Lexing LX-SLL136L User manual

LX-SLL136L Low-Power Solar Infrared Sensor Light Instruction
Summary
LX-SLL136L is a PIR sensor LED lamp, which takes solar energy as the main source and uses the lithium
cell as the back-up power and which also uses PIR sensor to achieves digital energy-saving control.
Moreover, its lightweight and thin design makes it much more convenient to be used in certain situations,
such as field trip, camping, repairing automobile lighting in dark, power failure from earthquake or electric
power circuit repair etc. LX-SLL136L is also an ideal substitute for charge power supplier in outdoor
emergency, used for mobile phone, camera, MP3, MP4 etc, for LX-SLL136L itself carries spared lithium cell
and external connected solar panel. LX-SLL136L adopts the PIR sensing technology to achieve the
energy-saving, that is, in AUTO state, it will auto-detected the motion signals and light on, and will light off if
you leave away. In ON condition, it can auto detect whether there are motion signals within the detection
range to adjust the light intensity, which helps to extend the time of power supply. LX-SLL136L is an ideal
and multifunctional intelligent PIR sensor lamp and it will become more and more important for daily living
and travelling.
100V-240V Convert 10V USB data lines USB transfer cable
• 36 LED matrix light /
motion detector
• Adapter
• USB data lines
• USB transfer cable
• User Manual
Packing items
Adapter
Outdoor camping lighting
Auto repair lighting
Indoor
10LUX 60°
Specifications
Solar energy battery tag: 10VDC/3W
Rated load: 2.8W Max.
Power adapter: DC10V 0.5A
Internal lithium cell: 7.4V 1800mA/h
Light source: 36PCS LEDs
System control chip: MCU
Detection range : >12m
Time setting("AUTO “induction trigger):
10sec/night, 60sec/10lux
Induction working time(manual trigger ON:constant): >4hours
Working time (No manual trigger ON): >8hours
Detection angle: 140°/120°
Coverage: 180º sensing angle
Working temperature: -15~+40℃
Charge temperature (solar charge): <60℃
Charge requirement and time (solar charge): >6000lux, 8hours
Primary charge time(use power adapter to charge): >15hours

Sensor information
Detection range Detection angle Detection angle
>12m 140° 120°
Application and attentions
1. The procedure of application
2. The way of charging
Considering of the loss of the quantity of electricity of inner battery in the process of production and
long-playing transportation, so we would better charge up the battery before operation. The primary charge
time should over 15 hours, in this way, it will help the battery recover fully and increase the life of battery.
When taking the product from packing box，firstly, we
should press "ON" once in order to test whether the light is ok
or not. If you just see the LED indicator light is working not
whole light system, we can confirm the quantity of electricity
of inner battery is not enough and should start to charge
immediately.Here can we recommend we would better
connect up the charger ，in this way, we can test whole light
system. When it works normally，you can charge as you
test the function according to the instruction. The Detailed
procedure of operation as follow.
There are two ways: one is direct charging using sun, the other is to use the power adapter to charge.
Considering of the unsure luminance of sun and the significance of first charge, we recommend we would
better use the power adapter to finish the first charge.
ON OFFAUTO
Night work
model indicator
PIR
sensor
Induction test
Press the “AUTO” once and the light will turn on, and then fully cover the lens with towel or other thicker
paper (the instruction of the product is ok), we will find the light will turn off automatically after approx.10sec,if
you take away the towel or other covering，the light will turn on automatically. Next cover and take away will
repeat the process ,we call it the short time test and it has no any requirement to the ambient light.If you hope
it to work in night, you can press the “AUTO” again, and then you will see the LED indicator light located in
the side of it will start to work, after approx.2sec, the indicator light will be off automatically, and then the
product has been under night mode, at this time, you could place the product in a environment where the
luminance is below 10lux, and then the sensor starts to work and you will find the light switches on. In this
period, people must keep far away from the detection zone, the light will be auto off through the 60sec
delay-time. Any movement detected before this time elapse will re-start the timer. If detect the movement
exist in whole process, the light will keep on at all times.

Reasonable application
Attention: only when the luminance is below 10lux, the product can work under night mode.
Therefore, we have to keep it away from the environment where he luminance is above 10lux such as
some places where the street-light or other rays can make a direct beam.
A. Please keep the whole back of product flat under sun to charge.
B. Please keep the whole back of product fully to aim at the sun to charge.
C. Please hang the product on no opaque glass window and keep the whole back face to the sun to charge.
A way is optional and convenient and is recommended to use.
B way: please be sure that the whole front of product fully aim at the sun, in this way, the product will get
much more energy.
C way: when use the C way, please check whether enough and ideal sun to radiate into the user environment
or not, also check the glass window is no opaque or not, otherwise, the affection of charging is bad and the
long-time inadequate charging will seriously affect the life of battery.
1. The procedure of application
Charge
A B C
When the sun is not enough or the electric quantity has run out or when the use worry the electric quantity
and want to supplement，we can charge up the battery using the power adapter adherent to the product.
LX- SLL136L can be used as a charge power supply. When your electric quantity of mobile phone or camera
has run out in camping or travelling, you can take the LX- SLL136L as a power supply to supply electric
quantity to these compact electronic products only by a exchanging connection wire, also charge up them. In
some emergent conditions, with its help, you can recover the communication and maybe save your life.
Put on three times "OFF" button, the product foreign equipment 5 V output voltage, and then press "OFF"
key will stop charging foreign equipment, "ON" button and "AUTO" key function is still effective.
2. Charge using the power adapter
3. Charge up other equipments

The scope of application
Due to the light and thin design of LX- SLL136, so it is an ideal solar energy remove light and is widely used
in field trip，camping, Night repair lighting of car. Considering the feature of solar energy battery, it will be
much fitter in some country where the sun is enough.
LX-SLL136L also has the warning function, press on three times "ON" button to enter warning state.
When you press one time "AUTO" button , press two times "ON" button, this product enter the alarm
condition, induction to human body moves in the light of the pearl shine, have warning role. Press the "OFF"
button to cancel the alarm condition.
This product is used for remote for help and warning, flashing lights low power consumption, ensure products
work long time continuous.
press three times press one
time press two
times cancel the alarm condition.
flashing
10LUX 60°
Problems and solutions
1. The product doesn’t work:
The whole light doesn’t work when press “ON”.
Firstly, we should check whether the LED indicator blinks or not, if you don’t see the whole light work but
the LED indicator only works, and then we can confirm the electric quantity of inner battery has dropped
to the lower limit value should supplement the electric quantity.

No any response appears when press “ON” .
We should try to charge up the product for 5minutes by the power adapter when there is no any response
with pressing the “ON”, afterwards, press the “ON” again to check whether there is response or not . If
there is response, we can be sure the previous phenomenon is caused by the inner battery that has run
out ，we need to recover the electric quantity and make sure the charging time over 15 hours.

2. The sensor sensitivity is low:
3. The product works all times in day and night:
In night work mode, critical masses of light-control LUX maybe result in low sensor sensitivity. At this time,
please place the product in a dark place to adjust, till the product works normally.
Excess temperature also can lower the sensor sensitivity of human .When the ambient temperature
exceeds 30℃,the sensitivity will start to drop. The higher the temperature, the lower the sensitivity,
therefore, we should pay more attention to the law.
The state usually result from the improper operation. For example, set the product in the AUTO mode that
called short time sensor mode in day. At this moment, we should press “AUTO” once again, you will find
the LED indicator located in side lights and auto off through 2sec, and then the night mode starts to turn
on .The light will automatically come into the sensor mode with the setting value taking on, when human
left the detection zone approximately 60sec, it will be off automatically.



4. The sensor cannot automatically shut off the lamp:
5. Charge up the light and directly charge up exterior equipments:
Please be sure the function knob is set in “AUTO” and there is no any human movement in the detection
zone, through a long time, if the light is not always auto off, please move the light to another place to
adjust .However, the same states will take on again, we can more or less believe the light is off normal,
otherwise, the strong disturb existing around the light can lead the sensor to make a wrong induction and
lead the light not to be auto off. User could find out the cause according above method.
Charge up the light by power adapter.
Charge up the LX-SLL136L by power adapter, if not charging normally, firstly, we should check if the
connection between the adapter and connection wire is good . Meanwhile, insert the plug cord into the
light and check whether the red LED indicator blinks. If the indicator light doesn’t blink, maybe the plug
cord or adapter is not connected normally, or the power adapter has been bad.
Directly charge up exterior equipments by the product.
When directly charge up exterior equipments by the product, we should assure the connection between
power convert wire and the product that be charged is very well. If not charging, please check whether the
connection is good or not, also check if the charging indicator position of these products charged is in the
condition of charging. We believe it will normally charge up exterior equipments as long as all connections
are ok!
Special notes: Please avoid some places where the air temperature near the sensor lamp change
obviously, also can find some electrical sparkle electromagnetic interference around it, they maybe lead
the product to come into a wrong induction.


1. Please keep the LX-SLL136L away from the rainwater that will cause the inner circuitry to damage.
2. Please keep the photovoltaic panel face to the sun when charge up the product，because the glass and
other transparent Materials can obstruct the energy from sun and will extend to charge up the product.
3. The product shouldn’t be used in the zones the air temperature changes obviously: for example, air
conditioning and air heating.
Notes
Warning!
● Please confirm with prefessional installation.
● For safety purposes, please cut off power before installation and removal operations.
● Any losses caused by improper operation,the manufacturer does not undertake any
responsibility.
We are committed to promoting the product quality and reliability, however, all the
electronic components have certain probabilities to become ineffective, which will
cause some troubles. When designing, we have paid attention to redundant designs
and adopted safety quota to avoid any troubles.
This instruction, without our permission, should not be copied for any other purposes.
