Leviton Berk-Tek EXT-100-Remote User manual

EXT-100-Remote
• Paired with EXT-100-Main
• Up to 30 W PoE
• PoE mode A and mode B
• Local power option
• IEEE compliant
EXT-100-Remote Adapter Applications
EXT-100-Remote Quick Install Guide
The EXT-100-Remote adapter enables extended Ethernet and PoE reach beyond traditional
distances using four-pair UTP infrastructure. When paired with the EXT-100-Main the
adapter delivers 10/100 Mbps, symmetrical full duplex. The EXT-100 offering is designed
specifically to enable easy deployment over UTP for reaches beyond that of standard
Ethernet eliminating the costs and disruption associated with IDF closet requirements.
Link Activity
Activity
37-55V
DC IN
Link/Speed
Green:
100Mbps
Orange:
10Mbps
To Device
To Main
(EXT-100-Main)
1. Remove the EXT-100-Remote from its packaging.
2. Must ensure cable is properly terminated before connecting any EXT-100 product.
3. In order to avoid damage to devices, it is important that only IP devices are connected when you
connect the EXT-100-Main.
4. Connect the Network Infrastructure cable from the EXT-100-Main to the EXT-100-Remote (Main
side).
5. Using Cat 5e or higher category cable, connect the device to the EXT-100-Remote (Device Side).
NOTE: Berk-Tek recommends using LANmark IP (22AWG) or higher for indoor applications;
LANmark-6 OSP, LANmark-1000 OSP, or LANmark-10G OSP should be used for outdoor applica-
tions.
The EXT-100-Remote must be installed either indoors or in a NEMA rated box appropriate for the
installation environment.
Installations must be compliant with the requirements of the local authority having jurisdiction.
1-800-BERK-TEK (1-800-237-5835) | [phone]
www.leviton.com/berktek
Copyright 2019 Berk-Tek LLC.
445-0029-A
EXT-100-Remote
Fast Ethernet and PoE+ (Up to 30 W) over UTP
EXT-100-Remote
Main Device
Redene the limits
TO MAIN
37-55V
DC IN
ACTLNK/SPD TO DEVICE
ACTLNK
10/100 Mbps (full duplex, symmetrical) & PoE+ over UTP with 2,000 ft (610 m) reach.
EXT-100-Main*EXT-100-Remote
Standard PoE Switch
Local Power Option
Four-Pair UTP Cable
up to 2,000 ft (610 m)
3519117151713212319272925333531394137454743
462101281618142224202830263436
SFP+1
SFP+2
SFP1
SFP2
32404238464844
*EXT-100-Main can be powered locally for use with non-PoE switches.
EXT-100-Remote
Main Device
Redene the limits DEVICE
EXT-100 max. power 30 W
The max length supported
between the EXT-100-Main
and the PoE Switch is 328 ft
(100 m)
The max length supported
between the EXT-100-Remote
and the Device is 328 ft
(100 m)

Technical Specifications
1-800-BERK-TEK (1-800-237-5835) | [phone]
www.leviton.com/berktek
Copyright 2019 Berk-Tek LLC.
445-0029-A
Note the following:
All of the above instructions provide basic installation information necessary for the proper and safe
functioning of this equipment. Persons installing or maintaining this product must read all of the safety
instructions, which are applicable to the system being maintained. Only trained, qualified service
personnel shall install or maintain this product.
• Keep these instructions with the equipment.
• Do not attempt to install or service this equipment unless you are skilled in the installation and
maintenance of electronic telecommunications equipment and have successfully completed specific
training for this equipment.
WARNING: FAILURE TO FOLLOW ALL INSTRUCTIONS MAY RESULT IN IMPROPER EQUIPMENT OPERATION
AND/OR RISK OF ELECTRICAL SHOCK.
WARNING: ANY CONNECTION TO AN OUTSIDE PLANT LEAD, AN OFF-PREMISE APPLICATION, OR ANY OTHER
EXPOSED PLANT APPLICATION MAY RESULT IN A FIRE OR SHOCK HAZARD, AND/OR DEFECTIVE OPERATION,
AND/OR EQUIPMENT DAMAGE.
All safety warnings and precautions in addition to compliance and environmental information is
available on our website www.leviton.com/berktek.
Safety Warnings, Precautions, Compliance and Environmental Information
• CAUTION, Hot surface
• ATTENTION, Surface chaude
• VORSICHT, Heiße Oberfläche
• PRECAUCIÓN, Superficie caliente
• VAROITUS, Kuuma pinta
• VOORZICHTIGHEID, Heet oppervlakte
• VARNING, Varm yta
• ADVARSEL, Varm overflade
• ΠΡΟΣΟΧΗ, Καυτή επιφάνεια
• ATTENZIONE, Superficie calda
• CUIDADO, Superfície quente
• ATTENZJONI, Wiċċ sħun
• ETTEVAATUST, Kuum pind
• VIGYÁZAT, Forró felület
• PREVIDNOST, Vroča površina
• POZOR, Horký povrch
• ATSARGIAI, Karštas paviršius
• UZMANĪBU, Karstā virsma
• POZOR, Horúci povrch
• VARÚÐ, Heitt yfirborð
• PRZESTROGA, Gorąca powierzchnia
• FORSIKTIG, Varm overflate
• PRUDENȚĂ, Suprafata fierbinte
Distances assumes a 4-Pair category cable between the main and remote at 20°C. From the
remote, a full 100 meters to the device. For other installation configurations, please go to
www.leviton.com/berktek.
Support and Warranty
Technical Support
The Berk-Tek TEK Support group is available to assist you with product installation,
configuration, monitoring, and troubleshooting procedures. Should you experience trouble
with this equipment or need repair/warranty information, please contact TEK Support at
1-800-BERK-TEK or directly through email at [email protected].
Warranty: The EXT-100 adapters are backed by Berk-Tek's customer support and a three
(3) year warranty.
Power & Distance
PoE Level Max Supported Distance between the Main and Remote
IEEE 802.3af (PoE) 2000 ft (610 m)
IEEE 802.3at (PoE+) 1250 ft (380 m)
Model Number EXT-100-Remote
Part Number EXT-100-Remote
Dimensions •3.46” x 1.97” x 0.98” (LxWxH)
•8.8 cm x 5.0 cm x 2.5 cm (LxWxH);
Weight 3.74 oz. (106 g)
Interface:
Network
Infrastructure
side
1 RJ45 port: UTP/FTP four-pair cable
Interface: IEEE
Side (IP Device)
1 RJ45 port; adapter is IEEE 802.3 af/at
compliant and will negotiate power
requirements with IP end device
Power Supply PoE from the EXT-100-Main or external
power supply; maximum 30 W
Power
Consumption 1.5 W
DC IN
Optional (sold separately)
48-56 VDC via an external AC/DC Power
Adapter (IEC Class II isolated only)
NOTE 1: Local power supply used must have its
output isolated from Earth potential.
NOTE 2: If voltage of local power supply is
lower than the power voltage provided from
the PoE switch, then power on the PoE switch
should be turned off.
Operating
Temperature
-40°C to +70°C (-40°F to +158°F)
Tests conducted against international safety
standard at maximum ambient temperatures of
60ºC at 30 W
Mean Time
Before Failure
(MTBF)
20+ years
Humidity 10% to 95% (non-condensing) at
35°C
