LEQISMART A5 User manual
USER MANUAL
ELECTRIC SCOOTER A5
Powered By LEQISMART
Contact Information:
Website: www.megawheels.com
Ocial website service: [email protected]
Amazon store service: [email protected]
eBay store service: [email protected]
Whatsapp: 008613760468813
Contents
Function................................................................1
Package Contents................................................. 1
Parameters............................................................ 2
Assembly............................................................... 2
Charger Connection.............................................. 3
How to Ride......................................................... 4
Fold..................................................................... 5
Unfold.................................................................... 5
LEQISMART APP.................................................. 6
Safety Precautions............................................... 7
Cleaning and Storage.......................................... 10
Tire Ination Maintenance................................... 10
Battery Maintenance........................................... 10
Environmental Protection.................................... 11
Limited Warranty Statement................................ 12
Warranty Content................................................ 13
Question & Answer.............................................. 14
Contact US..................................................14
1
Function
Brake Handle
Fixed Button
Folding Hook
Accelerator
Fold Handle
Function mode: Cruise mode, pedestrian mode, fault prompt,
light, Bluetooth, Lock.
Gear mode: The maximum speed is 6 km/h for L gear, 15 km/h
for M gear and 25 km/h for H gear.
Speedometer: Displays the current speed; displays the
remaining mileage within 6 seconds after power-on.
Battery level: Displays the remaining battery power; it displays
in red and ashing when the power is about 10%.
Power switch: Press it to turn on, press and hold for 3 seconds
to shut down; in power-on state, press once to turn on/o the
light, and press twice consecutively to switch gears.
Charging Port
Ambient Lamp
Motor Unit
Front Tube
Power Adapter
Hexagon
wrench ScrewUser’s ManualScooter
Package Contents
2
Parameters
Model A5
Net weight Approx 14 KG
Expanded size 112.4×44×121.5 CM
Applicable age 10+
Applicable height 130~200 CM
Maximum load 120 KG(265 LB)
Maximum speed 25 KM/H(15.5MPH)
Distance per charge Max 30 KM(18.6Miles)
Gradeability About 15%
Protection grade IPX5
Charging time About 4H
Battery capacity 7800mAh
Voltage 36V
Motor 350W
BMS management Over-charge, Over-temperature, Over-discharge,
Over-current, Short circuit, Over-voltage
Brake system Manual disc brake + Electronic brake
Connection method Bluetooth
Tire size 9 inch puncture-proof tubeless tyres
Assembly
1. Pull the folding handle upwards until there is a click sound,
and pull the folding handle to conrm whether it is locked.
2. Manually connect the xing seat and the data cable in the
front tube, and check whether it is turned on normally.
3. Insert the xing seat into the front tube, and use a hexagon
wrench to tighten the six screws.
23
1
3
Attention:
1. Only use the original power adapter when charging.
2. Keep away from children and animals when charging, and keep away from
ammable materials.
3. Do not charge or use the battery if it emits a peculiar smell, overheats or leaks.
4. Do not open the battery pack or insert anything into the charging port as the
battery contains dangerous substances.
5. If it won’t be used for a long time, please fully charge it rst, store in a cool and
dry place, and fully charge it every 30 days.
Charger Connection
1. Connect the charger to the power supply, and the indicator
light of the charger turns green.
2. Insert the charging plug, and the indicator light turns from
green to red.
3. After charging, the indicator light turns from red to green.
Lift up the rubber ap Plug the power adapter
into the charging port
Put back the rubber ap.
4
How to Ride
1. Press the power button to
turn on the scooter and check
the battery level. If the battery
level is too low, please charge
it in time.
3. During the sliding, keep your
balance, place the other foot
on the pedal and lightly press
the shifter to move forward.
2. Stand with your right foot
on the pedal and thrust
against the ground with your
left foot. When the speed of
the scooter is ≥ 4 km/h, press
the accelerator to start the
motor,and keep speeding.
4. When steering or decelerating,
release the shifter and use the
brake lever to brake.
5
Fold
1. Press the red safety lock in the folding handle, open the
folding handle and lower the front tube.
2. Press the folding hook to buckle the hook xing buckle, and
pull the front tube to conrm whether it is stable.
Unfold
1. Press the fold hook buckle and take it out from the hook xing
buckle.
2. Straighten the front tube, close the folding handle, and press
the folding handle to check whether it is locked.
12
12
6
LEQISMART APP
Scan the QR code below with your mobile phone or search for
"LEQISMART" in the APP market, download and install the APP.
If the APP has already been downloaded on your mobile phone, please
upgrade the APP to the lastest.
STEP 1
Press the button to turn on the scooter and turn on the Bluetooth function
of the mobile phone.
STEP 2
Open the LEQISMART APP. For the rst use, please register/log in to your
account according to the APP guide.
APP
STEP 3
Enter on APP homepage, select “Search for binding”.The APP will scan the
scooter to be congured with “Megawheels” and add the device according
to the prompt in the APP interface.
7
Safety Precautions
1. Please carefully read the User Manual, which will assist in explaining
the basic working principles and provide tips on how to best enjoy your
scooter experience.
2. Please wear all appropriate safety and protective gear as previously
mentioned in the User Manual before operating the scooter.
3. Obligation to always wear shoes, Make sure to wear comfortable clothes.
4. Do not use any accessories or additional items not approved by the
manufacturer with the scooter. Do not try to open or modify your scooter,
as doing so will void your manufacturer warranty, and may cause failure
to your device leading to serious bodily injury or death.
5. WARNING! Keep plastic covering away from children to avoid
suocation.
6. Do not operate the scooter while under the inuence of drugs and/or alcohol.
7. Do not operate the scooter when you are restless or sleepy.
8. Use your best judgment to keep yourself out of dangerous situations
with your scooter.
9. The scooters have a range of about 30 km and a maximum speed of 25 km/h.
10. Do not turn sharply, especially at high speeds.
11. Do not abuse your scooter, doing so can damage your unit and cause
failure to the operating system leading to injury.
12. Do not drive in or near puddles of water, mud, sand, stones, gravel,
debris or near rough and rugged terrain.
13. The scooter can be used on paved roads that are at and even. If
you encounter uneven pavement, please lift your scooter over and past
the obstruction.
14. Do not ride in inclement weather: snow, rain, hail, sleek, on icy roads or in
extreme heat.
15. Do not ride in or near pools or other large bodies of water.
16. Trac in the city has many obstacles to cross such as curbs or steps.
It is recommended to avoid obstacle jumps. It is important to anticipate
and adapt your trajectory and speed to those of a pedestrian before
crossing these obstacles. It is also recommended to get out of the vehicle
when these obstacles become dangerous due to their shape, height or
slippage.
17. Do not attempt to ride over bumps or objects greater than 1.5 cm
even when prepared and bending your knees.
18. PAY ATTENTION - look at where you are riding and be watchful /
attentative of the road conditions, people, places, property and objects
around you.
19. Do not operate the scooter in crowded areas.
20. Operate your scooter with extreme caution when indoors, especially
8
around people, property, and narrow spaces like doorways and other
narrow spaces.
21. Other recommendations such as: special precautions for use at dark; not
to touch the brake disc.
22. Do not operate the scooter while talking, texting, or looking at your phone.
23. Do not ride your scooter where it is not permitted.
24. Do not ride your scooter near motor vehicles or on public roads.
25. Do not climb or travel down steep hills with your scooter.
26. The scooter is intended for use by a single individual, Do not attempt
to operate
the scooter with two or more people.
27. A statement that any load attached to the handlebar will aect the
stability of the vehicle. Do not carry anything while riding the scooter.
28. People who lack balance should not attempt to operate a scooter.
29. Women who are pregnant or are preparing for pregnancy should not operate
the scooter.
30. Young children and the elderly should not operate the scooter without
proper instruction and supervision from a Certied scooter trainer.
31. At higher speeds, always take into consideration longer stopping
distances.
32. Do not step forward of your scooter.
33. Do not attempt to jump on or o your scooter.
34. Do not attempt any stunts or tricks with your scooter.
35. Do not ride the scooter in dark or poorly lit areas.
36. Do not ride the scooter near or over potholes, cracks or uneven
pavement.
37. Do not operate your scooter o-road.
38. Do not exceed the maximum weight limit of 100 kg.
39. Avoid driving the scooter in unsafe places, including near areas with
ammable gas, steam, liquid, dust, ber, which could cause re and
explosion accidents.
40. Scooter users are recommended to be 10+ age and 130 to 200 cm tall.
41. In any case, anticipate your trajectory and your speed while
respecting the code
of the road, the code of the sidewalk and the most vulnerable.
42. Notify your presence when approaching a pedestrian or cyclist when you
are not seen or heard.
43. Cross the protected passages while walking.
44. In all cases, take care of yourself and others.
45. Do not divert the use of the vehicle.
46. This vehicle is not intended for acrobatic use.
47. Caution, the brake may become hot in use. Do not touch after use.
48. Warning aiming to draw the user's attention to any damages related
to intensive use and to recommend periodic inspections of the frame, fork
9
and suspension attachments (if any).
49. Regularly check the tightening of the various bolted elements, in
particular the wheel axles, the folding system, the steering system and
the brake shaft.
50. Do not modify or transform the vehicle, including the steering tube
and sleeve, stem, folding mechanism and rear brake.
51. For pneumatic tires, the recommended maximum tire pressure is 45-
50 psi.
52. WARNING! As with any mechanical component, a vehicle is subject
to high stresses and wear. The various materials and components may
react dierently to wear or fatigue. If the expected service life for a
component has been exceeded, it may break suddenly, therefore risking
causing injuries to the user. Cracks, scratches and discoloration in the
areas subject to high stresses indicate that the component has exceeded
its service life and should be replaced.
53. List regarding the maintenance that can be performed by the user
himself;Instructions for routine inspection, maintenance, cleaning and/or
cleaning.
54. Instructions covering all functions of the vehicle, especially driving
power assistance start mode (e.g. pushing the vehicle by more than 4
km/h and activating the power assistance mode).
55. Do not place the scooter in a high temperature higher than 50℃
or a low temperature lower than -20℃(for example, do not put the
scooter in a car exposed to the sun in summer). Do not put the scooter
into a re, otherwise it may lead to battery failure, overheating, and even
re risk.
56.Environmental conditions (e.g. outdoor or indoor charging);
requirement to power o the vehicle during charging, or into a certain
non-operational mode.
57. When not in use for more than 30 days, fully charge, store in a cool,
dry place,and fully charge every 30 days.
58. The equipment contains a radio transmitting module with type
approval code CMIIT ID: 2020DP3421; Do not use wireless devices in
places where the use of wireless devices is prohibited. Otherwise, it may
interfere with other electronic devices or cause other risks.
59. Take the time to learn the basics of the practice to avoid any serious
accident that can take place in the rst months.
60. An instruction to keep the printed instructions for further reference
and to be read carefully before use.
10
Cleaning and Storage
If there are stains on the surface of the scooter, use a soft cloth
to dip in a small amount of water to wipe; If there are stains that
are difficult to clean, smear them with toothpaste and brush
them repeatedly, then clean them with a damp cloth. If the
plastic parts of the body are scratched, use sandpaper or other
abrasive materials to polish them.
Attention:
Do not use alcohol, gasoline, kerosene or other corrosive and
volatile chemical solvents to clean, otherwise it will seriously
damage the appearance and internal structure of the car body.
It is forbidden to use pressure water gun to spray and wash.
Ensure that the scooter is o and the charging port rubber cover
is tightly fastened during cleaning, otherwise electric shock or
serious failure may occur due to internal water inflow. When
not in use, store in a dry and cool place indoors. Avoid outdoor
storage for a long time. Long-term sun exposure, overheating
and cold outdoor environment will accelerate the appearance
and tire aging of the scooter, and reduce the service life of the
scooter and battery pack.
Tire Ination Maintenance
This product tire is a vacuum tire, when the tire height sinks
20%-30%, needs to inate. The recommended tire pressure is
45-50 psi after ination, and the tire should be inated at least
once every 2-3 months. Regular ination and cleaning of tire
surface debris can prolong the service life of the tire.
Battery Maintenance
● Do not use battery packs of other models or brands, or else
there may be safety risks.
It is strictly forbidden to disassemble, squeeze, or puncture
this product; it is forbidden to throw this product into water, re
(including heat sources such as stove, heater, etc.) or expose it
to an environment with a temperature higher than 50°C.
● Water entering the battery may cause damage to the internal
circuit, and there is a risk of fire or even explosion; if the
11
battery is suspected of water entering, please stop using it
immediately and contact the after-sales service.
● Do not touch the battery contacts, disassemble or puncture
the case. Avoid metal objects contacting the battery contacts,
or else it may cause short circuits, damage to the battery or
personal injury or death.
● Avoid recharging after the battery is completely depleted,
and try to charge as soon as possible, so as to prolong the
service life of the battery.
● Only use the original power adapter when charging, or else
there is a danger of damage or re.
● Please fully charge the battery before storing it after each
use, which will help to extend the battery life.
● Do not place the scooter in an environment above 50°C
or below -20°C (for example: in a car exposed to the sun in
summer). It is forbidden to throw the scooter into a re, or else
it may cause the battery to fail, overheat, and even cause a re.
● When used at normal temperature, the battery pack
can exert a higher range and performance; if used in an
environment below 0°C, the battery life and performance will
decrease. For details, please refer to the remaining mileage
display in the APP.
● If it won’t be used for a long time, please fully charge it rst,
store in a cool and dry place, and fully charge it every 30 days,
or else the battery may be damaged and such damage is not
covered by the warranty.
● Improper disposal of used batteries may seriously pollute the
environment. Please abide by local regulations when disposing
of the battery pack. Do not throw away the battery pack in
order to protect the natural environment.
Environmental Protection
This product contains battery or recyclable electronic waste,
and the built-in rechargeable battery contains substances that
may pollute the environment. When disposing of the product,
please do not pile it with general household waste, but hand it
to the electronic waste collection point designated by the state,
which is benecial to environmental protection.
12
Limited Warranty Statement
30 DAY SATISFACTION GUARANTEED RETURN
POLICY
If you are unsatisfied with your purchase, MEGAWHEELS
return policy allows you to return the product purchased on the
Authorization channel within 30 days counting from the date of
receipt of shipment, and request a refund from the Authorization
channel for any reason. NOTE: Express shipping cost is non-
refundable.
For the return request, MEGAWHEELS is not responsible for
lost packages due to the carrier, or products received that
cannot be verified. Received products that have damage
determined to have been caused by the end-user may be
subject to denial of the return request.
TO QUALIFY FOR A REFUND, ALL THE
FOLLOWING CONDITIONS MUST BE MET:
1. A Return Merchandise Authorization (RMA) must be
requested from MEGAWHEELS within 30 days from the
date of receipt of shipment. To request an RMA, contact
MEGAWHEELS Service:
2. The cost of return shipping will be borne by the customer.
3. For warranty service, please keep your receipt and/or invoice
to validate proof of purchase.
4. Returned product must be in good physical condition (not
physically broken or damaged).
5. All accessories originally included with your purchase must
be included with your return.
6. If you return a product to MEGAWHEELS (a) without an RMA
from MEGAWHEELS(b) without all parts included in the original
package, MEGAWHEELS retains the right to refuse delivery of
such return.
13
Type Parts Times
Main parts
Frame body, motor components, controllers, handles,
meters, handle mounts, front tubes, brake discs, disc
brake components, front fork components
12 Months
Attachment Battery body, charger, throttle dial, brake lever, folding
hook, front wheel, Brake cable, connecting cable, foot
support group
6 Months
Wearing
parts
Cover, front and rear lights, front and rear fenders,
silicone pad, atmosphere lamp, rubber plug, instrument
cover, reflective strip, frame bottom cover, charging
seat, hook xing seat
3 Months
HOW TO OBTAIN WARRANTY SERVICE
A Warranty Service Order must be requested from
MEGAWHEELS within Warranty Period from the date of receipt
of shipment. To request a Warranty Service Order, contact
MEGAWHEELS:
To obtain warranty service, you must deliver the product,
in either its original packaging or packaging providing
an equal degree of protection, to the address specified
by MEGAWHEELS. In accordance with applicable law,
MEGAWHEELS may require the customer to furnish proof of
purchase details and/or comply with registration requirements
before receiving warranty service.period or thirty (30) days,
whichever is longer, or for any additional period of time that may
be applicable in your jurisdiction.
Warranty Content
Question & Answer
1. What if the E-Scooter arrived missing accessory or broken
part?
A: Please take a photo and send it to MEGAWHEELS Support
Team by sending an email: [email protected]
And MEGAWHEELS Support Team will reply to you soon and
send the correct accessory or part replacement.
2.Is that possible to replace some components for example the
tire?
A: Yes, please take a photo and send it to MEGAWHEELS
Support Team by sending an email: [email protected]
And MEGAWHEELS Support Team will reply to you soon.
3. Is there an Android/iOS APP? If so, what does it do?
A: Yes, the APP is LEQISMART APP. The APP can be
installed by scanning the QR code in the manual or searching
"LEQISMART" in the Google Play. Simply pair Megawheels
scooter via Bluetooth and use the app to view current speed,
remaining miles, and other real-time riding statistics.
Contact US
Contact us if you experience issues relating to riding,
maintenance and safety, or errors/faults with your electric
scooters.
E-mail Service: [email protected]
@Megawheels.com Megawheels
www.megawheels.com
Contact Information:
Website: www.megawheels.com
Ocial website service: [email protected]
Amazon store service: [email protected]
eBay store service: [email protected]
Whatsapp: 008613760468813
Other manuals for A5
1
Table of contents
Other LEQISMART Scooter manuals
