Lexing LX-MV-360S15B-Z User manual

43.7mm
60.7mm
50mm
68mm
Detection angle: 360°(Ceiling installation),
180°(Wall installation)
Detection range: 2-10m(radii.) (adjustable)
(Ceiling installation)
25m Max.(radii.) (adjustable)
(Wall installation)
Light-ontrol: 2-2000LUX (adjustable)
Installation sit: indoors, ceiling mounting
HF system: 5.8GHz CW electric wave,ISM band
Power source: 100-240VAC
Power frequency: 50/60Hz
Rated load: 3000W Max.tungsten (220-240VAC)
1000W Max.fluorescent & LED (220-240VAC)
1500W Max.tungsten (100-130VAC)
750W Max.fluorescent & LED (100-130VAC)
Transmission power: <0.2mW
Working temperature: -15°C~+70°C
Protection level: IP20,Class II
Time setting: 8sec to 12min (adjustable)
Specifications
Sensor information
(Ceiling installation)
Summary
Features
This is a hi-precision digital microwave sensor whose detection range is 360°and working frequency is
5.8GHz. It is based on Doppler principle which integrates the emitting and receiving. It adopts MCU (Micro
Control Unit) that greatly increases its precision and decreases its fault rate. It’s delicate in appearance and
compact in structure. It can be independently connected to the loads or easily installed inside the lightings with
lampshade made of glass or plastic. It is widely applied in the passageway, washroom, elevator, household or
other public areas for security protection or energy saving. It applies for several technical patents and is the
perfect choice for your intelligent living.
1.Non-radiation harm: its transmitter power is lower than 0.3mW, which does no harm to human body.
2.Reliable & Stable performance: it applies the RC filtering and digital filtering in digital processing. It also uses
the digital zero trigger technology, that is, at zero point it will be auto-connected or auto-disconnected. It uses
the Tyco high-power relay to control output, which ensures its reliable performance. It adopts power
management chip to guarantee its stable performance in 100-240VAC.
360º
Sensing angle adjustment range
H
LL
1
2
3
4
5
6
7
8
9
10
11
12
0 11 22 33 44 55 66 77 88 99 1010 1111 1212 1313 1414
Detection range: 11m max (Height of installation2.5m) Detection range: 11m max (Height of installation4m)
Detection range: 10m max (Height of installation8m)
Detection range: 10m max (Height of installation6m)
Detection range: 10m max (Height of installation10m)
Ground
LX-MV-360S15B-Z Microwave Sensor Instruction

LUX
SENS
TIME
1-6m
Correct moving orientation Detection angle
25m Max.180°
Height of installation1-6M
(Wall installation)
Applications
Microwave can penetrate the glass, plastic and wood, thus the microwave sensor can be installed inside the
shade made of certain thickness of glass, plastic or wood. For example, the application in lightings, only if
making connection as below shown can you change the common lightings into auto-sensing lightings.
You can install one or more inside the ceiling or floor to control the whole passageway.
Friendly reminder: when installing two or more microwaves together, you are required to keep 4 meters one from
another, otherwise the interference among them will lead to error reaction.
Nonmetals
Warning!
Microwave will be reflected by the metal, thus
the microwave sensor cannot be installed
inside the shade made of metal, or it won’t
work normally. When installed inside the ceiling or floor, the microwave sensor
fails to distinguish the ambient light intensity automatically.
N LL’
Connect N, L with power;
Connect N, L’with load.’
L
L
N
input~ output~
Sensor
Load
Setting manner one:potentiometer
It may take times to adjust values before they satisfy your need.

Light-control setting
2-2000LUX
Time setting
8sec-12min
Detection range setting(sensitivity)
2-10m
Note: the above detection range is gained in the case of a person who is between 1.6m~1.7m
tall with middle figure and moves at a speed of 1.0~1.5m/sec. if person’s stature, figure and
moving speed change, the detection range will also change.
It is mainly for the adjustment of the delay time from the moment the signal detected and light
auto-on till the light auto-off. You can define the delay time to your practical need. But you’d
better lower the delay time for the sake of energy saving, since the microwave sensor has the
function of continuous sensing, that is, any movement detected before the delay time
elapses will re-start the timer and the light will keep on only if there is human in the detection
range.
Notice: when using this product, please adjust the sensitivity (detection range) to an
appropriate value but the maximum to avoid the abnormal reaction caused by the easy
detection of the wrong motion by the blowing leaves & curtains, small animals or the
interference of power grid & electrical equipment. All the above mentioned will lead to the
error reaction. When the product does not work normally, please try to lower the sensitivity
appropriately, and then test it.Human movement will cause the sensor induction,so when you
under the function testing,please leave the induction region and don't make movement to
prevent the sensor continuous work.
Note: please don’t adjust the three functional knobs to excess. That is because the three
functional knobs were connected to the components directly, there is a small stopper in each
of the three components, when you adjust the knobs from start to end, the excessive turn will
damage the stopper，and lead to the 360°non-stop turn around. The adjust range limit is
270°, please do pay attention to this.
Friendly reminder: when installing two or more microwaves together, you are required to
keep 4 meters one from another, otherwise the interference among them will lead to error
reaction.
Detection range is the term used to escribe the radii of the roughly circle casting on the
ground when installed at the height of 2.5 m. To turn the knob fully anti-clockwise is the
minimum range, fully clockwise is the maximum.
It can be defined from 8 seconds(turn fully anti-clockwise) to 12minutes(turn fully
clockwise). Any movement detected before this time elapses will re-start the timer. It is
recommended to select the shortest time for adjusting the detection range and for
performing the walk test.
NOTE:When the light be auto off,it will take 1 second before the sensor is ready to detect
another movement,that is,only signal detected 1 seconds later can the light be auto-on.
It can be defined in the range of 2~2000 LUX. To turn the knob fully anti-clockwise is
about 2 lux,fully clockwise is about 2000 lux.When adjusting the detection zone and
performing the walk test in daylight,you should turn the knob fully clockwise.





Installation
Switch off the power.
Set threaded tubes into the power cord and control line.
Connect the power and the load with the sensor according to the connection-line diagram.
Turn the knobs to the ideal conditions
(Please define the settings as per the above SETTING MANNER ONE part mentioned.).
49~50mm
Warning!
1、Being installed on the rocking object will lead to error reaction.
2、The shaking curtain blown by wind will lead to error reaction. Please select the suitable place to install.
3、Being installed where the traffic is busy will lead to error reaction.
4、The sparks produced by some equipment nearby will lead to error reaction.
The following situations will lead to error reaction.
Fault and the solution
The load fails to work.
Light-illumination is set incorrectly.Adjust the setting of the load.
Change the load.
Turn the power on.
Check the settings of the
detection area.
Re-adjust the installation place.
Check the settings of the
detection area.
Check the settings of the
detection area.
The load is broken.
The power is off.
There is a continuous signal in the region of the detection.
Moving signal is detected by the sensor (movement
behind the wall, the movement of small objects, etc.)
The lamp isn't installed well so that sensor fails to
detect reliable signals.
The motion speed is too fast or the defined detection
area is too small.
Fault Failure cause Solution
The load works all the time.
The load works when there is
no motion signal detected.
The load fails to work when
there is motion signal detected.
● Please confirm with prefessional installation.
● For safety purposes, please cut off power before installation and removal operations.
● Any losses caused by improper operation,the manufacturer does not undertake any
responsibility.
Warning!
We are committed to promoting the product quality and reliability, however, all the electronic
components have certain probabilities to become ineffective, which will cause some
troubles.When designing, we have paid attention to redundant designs and adopted safety
quota to avoid any troubles.
This instruction, without our permission, should not be copied for any other purposes.
