Revised 09/29/14
536-912C instructions continued…
1. Place one End Unit flush beside Center Unit so that holes on side of Center Unit align with holes on side
of End Unit.
2. Position insert nut (E) in hole on side of End Unit (Diagram 1). Use one Allen wrench (C) to hold insert
nut stationary. At the same time, use other Allen wrench (C) to tighten 1” bolt (D) into insert nut. Do not
fully tighten bolt at this time. Repeat this step for other (5) insert nuts/bolts to assemble End Unit to
Center Unit.
3. Repeat steps 1 and 2 for other End Unit on other side of Center Unit. Now securely tighten all bolts on
both sides of Center Unit.
4. Carefully lay assembled Center/End Units on its back on a non-marring surface. Place Base Frame on
bottom of assembled Center/End Units so that holes in Base Frame align with holes in bottom of
Center/End Units. (Diagram 2)
5. Use Allen wrench (C) to assemble Base Frame to Center Unit with (4) 1-3/4” bolts (B). Do not fully
tighten bolts at this time.
6. Use Allen wrench (C) to assemble Base Frame to End Units with (18) 3-3/4” bolts (F). Securely tighten
all bolts including bolts from step 5.
7. Insert bolted end of Center Leg (H) into hole in middle of bottom side of Base Frame. Twist center leg
clockwise until tight. Return assembled entertainment center to an upright position.
8. Place Top Panel on top of assembled Center/End Units so that holes in Top Panel align with holes in
Top Frame.
9. Use Allen wrench (C) to assemble Top Panel to Top Frame with (10) 1-3/4” bolts (B) across front and
ends and (8) 2-3/8” bolts (G) across back (Diagram 3). Securely tighten all bolts.
10. Position door panels on guide and track so that doors slide smoothly. Use Allen wrench (C) and Phillips
screwdriver to adjust sliding doors (Diagram 4).
11. Adjustable shelves are secured with screws through shelf supports on each end to stabilize them during
shipping (Diagram 5). To adjust shelves, remove screws from shelf supports (underneath shelf) with a
small Phillips head screwdriver. Shelf can then be lifted out, support moved to appropriate position, and
shelf replaced. Use screwdriver to replace screws through shelf supports and into bottom of shelf.
12. Connect male power plug to female power plug (Diagram 6) on back side of assembled entertainment
center.
13. Connect female harness to male harness (Diagram 7) on back side of assembled entertainment center.
14. Plug in male power cord at bottom of entertainment center to power source.
15. Place case in desired location. Use separate leveling instructions to level case.
For additional consumer assistance please contact your Lexington dealer or call our
Consumer Services Department at 1-336-474-5300, Monday-Friday, 8-5 Eastern Page 2 of 2
