Lenovo ThinkSystem SR550 User manual

ThinkSystem SR550
Setup Guide
Machine Types: 7X03 and 7X04

Note
Before using this information and the product it supports, e sure to read and understand the safety
information and the safety instructions, which are availa le at:
http://thinksystem.lenovofiles.com/help/topic/safety_documentation/pdf_files.html
In addition, e sure that you are familiar with the terms and conditions of the Lenovo warranty for your server,
which can e found at:
http://datacentersupport.lenovo.com/warrantylookup
Fourteenth Edition (November 2020)
© Copyright enovo 2017, 2020.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration (GSA) contract, use, reproduction, or disclosure is su ject to restrictions set forth in Contract No. GS-35F-
05925.

Contents
Chapter 1. Introduction . . . . . . . . . 1
Server package contents . . . . . . . . . . . . 2
Features. . . . . . . . . . . . . . . . . . . 3
Specifications . . . . . . . . . . . . . . . . 5
Particulate contamination . . . . . . . . . 10
Management offerings . . . . . . . . . . . . 11
Chapter 2. Server components . . . . 15
Front view . . . . . . . . . . . . . . . . . 15
Front I/O assem ly . . . . . . . . . . . . . 19
Rear view . . . . . . . . . . . . . . . . . 22
Rear view LEDs . . . . . . . . . . . . . . . 24
System oard components . . . . . . . . . . 27
Internal ca le routing. . . . . . . . . . . . . 28
Server models with eight 3.5-inch simple-
swap drives . . . . . . . . . . . . . . 30
Server models with eight 3.5-inch hot-swap
drives . . . . . . . . . . . . . . . . . 31
Server models with twelve 3.5-inch hot-swap
drives . . . . . . . . . . . . . . . . . 33
Server models with eight 2.5-inch hot-swap
drives . . . . . . . . . . . . . . . . . 35
Server models with sixteen 2.5-inch hot-swap
drives . . . . . . . . . . . . . . . . . 37
Parts list. . . . . . . . . . . . . . . . . . 41
Power cords . . . . . . . . . . . . . . 44
Chapter 3. Server hardware setup . . 45
Server setup checklist . . . . . . . . . . . . 45
Installation Guidelines . . . . . . . . . . . . 46
Safety inspection checklist. . . . . . . . . 47
System relia ility guidelines . . . . . . . . 48
Working inside the server with the power on . . 48
Handling static-sensitive devices . . . . . . 48
Install server hardware options . . . . . . . . . 49
Remove the security ezel . . . . . . . . . 50
Remove the top cover . . . . . . . . . . 51
Remove the air affle . . . . . . . . . . . 52
Install a processor-heat-sink module. . . . . 53
Install a memory module . . . . . . . . . 55
Install the 2.5-inch-drive ackplane . . . . . 61
Install the 3.5-inch-drive ackplane . . . . . 64
Install a system fan. . . . . . . . . . . . 66
Install the serial port module . . . . . . . . 68
Install the LOM adapter . . . . . . . . . . 69
Install a PCIe adapter . . . . . . . . . . . 70
Install the M.2 ackplane and M.2 drive. . . . 74
Install a hot-swap power supply . . . . . . 78
Install the air affle . . . . . . . . . . . . 81
Install a RAID super capacitor module . . . . 83
Install the top cover . . . . . . . . . . . 84
Install a hot-swap drive . . . . . . . . . . 85
Install a simple-swap drive. . . . . . . . . 87
Install the server in a rack . . . . . . . . . . . 89
Ca le the server . . . . . . . . . . . . . . 89
Power on the server . . . . . . . . . . . . . 89
Validate server setup. . . . . . . . . . . . . 90
Power off the server . . . . . . . . . . . . . 90
Chapter 4. System configuration . . . 91
Set the network connection for the Lenovo XClarity
Controller . . . . . . . . . . . . . . . . . 91
Update the firmware . . . . . . . . . . . . . 92
Configure the firmware . . . . . . . . . . . . 95
Memory configuration . . . . . . . . . . . . 96
RAID configuration . . . . . . . . . . . . . 96
Deploy the operating system. . . . . . . . . . 96
Back up the server configuration . . . . . . . . 97
Update the Vital Product Data (VPD). . . . . . . 97
Update the Universal Unique Identifier
(UUID). . . . . . . . . . . . . . . . . 97
Update the asset tag . . . . . . . . . . . 99
Chapter 5. Resolving installation
issues . . . . . . . . . . . . . . . . . 103
Appendix A. Getting help and
technical assistance . . . . . . . . . . 107
Before you call . . . . . . . . . . . . . . . 107
Collecting service data . . . . . . . . . . . . 108
Contacting Support . . . . . . . . . . . . . 109
Appendix B. Trademarks . . . . . . . 111
Index . . . . . . . . . . . . . . . . . . 113
© Copyright Lenovo 2017, 2020 i

ii ThinkSystem SR550 Setup Guide

Chapter 1. Introduction
The ThinkSystem™ SR550 is a 2U all-purpose rack server with two processor sockets that com ines
performance, flexi ility, expanda ility, and managea ility into a package. The enterprise-quality design
delivers the flexi ility and scala ility needed for the varied demands of 2U rack deployments for workloads in
small-to-medium sized usinesses and remote or ranch offices. This server can tackle infrastructure,
colla oration, cold storage, and line-of- usiness applications, as well as hosting.
The server comes with a limited warranty. For details a out the warranty, see:
https://support.lenovo.com/us/en/solutions/ht503310
For details a out your specific warranty, see:
http://datacentersupport.lenovo.com/warrantylookup
Identifying your server
When you contact Lenovo for help, the machine type and serial num er information helps support
technicians to identify your server and provide faster service.
The machine type and serial num er are on the ID la el on the right rack latch in the front of the server.
Figure 1. Location of the ID label
© Copyright Lenovo 2017, 2020 1

XClarity Controller network access label
The XClarity® Controller network access la el is attached on the top side of the pull-out information ta . After
you get the server, peel the XClarity Controller network access la el away and store it in a safe place.
Figure 2. Location of the XClarity Controller network access label
Quick response code
The system service la el, which is on the top cover, provides a quick response (QR) code for mo ile access
to service information. Scan the QR code with a mo ile device and a QR code reader application to get quick
access to the Lenovo Service we site for this server. The Lenovo Service Information We site provides
additional information for parts installation and replacement videos, and error codes for server support.
The following illustration shows the QR code: https://support.lenovo.com/p/servers/sr550
Figure 3. QR co e
Server package contents
When you receive your server, verify that the shipment contains everything that you expected to receive.
The server package includes the following items:
2ThinkSystem SR550 Setup Guide

Note: Items marked with asterisk (*) are availa le on some models only.
• 1 Server
• 2 Rail kit*. Detailed instructions for installing the rail kit are provided in the package with the rail kit.
• 3 Ca le management arm*
• 4 Material ox, including items such as accessory kit, power cords* and documentation
Features
Performance, ease of use, relia ility, and expansion capa ilities were key considerations in the design of
your server. These design features make it possi le for you to customize the system hardware to meet your
needs today and provide flexi le expansion capa ilities for the future.
Your server implements the following features and technologies:
• enovo XClarity Controller (XCC)
The Lenovo XClarity Controller is the common management controller for Lenovo ThinkSystem server
hardware. The Lenovo XClarity Controller consolidates multiple management functions in a single chip on
the server system oard.
Some of the features that are unique to the Lenovo XClarity Controller are enhanced performance, higher-
resolution remote video, and expanded security options. For additional information a out the Lenovo
XClarity Controller, see:
http://sysmgt.lenovofiles.com/help/topic/com.lenovo.systems.management.xcc.doc/product_page.html
• UEFI-compliant server firmware
Chapter 1.Introduction 3

Lenovo ThinkSystem firmware is Unified Extensi le Firmware Interface (UEFI) 2.5 compliant. UEFI
replaces BIOS and defines a standard interface etween the operating system, platform firmware, and
external devices.
Lenovo ThinkSystem servers are capa le of ooting UEFI-compliant operating systems, BIOS- ased
operating systems, and BIOS- ased adapters as well as UEFI-compliant adapters.
Note: The server does not support DOS (Disk Operating System).
• arge system-memory capacity
The server supports registered dual-inline memory modules (RDIMMs) and load-reduced DIMMs
(LRDIMMs) with error correcting code (ECC). The server supports up to a maximum system memory of
384 GB (using RDIMMs) or 768 GB (using LRDIMMs). For more information, see “Specifications” on page
5.
• Integrated Trusted Platform Module (TPM)
This integrated security chip performs cryptographic functions and stores private and pu lic secure keys.
It provides the hardware support for the Trusted Computing Group (TCG) specification. You can
download the software to support the TCG specification.
Trusted Platform Module (TPM) has two versions - TPM 1.2 and TPM 2.0. You can change the TPM
version from 1.2 to 2.0 and ack again.
For more information on TPM configurations, see “Ena le TPM/TCM” in the Maintenance Manual.
Note: For customers in Chinese Mainland, a Lenovo-qualified TPM 2.0 adapter or a Trusted
Cryptographic Module (TCM) adapter (sometimes called a daughter card) may e pre-installed.
• arge data-storage capacity and hot-swap capability
The hot-swap server models support up to twelve 3.5-inch hot-swap SAS/SATA drives or sixteen 2.5-inch
hot-swap SAS/SATA drives. The simple-swap server models support a maximum of eight 3.5-inch simple-
swap SATA drives.
With the hot-swap feature, you can add, remove, or replace hard disk drives without turning off the server.
• Mobile access to enovo Service Information website
The server provides a QR code on the system service la el, which is on the cover of the server, that you
can scan using a QR code reader and scanner with a mo ile device to get quick access to the Lenovo
Service Information we site. The Lenovo Service Information we site provides additional information for
parts installation, replacement videos, and error codes for server support.
• Redundant networking connection
The Lenovo XClarity Controller provides failover capa ility to a redundant Ethernet connection with the
applica le application installed. If a pro lem occurs with the primary Ethernet connection, all Ethernet
traffic that is associated with the primary connection is automatically switched to the optional redundant
Ethernet connection. If the applica le device drivers are installed, this switching occurs without data loss
and without user intervention.
• Redundant cooling and optional power capabilities
The server supports a maximum of two 550-watt or 750-watt hot-swap power supplies and four non hot-
swap fans, which provide redundancy for a typical configuration. The redundant cooling y the fans in the
server ena les continued operation if one of the fans fails.
Note: You cannot mix 550-watt and 750-watt power supplies in the server.
4ThinkSystem SR550 Setup Guide

Specifications
The following information is a summary of the features and specifications of the server. Depending on the
model, some features might not e availa le, or some specifications might not apply.
Table 1. Server specifications
Specification Description
Size • 2U
• Height: 86.5 mm (3.4 inches)
• Width:
– With rack latches: 482.0 mm (19.0 inches)
– Without rack latches: 444.6 mm (17.5 inches)
• Depth with rack latches: 763.7 mm (30.1 inches)
Note: The depth is measured with rack latches installed, ut without the security
ezel installed.
Weight Up to 26.0 kg (57.3 l )
Processor (depending on the
model) • Up to two Intel® Xeon® Scala le Processors
– Scala le up to 20 cores
– Designed for Land Grid Array (LGA) 3647 socket
– Multi-chip package processor architecture
For a list of supported processors, see:
http://www.lenovo.com/us/en/serverproven/
Notes:
• For server models with twelve 3.5-inch drive ays, Intel Xeon 6230T processor is
not supported.
• If you are going to install Intel Xeon 6230N, 6230T, or 5220T processor, use the
heat sink with part num er 01KP652 or 01KP653.
Chapter 1.Introduction 5

Table 1. Server specifications (continue )
Specification Description
Memory For 1st Generation Intel Xeon Scala le Processor (SP Gen 1):
• Minimum: 8 GB
• Maximum:
– 384 GB using registered DIMMs (RDIMMs)
– 768 GB using load-reduced DIMMs (LRDIMMs)
• Type (depending on the model):
– TruDDR4 2666, single-rank or dual-rank, 8 GB/16 GB/32 GB RDIMMs
– TruDDR4 2666, quad-rank, 64 GB LRDIMMs
• Slots: 12 slots
For 2nd Generation Intel Xeon Scala le Processor (SP Gen 2):
• Minimum: 8 GB
• Maximum: 768 GB
• Type (depending on the model):
– TruDDR4 2666, single-rank or dual-rank, 16 GB/32 GB RDIMMs
– TruDDR4 2933, single-rank or dual-rank, 8 GB/16 GB/32 GB/64 GB RDIMMs
• Slots: 12 slots
For a list of supported memory modules, see:
http://www.lenovo.com/us/en/serverproven/
Operating systems
Supported and certified operating systems:
• Microsoft Windows Server
• VMware ESXi
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
For a complete list of operating systems, see:
https://lenovopress.com/osig
For OS deployment instructions, see: “Deploy the operating system” on page 96.
Internal drives • Up to eight 3.5-inch simple-swap SATA drives
• Up to twelve 3.5-inch hot-swap SAS/SATA drives
• Up to sixteen 2.5-inch hot-swap SAS/SATA drives
• Up to two internal M.2 drives
PCI Express (PCIe) slots • One PCIe slot on system oard
• Three PCIe slots on the riser 1 adapter
• Two PCIe slots on the riser 2 adapter
For detailed information, see “Rear view” on page 22.
6ThinkSystem SR550 Setup Guide

Table 1. Server specifications (continue )
Specification Description
Input/Output (I/O) features • Front panel:
– One XClarity Controller USB connector
– One USB 3.0 connector
– One VGA connector (availa le on some models)
• Rear panel:
– One VGA connector
– Two USB 3.0 connectors
– One XClarity Controller network connector
– Two Ethernet connectors
– Two Ethernet connectors on the LOM adapter (availa le on some models)
RAID adapters (depending on
the model) • A RAID 530-8i SAS/SATA adapter that supports JBOD mode and RAID levels 0, 1,
5, 10, and 50
• A RAID 730-8i 1G Cache SAS/SATA adapter that supports JBOD mode and RAID
levels 0, 1, 5, 10, and 50
• A RAID 730-8i 2G Flash SAS/SATA adapter that supports JBOD mode and RAID
levels 0, 1, 5, 6, 10, 50, and 60
• A RAID 930-8i or 930-16i SAS/SATA adapter that supports JBOD mode and RAID
levels 0, 1, 5, 6, 10, 50, and 60
• A RAID 930-8e SAS/SATA adapter that supports JBOD mode and RAID levels 0,
1, 5, 6, 10, 50, and 60
Notes:
• RAID 730-8i 1G Cache SAS/SATA adapter is not availa le for North America.
• RAID 530-8i SAS/SATA adapter cannot e mixed with RAID 730-8i 1G Cache
SAS/SATA adapter.
• RAID 730-8i 2G Flash SAS/SATA adapter cannot e mixed with RAID 730-8i 1G
Cache SAS/ SATA adapter or RAID 930-8i SAS/SATA adapter.
• A RAID super capacitor module must e installed if the RAID 730-8i 2G Flash SAS/
SATA adapter, RAID 930-8i or 930-16i SAS/SATA adapter, or RAID 930-8e SAS/
SATA adapter is installed.
Fans • One processor: three system fans (including one redundant fan)
• Two processors: four system fans (including one redundant fan)
Note: If your server comes with only one processor, three system fans (fan 1 to fan
3) are adequate to provide proper cooling. However, you must keep the locations for
fan 4 occupied y a fan filler to ensure proper airflow.
Power supplies One or two hot-swap power supplies for redundancy support
• 550-watt ac 80 PLUS Platinum
• 750-watt ac 80 PLUS Platinum
• 750-watt ac 80 PLUS Titanium
Chapter 1.Introduction 7

Table 1. Server specifications (continue )
Specification Description
Acoustical noise emissions • Sound power levels, idle
– 4.9 els, minimum
– 5.3 els, typical
– 6.1 els, maximum
• Sound power levels, operating
– 4.9 els, minimum
– 5.5 els, typical
– 6.2 els, maximum
Notes:
• These sound power levels are measured in controlled acoustical environments
according to procedures specified y ISO 7779 and are reported in accordance
with ISO 9296.
• The declared acoustic noise levels are ased on specified configurations and they
may change depending on configurations/conditions.
• The declared acoustic noise levels may increase greatly, if high-power
components are installed, for example, some high-power NICs, CPUs, and GPUs.
Minimal configuration for
de ugging • One processor in processor socket 1
• One DIMM in slot 3
• One power supply
• Three system fans (fan 1 to fan 3)
8ThinkSystem SR550 Setup Guide

Table 1. Server specifications (continue )
Specification Description
Electrical input • Sine-wave input (50–60 Hz) required
• 550-watt ac and 750-watt ac Platinum input voltage range:
– Low range: 100–127 V ac
– High range: 200–240 V ac
• 750-watt ac Titanium input voltage range: 200–240 V ac
CAUTION:
1. 240 V dc input (input range: 180-300 V dc) is ON Y supported in Chinese
Mainland.
2. Power supplies with 240 V dc are not hot-swappable. To remove the power
cord, ensure you have turned off the server or disconnected the dc power
sources at the breaker panel.
3. In order for the ThinkSystem products to operate error free in both a DC or
AC electrical environment, a TN-S earthing system which complies to
60364-1 IEC 2005 standard has to be present or installed.
Environment ASHRAE (American Society of Heating, Refrigerating and Air-Conditioning
Engineers).
Note: This server is designed for standard data center environment and
recommended to e placed in industrial data center.
• Air temperature:
– Operating:
– ASHRAE class A2: 10–35°C (50–95°F); when the altitude exceeds 900 m
(2953 ft), the maximum am ient temperature value decreases y 1°C (1.8°F)
with every 300 m (984 ft) of altitude increase.
– ASHRAE class A3: 5–40°C (41–104°F); when the altitude exceeds 900 m
(2953 ft), the maximum am ient temperature value decreases y 1°C (1.8°F)
with every 175 m (574 ft) of altitude increase.
– ASHRAE class A4: 5–45°C (41–113°F); when the altitude exceeds 900 m
(2953 ft), the maximum am ient temperature value decreases y 1°C (1.8°F)
with every 125 m (410 ft) of altitude increase.
– Server off: 5–45°C (41–113°F)
– Shipping or storage: -40–60°C (-40–140°F)
• Maximum altitude: 3050 m (10 000 ft)
• Relative humidity (non-condensing):
– Operating:
– ASHRAE class A2: 8%–80%; maximum dew point: 21°C (70°F)
– ASHRAE class A3: 8%–85%; maximum dew point: 24°C (75°F)
– ASHRAE class A4: 8%–90%; maximum dew point: 24°C (75°F)
– Shipping or storage: 8%–90%
• Particulate contamination
Attention: Air orne particulates and reactive gases acting alone or in
com ination with other environmental factors such as humidity or temperature
might pose a risk to the server.
Chapter 1.Introduction 9

Table 1. Server specifications (continue )
Specification Description
Notes: Your server complies with ASHRAE class A2 specifications. The server
performance might e impacted when the operating temperature is outside the
ASHRAE A2 specifications. Depending on the hardware configuration, some server
models comply with ASHRAE class A3 and class A4 specifications. To comply with
ASHRAE class A3 and class A4 specifications, the server models must meet the
following hardware configuration requirements at the same time:
• Two power supplies must e installed.
• No system fan fails.
Important information about EU ecodesign requirements
To meet the EU ecodesign requirements for energy-related products (ErP) Lot 9, your server must meet the
following requirements:
• Minimum memory: 16 GB
• If your server is configured with one processor, these processors are not supported: Intel Xeon 3104,
3106, 3204, 4108, 4109T, 4110, 4112, 5122, 5222, 8156, and 8256.
Particulate contamination
Attention: Air orne particulates (including metal flakes or particles) and reactive gases acting alone or in
com ination with other environmental factors such as humidity or temperature might pose a risk to the
device that is descri ed in this document.
Risks that are posed y the presence of excessive particulate levels or concentrations of harmful gases
include damage that might cause the device to malfunction or cease functioning altogether. This
specification sets forth limits for particulates and gases that are intended to avoid such damage. The limits
must not e viewed or used as definitive limits, ecause numerous other factors, such as temperature or
moisture content of the air, can influence the impact of particulates or environmental corrosives and gaseous
contaminant transfer. In the a sence of specific limits that are set forth in this document, you must
implement practices that maintain particulate and gas levels that are consistent with the protection of human
health and safety. If Lenovo determines that the levels of particulates or gases in your environment have
caused damage to the device, Lenovo may condition provision of repair or replacement of devices or parts
on implementation of appropriate remedial measures to mitigate such environmental contamination.
Implementation of such remedial measures is a customer responsi ility.
10 ThinkSystem SR550 Setup Guide

Table 2. Limits for particulates an gases
Contaminant imits
Gaseous Severity level G1 as per ANSI/ISA 71.04-19851, which states that the reactivity rate of copper
coupons shall e less than 300 Angstroms per month (Å/month, ≈ 0.0039 μg/cm2-hour weight
gain).2 In addition, the reactivity rate of silver coupons shall e less than 200Å/month (≈ 0.0035
μg/cm2-hour weight gain).3 The reactive monitoring of gaseous corrosivity must e conducted
approximately 5 cm (2 in.) in front of the rack on the air inlet side at one-quarter and three-quarter
frame height off the floor or where the air velocity is much higher.
Particulate Data centers must meet the cleanliness level of ISO 14644-1 class 8. For data centers without
airside economizer, the ISO 14644-1 class 8 cleanliness might e met y choosing one of the
following filtration methods:
• The room air might e continuously filtered with MERV 8 filters.
• Air entering a data center might e filtered with MERV 11 or prefera ly MERV 13 filters.
For data centers with airside economizers, the choice of filters to achieve ISO class 8 cleanliness
depends on the specific conditions present at that data center.
The deliquescent relative humidity of the particulate contamination should e more than 60%
RH.4
Data centers must e free of zinc whiskers.5
1 ANSI/ISA-71.04-1985. Environmental con itions for process measurement an control systems: Airborne
contaminants. Instrument Society of America, Research Triangle Park, North Carolina, U.S.A.
2 The derivation of the equivalence etween the rate of copper corrosion growth in the thickness of the corrosion
product in Å/month and the rate of weight gain assumes that Cu2S and Cu2O grow in equal proportions.
3 The derivation of the equivalence etween the rate of silver corrosion growth in the thickness of the corrosion
product in Å/month and the rate of weight gain assumes that Ag2S is the only corrosion product.
4 The deliquescent relative humidity of particulate contamination is the relative humidity at which the dust a sor s
enough water to ecome wet and promote ionic conduction.
5 Surface de ris is randomly collected from 10 areas of the data center on a 1.5 cm diameter disk of sticky
electrically conductive tape on a metal stu . If examination of the sticky tape in a scanning electron microscope
reveals no zinc whiskers, the data center is considered free of zinc whiskers.
Management offerings
The XClarity portfolio and other system management offerings descri ed in this section are availa le to help
you manage the servers more conveniently and efficiently.
Chapter 1.Introduction 11

Overview
Offerings Description
Lenovo XClarity Controller
Base oard management controller.
Consolidates the service processor functionality, Super I/O, video controller, and
remote presence capa ilities into a single chip on the server system oard.
Interface
• CLI application
• GUI application
• Mo ile application
• We interface
• REST API
Usage and downloads
http://sysmgt.lenovofiles.com/help/topic/com.lenovo.systems.management.xcc.doc/
product_page.html
Lenovo XClarity Administrator
Centralized interface for multi-server management.
Interface
• GUI application
• Mo ile application
• We interface
• REST API
Usage and downloads
http://sysmgt.lenovofiles.com/help/topic/com.lenovo.lxca.doc/aug_product_page.html
Lenovo XClarity Essentials
toolset
Porta le and light toolset for server configuration, data collection, and firmware
updates. Suita le oth for single-server or multi-server management contexts.
Interface
• OneC I: CLI application
• Bootable Media Creator: CLI application, GUI application
• UpdateXpress: GUI application
Usage and downloads
http://sysmgt.lenovofiles.com/help/topic/xclarity_essentials/overview.html
Lenovo XClarity Provisioning
Manager
UEFI- ased GUI tool on a single server that can simplify management tasks.
Interface
• We interface (BMC remote access)
• GUI application
Usage and downloads
https://sysmgt.lenovofiles.com/help/topic/lxpm_frontend/lxpm_a out.html
12 ThinkSystem SR550 Setup Guide

Offerings Description
Lenovo XClarity Integrator
Series of applications that can integrate management features of Lenovo XClarity
Administrator and your server with software used in a certain deployment
infrastructure, such as VMware vCenter, Microsoft Admin Center, or Microsoft System
Center.
Interface
GUI application
Usage and downloads
https://sysmgt.lenovofiles.com/help/topic/lxci/lxci_product_page.html
Lenovo XClarity Energy
Manager
Application that can manage and monitor server power and temperature.
Interface
• GUI application
• We Interface
Usage and downloads
https://datacentersupport.lenovo.com/solutions/lnvo-lxem
Lenovo Capacity Planner
Application that supports power consumption planning for a server or rack.
Interface
• GUI application
• We Interface
Usage and downloads
https://datacentersupport.lenovo.com/solutions/lnvo-lcp
Functions
Offerings
Functions
Multi-
system
mgmt
OS
deploy-
ment
System
configu-
ration
Firm-
ware
up-
dates
Event-
s/alert
moni-
toring
Inven-
tory/
logs
Pow-
er
mgmt
Power
planning
Lenovo XClarity Controller √ √ √ √
Lenovo XClarity
Administrator √ √ √ √ √ √
Lenovo
XClarity
Essen-
tials
toolset
OneCLI √ √ √ √ √
Boota le Media
Creator √ √ √
UpdateXpress √ √
Lenovo XClarity Provisioning
Manager √ √ √ √
Lenovo XClarity Integrator √ √ √ √ √ √
Chapter 1.Introduction 13

Offerings
Functions
Multi-
system
mgmt
OS
deploy-
ment
System
configu-
ration
Firm-
ware
up-
dates
Event-
s/alert
moni-
toring
Inven-
tory/
logs
Pow-
er
mgmt
Power
planning
Lenovo XClarity Energy
Manager √ √ √
Lenovo Capacity Planner √
Notes:
1. Most options can e updated through the Lenovo tools. Some options, such as GPU firmware or Omni-
Path firmware, require the use of vendor tools.
2. Firmware updates are limited to Lenovo XClarity Provisioning Manager, BMC firmware, and UEFI
updates only. Firmware updates for optional devices, such as adapters, are not supported.
3. The server UEFI settings for option ROM must e set to UEFI to update firmware using Lenovo XClarity
Essentials Boota le Media Creator.
4. The server UEFI settings for option ROM must e set to UEFI for detailed adapter card information, such
as model name and firmware levels, to e displayed in Lenovo XClarity Administrator, Lenovo XClarity
Controller, or Lenovo XClarity Essentials OneCLI.
5. It’s highly recommended that you check the power summary data for your server using Lenovo Capacity
Planner efore purchasing any new parts.
14 ThinkSystem SR550 Setup Guide

Chapter 2. Server components
This topic provides information to help you locate the components of your server.
Front view
The front view of the server varies y model.
• “Front view of server models with 2.5-inch hot-swap drives” on page 15
• “Front view of server models with 3.5-inch hot-swap drives” on page 16
• “Front view of server models with 3.5-inch simple-swap drives” on page 18
Front view of server models with 2.5-inch hot-swap drives
The following illustrations show the front view of server models with eight and sixteen 2.5-inch hot-swap
drives.
Figure 4. Front view of server mo els with eight 2.5-inch hot-swap rives (0-7)
Figure 5. Front view of server mo els with sixteen 2.5-inch hot-swap rives (0-15)
Table 3. Components on the front of server mo els with 2.5-inch hot-swap rives
1 Rack latch (left) 2 2.5-inch hot-swap drive ays
3 Drive activity LED 4 Drive status LED
© Copyright Lenovo 2017, 2020 15

Table 3. Components on the front of server mo els with 2.5-inch hot-swap rives (continue )
5 Pull-out information ta 6 Front I/O assem ly
7 Rack latch (right) 8 VGA connector (optional)
1 7 Rack latches
If your server is installed in a rack, you can use the rack latches to help you slide the server out of the rack.
You also can use the rack latches and screws to secure the server in the rack so that the server cannot slide
out, especially in vi ration-prone areas. For more information, refer to the Rack Installation Gui e that comes
with your rail kit.
2 2.5-inch hot-swap drive bays
The num er of the installed drives in your server varies y model. When you install drives, follow the order of
the drive ay num ers.
The EMI integrity and cooling of the server are protected y having all drive ays occupied. The vacant drive
ays must e occupied y drive fillers.
3 Drive activity ED
4 Drive status ED
Each hot-swap drive has two LEDs.
Drive ED Status Description
Drive status LED Solid yellow The drive has an error.
Blinking yellow ( linking slowly, a out one
flash per second)
The drive is eing re uilt.
Blinking yellow ( linking rapidly, a out four
flashes per second)
The RAID adapter is locating the drive.
Drive activity LED Solid green The drive is powered ut not active.
Blinking green The drive is active.
5 Pull-out information tab
The Lenovo XClarity Controller network access la el of the server is attached on the pull-out information ta .
6 Front I/O assembly
For information a out the controls, connectors, and status LEDs on the front I/O assem ly, see “Front I/O
assem ly” on page 19.
8 VGA connector (optional)
Used to attach a high-performance monitor, a direct-drive monitor, or other devices that use a VGA
connector.
Front view of server models with 3.5-inch hot-swap drives
The following illustrations show the front view of server models with eight and twelve 3.5-inch hot-swap
drives.
16 ThinkSystem SR550 Setup Guide
