filter (portrait) 0C33168 ann 10/23/12
3M ThinkPad Tablet 2 Privacy Filter (4-way) 0C33170 ann 10/23/12
3M ThinkPad Tablet 2 Anti-glare Matte Removable Film 0C33169 ann 10/23/12
Power Adapters
ThinkPad Tablet 2 AC Charger 0B47010 ann 10/23/12
ThinkPad Tablet DC Charger 0A36247 ann 08/16/11
ThinkPad 65W AC Adapter66 40Y7696 ann 01/05/06
66
Attachment via the ThinkPad Tablet 2 Dock 0B47109
More info at www.lenovo.com/support/poweradapters
Carrying Cases
ThinkPad Tablet 2 Fitted Sleeve71 0A33902 ann 10/23/12
71
ThinkPad Tablet 2 Fitted Sleeve perfectly fits the ThinkPad Tablet 2 and
ThinkPad Tablet 2 Bluetooth Keyboard with Stand 0B47270
ThinkPad 11W Sling Case 57Y4287 ann 08/16/11
ThinkPad Tablet 2 Slim Case - Black 0A33907 ann 10/23/12
ThinkPad Tablet 2 Slim Case - Red 0A33905 ann 10/23/12
More information at www.lenovo.com/support/cases
Lenovo luxury cases at www.lenovoluxurycases.com
Monitor Accessories46
ThinkPad Tablet 2 VGA Adapter 0B47084 ann 10/23/12
46
Compatible on selected Lenovo and ThinkVision monitors.
More information at www.lenovo.com/support/monitoraccessories
For more information on accessories:
www.lenovo.com/accessories
Purchase Lenovo accessories
www.lenovo.com/support/accessories
Product specifications on Lenovo Support
www.lenovo.com/accessoriesguide
Option Compatibility Matrix (OCM) and accessory brochures
www.lenovoquickpick.com
An Options Compatibility Configurator for Lenovo systems
© Lenovo
(O-Tablet-2) February 2013
ThinkPad®Tablet 2 Accessories Personal Systems Reference (PSREF)

The TopSeller™ services are designed to make selling the popular services with TopSeller systems faster and easier. Channel partners should always
use TopSeller services with TopSeller systems. TopSeller services part numbers typically provide enhanced discounts and incentives for channel
partners. The TopSeller service delivered to the customer is identical to the service delivered using a standard service part number. In situations where
a desired service is not offered under a TopSeller service part number or the sale requires a special bid process, use available standard service part
numbers.
TopSeller services should always be offered by channel business partners with TopSeller hardware, unless the sale requires special bid pricing or the
desired service is not offered as a TopSeller service part.
For more information see:
http://www2.partnerinfo.lenovo.com/partners/us/resources/salestoolkit.shtml
TopSeller service upgrade options for ThinkPad Tablet / Tablet 2
ThinkPad Tablet / Tablet 2 with 1-year Depot warranty
3 YEAR Depot Warranty 04W8773
3 YEAR Depot Warranty & ThinkPad Protection 04W8775
3 YEAR Onsite Warranty 04W8774
3 YEAR Onsite Warranty & ThinkPad Protection 04W8776
© Lenovo
(S-TOPTablet) October 2012
ThinkPad®Tablet / Tablet 2 - TopSeller Services Personal Systems Reference (PSREF)

Partial list of Lenovo Services22 for ThinkPad Tablet / Tablet 2
For more information see: http://www.lenovo.com/services_warranty/us/en/index.html
Lenovo service upgrade options for ThinkPad Tablet / Tablet 2
ThinkPad Tablet / Tablet 2 with 1-year Depot warranty
1 YEAR Depot Warranty & ThinkPad Protection 04W8309
2 YEAR Depot Warranty 04W8312
2 YEAR Depot Warranty & ThinkPad Protection 04W8313
3 YEAR Depot Warranty 04W8319
3 YEAR Depot Warranty & ThinkPad Protection 04W8320
1 YEAR Onsite Warranty 04W8326
2 YEAR Onsite Warranty 04W8330
3 YEAR Onsite Warranty 04W8337
© Lenovo
(S-Tablet) October 2012
ThinkPad®Tablet / Tablet 2 - Lenovo®Services Personal Systems Reference (PSREF)
Lenovo Priority Support for enterprise customers
• 24x7 support with priority routing and advanced level technicians
ThinkPad Tablet / Tablet 2 with 1-year Depot warranty
1 YEAR Depot Warranty & Priority Support* 04W8310
1 YEAR Depot Warranty & ThinkPad Protection & Priority Support* 04W8311
2 YEAR Depot Warranty & Priority Support* 04W8315
2 YEAR Depot Warranty & ThinkPad Protection & Priority Support* 04W8316
3 YEAR Depot Warranty & Priority Support* 04W8322
3 YEAR Depot Warranty & ThinkPad Protection & Priority Support* 04W8323
1 YEAR Onsite Warranty & Priority Support* 04W8328
2 YEAR Onsite Warranty & Priority Support* 04W8333
2 YEAR Onsite Warranty & ThinkPad Protection & Priority Support* 04W8334
3 YEAR Onsite Warranty & Priority Support* 04W8340
3 YEAR Onsite Warranty & ThinkPad Protection & Priority Support* 04W8341
* Covered machine must have concurrent warranty coverage.

Lenovo®ThinkPad L430
Lenovo ThinkPad L430Lenovo ThinkPad L430
Lenovo ThinkPad L430
Lenovo ThinkPad L430 Lenovo ThinkPad L430

Mainstream business performance; two spindles
Intel®Core™i3-2370M processor (2 cores, 2.40GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i5-2520M processor (2 cores, 2.50GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), Intel Turbo Boost 2.0 (3.20GHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
DVD burner, 12.7mm high, fixed, not removable, tray-in
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" wide, 7mm high, removable, upgradable
Some: Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable,
Active Protection System ™
None
Some: 14.0" (355mm) HD (1366x768) color, anti-glare, LED backlight,
200 nits, 16:9 aspect ratio, 400:1 contrast ratio
Some: 14.0" (355mm) HD+ (1600x900) color, anti-glare, LED backlight,
250 nits, 16:9 aspect ratio, 400:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 3000 in processor,
supports external analog monitor via VGA DB-15 and digital monitor via Mini DisplayPort;
supports dual independent display;
Maximum external resolution: 2560x1600@60Hz (DisplayPort via optional Mini DP cable);
1920x1200@60Hz (single-link DVI-I via optional Mini DP cable); 2048x1536@75Hz (VGA)
6-row, 84-key, ThinkVantage button, spill-resistant, multimedia Fn keys
TrackPoint® pointing device, Internet Scroll Bar13, magnifying glass
UltraNav™, wide touchpad below keyboard, Tap Zones, scrolling, multi-touch
None
14.0W" (WxDxH): 13.94" x 9.57" x 1.17–1.24"; 354mm x 243mm x 29.6–31.4mm
6-cell: from 5.11 lb (2.32kg); 9-cell: from 5.48 lb (2.49kg)
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell or 9-cell, HW Authentication
6-cell (57Whr): up to 7.5 hr; 9-cell (94Whr): up to 12.3 hr
Mobile Intel HM76 Express Chipset
Some: One slot (ExpressCard/34, ExpressCard/54)
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
One USB 3.0, three USB 2.0 (one powered), VGA DB-15, Mini DisplayPort, ethernet (RJ-45)
Two PCI Express Mini Card slots
11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2200, 2x2
Wireless WAN upgradable
None
None
None
Realtek®RTL8111F Gigabit Network Connection
None
HD Audio, Realtek ALC3202 codec, Dolby®Advanced Audio™v2 / stereo speakers, 1.5W x 2 /
volume up, down, mute buttons / monaural digital mic , mic mute button, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
Trusted Platform Module, TCG 1.2-compliant
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touch pad
ThinkLight™
Dimensions3
Weight
2
Case material
Battery - type
Battery - life10
Chipset
ExpressCard
Smart Card read
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
Carrier
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®L430 2468 (TopSeller)
65-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
GREENGUARD®certified
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
2468-2AU i3-2370M 4GBx1 14.0" HD 720p 320G 7200 Intel 2200 WWAN upg Express 54 None None 6 Pro 64 06/12
2468-3AU i5-2520M 4GBx1 14.0" HD 720p 500G 7200 Intel 2200 WWAN upg None None None 6 Pro 64 07/12
Type-model
Personal Systems Reference (PSREF)
© Lenovo
(CD1-1) August 2012
Supports ThinkVantage®technologies
Preloaded operating system20
Genuine Windows®7
Professional 64
Ready to install applications14 (only
some listed)
•Rescue and Recovery™
•Password Manager
Preloaded applications14 (only some
listed)
•Lenovo Message Center Plus
•ThinkVantage Product Recovery
•Access Connections™
•Fingerprint Software (fingerprint
models)
•ThinkVantage System Update
•ThinkVantage Power Manager
•Norton™Internet Security 2012
(30 days of virus definitions)
•Adobe®Reader®
•Skype™for Windows
•Windows Live™Essentials
• Microsoft®Office 2010 preloaded;
purchase product key to activate
•Corel®WinDVD®(DVD±RW)
•Corel Burn.Now™Lenovo Edition
(DVD±RW)
•Corel DVD MovieFactory®Lenovo
Edition (DVD±RW)
See footnotes for more detailed information
US model(s) announced June 5 or July 31, 2012
•Small and medium business (SMB) model(s), part of the US TopSeller
™Program
•Microsoft® Office 2010 Product Key Ready (O10PKR)
For compatible accessories, please
go to O-L430 sheet;
For Lenovo service22 upgrade options,
please go to S-TA sheet
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm Blue-
tooth
PCIe
Mini Card
WWAN/mSATA
Finger
print
reader PreloadCamera
PCIe
Mini Card
WLANProcessor
Bat-
tery
cells
Ann
Date
(mm/yy)Card slot

Mainstream business performance; two spindles
Intel®Core™i5-2520M processor (2 cores, 2.50GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), Intel Turbo Boost 2.0 (3.20GHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
DVD burner, 12.7mm high, fixed, not removable, tray-in
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" wide, 7mm high, removable, upgradable
Some: Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable,
Active Protection System ™
None
Some: 14.0" (355mm) HD (1366x768) color, anti-glare, LED backlight,
200 nits, 16:9 aspect ratio, 400:1 contrast ratio
Some: 14.0" (355mm) HD+ (1600x900) color, anti-glare, LED backlight,
250 nits, 16:9 aspect ratio, 400:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 3000 in processor,
supports external analog monitor via VGA DB-15 and digital monitor via Mini DisplayPort;
supports dual independent display;
Maximum external resolution: 2560x1600@60Hz (DisplayPort via optional Mini DP cable);
1920x1200@60Hz (single-link DVI-I via optional Mini DP cable); 2048x1536@75Hz (VGA)
6-row, 84-key, ThinkVantage button, spill-resistant, multimedia Fn keys
TrackPoint® pointing device, Internet Scroll Bar13, magnifying glass
UltraNav™, wide touchpad below keyboard, Tap Zones, scrolling, multi-touch
None
14.0W" (WxDxH): 13.94" x 9.57" x 1.17–1.24"; 354mm x 243mm x 29.6–31.4mm
6-cell: from 5.11 lb (2.32kg); 9-cell: from 5.48 lb (2.49kg)
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell or 9-cell, HW Authentication
6-cell (57Whr): up to 7.5 hr; 9-cell (94Whr): up to 12.3 hr
Mobile Intel HM76 Express Chipset
None
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
One USB 3.0, three USB 2.0 (one powered), VGA DB-15, Mini DisplayPort, ethernet (RJ-45)
Two PCI Express Mini Card slots
11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2200, 2x2
Wireless WAN upgradable
None
None
None
Realtek®RTL8111F Gigabit Network Connection
None
HD Audio, Realtek ALC3202 codec, Dolby®Advanced Audio™v2 / stereo speakers, 1.5W x 2 /
volume up, down, mute buttons / monaural digital mic , mic mute button, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
Trusted Platform Module, TCG 1.2-compliant
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touch pad
ThinkLight™
Dimensions3
Weight
2
Case material
Battery - type
Battery - life10
Chipset
ExpressCard
Smart Card read
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
Carrier
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®L430 2468 (TopSeller) - Windows 8
65-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
GREENGUARD®certified
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
2468-3BU i5-2520M 4GBx1 14.0" HD 720p 500G 7200 Intel 2200 WWAN upg None None None 6 Win8 Pro64 10/12
Type-model
Personal Systems Reference (PSREF)
© Lenovo
(CD1-7) October 2012
Supports ThinkVantage®technologies
Preloaded operating system20
- Windows®8 Pro 64-bit
Preloaded applications5(only some
listed)
- Windows 7 models
•Lenovo®Message Center Plus
•ThinkVantage Product Recovery
•Access Connections™
•ThinkVantage Power Manager
•Lenovo SimpleTap
• Microsoft®Office 2010 preloaded;
purchase product key to activate
•Corel®WinDVD®(DVD±RW)
•Corel Burn.Now™Lenovo Edition
(DVD±RW)
•Corel DVD MovieFactory®Lenovo
Edition (DVD±RW)
- Windows 8 models
•Lenovo Support
•Lenovo Companion
•Lenovo QuickLaunch
•Microsoft®Office 2013 preloaded;
purchase product key to activate
•Cyberlink Power2Go (DVD±RW)
•Cyberlink PowerProducer
(DVD±RW)
- All models
•Lenovo Solution Center
•Password Manager
•Fingerprint Software (fingerprint
models)
•Lenovo Cloud Storage
by SugarSync
•Norton™Internet Security
(30 days of virus definitions)
See footnotes for more detailed information
US model(s) announced October 23, 2012
•Small and medium business (SMB) model(s), part of the US TopSeller
™Program
For compatible accessories, please
go to O-L430 sheet;
For Lenovo service22 upgrade options,
please go to S-TA sheet
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Blue-
tooth
PCIe
Mini Card
WWAN/mSATA
Finger
print
reader PreloadCamera
PCIe
Mini Card
WLANProcessor
Bat-
tery
cells
Ann
Date
(mm/yy)Card slot

Mainstream business performance; two spindles
Intel®Core™i3-2370M processor (2 cores, 2.40GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i5-3210M processor (2 cores, 2.50GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.10GHz), HT technology
Intel Core i5-3320M processor (2 cores, 2.60GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.30GHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
DVD burner, 12.7mm high, fixed, not removable, tray-in
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" wide, 7mm high, removable, upgradable
Some: Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable, Active Protection System ™
None
Some: 14.0" (355mm) HD (1366x768) color, anti-glare, LED backlight,
200 nits, 16:9 aspect ratio, 400:1 contrast ratio
Some: 14.0" (355mm) HD+ (1600x900) color, anti-glare, LED backlight,
250 nits, 16:9 aspect ratio, 400:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 3000 or 4000 in processor,
supports external analog monitor via VGA DB-15 and digital monitor via Mini DisplayPort;
supports dual independent display;
Maximum external resolution: 2560x1600@60Hz (DisplayPort via optional Mini DP cable);
1920x1200@60Hz (single-link DVI-I via optional Mini DP cable); 2048x1536@75Hz (VGA)
6-row, 84-key, ThinkVantage button, spill-resistant, multimedia Fn keys
TrackPoint® pointing device, Internet Scroll Bar13, magnifying glass
UltraNav™, wide touchpad below keyboard, Tap Zones, scrolling, multi-touch
None
14.0W" (WxDxH): 13.94" x 9.57" x 1.17–1.24"; 354mm x 243mm x 29.6–31.4mm
6-cell: from 5.11 lb (2.32kg); 9-cell: from 5.48 lb (2.49kg)
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell or 9-cell, HW Authentication
6-cell (57Whr): up to 7.5 hr; 9-cell (94Whr): up to 12.3 hr
Mobile Intel HM76 Express Chipset
None
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
One USB 3.0, three USB 2.0 (one powered), VGA DB-15, Mini DisplayPort, ethernet (RJ-45)
Two PCI Express Mini Card slots
Some:
11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2200, 2x2
Some: 11a/b/g/n , PCIe Half Mini Card, Intel Centrino Advanced-N 6205, 2x2
Wireless WAN upgradable
None
None
Some: Bluetooth 4.0 wireless
Realtek®RTL8111F Gigabit Network Connection
None
HD Audio, Realtek ALC3202 codec, Dolby®Advanced Audio™v2 / stereo speakers, 1.5W x 2 /
volume up, down, mute buttons / monaural digital mic , mic mute button, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
Trusted Platform Module, TCG 1.2-compliant
Some: AuthenTec fingerprint reader on palm rest, swipe sensor, LED indicator,
supports the security chip
3-years/1-yr battery - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touch pad
ThinkLight™
Dimensions3
Weight
2
Case material
Battery - type
Battery - life10
Chipset
ExpressCard
Smart Card read
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
Carrier
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®L430 2469 (TopSeller)
65-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
GREENGUARD®certified
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
2469-24U i5-3320M 4GBx1 14.0" HD 720p 320G 7200 Intel 620528 WWAN upg None Finger BT 6 Pro 64 06/12
2469-25U i5-3320M 4GBx1 14.0" HD 720p 500G 7200 Intel 6205 WWAN upg None Finger BT 6 Pro 64 06/12
2469-26U i5-3320M 4GBx1 14.0" HD 720p 320G 7200 Intel 6205 WWAN upg None None None 6 Pro 64 06/12
2469-27U i5-3210M 4GBx1 14.0" HD 720p 320G 7200 Intel 2200 WWAN upg None None None 6 Pro 64 06/12
2469-28U i3-2370M 4GBx1 14.0" HD 720p 500G 7200 Intel 2200 WWAN upg None Finger BT 6 Pro 64 06/12
Type-model
Personal Systems Reference (PSREF)
© Lenovo
(CD1-2) June 2012
Supports ThinkVantage®technologies
Preloaded operating system20
Genuine Windows®7
Professional 64
Ready to install applications14 (only
some listed)
•Rescue and Recovery™
•Password Manager
Preloaded applications14 (only some
listed)
•Lenovo Message Center Plus
•ThinkVantage Product Recovery
•Access Connections™
•Fingerprint Software (fingerprint
models)
•ThinkVantage System Update
•ThinkVantage Power Manager
•Norton™Internet Security 2012
(30 days of virus definitions)
•Adobe®Reader®
•Skype™for Windows
•Windows Live™Essentials
• Microsoft®Office 2010 preloaded;
purchase product key to activate
•Corel®WinDVD®(DVD±RW)
•Corel Burn.Now™Lenovo Edition
(DVD±RW)
•Corel DVD MovieFactory®Lenovo
Edition (DVD±RW)
See footnotes for more detailed information
US model(s) announced June 5, 2012
•Small and medium business (SMB) model(s), part of the US TopSeller
™Program
•A depot repair service 3-year limited warranty
•Microsoft® Office 2010 Product Key Ready (O10PKR)
For compatible accessories, please
go to O-L430 sheet;
For Lenovo service22 upgrade options,
please go to S-TA sheet
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm Blue-
tooth
PCIe
Mini Card
WWAN/mSATA
Finger
print
reader PreloadCamera
PCIe
Mini Card
WLANProcessor
Bat-
tery
cells
Ann
Date
(mm/yy)
Card
slot

Mainstream business performance; two spindles
Intel®Core™i3-3110M processor (2 cores, 2.40GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), HT technology
Intel Core i5-3210M processor (2 cores, 2.50GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.10GHz), HT technology
Intel Core i5-3320M processor (2 cores, 2.60GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.30GHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
DVD burner, 12.7mm high, fixed, not removable, tray-in
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" wide, 7mm high, removable, upgradable
Some: Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable,
Active Protection System ™
None
Some: 14.0" (355mm) HD (1366x768) color, anti-glare, LED backlight,
200 nits, 16:9 aspect ratio, 400:1 contrast ratio
Some: 14.0" (355mm) HD+ (1600x900) color, anti-glare, LED backlight,
250 nits, 16:9 aspect ratio, 400:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 4000 in processor,
supports external analog monitor via VGA DB-15 and digital monitor via Mini DisplayPort;
supports dual independent display;
Maximum external resolution: 2560x1600@60Hz (DisplayPort via optional Mini DP cable);
1920x1200@60Hz (single-link DVI-I via optional Mini DP cable); 2048x1536@75Hz (VGA)
6-row, 84-key, ThinkVantage button, spill-resistant, multimedia Fn keys
TrackPoint® pointing device, Internet Scroll Bar13, magnifying glass
UltraNav™, wide touchpad below keyboard, Tap Zones, scrolling, multi-touch
None
14.0W" (WxDxH): 13.94" x 9.57" x 1.17–1.24"; 354mm x 243mm x 29.6–31.4mm
6-cell: from 5.11 lb (2.32kg); 9-cell: from 5.48 lb (2.49kg)
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell or 9-cell, HW Authentication
6-cell (57Whr): up to 7.5 hr; 9-cell (94Whr): up to 12.3 hr
Mobile Intel HM76 Express Chipset
One slot (ExpressCard/34, ExpressCard/54)
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
One USB 3.0, three USB 2.0 (one powered), VGA DB-15, Mini DisplayPort, ethernet (RJ-45)
Two PCI Express Mini Card slots
Some:
11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2200, 2x2
Some: 11a/b/g/n , PCIe Half Mini Card, Intel Centrino Advanced-N 6205, 2x2
Wireless WAN upgradable
None
None
Some: Bluetooth 4.0 wireless
Realtek®RTL8111F Gigabit Network Connection
None
HD Audio, Realtek ALC3202 codec, Dolby®Advanced Audio™v2 / stereo speakers, 1.5W x 2 /
volume up, down, mute buttons / monaural digital mic , mic mute button, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
Trusted Platform Module, TCG 1.2-compliant
Some: AuthenTec fingerprint reader on palm rest, swipe sensor, LED indicator,
supports the security chip
3-years/1-yr battery - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touch pad
ThinkLight™
Dimensions3
Weight
2
Case material
Battery - type
Battery - life10
Chipset
ExpressCard
Smart Card read
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
Carrier
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®L430 2469 (TopSeller) - Windows 8
65-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
GREENGUARD®certified
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
2469-2TU i5-3320M 4GBx1 14.0" HD 720p 500G 7200 Intel 620528 WWAN upg Express 54 Finger BT 6 Win7 Pro64 10/12
2469-2SU i5-3210M 4GBx1 14.0" HD 720p 500G 7200 Intel 2200 WWAN upg Express 54 None None 6 Win7 Pro64 10/12
2469-2RU i3-3110M 4GBx1 14.0" HD 720p 320G 7200 Intel 2200 WWAN upg Express 54 None None 6 Win7 Pro64 10/12
Type-model
Personal Systems Reference (PSREF)
© Lenovo
(CD1-10) November 2012
Supports ThinkVantage®technologies
Preloaded operating system20
- Windows®7 Professional 64
preinstalled through
downgrade rights in
Windows 8 Pro 64-bit
Preloaded applications5(only some
listed)
- Windows 7 models
•Lenovo®Message Center Plus
•ThinkVantage Product Recovery
•Access Connections™
•ThinkVantage Power Manager
•Lenovo SimpleTap
•Adobe®Reader®
• Microsoft®Office 2010 preloaded;
purchase product key to activate
•Corel®WinDVD®(DVD±RW)
•Corel Burn.Now™Lenovo Edition
(DVD±RW)
•Corel DVD MovieFactory®Lenovo
Edition (DVD±RW)
- Windows 8 models
•Lenovo Support
•Lenovo Companion
•Lenovo QuickLaunch
•Microsoft®Office 2013 preloaded;
purchase product key to activate
•Cyberlink Power2Go (DVD±RW)
•Cyberlink PowerProducer
(DVD±RW)
- All models
•Lenovo Solution Center
•Password Manager
•ThinkVantage System Update
•Fingerprint Software (fingerprint
models)
•Lenovo Cloud Storage
by SugarSync
•Norton™Internet Security
(30 days of virus definitions)
•Skype™
See footnotes for more detailed information
US model(s) announced October 30, 2012
•Small and medium business (SMB) model(s), part of the US TopSeller
™Program
•A depot repair service 3-year limited warranty
For compatible accessories, please
go to O-L430 sheet;
For Lenovo service22 upgrade options,
please go to S-TA sheet
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Blue-
tooth
PCIe
Mini Card
WWAN/mSATA
Finger
print
reader PreloadCamera
PCIe
Mini Card
WLANProcessor
Bat-
tery
cells
Ann
Date
(mm/yy)
Card
slot

Memory
2GB PC3-12800 DDR3 SODIMM 0A65722 ann 06/05/12
4GB PC3-12800 DDR3 SODIMM 0A65723 ann 06/05/12
Storage and removable storage
ThinkPad 16GB mSATA Solid State Cache Drive 0B47309 ann 12/11/12
USB 2.0 Portable 320GB Hard Disk 45K1689 ann 03/17/09
USB 2.0 Portable 500GB Hard Disk 45K1690 ann 05/26/09
USB 3.0 Secure 500GB Hard Drive 0A65619 ann 11/29/11
USB 3.0 Secure 750GB Hard Drive 0A65616 ann 11/29/11
USB 3.0 Secure 1TB Hard Drive 0A65621 ann 08/28/12
Lenovo Slim USB Portable DVD Burner 0A33988 ann 06/14/11
ThinkPad Expansion
Lenovo®Essential Notebook Stand 45J9292 ann 05/12/09
ThinkPad Port Replicator Series 3 with USB 3.0 433615W ann 06/05/12
ThinkPad Mini Dock Series 3 - 90W 433710U ann 06/23/09
ThinkPad Mini Dock Series 3 w/ USB 3.0 - 90W 433715U ann 06/05/12
TP Mini Dock Plus Series 3 w/ USB 3.0 - 90W 433815U ann 06/05/12
TP Mini Dock Plus Series 3 w/ USB 3.0 - 170W 433835U ann 06/05/12
Keyboard
TrackPoint Cap Collection 73P2698 ann 12/16/03
Ultraslim Plus Wireless Keyboard and Mouse52 0A34032 ann 04/05/11
USB Numeric Keypad 33L3225 ann 05/01/00
Preferred Pro USB Keyboard 73P5220 ann 06/21/05
Enhanced Performance USB Keyboard 73P2620 ann 03/23/04
ThinkPad USB Keyboard with TrackPoint 55Y9003 ann 08/18/09
Lenovo®USB Fingerprint Keyboard 73P4730 ann 02/22/05
Lenovo USB Smartcard Keyboard 51J0155 ann 03/24/09
52
Wireless via 2.4GHz technology using a micro-size USB receiver.
Mouse
Lenovo Optical Mouse (USB) 06P4069 ann 05/21/03
Lenovo Laser Mouse (USB) 41U3074 ann 01/23/07
ThinkPad USB Laser Mouse 57Y4635 ann 12/15/09
Lenovo ScrollPoint®Mouse (USB, Optical) 31P7405 ann 08/27/02
ThinkPad Travel Mouse (USB, Optical) 31P7410 ann 06/04/02
ThinkPad Bluetooth Laser Mouse 0A36407 ann 06/26/12
Lenovo Wireless Laser Mouse52 0A36188 ann 12/20/11
Multimedia
ThinkPad In-Ear Headphones with microphone 57Y4488 ann 01/07/10
Modem
USB 2.0 Lenovo Modem 43R1814 ann 02/26/08
Security
3M 14.0W Privacy Filter from Lenovo 0A61769 ann 04/05/11
Kensington®MicroSaver®Cable Lock 73P2582 ann 12/29/03
Kensington Twin Head Cable Lock 45K1620 ann 09/30/08
Lenovo Security Cable Lock 57Y4303 ann 08/24/10
USB Gemplus GemPC Smart Card Reader 41N3040 ann 02/21/06
ExpressCard Gemplus Smart Card Reader57 41N3043 ann 06/27/06
57 Only compatible with the models having 54mm Express card slot.
Batteries
ThinkPad Battery 70+ (6-cell) 0A36302 ann 06/05/12
ThinkPad Battery 70++ (9-cell) 0A36303 ann 06/05/12
ThinkPad External Battery Charger44 40Y7625 ann 09/20/05
44
Requires the ThinkPad 90W AC Adapter
40Y7659 or the adapter provided with the system.
More information at www.lenovo.com/alldaycomputing
ThinkPad 65W AC Adapter45 40Y7696 ann 01/05/06
45
Only compatible with the integrated graphics models.
ThinkPad 90W AC Adapter 40Y7659 ann 09/20/05
90W Ultraslim AC/DC Combo Adapter 41R4493 ann 09/22/09
More info at www.lenovo.com/support/poweradapters
Charging tips for 90W Ultraslim AC/DC Combo Adapter 41R4493
•iPod and iPhone Charge Tip (L10a) 41R4481 ann 12/18/07
•Generic Micro USB charge tip (L18) 41R4490 ann 01/06/09
More information at www.lenovopowertips.com
Carrying Cases
Up to 14" widescreen models:
ThinkPad 14W Case Sleeve 57Y4294 ann 03/16/10
Up to 15.6" widescreen models:
Lenovo Messenger Max 41U5253 ann 05/01/07
Lenovo Performance BackPack 41U5254 ann 05/01/07
ThinkPad Business Topload Case 43R2476 ann 05/13/08
ThinkPad Business Backpack 43R2482 ann 05/13/08
ThinkPad Deluxe Expander Case 43R2478 ann 05/13/08
ThinkPad Executive Leather Case 43R2480 ann 05/13/08
Lenovo Sport Backpack - Red 0A33896 ann 02/28/12
Lenovo Sport Slimcase - Red 0A33897 ann 02/28/12
Lenovo Sport Messenger - Red 0A33898 ann 02/28/12
More information at www.lenovo.com/support/cases
Monitors
ThinkVision
®
L1711p 17" (VGA, DVI-D) 5047HB2 ann 10/20/09
ThinkVision L1900p 19" (VGA, DVI-D) 4431HE1 ann 11/11/08
ThinkVision LT1952p Wide 19" (VGA, DP, DVI-D)
69
2448MB6 ann 09/13/11
ThinkVision L2250p Wide 22" (VGA, DVI-D) 2572HB6 ann 10/20/09
ThinkVision L2251x Wide 22" (VGA, DP)
69
2578HB6 ann 10/20/09
ThinkVision LT2252p Wide 22" (VGA, DP, DVI-D)
69
2572MB6 ann 09/13/11
ThinkVision LT2452p Wide 24" (VGA, DP, DVI-D)
69
4420MB2 ann 09/13/11
69 DisplayPort cable is not included.
ThinkVision LT1421 Wide 14" Mobile Monitor
with Protective Screen Cover (USB 2.0) 1452DS6 ann 08/16/11
ThinkVision LT1421 Wide 14" Mobile Monitor
with Protective Case (USB 2.0) 1452DB6 ann 08/16/11
More information at www.lenovo.com/support/monitors
Monitor Accessories46
Lenovo USB 3.0 to DVI/VGA Monitor Adapter 0B47072 ann 08/14/12
Lenovo Mini-DisplayPort to VGA Monitor Cable 0A36536 ann 05/17/11
Mini-DisplayPort to Single-link DVI Monitor Cable 0B47090 ann 06/26/12
Mini-DisplayPort to DisplayPort Monitor Cable 0B47091 ann 07/24/12
Lenovo USB Soundbar 0A36190 ann 05/01/12
Kensington MicroSaver Cable Lock 73P2582 ann 12/29/03
Kensington Twin Head Cable Lock 45K1620 ann 09/30/08
Lenovo Security Cable Lock 57Y4303 ann 08/24/10
Lenovo Easy Reach Monitor Stand 55Y9258 ann 09/22/09
46
Compatible on selected Lenovo and ThinkVision monitors.
More information at www.lenovo.com/support/monitoraccessories
For more information on accessories:
www.lenovo.com/accessories
Purchase Lenovo accessories
www.lenovo.com/support/accessories
Product specifications on Lenovo Support
www.lenovo.com/accessoriesguide
Option Compatibility Matrix (OCM) and accessory brochures
www.lenovoquickpick.com
An Options Compatibility Configurator for Lenovo systems
© Lenovo
(O-L430) June 2012
ThinkPad®L430 Accessories Personal Systems Reference (PSREF)

Lenovo®ThinkPad L530
Lenovo Sport Backpack - Blue 0B47298
Lenovo Sport Backpack - Red 0A33896
Lenovo Sport Backpack - Grey 0B47301
Lenovo ThinkPad L530
Lenovo ThinkPad L530
Lenovo ThinkPad L530 Lenovo ThinkPad L530

Mainstream business performance; two spindles
Intel®Core™i3-2370M processor (2 cores, 2.40GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i5-2520M processor (2 cores, 2.50GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), Intel Turbo Boost 2.0 (3.20GHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
DVD burner, 12.7mm high, fixed, not removable, tray-in
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" wide, 7mm high, removable, upgradable
Some: Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable,
Active Protection System ™
None
Some: 15.6" (396mm) HD (1366x768) color, anti-glare, LED backlight,
220 nits, 16:9 aspect ratio, 500:1 contrast ratio
Some: 15.6" (396mm) HD+ (1600x900) color, anti-glare, LED backlight,
220 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 3000 in processor,
supports external analog monitor via VGA DB-15 and digital monitor via Mini DisplayPort;
supports dual independent display;
Maximum external resolution: 2560x1600@60Hz (DisplayPort via optional Mini DP cable);
1920x1200@60Hz (single-link DVI-I via optional Mini DP cable); 2048x1536@75Hz (VGA)
6-row, 84-key, ThinkVantage button, spill-resistant, multimedia Fn keys
TrackPoint® pointing device, Internet Scroll Bar13, magnifying glass
UltraNav™, wide touchpad below keyboard, Tap Zones, scrolling, multi-touch
None
15.6W" (WxDxH): 14.96" x 9.72" x 1.25–1.31"; 380mm x 247mm x 31.7–33.4mm
6-cell: from 5.69 lb (2.58kg); 9-cell: from 6.05 lb (2.75kg)
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell or 9-cell, HW Authentication
6-cell (57Whr): up to 7.5 hr; 9-cell (94Whr): up to 12.3 hr
Mobile Intel HM76 Express Chipset
None
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
One USB 3.0, three USB 2.0 (one powered), VGA DB-15, Mini DisplayPort, ethernet (RJ-45)
Two PCI Express Mini Card slots
11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2200, 2x2
Wireless WAN upgradable
None
None
None
Realtek®RTL8111F Gigabit Network Connection
None
HD Audio, Realtek ALC3202 codec, Dolby®Advanced Audio™v2 / stereo speakers, 1.5W x 2 /
volume up, down, mute buttons / monaural digital mic , mic mute button, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
Trusted Platform Module, TCG 1.2-compliant
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touch pad
ThinkLight™
Dimensions3
Weight
2
Case material
Battery - type
Battery - life10
Chipset
ExpressCard
Smart Card read
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
Carrier
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®L530 2481 (TopSeller)
65-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
GREENGUARD®certified
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
2481-26U i3-2370M 4GBx1 15.6" HD 720p 320G 7200 Intel 2200 WWAN upg None None None 6 Pro 64 06/12
2481-34U i5-2520M 4GBx1 15.6" HD 720p 500G 7200 Intel 2200 WWAN upg None None None 6 Pro 64 07/12
Type-model
Personal Systems Reference (PSREF)
© Lenovo
(BF1-1) August 2012
Supports ThinkVantage®technologies
Preloaded operating system20
Genuine Windows®7
Professional 64
Ready to install applications14 (only
some listed)
•Rescue and Recovery™
•Password Manager
Preloaded applications14 (only some
listed)
•Lenovo Message Center Plus
•ThinkVantage Product Recovery
•Access Connections™
•Fingerprint Software (fingerprint
models)
•ThinkVantage System Update
•ThinkVantage Power Manager
•Norton™Internet Security 2012
(30 days of virus definitions)
•Adobe®Reader®
•Skype™for Windows
•Windows Live™Essentials
• Microsoft®Office 2010 preloaded;
purchase product key to activate
•Corel®WinDVD®(DVD±RW)
•Corel Burn.Now™Lenovo Edition
(DVD±RW)
•Corel DVD MovieFactory®Lenovo
Edition (DVD±RW)
See footnotes for more detailed information
US model(s) announced June 5 or July 31, 2012
•Small and medium business (SMB) model(s), part of the US TopSeller
™Program
•Microsoft® Office 2010 Product Key Ready (O10PKR)
For compatible accessories, please
go to O-L530 sheet;
For Lenovo service22 upgrade options,
please go to S-TA sheet
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm Blue-
tooth
PCIe
Mini Card
WWAN/mSATA
Finger
print
reader PreloadCamera
PCIe
Mini Card
WLANProcessor
Bat-
tery
cells
Ann
Date
(mm/yy)
Card
slot

Mainstream business performance; two spindles
Intel®Core™i5-2520M processor (2 cores, 2.50GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), Intel Turbo Boost 2.0 (3.20GHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
DVD burner, 12.7mm high, fixed, not removable, tray-in
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" wide, 7mm high, removable, upgradable
Some: Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable,
Active Protection System ™
None
Some: 15.6" (396mm) HD (1366x768) color, anti-glare, LED backlight,
220 nits, 16:9 aspect ratio, 500:1 contrast ratio
Some: 15.6" (396mm) HD+ (1600x900) color, anti-glare, LED backlight,
220 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 3000 in processor,
supports external analog monitor via VGA DB-15 and digital monitor via Mini DisplayPort;
supports dual independent display;
Maximum external resolution: 2560x1600@60Hz (DisplayPort via optional Mini DP cable);
1920x1200@60Hz (single-link DVI-I via optional Mini DP cable); 2048x1536@75Hz (VGA)
6-row, 84-key, ThinkVantage button, spill-resistant, multimedia Fn keys
TrackPoint® pointing device, Internet Scroll Bar13, magnifying glass
UltraNav™, wide touchpad below keyboard, Tap Zones, scrolling, multi-touch
None
15.6W" (WxDxH): 14.96" x 9.72" x 1.25–1.31"; 380mm x 247mm x 31.7–33.4mm
6-cell: from 5.69 lb (2.58kg); 9-cell: from 6.05 lb (2.75kg)
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell or 9-cell, HW Authentication
6-cell (57Whr): up to 7.5 hr; 9-cell (94Whr): up to 12.3 hr
Mobile Intel HM76 Express Chipset
None
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
One USB 3.0, three USB 2.0 (one powered), VGA DB-15, Mini DisplayPort, ethernet (RJ-45)
Two PCI Express Mini Card slots
11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2200, 2x2
Wireless WAN upgradable
None
None
None
Realtek®RTL8111F Gigabit Network Connection
None
HD Audio, Realtek ALC3202 codec, Dolby®Advanced Audio™v2 / stereo speakers, 1.5W x 2 /
volume up, down, mute buttons / monaural digital mic , mic mute button, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
Trusted Platform Module, TCG 1.2-compliant
None
1-year - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touch pad
ThinkLight™
Dimensions3
Weight
2
Case material
Battery - type
Battery - life10
Chipset
ExpressCard
Smart Card read
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
Carrier
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®L530 2481 (TopSeller) - Windows 8
65-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
GREENGUARD®certified
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
2481-33U i5-2520M 4GBx1 15.6" HD 720p 500G 7200 Intel 2200 WWAN upg None None 6 Win8 Pro64 10/12
Type-model
Personal Systems Reference (PSREF)
© Lenovo
(BF1-5) October 2012
Supports ThinkVantage®technologies
Preloaded operating system20
- Windows®8 Pro 64-bit
Preloaded applications5(only some
listed)
- Windows 7 models
•Lenovo®Message Center Plus
•ThinkVantage Product Recovery
•Access Connections™
•ThinkVantage Power Manager
•Lenovo SimpleTap
• Microsoft®Office 2010 preloaded;
purchase product key to activate
•Corel®WinDVD®(DVD±RW)
•Corel Burn.Now™Lenovo Edition
(DVD±RW)
•Corel DVD MovieFactory®Lenovo
Edition (DVD±RW)
- Windows 8 models
•Lenovo Support
•Lenovo Companion
•Lenovo QuickLaunch
•Microsoft®Office 2013 preloaded;
purchase product key to activate
•Cyberlink Power2Go (DVD±RW)
•Cyberlink PowerProducer
(DVD±RW)
- All models
•Lenovo Solution Center
•Password Manager
•Fingerprint Software (fingerprint
models)
•Lenovo Cloud Storage
by SugarSync
•Norton™Internet Security
(30 days of virus definitions)
See footnotes for more detailed information
US model(s) announced October 23, 2012
•Small and medium business (SMB) model(s), part of the US TopSeller
™Program
For compatible accessories, please
go to O-L530 sheet;
For Lenovo service22 upgrade options,
please go to S-TA sheet
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm
Blue-
tooth
PCIe
Mini Card
WWAN/mSATA
Finger
print
reader PreloadCamera
PCIe
Mini Card
WLANProcessor
Bat-
tery
cells
Ann
Date
(mm/yy)

Mainstream business performance; two spindles
Intel®Core™i3-2370M processor (2 cores, 2.40GHz, 3MB cache), Intel HD Graphics 3000,
DDR3 memory controller (up to 1333MHz), HT technology
Intel Core i5-3210M processor (2 cores, 2.50GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.10GHz), HT technology
Intel Core i5-3320M processor (2 cores, 2.60GHz, 3MB cache), Intel HD Graphics 4000,
DDR3 memory controller (up to 1600MHz), Intel Turbo Boost 2.0 (3.30GHz), HT technology
8GB max7/ PC3-12800 1600MHz DDR3, non-parity,
dual-channel capable, two 204-pin SO-DIMM sockets
* System automatically clocks down for processors with 1333MHz DDR3 memory controller
DVD burner, 12.7mm high, fixed, not removable, tray-in
Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" wide, 7mm high, removable, upgradable
Some: Hard Disk Drive / SATA 3.0Gb/s, 2.5" wide, 7mm or 9.5mm high,
removable, upgradable,
Active Protection System ™
None
Some: 15.6" (396mm) HD (1366x768) color, anti-glare, LED backlight,
220 nits, 16:9 aspect ratio, 500:1 contrast ratio
Some: 15.6" (396mm) HD+ (1600x900) color, anti-glare, LED backlight,
220 nits, 16:9 aspect ratio, 500:1 contrast ratio
HD720p resolution, wide view angle, low light sensitive, face tracking, fixed focus
Intel HD Graphics 3000 or 4000 in processor,
supports external analog monitor via VGA DB-15 and digital monitor via Mini DisplayPort;
supports dual independent display;
Maximum external resolution: 2560x1600@60Hz (DisplayPort via optional Mini DP cable);
1920x1200@60Hz (single-link DVI-I via optional Mini DP cable); 2048x1536@75Hz (VGA)
6-row, 84-key, ThinkVantage button, spill-resistant, multimedia Fn keys
TrackPoint® pointing device, Internet Scroll Bar13, magnifying glass
UltraNav™, wide touchpad below keyboard, Tap Zones, scrolling, multi-touch
None
15.6W" (WxDxH): 14.96" x 9.72" x 1.25–1.31"; 380mm x 247mm x 31.7–33.4mm
6-cell: from 5.69 lb (2.58kg); 9-cell: from 6.05 lb (2.75kg)
Acrylonitrile-Butadiene-Styrene (ABS) plastic
Lithium Ion 6-cell or 9-cell, HW Authentication
6-cell (57Whr): up to 7.5 hr; 9-cell (94Whr): up to 12.3 hr
Mobile Intel HM76 Express Chipset
None
None
4-in-1 reader (MMC, SD, SDHC, SDXC)
One USB 3.0, three USB 2.0 (one powered), VGA DB-15, Mini DisplayPort, ethernet (RJ-45)
Two PCI Express Mini Card slots
Some:
11b/g/n , PCIe Half Mini Card, Intel Centrino
®
Wireless-N 2200, 2x2
Some: 11a/b/g/n , PCIe Half Mini Card, Intel Centrino Advanced-N 6205, 2x2
Wireless WAN upgradable
None
None
Some: Bluetooth 4.0 wireless
Realtek®RTL8111F Gigabit Network Connection
None
HD Audio, Realtek ALC3202 codec, Dolby®Advanced Audio™v2 / stereo speakers, 1.5W x 2 /
volume up, down, mute buttons / monaural digital mic , mic mute button, combo audio/mic jack
Power-on password, hard disk password, supervisor password, security keyhole
Trusted Platform Module, TCG 1.2-compliant
Some: AuthenTec fingerprint reader on palm rest, swipe sensor, LED indicator,
supports the security chip
3-years/1-yr battery - depot repair service / service upgrades
22
available
Positioning
Processor
Memory
Optical
SATA disk
m S ATA ™SSD
Widescreen
display
Camera
Graphics
Keyboard
TrackPoint®
Touch pad
ThinkLight™
Dimensions3
Weight
2
Case material
Battery - type
Battery - life10
Chipset
ExpressCard
Smart Card read
Multicard Reader
Ports
PCIe Mini Card
PCIe WLAN4
PCIe WWAN
Carrier
Modem
Bluetooth™
Ethernet
Intel AMT
Audio support
Security
Security chip
Fingerprint reader
Limited warranty12
ThinkPad®L530 2485 (TopSeller)
65-watt AC adapter
EPEAT™Gold rating
ENERGY STAR®5.0-compliant
GREENGUARD®certified
RoHS-compliant
International Warranty Service17
24 hour x 7 day18 toll-free support
during the warranty period12
2485-22U i5-3320M 4GBx1 15.6" HD 720p 500G 7200 Intel 620528 WWAN upg None Finger BT 6 Pro 64 06/12
2485-23U i5-3320M 4GBx1 15.6" HD 720p 320G 7200 Intel 6205 WWAN upg None Finger BT 6 Pro 64 06/12
2485-24U i5-3320M 4GBx1 15.6" HD 720p 320G 7200 Intel 6205 WWAN upg None None None 6 Pro 64 06/12
2485-25U i5-3210M 4GBx1 15.6" HD 720p 320G 7200 Intel 2200 WWAN upg None None None 6 Pro 64 06/12
2485-26U i3-2370M 4GBx1 15.6" HD 720p 500G 7200 Intel 2200 WWAN upg None Finger BT 6 Pro 64 06/12
Type-model
Personal Systems Reference (PSREF)
© Lenovo
(BF1-2) August 2012
Supports ThinkVantage®technologies
Preloaded operating system20
Genuine Windows®7
Professional 64
Ready to install applications14 (only
some listed)
•Rescue and Recovery™
•Password Manager
Preloaded applications14 (only some
listed)
•Lenovo Message Center Plus
•ThinkVantage Product Recovery
•Access Connections™
•Fingerprint Software (fingerprint
models)
•ThinkVantage System Update
•ThinkVantage Power Manager
•Norton™Internet Security 2012
(30 days of virus definitions)
•Adobe®Reader®
•Skype™for Windows
•Windows Live™Essentials
• Microsoft®Office 2010 preloaded;
purchase product key to activate
•Corel®WinDVD®(DVD±RW)
•Corel Burn.Now™Lenovo Edition
(DVD±RW)
•Corel DVD MovieFactory®Lenovo
Edition (DVD±RW)
See footnotes for more detailed information
US model(s) announced June 5, 2012
•Small and medium business (SMB) model(s), part of the US TopSeller
™Program
•A depot repair service 3-year limited warranty
•Microsoft® Office 2010 Product Key Ready (O10PKR)
For compatible accessories, please
go to O-L530 sheet;
For Lenovo service22 upgrade options,
please go to S-TA sheet
Wide-
screen
displayMemory
Disk
SATA
GB8 rpm Blue-
tooth
PCIe
Mini Card
WWAN/mSATA
Finger
print
reader PreloadCamera
PCIe
Mini Card
WLANProcessor
Bat-
tery
cells
Ann
Date
(mm/yy)
Card
slot

Memory
2GB PC3-12800 DDR3 SODIMM 0A65722 ann 06/05/12
4GB PC3-12800 DDR3 SODIMM 0A65723 ann 06/05/12
Storage and removable storage
ThinkPad 16GB mSATA Solid State Cache Drive 0B47309 ann 12/11/12
USB 2.0 Portable 320GB Hard Disk 45K1689 ann 03/17/09
USB 2.0 Portable 500GB Hard Disk 45K1690 ann 05/26/09
USB 3.0 Secure 500GB Hard Drive 0A65619 ann 11/29/11
USB 3.0 Secure 750GB Hard Drive 0A65616 ann 11/29/11
USB 3.0 Secure 1TB Hard Drive 0A65621 ann 08/28/12
Lenovo Slim USB Portable DVD Burner 0A33988 ann 06/14/11
ThinkPad Expansion
Lenovo®Essential Notebook Stand 45J9292 ann 05/12/09
ThinkPad Port Replicator Series 3 with USB 3.0 433615W ann 06/05/12
ThinkPad Mini Dock Series 3 - 90W 433710U ann 06/23/09
ThinkPad Mini Dock Series 3 w/ USB 3.0 - 90W 433715U ann 06/05/12
TP Mini Dock Plus Series 3 w/ USB 3.0 - 90W 433815U ann 06/05/12
TP Mini Dock Plus Series 3 w/ USB 3.0 - 170W 433835U ann 06/05/12
Keyboard
TrackPoint Cap Collection 73P2698 ann 12/16/03
Ultraslim Plus Wireless Keyboard and Mouse52 0A34032 ann 04/05/11
USB Numeric Keypad 33L3225 ann 05/01/00
Preferred Pro USB Keyboard 73P5220 ann 06/21/05
Enhanced Performance USB Keyboard 73P2620 ann 03/23/04
ThinkPad USB Keyboard with TrackPoint 55Y9003 ann 08/18/09
Lenovo®USB Fingerprint Keyboard 73P4730 ann 02/22/05
Lenovo USB Smartcard Keyboard 51J0155 ann 03/24/09
52
Wireless via 2.4GHz technology using a micro-size USB receiver.
Mouse
Lenovo Optical Mouse (USB) 06P4069 ann 05/21/03
Lenovo Laser Mouse (USB) 41U3074 ann 01/23/07
ThinkPad USB Laser Mouse 57Y4635 ann 12/15/09
Lenovo ScrollPoint®Mouse (USB, Optical) 31P7405 ann 08/27/02
ThinkPad Travel Mouse (USB, Optical) 31P7410 ann 06/04/02
ThinkPad Bluetooth Laser Mouse 0A36407 ann 06/26/12
Lenovo Wireless Laser Mouse52 0A36188 ann 12/20/11
Multimedia
ThinkPad In-Ear Headphones with microphone 57Y4488 ann 01/07/10
Modem
USB 2.0 Lenovo Modem 43R1814 ann 02/26/08
Security
3M 15.6W Privacy Filter from Lenovo 0A61771 ann 04/05/11
Kensington®MicroSaver®Cable Lock 73P2582 ann 12/29/03
Kensington Twin Head Cable Lock 45K1620 ann 09/30/08
Lenovo Security Cable Lock 57Y4303 ann 08/24/10
USB Gemplus GemPC Smart Card Reader 41N3040 ann 02/21/06
ExpressCard Gemplus Smart Card Reader57 41N3043 ann 06/27/06
57 Only compatible with the models having 54mm Express card slot.
Batteries
ThinkPad Battery 70+ (6-cell) 0A36302 ann 06/05/12
ThinkPad Battery 70++ (9-cell) 0A36303 ann 06/05/12
ThinkPad External Battery Charger44 40Y7625 ann 09/20/05
44
Requires the ThinkPad 90W AC Adapter
40Y7659 or the adapter provided with the system.
More information at www.lenovo.com/alldaycomputing
ThinkPad 65W AC Adapter45 40Y7696 ann 01/05/06
45
Only compatible with the integrated graphics models.
ThinkPad 90W AC Adapter 40Y7659 ann 09/20/05
90W Ultraslim AC/DC Combo Adapter 41R4493 ann 09/22/09
More info at www.lenovo.com/support/poweradapters
Charging tips for 90W Ultraslim AC/DC Combo Adapter 41R4493
•iPod and iPhone Charge Tip (L10a) 41R4481 ann 12/18/07
•Generic Micro USB charge tip (L18) 41R4490 ann 01/06/09
More information at www.lenovopowertips.com
Carrying Cases
Up to 15.6" widescreen models:
Lenovo Messenger Max 41U5253 ann 05/01/07
Lenovo Performance BackPack 41U5254 ann 05/01/07
ThinkPad Business Topload Case 43R2476 ann 05/13/08
ThinkPad Business Backpack 43R2482 ann 05/13/08
ThinkPad Deluxe Expander Case 43R2478 ann 05/13/08
ThinkPad Executive Leather Case 43R2480 ann 05/13/08
Lenovo Sport Backpack - Red 0A33896 ann 02/28/12
Lenovo Sport Slimcase - Red 0A33897 ann 02/28/12
Lenovo Sport Messenger - Red 0A33898 ann 02/28/12
Lenovo Sport Backpack - Blue 0B47298 ann 08/28/12
Lenovo Sport Slimcase - Blue 0B47300 ann 08/28/12
Lenovo Sport Messenger - Blue 0B47299 ann 08/28/12
Lenovo Sport Backpack - Grey 0B47301 ann 08/28/12
Lenovo Sport Slimcase - Grey 0B47303 ann 08/28/12
Lenovo Sport Messenger - Grey 0B47302 ann 08/28/12
More information at www.lenovo.com/support/cases
Monitors
ThinkVision
®
L1711p 17" (VGA, DVI-D) 5047HB2 ann 10/20/09
ThinkVision L1900p 19" (VGA, DVI-D) 4431HE1 ann 11/11/08
ThinkVision LT1952p Wide 19" (VGA, DP, DVI-D)
69
2448MB6 ann 09/13/11
ThinkVision L2250p Wide 22" (VGA, DVI-D) 2572HB6 ann 10/20/09
ThinkVision L2251x Wide 22" (VGA, DP)
69
2578HB6 ann 10/20/09
ThinkVision LT2252p Wide 22" (VGA, DP, DVI-D)
69
2572MB6 ann 09/13/11
ThinkVision LT2452p Wide 24" (VGA, DP, DVI-D)
69
4420MB2 ann 09/13/11
69 DisplayPort cable is not included.
ThinkVision LT1421 Wide 14" Mobile Monitor
with Protective Screen Cover (USB 2.0) 1452DS6 ann 08/16/11
ThinkVision LT1421 Wide 14" Mobile Monitor
with Protective Case (USB 2.0) 1452DB6 ann 08/16/11
More information at www.lenovo.com/support/monitors
Monitor Accessories46
Lenovo USB 3.0 to DVI/VGA Monitor Adapter 0B47072 ann 08/14/12
Lenovo Mini-DisplayPort to VGA Monitor Cable 0A36536 ann 05/17/11
Mini-DisplayPort to Single-link DVI Monitor Cable 0B47090 ann 06/26/12
Mini-DisplayPort to DisplayPort Monitor Cable 0B47091
ann 07/24/12
Lenovo USB Soundbar 0A36190 ann 05/01/12
Kensington MicroSaver Cable Lock 73P2582 ann 12/29/03
Kensington Twin Head Cable Lock 45K1620 ann 09/30/08
Lenovo Security Cable Lock 57Y4303 ann 08/24/10
Lenovo Easy Reach Monitor Stand 55Y9258 ann 09/22/09
46
Compatible on selected Lenovo and ThinkVision monitors.
More information at www.lenovo.com/support/monitoraccessories
For more information on accessories:
www.lenovo.com/accessories
Purchase Lenovo accessories
www.lenovo.com/support/accessories
Product specifications on Lenovo Support
www.lenovo.com/accessoriesguide
Option Compatibility Matrix (OCM) and accessory brochures
www.lenovoquickpick.com
An Options Compatibility Configurator for Lenovo systems
© Lenovo
(O-L530) June 2012
ThinkPad®L530 Accessories Personal Systems Reference (PSREF)

Lenovo®ThinkPad T430
Lenovo ThinkPad T430
Lenovo ThinkPad T430
Lenovo ThinkPad T430 with
ThinkPad Port Replicator Series 3 with USB 3.0
433615W
Lenovo ThinkPad T430
Lenovo ThinkPad T430
