LEQISMART A5 User manual

USER MANUAL
LEQISMART ELECTRIC SCOOTER A5
Wear personal Protective equipment
EN17128:2020(Class 2)

1
Package Contents
Power Adapter T-shape Allen Key Screw
User Manual

2
Function
Brake Handle
Fixed Button
Folding Hook
Accelerator
Fold Handle
Function mode: Cruise mode, pedestrian mode, fault prompt,
light, Bluetooth, Lock.
Gear mode: The maximum speed is 6Km/h for L gear, 15Km/h
for M gear and 25Km/h for H gear.
Speedometer: Displays the current speed; displays the
remaining mileage within 6 seconds after power-on.
Battery level: Displays the remaining battery power; it displays
in red and ashing when the power is about 10%.
Power switch: Press it to turn on, press and hold for 3 seconds
to shut down; in power-on state, press once to turn on/off the
light, and press twice consecutively to switch gears; in power-
o󰀨 state.
Charging port
Ambient lamp
Motor unit
Front Tube

3
Parameters
Model A5
Net weight 14 kg
Expanded size 112.4×44×121.5 cm
Applicable age 14~60 years
Applicable height 130~200 cm
Maximum load 100 kg
Maximum speed 25 km/h
Distance per charge About 25 km
Gradeability About 15%
Protection grade IP65
Charging time About 5.5 hours
BMS management Over-charge, over-temperature, over-discharge,
over-current, short circuit, over-voltage
Brake system Manual disc brake + electronic brake
Connection method Bluetooth
Tire size 9 inch tubeless tire
Assembly
1. Pull the folding handle upwards until there is a click sound,
and pull the folding handle to conrm whether it is locked.
2. Manually connect the fixing seat and the data cable in the
front tube, and check whether it is turned on normally.
3. Insert the xing seat into the front tube, and use a hexagon
wrench to tighten the six screws.
2 3
1

4
Attention:
●Only use the original power adapter when charging.
●Keep away from children and animals when charging, and keep away from
ammable materials.
●Do not charge or use the battery if it emits a peculiar smell, overheats or leaks.
●Do not open the battery pack or insert anything into the charging port as the
battery contains dangerous substances.
●If it won’t be used for a long time, please fully charge it rst, store in a cool and
dry place, and fully charge it every 30 days.
Charger Connection
1. Connect the charger to the power supply, and the indicator
light of the charger turns green.
2. Insert the charging plug, and the indicator light turns from
green to red.
3. After charging, the indicator light turns from red to green.
Lift up the rubber ap Plug the power adapter
into the charging port
Put back the rubber ap.

5
How to ride Scooter
1. Press the power button
to turn on the scooter and
check the battery level. If
the battery level is too low,
please charge it in time.
3. During the sliding, keep
your balance, place the
other foot on the pedal and
lightly press the shifter to
move forward.
2. Stand with your right foot
on the pedal and thrust
against the ground with your
left foot. When the speed of
the scooter is ≥ 4 km/h, start
the motor.
4. When steering or
decelerating, release the
shifter and use the brake
lever to brake.

6
Fold
1. Press the red safety lock in the folding handle, open the
folding handle and lower the front tube;
2. Press the folding hook to buckle the hook xing buckle, and
pull the front tube to conrm whether it is stable.
Unfold
1. Press the fold hook buckle and take it out from the hook xing
buckle;
2. Straighten the front tube, close the folding handle, and press
the folding handle to check whether it is locked.
12
1 2

7
LEQISMART APP
Scan the QR code below with your mobile phone or search for
"LEQISMART" in the APP market, download and install the APP.
If the APP has already been downloaded on your mobile phone, please
upgrade the APP to the lastest.
STEP 1
Press the button to turn on the scooter and turn on the Bluetooth function
of the mobile phone.
STEP 2
Open the LEQISMART APP. For the rst use, please register/log in to your
account according to the APP guide.
APP
STEP 3
Enter on APP homepage, select “Search the binding”.The APP will scan
the scooter to be congured and add the device according to the prompt in
the APP interface.

8
Safety Precautions
1. Please carefully read the User Manual, which will assist in explaining the basic
working principles and provide tips on how to best enjoy your scooter experience.
2. Please wear all appropriate safety and protective gear as previously mentioned in
the User Manual before operating the scooter.
3. Obligation to always wear shoes, Make sure to wear comfortable clothes.
4. A statement that accessories and any additional items which are not approved by
the manufacturer shall not be used. Do not try to open or modify your scooter, as
doing so will vlid your manufacturer warranty, and may cause failure to your device
leading to serious bodily injury or death.
5. WARNING! Keep plastic covering away from children to avoid su󰀨ocation.
6. Do not operate the scooter while under the inuence of drugs and/or alcohol.
7. Do not operate the scooter when you are restless or sleepy.
8. Use your best judgment to keep yourself out of dangerous situations with your
scooter.
9. The scooters have a range of about 40 km and a maximum speed of 25 km/h.
10. Do not turn sharply, especially at high speeds.
11. Do not abuse your scooter, doing so can damage your unit and cause failure to
the operating system leading to injury.
12. Do not drive in or near puddles of water, mud, sand, stones, gravel, debris or near
rough and rugged terrain.
13. The scooter can be used on paved roads that are at and even. If you encounter
uneven pavement, please lift your scooter over and past the obstruction.
14. Do not ride in inclement weather: snow, rain, hail, sleek, on icy roads or in
extreme heat.
15. Do not ride in or near pools or other large bodies of water.
16. Traffic in the city has many obstacles to cross such as curbs or steps. It is
recommended to avoid obstacle jumps. It is important to anticipate and adapt your
trajectory and speed to those of a pedestrian before crossing these obstacles. It is
also recommended to get out of the vehicle when these obstacles become dangerous
due to their shape, height or slippage.
17. Do not attempt to ride over bumps or objects greater then 1.5 cm even when
prepared and bending your knees.
18. PAY ATTENTION - look at where you are riding and be cognoscente of the road
conditions, people, places, property and objects around you.
19. Do not operate the scooter in crowded areas.
20. Operate your scooter with extreme caution when indoors, especially around
people, property, and narrow spaces like doorways and other narrow spaces.
21. Others recommendations such as: special precautions for use at dark; not to touch the
brake disc.
22. Do not operate the scooter while talking, texting, or looking at your phone.
23. Do not ride your scooter where it is not permitted.
24. Do not ride your scooter near motor vehicles or on public roads.
25. Do not climb or travel down steep hills with your scooter.
26. The scooter is intended for use by a single individual, Do not attempt to operate
the scooter with two or more people.
27. A statement that any load attached to the handlebar will a󰀨ect the stability of the
vehicle. Do not carry anything while reding the scooter.
28. Individuals with lack of balance should not attempt to operate the scooter.
29. Women who are pregnant or are preparing for pregnancy should not operate the

9
scooter.
30. Young children and the elderly should not operate the scooter without proper
instruction and supervision from a Certied scooter trainer.
31. At higher speeds, always take into consideration longer stopping distances.
32. Do not step forward o󰀨 your scooter.
33. Do not attempt to jump on or o󰀨 your scooter.
34. Do not attempt any stunts or tricks with your scooter.
35. Do not ride the scooter in dark or poorly lit areas.
36. Do not ride the scooter near or over potholes, cracks or uneven pavement.
37. Do not operate yout scooter o󰀨-road.
38. Do not exceed the maximum weight limit of 100 kg.
39. Avoid driving the scooter in unsafe places, including near areas with ammable
gas, steam, liquid, dust, ber, which could cause re and explosion accidents.
40. Scooter users are recommended to be 14 to 60 years and 130 to 200 cm tall.
41. In any case, anticipate your trajectory and your speed while respecting the code
of the road, the code of the sidewalk and the most vulnerable.
42. Notify your presence when approaching a pedestrian or cyclist when you are not seen
or heard.
43. Cross the protected passages while walking.
44. In all cases, take care of yourself and others.
45. Do not divert the use of the vehicle.
46. This vehicle is not intended for acrobatic use.
47. Caution, the brake may become hot in use. Do not touch after use.
48. Warning aiming to draw the user's attention to any damages related to intensive
use and to recommend periodic inspections of the frame, fork and suspension
attachments (if any).
49. Regularly check the tightening of the various bolted elements, in particular the
wheel axles, the folding system, the steering system and the brake shaft.
50. Do not modify or transform the vehicle, including the steering tube and sleeve,
stem, folding mechanism and rear brake.
51. For pneumatic tires, the recommended maximum tire pressure is 45-50 psi.
52. WARNING ! As with any mechanical component, a vehicle is subject to high
stresses and wear. The various materials and components may react di󰀨erently to
wear or fatigue. If the expected service life for a component has been exceeded, it
may break suddenly, therefore risking causing injuries to the user. Cracks, scratches
and discoloration in the areas subject to high stresses indicate that the component
has exceeded its service life and should be replaced.
53. List regarding the maintenance that can be performed by the user
himself;Instructions for routine inspection, maintenance, cleaning and/or cleaning.
Instructions for routine inspection, maintenance, cleaning and/or cleaning.
54. Instructions covering all functions of the vehicle, specially driving power
assistance start mode (e.g. pushing the vehicle by more than 4 km/h and activating
the power assistance mode).
55. Do not place the scooter in a high temperature higher than 50 °C or a low
temperature lower than -20 °C(for example, do not put the scooter in a car exposed to
the sun in summer). Do not put the scooter into a re, otherwise it may lead to battery
failure, overheating, and even re risk.
56. Environmental conditions (e.g. outdoor or indoor charging); requirement to power-
o󰀨 the vehicle during charging, or into a certain non-operational mode.
57. When not in use for more than 30 days, fully charge, store in a cool, dry place,
and fully charge every 30 days.

10
58. The equipment contains a radio transmitting module with type approval code
CMIIT ID:2020DP3421; Do not use wireless devices in places where the use of
wireless devices is prohibited. Otherwise, it may interfere with other electronic
devices or cause other risks.
59. Take the time to learn the basics of the practice to avoid any serious accident that
can take place in the rst months.
60. An instruction to keep the printed instructions for further reference and to be read
carefully before use.
Cleaning and Storage
If there are stains on the surface of the scooter, use a soft cloth
to dip in a small amount of water to wipe; If there are stains that
are difficult to clean, smear them with toothpaste and brush
them repeatedly, then clean them with a damp cloth. If the
plastic parts of the body are scratched, use sandpaper or other
abrasive materials to polish them.
Attention:
Do not use alcohol, gasoline, kerosene or other corrosive and volatile chemical
solvents to clean, otherwise it will seriously damage the appearance and internal
structure of the car body. It is forbidden to use pressure water gun to spray and wash.
Ensure that the scooter is o󰀨 and the charging port rubber cover is tightly fastened
during cleaning, otherwise electric shock or serious failure may occur due to internal
water inow. When not in use, store in a dry and cool place indoors. Avoid outdoor
storage for a long time. Long-term sun exposure, overheating and cold outdoor
environment will accelerate the appearance and tire aging of the scooter, and reduce
the service life of the scooter and battery pack.
Tire ination maintenance
This product tire is vacuum tire, when the tire height sinks 20%-
30%, need to inate. The recommended tire pressure is 45-
50Psi after ination, and the tire should be inated at least once
every 2-3 months. Regular ination and cleaning of tire surface
debris can prolong the service life of the tire.
Battery Maintenance
1. Do not use battery packs of other models or brands, or else
there may be safety risks.
2. It is strictly forbidden to disassemble, squeeze, or puncture
this product; it is forbidden to throw this product into water, fire
(including heat sources such as stove, heater, etc.) or expose it to
an environment with a temperature higher than 50°C.

11
3. Water entering the battery may cause damage to the internal
circuit, and there is a risk of re or even explosion; if the battery is
suspected of water entering, please stop using it immediately and
contact the after-sales service.
4. Do not touch the battery contacts, disassemble or puncture the
case. Avoid metal objects contacting the battery contacts, or else it
may cause short circuits, damage to the battery or personal injury
or death.
5. Avoid recharging after the battery is completely depleted, and
try to charge as soon as possible, so as to prolong the service life
of the battery.
6. Only use the original power adapter when charging, or else
there is a danger of damage or re.
7. Please fully charge the battery before storing after each use,
which will help to extend the battery life.
8. Do not place the scooter in an environment above 50°C or below
-20°C (for example: in a car exposed to the sun in summer). It is
forbidden to throw the scooter into a re, or else it may cause the
battery to fail, overheat, and even cause re.
9. When used at normal temperature, the battery pack can exert
a higher range and performance; if used in an environment below
0°C, the battery life and performance will decrease. For details,
please refer to the remaining mileage display in the APP.
10. If it won’t be used for a long time, please fully charge it rst,
store in a cool and dry place, and fully charge it every 30 days, or
else the battery may be damaged and such damage is not covered
by the warranty.
11. Improper disposal of used batteries may seriously pollute the
environment. Please abide by local regulations when disposing of
the battery pack. Do not throw away the battery pack in order to
protect the natural environment.
Environmental Protection
This product contains battery or recyclable electronic waste,
and the built-in rechargeable battery contains substances that
may pollute the environment. When disposing of the product,
please do not pile it with general household waste, but hand it
to the electronic waste collection point designated by the state,
which is benecial to environmental protection.

ShenZhen LEQI Intelligent Technology Co., Ltd.
Address: Factory Room 202, No. 340 Guihua Road, Guixiang Community,
Guanlan Sub-district, Longhua District, Shenzhen, Guangdong, China
Tel ：[phone] Web:www.lqwheel.com

Federal Communications Commission (FCC) Statement. This device complies with part 15 of the
FCC Rules. Operation is subject to the following twoconditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation. Note: This equipment has been
tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide Reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one ormore of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications made to this device not expressly approved by Shenzhen
LEQI Intelligent Technology Co., Ltd. may void the FCC authorization to operate this
device.Note: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s authority
to operate the equipment.
RF exposure statement:
The device compliance RF exposure requirement and can installed and used without
restriction
