Lexicomm ViLX-EX8 Guide

Lexicomm ViLX-EX8 EVCS
System Expander Panel
Installation and Commissioning Manual
Version 1- October 2017

Document PViLXEX8 7001-01 Rev 1 2017 Page 2 of 16
Table of Contents
1Introduction..........................................................................................................................3
1.1 What is an Emergency Voice Communication System ........................................................3
1.2 Suitability......................................................................................................................3
2Product Overview..................................................................................................................3
3Important Safety Information.................................................................................................4
3.1 Unpacking the ViLX-EX8 .................................................................................................4
4Installation ...........................................................................................................................5
4.1 Connecting the ViLX-EX8 System Expander panel..............................................................5
4.2 Planning the Wiring........................................................................................................6
4.3 Cable and Wiring Guidance.............................................................................................6
4.3.1 Fire Telephone system............................................................................................6
4.3.2 Disabled Refuge EVC System...................................................................................6
4.3.3 Combined Systems.................................................................................................6
4.3.4 “Assist Call” Emergency Assistance Alarm Systems....................................................6
4.4 Cabling methods............................................................................................................6
4.4.1 ViLX-EX8 System Expander Panel Wiring..................................................................7
4.4.2 ViLX-TMS Master, ViLX-EX8 System Expander Panel wiring in ring ..............................7
4.4.3 Mains Connection...................................................................................................8
4.5 Battery Information........................................................................................................8
4.6 Outstation Connections...................................................................................................9
4.6.1 Type A outstation...................................................................................................9
4.6.2 Type B outstation...................................................................................................9
4.6.3 “Assist Call” ACA Accessible Toilet Kit.....................................................................10
4.6.4 Enable Switch Input .............................................................................................10
4.7 TMS Auxiliary Connections............................................................................................10
4.8 Powering up procedure.................................................................................................10
4.9 Powering down procedure ............................................................................................10
5Hardware configuration procedure........................................................................................11
5.1 Exchange PCB Dipswitch Settings..................................................................................11
6Indications..........................................................................................................................12
6.1 Mode Indicator Summary..............................................................................................12
6.2 Power supply and CPU indicator Summary......................................................................12
6.3 Zone Indicator Summary ..............................................................................................12
7Commissioning procedure ....................................................................................................13
8Maintenance.......................................................................................................................13
Notes..........................................................................................................................................14
Notes..........................................................................................................................................15
9Technical Specification.........................................................................................................16

Page 3 of 16 Document PViLXEX8 7001-01 Rev 1 2017
1Introduction
1.1 What is an Emergency Voice Communication System
An Emergency Voice Communication System, or EVCS, is a system that allows voice communication in
either direction between a central control point and a number of other points throughout a building or
building complex, particularly in an emergency situation. The control points, or outstations by which
they are more commonly referred, generally comprise of a Type A outstation, a Type B outstation, or a
Type C Combined Type outstation. “Assist Call” emergency assistance alarm systems can also be
incorporated into the EVCS.
EVCS is generally required in the following situations:
In any building or sports or similar venue where there are disabled people, or people who may
have difficulty negotiating the evacuation route.
In buildings with phased evacuation and/or firefighting lifts where it facilitates secure
communications for building managers, fire wardens, and attending fire officers.
At sports venues and similar complexes, where it will assist stewards in controlling the
evacuation of the area in an emergency.
The Lexicomm ViLX-TMS Emergency Voice Communications System (EVCS) is designed to fully comply
with BS5839 Part 9:2011 for use as a Fire Telephone system, Disabled Refuge Call system or as a
combined system when both Fire Telephones and Disabled Refuge Points are required.
1.2 Suitability
Fire telephone systems are recommended for all public buildings and multi-story buildings over four
floors by BS9999.
Disabled Refuge systems are required in buildings where the public or disabled staff gain access to any
floor other than the ground floor using lifts. Refuge areas are provided at each storey exit from each
protected stairway.
2Product Overview
The Lexicomm EVCS has been designed around a total network concept so all of the Lexicomm panels
have inbuilt networking.
The system comprises 3 types of panel; ViLX-TMS touch screen master station (hereafter referred to as
TMS), the ViLX-228 2 to 8 line master station (hereafter referred to as LX228) and a ViLX-EX8 system
expander panel (hereafter referred to as EX8). For Lexicomm systems in excess of 8 lines a TMS must
be used as the master station, the system can then be expanded by the use of a EX8 or LX228 in blocks
of 8 lines up to a maximum system capacity of 512 lines. Additional TMS panels can be used wherever
indication and control is required i.e. Fire Control rooms and building reception.
The wiring is a ring and spur topology with outstations being wired on radial spurs from any master
station or system expander panel. The EX-8 and any TMS or LX228 are wired in a ring network up to a
maximum of 64. The EX-8 would typically be sited in convenient locations close to the outstations i.e.
risers or stairwells resulting in short vertical wiring runs. The LX228 can be used to provide local control
of up to 8 lines within a building this can then report back to a TMS which can provide overall control of
an entire site.
In this way a very large system can be completed with a minimum of cabling coming back the master
station via the network ring.
Additionally the “Assist Call” emergency assistance alarm system can either be connected to the same
line with an outstation, or connected to a dedicated line.Neither the outstations nor the “Assist Call”
emergency alarm system require a separate power supply unit as each line is powered from the Master
Station. This has the additional benefit of each line being fully monitored and battery backed up.

Document PViLXEX8 7001-01 Rev 1 2017 Page 4 of 16
3Important Safety Information
This Equipment must only be installed and maintained by a suitably skilled and competent person.
This Equipment is defined as Class 1 in EN60065 (Low Voltage Directive) and must be EARTHED.
Caution
Indoor Use Only
Warning
Shock Hazard-
Isolate Before Opening
Warning
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN
OR MOISTURE
Warning
THIS UNIT MUST BE EARTHED
Warning
NO USER SERVICEABLE PARTS
Each TMS and EX8 requires a 3A spur, returning to a breaker clearly marked “EVCS DO NOT TURN
OFF”.
If the TMS, LX228 and the EX-8 are distributed around a site, it is essential that all panels are on the
same mains phase, as they are classified TEN 230V. Powering from different phases can mean a 440V
potential can be present in a panel during a major fault incident.
Anti-static handling guidelines
Make sure that electrostatic handling precautions are taken immediately before handling PCBs and other
static sensitive components.
Before handling any static-sensitive items, operators should get rid of any electrostatic charge by
touching a sound safety earth. Always handle PCBs by their sides and avoid touching any components.
3.1 Unpacking the ViLX-EX8
Remove the EX-8 from its packing, and check the contents against the following list:
•ViLX-EX8 System Expander Panel.
•Accessory pack with the following contents:-
o1 number 2.5mm AF Hex Key.
o8off 10K End of Line (EoL) Resistors.
oInstallation and Commissioning Manual ( this document)
Use the 2.5mm AF Hex Key supplied to open the right hand front cover.
Verify the following items are present:
•4 number Line cards c/w 2 way line connector.
•1 number 2 way Fault connector.
•1 number 2 way In Use connector.
•1 number 2 way Enable connector.
•4 number 2 way Network connectors.
•1 number 3 way mains connector.
•1 number battery lead.

Page 5 of 16 Document PViLXEX8 7001-01 Rev 1 2017
4Installation
4.1 Connecting the ViLX-EX8 System Expander panel
To comply with EMC (Electro Magnetic Compatibility) regulations and to reduce the risk of electrical
interference in the system wiring, the use of fire-resistant screened cables is recommended throughout
the installation.
All wiring should come into the enclosure via the knockouts provided, and be fixed tidily to the relevant
terminals.
Note that correct cable glanding is essential. Due regard should be paid to any system specifications
which demand a certain cable type, providing it meets the appropriate national wiring regulations.
Prior to mounting the EX8, it should be decided if the field wiring is to be run on the surface or
concealed. There are 14 knockouts on the top and 2 slotted entries with a dedicated mains supply
entry at the rear. If a knockout is removed by mistake, fill the hole with a good quality cable gland.
Unused knockouts must be left unopened to comply with the Low Voltage Directive. Accidentally
knocked out holes should be blanked off.
The ViLX-EX8 weighs 5kg with batteries, so care should be taken to securely mount the Station on stud
walling.

Document PViLXEX8 7001-01 Rev 1 2017 Page 6 of 16
4.2 Planning the Wiring
All system wiring should be installed to meet the appropriate parts of BS5839 Part9:2011 and BS 7671
(Wiring Regulations). Other national standards of installation should be adhered to where applicable.
Do not test wiring using an insulation tester (Megger) with any
equipment connected, as the 500 Volt test voltage will destroy
these devices.
You must observe local wiring regulations. Do not run SELV and LV cables in the same enclosure
without adequate insulation between them.
4.3 Cable and Wiring Guidance
4.3.1 Fire Telephone system
Any system using Type A outstations must use enhanced grade cabling throughout for all wiring,
including the mains supply to the ViLX-EX8 Expander Station.
4.3.2 Disabled Refuge EVC System
For buildings less than 30m in height, or any building with sprinklers fitted, standard grade fire resistant
cable may be used to wire Type B outstation and the mains supply to the Master Controller; as long as
the planned evacuation will be completed in 30 minutes.
If the building is over 30m in height without sprinklers, or where the evacuation will take place over
multiple stages exceeding 30 minutes, then enhanced grade cables must be used.
4.3.3 Combined Systems
For systems containing Type A, Type B or Type C outstations, shared cable such as network cables
must be enhanced grade.
Cabling to Type A or Type C outstations must be in enhanced grade fire resistant cabling.
Individual spurs to Type B outstations can be wired in standard grade fire resistant cabling in
accordance with the wiring guidelines already set out for disabled refuge systems.
4.3.4 “Assist Call” Emergency Assistance Alarm Systems
All installations must conform to Building Regulations Approved Document M and BS8300. The “Assist
Call” is wired using 2 core cable, and the “Assist Call” plates can be wired in any order.
4.4 Cabling methods
There are 3 cabling methods available:
•Connection to a Type A or Type C outstation: use 2 core enhanced grade fire resistant cable
when extending a firefighting telephone system.
•Connection to a Type B outstation: use 2 core standard grade fire resistant cable when
extending a disabled refuge system.
•Connection to an “Assist Call” system on a dedicated line: requires 2 core 1mm CSA or above
PVC sheathed.

Page 7 of 16 Document PViLXEX8 7001-01 Rev 1 2017
4.4.1 ViLX-EX8 System Expander Panel Wiring
Typical wiring for a ViLX-EX8 system expander panel is shown in the schematic below.
4.4.2 ViLX-TMS Master, ViLX-EX8 System Expander Panel wiring in
ring
If more than 8 lines are required then an EX-8 will be required in addition to the TMS, with the
outstations shared between both the TMS and the EX8, the system has to be wired as a ring as shown
in the schematic below. This ensures that the loss of any single cable will not affect the operation of
more than one outstation.

Document PViLXEX8 7001-01 Rev 1 2017 Page 8 of 16
4.4.2.1 Network Wiring
Note: Only connect the earth screens on the Net in cables, cut back and insulate Net OUT
earth screens.
4.4.3 Mains Connection
>3mm
3A
Main
Distribution
Board
>0.75mm2<2.5mm2
UNITY
DAU
Each TMS, EX8 and LX228 panel requires a 3A spur, returning to a breaker clearly marked “EVCS DO
NOT TURN OFF”.
If the TMS, LX228 and the EX-8 are distributed around a site, it is essential that all panels are on the
same mains phase, as they are classified TEN 230V. Powering from different phases can mean a 440V
potential can be present in a panel during a major fault incident.
4.5 Battery Information
In the event of mains failure BS5839 Part 9:2011 requires battery backup for 24 hours standby and 3
hours operation thereafter.
A ViLX-EX8 requires one number 12V 7AH vent regulated sealed lead acid battery. The battery is not
supplied with the ViLX-EX8 . There is space for up to a 7AH battery.
Safety Information:
Sealed Lead Acid batteries contain sulphuric acid which can cause burns if exposed to
the skin. The low internal resistance of these batteries mean large currents will flow if
they are accidentally short circuited causing burns and a risk of fire.
Exercise caution when handling batteries.
Power Up Procedure:
Always apply mains power before connecting batteries. When connecting batteries,
always connect the Positive (Red +) terminal first.
Power Down Procedure
Disconnect the batteries before removing the mains power. When disconnecting
batteries, always remove the Negative (Black –) terminal first.
Lexicomm
Panel

Page 9 of 16 Document PViLXEX8 7001-01 Rev 1 2017
4.6 Outstation Connections
The TMS and EX8 are configured via the configuration spreadsheet contained on the Micro SD card
supplied with the TMS, for configuration (see 6).
The following devices are available on the system:
•Type A (fixed phone)
•Type B (hands-free refuge point)
•Type C “Combi” (combined Type A and Type B)
•Jack point
•“Assist Call” emergency assistance alarm system
For Type A, Type B, and Type C outstations, put the supplied end-of-line 10kΩresistor into the end-of-
line terminal in the outstation.
For Jack points, and the “Assist Call” system, put the supplied end-of-line 10kΩresistor into the terminal
in the last plate on the system.
4.6.1 Type A outstation
Note: The Earth screen should be sleeved and connected to the terminal block in the controller,
and the earth stud in the Type A outstation.
4.6.2 Type B outstation
Note: The Earth screen should be sleeved and connected to the terminal block in the controller,
and the earth connection in the metal back box (if a plastic back-box is used cut the earth back
and insulate at the outstation).

Document PViLXEX8 7001-01 Rev 1 2017 Page 10 of 16
4.6.3 “Assist Call” ACA Accessible Toilet Kit
The “Assist Call” ACA kit comprises an Over door Indicator, a Pull Cord, and a Cancel Plate. The above
order is a typical order; with the Over door Indicator, Pull Cord and the Cancel Plate connected as
shown, but the plates can be wired in any order as long as the EOL resistor goes into the free terminal
of the last plate.
4.6.4 Enable Switch Input
The Swich input is used for remote enabling or disabling of panels. The input is monitored, and expects
a 470R resistor for activating (so a manual call point can be used). A 10K EOL resistor for the unit is
supplied with the panel.
4.7 TMS Auxiliary Connections
The TMS has three auxiliary connections:
Fault is a normally CLOSED volt free relay (30V DC 1A) which
OPENS on any fault on the network, including loss of power.
In Use is a normally OPEN volt free relay (30V DC 1A) connection.
The relay CLOSES when configured to do so by the TMS (see 7.13),
usually when an outstation on the network is operated.
Enable is a normally CLOSED input, and is required to operate the system. If Jumper J1 is in place,
then no connection is required at the terminals.
It is advised that this feature is not used as the system should be available at all times, not just during
an evacuation.
If this function is used, then the removal of Jumper J1 and opening the Enable input will not display
incoming calls from Type B outstations only. Calls from Type B outstations automatically “time out” after
approximately 30 minutes. Type A outstations and “Assist Call” emergency assistance alarm systems will
continue to operate.
If this function is used, it only requires connection with one panel on the network. If the Enable input
is CLOSED on one panel, then all panels on the network are CLOSED. To disable Type B outstations,
then the Enable input on all panels on the network must be OPEN.
4.8 Powering up procedure
To power up the EX-8, carefully check all internal wiring before applying mains power to the EX-8.
Once the EX-8 is powered, the battery can be attached using the battery leads supplied. When
attaching the battery, always attach the Positive (Red+) terminal first.
4.9 Powering down procedure
To power down the EX-8, first disconnect the battery. Always disconnect the Negative (Black -)
terminal first. Once the battery leads have been disconnected, then remove mains power.

Page 11 of 16 Document PViLXEX8 7001-01 Rev 1 2017
5Hardware configuration procedure
The Lexicomm range of panels has in-built networking. This is described in the product overview
section. Install the additional panel/station as per the relevant parts in the installation section 4.
Any panels on the network must be wired as a ring (see 4.4.2). This is due to the ability for outstations
to be wired from any panel therefore there is no loss of functionality due to cable faults as a ring
provides redundancy.
Network connections used are Network Out and Network In, with Network In on one Station wired to
Network Out on the other Station (A to A, B to B, C to C, and D to D).
The default network address setting for the EX-8 is 2.
When adding an EX8, it must have a unique network address, and must be included in the site
configuration file (see section 6 of the TMS manual).
If the site configuration is not updated the panel will not be seen by the rest of the network and
importantly any outstations connected to that panel will not operate as they will not be seen by the rest
of the network.
5.1 Exchange PCB Dipswitch Settings
The EX8 forms part of the Lexicomm network that can includes other TMS panels as well as EX8
Expander panels and LX228 panels. Each station on the network has to have a unique network
address. This address is set by the dipswitches on the Exchange PCB. The address is a binary number
given by the positions of dip switches 1 to 6, with valid addresses lying between 1 and 64 inclusive.
Network address dipswitch setting
Addr
1
2
3
4
5
6
Addr
1
2
3
4
5
6
1
1
0
0
0
0
0
33
1
0
0
0
0
1
2
0
1
0
0
0
0
34
0
1
0
0
0
1
3
1
1
0
0
0
0
35
1
1
0
0
0
1
4
0
0
1
0
0
0
36
0
0
1
0
0
1
5
1
0
1
0
0
0
37
1
0
1
0
0
1
6
0
1
1
0
0
0
38
0
1
1
0
0
1
7
1
1
1
0
0
0
39
1
1
1
0
0
1
8
0
0
0
1
0
0
40
0
0
0
1
0
1
9
1
0
0
1
0
0
41
1
0
0
1
0
1
10
0
1
0
1
0
0
42
0
1
0
1
0
1
11
1
1
0
1
0
0
43
1
1
0
1
0
1
12
0
0
1
1
0
0
44
0
0
1
1
0
1
13
1
0
1
1
0
0
45
1
0
1
1
0
1
14
0
1
1
1
0
0
46
0
1
1
1
0
1
15
1
1
1
1
0
0
47
1
1
1
1
0
1
16
0
0
0
0
1
0
48
0
0
0
0
1
1
17
1
0
0
0
1
0
49
1
0
0
0
1
1
18
0
1
0
0
1
0
50
0
1
0
0
1
1
19
1
1
0
0
1
0
51
1
1
0
0
1
1
20
0
0
1
0
1
0
52
0
0
1
0
1
1
21
1
0
1
0
1
0
53
1
0
1
0
1
1
22
0
1
1
0
1
0
54
0
1
1
0
1
1
23
1
1
1
0
1
0
55
1
1
1
0
1
1
24
0
0
0
1
1
0
56
0
0
0
1
1
1
25
1
0
0
1
1
0
57
1
0
0
1
1
1
26
0
1
0
1
1
0
58
0
1
0
1
1
1
27
1
1
0
1
1
0
59
1
1
0
1
1
1
28
0
0
1
1
1
0
60
0
0
1
1
1
1
29
1
0
1
1
1
0
61
1
0
1
1
1
1
30
0
1
1
1
1
0
62
0
1
1
1
1
1
31
1
1
1
1
1
0
63
1
1
1
1
1
1
32
0
0
0
0
0
1
64
0
0
0
0
0
0
Dipswitch 7 & 8 Are
reserved for future
expansion.

Document PViLXEX8 7001-01 Rev 1 2017 Page 12 of 16
6Indications
6.1 Mode Indicator Summary
Mode
Description
Green solid
Normal state
Red solid
Outstation off hook
Blue solid
Assist call active
Yellow Solid
Type B disable function active (Enable jumper open)
6.2 Power supply and CPU indicator Summary
AC
DC
PSU
CPU
Description

Mains OK
x

Mains failure

Battery OK
x
Flash
Battery open circuit
x

Battery short circuit
Flash

Battery high impedance


PSU processor fail

Display or Exchange Processor Fault or Display-Exchange comms flt
= LED illuminated
x = LED off
Flash= LED Flashing
Note: The general fault LED flashes on all fault conditions until accepted at the master station, when
accepted the LED goes solid.
6.3 Zone Indicator Summary
Zone Indicator Status
Description
Slow flash red
Outgoing call
Fast flash red
Incoming call from type A outstation
Normal flash red
Incoming call from type B outstation
Normal flash green
Call connected to master handset
Normal flash green/red
Call on hold
Solid yellow
Line Short circuited
Slow flash yellow
Line card missing
Normal flash yellow
Line Open circuit or EOL missing
Fast flash yellow
Line Earth fault
Normal flash blue
Incoming Assist Call alarm
Solid blue
Assist call acknowledged
Note: The general fault LED flashes on all fault conditions until accepted at the master station, when
accepted the LED goes solid.

Page 13 of 16 Document PViLXEX8 7001-01 Rev 1 2017
7Commissioning procedure
The commissioning should be carried out by a competent person who has a basic knowledge and
understanding of the design and installation sections of BS5839 part 9:2011, and has access to the
specification of the project.
The 500v insulation tests should have been carried out by the installer and the results made available to
the commissioning engineer.
All cables should be correctly labelled.
Test field wiring and check for end-of-line 10KΩresistor. Check cables are clear from any short or open
circuits.
Connect cables into Line Cards.
Configure relevant dipswitches for the network settings that may be required as per the set up section
in this manual.
Connect up network cabling, if network exists.
Power up the ViLX-TMS Master Station using mains only, fed from a 3A fuse fitted in an unswitched
fused spur. The AC power indicator will be illuminated, and the DC power indicator is extinguished. The
PSU fault and General fault indicators will be illuminated. There should be no line fault indicators
illuminated.
Configure the system (see section 6 of TMS manual)
If there are no line faults present, the battery may be connected. The DC power indicator will be
illuminated, and the PSU fault and General fault indicators are extinguished when battery is connected.
If there are any line fault indicators illuminated, then the field wiring should be checked prior to the
battery being connected.
Lift the master handset receiver and listen for a cadence tone.
Repeat the power up section for any ViLX-EX8 Expander panels.
All outstations may be tested now, visit each outstation in turn and test that it is connected to the
correct Master Station or Expander panel and perform an intelligibility test. This test should be
conducted when the building has normal background noise levels. The intelligibility test requires two
personnel.
When all outstation tests are complete, network cable checks should be performed to ascertain correct
operation by unplugging network cable to ensure the network is correctly fault monitoring and
continues to work with a single cable fault.
When complete the log may be retrieved from MICRO SD card, saved as a spreadsheet and kept for
record purposes.
8Maintenance
It is a requirement of BS 5839-9:2011 that a maintenance agreement be in place for the EVCS. The
maintenance schedule should be as follows:
Frequency
Test
Weekly
Test a different outstation on the system each week and make a call to the control.
Repeat each week until all outstations and master stations are tested. Record these
results in the site log. If more than one master station is present alternate weekly.
Biannually
Engineer call to check system operation, intelligibility, field strength of attached AFILS
equipment and check battery health. Record results and any variations into the site Log
Book
Copy all log files from the on-board MICRO SD Card, and erase log directory before
replacing card (to prevent out of memory errors)
Yearly
Engineer call to check system operation perform 100% outstation and master station
operation, field strength of attached AFILS equipment and check battery health. Record
results and any variations into the site Log Book
5 Yearly
In addition to Yearly tests replace all batteries and record in Log Book.

Document PViLXEX8 7001-01 Rev 1 2017 Page 14 of 16
Notes

Page 15 of 16 Document PViLXEX8 7001-01 Rev 1 2017
Notes

Document PViLXEX8 7001-01 Rev 1 2017 Page 16 of 16
9Technical Specification
Product Code
ViLX-EX8
Power Supply and Charger
AC Input
230Vac+- 10% 50/60Hz
Internal power supply
12Vdc nominal
Supply and battery
Monitored open, Short, Fuses
Protection
Deep discharge, Short,
Thermals
Temperature compensation
Yes
Battery information
1x 12V 7AH VRSLA
Mains fuse
1A HRC(T)
Battery fuse
Self Resetting PTC
Max charge current
500mA
Inputs
Number of lines
8
Remote enable
Short to use
End of line monitoring
10KΩ0.5 watt resistor
Relay outputs
Number and type
2; Fault and In use,
volt free 30Vdc 1A
Controls
Number and type
None
Indication
Number and type
3x PSU Status Indicators
1 x CPU Fault Indicators
1x General Fault Indicator
1x RGB Mode Indicator
8x RGB Line indicators
Enclosure Details
Back box finish
RAL 7035 Grey
Dimensions (WxHxD)
220 x 300 x 95
Entries
14 knockouts top, 2x rear
slots
Flush Cutout (WxHxD)
225 x 305 x 85
The Lexicomm ViLX-EX8 EVCS is designed and manufactured in the UK by:
Vox Ignis Ltd,
Unit 72T Wearfield
Enterprise Park East,
Sunderland,
SR5 2TH.
www.vox-ignis.com
[e-mail]
WEEE
Compliant
Product
