Lexmark C912 User manual

C912
Setup Guide
March 2003
www.lexmark.com

English

Edition: March 2003
The following paragraph does not applyto any countrywhere such
provisions are inconsistent with local law: LEXMARK
INTERNATIONAL, INC., PROVIDES THIS PUBLICATION “ASIS”
WITHOUTWARRANTYOFANYKIND,EITHEREXPRESSORIMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
Some states do not allow disclaimer of express or implied warranties in
certain transactions; therefore, this statement may not apply to you.
This publication could include technical inaccuracies or typographical
errors. Changes are periodically made to the information herein; these
changes will beincorporated in later editions. Improvements orchanges
in the productsor the programs described may be made at anytime.
Comments about this publication may be addressed to Lexmark
International, Inc., Department F95/032-2, 740 West New Circle Road,
Lexington, Kentucky 40550, U.S.A. In the United Kingdom and Eire, send
to Lexmark InternationalLtd., Marketing and Services Department,
Westhorpe House, Westhorpe, Marlow Bucks SL7 3RQ. Lexmark may
use or distribute any ofthe information you supply in any way it believes
appropriate without incurring any obligation to you. You can purchase
additional copies of publications relatedto this product bycalling 1-800-
553-9727. In the United Kingdom and Eire, call [phone]. In
other countries, contact your point of purchase.
References in this publication to products, programs, or services do not
implythatthemanufacturer intendsto maketheseavailable inallcountries
in which it operates. Any reference toa product,program, or service is not
intended to state or imply that only that product, program, or service may
be used. Any functionally equivalent product, program, orservice that
does not infringe any existing intellectualproperty right may be used
instead. Evaluation and verification of operation inconjunction with other
products, programs,orservices,exceptthose expresslydesignatedbythe
manufacturer, are the user’s responsibility.
Lexmark, Lexmark with diamond design, and MarkNet are trademarks of
Lexmark International,Inc., registered in the United States and/or other
countries.
ImageQuick is a trademark of Lexmark International, Inc.
PostScript® is a registered trademarkof Adobe Systems Incorporated.
PostScript 3 is Adobe Systems’ designation of a set of printer commands
(language) and functions included in its software products. This printer is
intended to be compatible with the PostScript 3 language. This means the
printer recognizes PostScript 3 commands used in various application
programs,and thatthe printeremulatesthe functionscorrespondingtothe
commands.
Other trademarks are the property of their respective owners.
©2003 Lexmark International, Inc.
All rights reserved.
UNITEDSTATES GOVERNMENT RIGHTS
This software and any accompanying documentation provided under this
agreement are commercial computer software and documentation
developed exclusively at private expense.
FCC emissions information
This printercomplies with thelimits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. Operationis subject to the followingtwo
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Any questions on thisstatement should be directed to:
Director of Lexmark Technology & Services
Lexmark International,Inc.
740 West New Circle Road
Lexington, KY 40550
[phone]
Refer to the online documentation for additional compliance information.
Safety information
• The power cord mustbe connected to a properly grounded
electrical outlet that is near the product and easily accessible.
CAUTION: Do not set up this product or make any electrical or
cabling connections, such as the power cord or telephone,
during a lightning storm.
• Refer service or repairs, other than those described in the
operating instructions, to a professionalservice person.
• This product isdesigned, tested, and approved to meet strict
global safety standards with the use ofspecific Lexmark
components. The safety featuresof some parts may not always
be obvious. Lexmark isnot responsible for the use ofother
replacementparts.
• Your product uses a laser.
CAUTION: Use of controls or adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
• Your product uses a printing process that heats the print media,
and the heat may cause the mediato release emissions. You
must understand the section in your operating instructions that
discusses the guidelines for selecting print mediato avoid the
possibility of harmful emissions.
Conventions
It may help you to recognize the caution, warning, and note conventions
used in this book. These appear in the left column for easy reference.
CAUTION: Acaution identifies something thatcould cause you harm.
Warning: A warning identifies something that could damage your printer
hardware or software.
Note: Anote provides information you may find useful.
Attention!
This symbol identifies static-sensitive parts. Do not touch in
the areas near these symbols without first touching the
metal frame of the printer.

Contents
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
About your printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Other sources of information . . . . . . . . . . . . . . . . . . . . . . . . . ix
Unpack your printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Select alocation for your printer . . . . . . . . . . . . . . . . . . . . .2
Considering environmentalissues . . . . . . . . . . . . . . . . . . . . . .2
Allowing enough space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Set up the printer and paper handling options . . . . . . . . . .4
Installing the printer base or cabinet . . . . . . . . . . . . . . . . . . . . .5
Installing a 550-sheet drawer . . . . . . . . . . . . . . . . . . . . . . . . . .5
Positioning the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Installing an optional heavy media tray . . . . . . . . . . . . . . . . . . .7
Installing an optional duplex unit . . . . . . . . . . . . . . . . . . . . . . . .8
Installing an optional high capacity feeder . . . . . . . . . . . . . . .10
Attaching the paper tray labels . . . . . . . . . . . . . . . . . . . . . . . .16
Install printer supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Opening the top cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Installing the fuser oil coating roll . . . . . . . . . . . . . . . . . . . . . .20
Installing the photodevelopers . . . . . . . . . . . . . . . . . . . . . . . .22
Installing the toner cartridges . . . . . . . . . . . . . . . . . . . . . . . . .24
Attaching an adhesive operator panel overlay. . . . . . . . . . . .27
Closingthe top cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Contents
v

Install memory and option cards . . . . . . . . . . . . . . . . . . . .29
Removing the system board access cover . . . . . . . . . . . . . . .29
Installing a memory card . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Installing a firmware card . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Installing a hard disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Installing an option card . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Reinstalling the system board access cover . . . . . . . . . . . . . .37
Load paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Loading the paper trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Loading the multipurpose feeder . . . . . . . . . . . . . . . . . . . . . .45
Loading the high capacity feeder . . . . . . . . . . . . . . . . . . . . . .48
Attach cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Attaching a local cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Attaching a network cable . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Turning on the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Install drivers for local printing . . . . . . . . . . . . . . . . . . . . . .54
Windows .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
UNIX/Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Serial connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Verify printer setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Printing a menusettings page . . . . . . . . . . . . . . . . . . . . . . . .64
Printing a network setup page . . . . . . . . . . . . . . . . . . . . . . . .64
Configure for TCP/IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Assigning a printer IP address . . . . . . . . . . . . . . . . . . . . . . . .66
Verifying the IP settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Configuring for Pull Printing . . . . . . . . . . . . . . . . . . . . . . . . . .67
Contents
vi

Install drivers for network printing . . . . . . . . . . . . . . . . . . .68
Windows .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
UNIX/Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
NetWare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Using the publications CD . . . . . . . . . . . . . . . . . . . . . . . . . .71
Viewing and using the CD contents . . . . . . . . . . . . . . . . . . . .71
Statement of limited warranty . . . . . . . . . . . . . . . . . . . . . . .72
Contents
vii

Introduction
About your printer
Your printer is available in three models:
To customize yourLexmark C912 printer,
you can purchase a variety of input
options, including a high capacity feeder.
Ifyoupurchasedafinisher togo withyour
printer, refer to the documentation that
came with the finisher for information
about setting it up with the printer.
High capacity
feeder
(see page 10)
Printer base
(see page 5)
Printer
(see page 6)
550-sheet
drawers
(see page 5)
Duplex unit
(see page 8)
•Lexmark C912 (base model)
•
•
– 2400 IQ resolution
– 128MB of standard memory
– One 550-sheet tray,
multipurpose feeder
– USB and parallel connectors
Lexmark C912n (network model)
– 256MB of standard memory
– One additional 550-sheetdrawer
– Ethernet 10BaseT/100BaseTX
print server installed
– USB and Ethernet connectors
Lexmark C912dn(duplex network)
– Duplex unit
– All features of the network model
Introduction
viii

Other sources of information
Publications CD
Quick Reference and Clearing Jams sheets
Drivers CD
Lexmark’s Web site
The publications CD provides
information about loading paper, clearing
error messages, ordering and replacing
supplies,installing maintenance kits,and
troubleshooting.It also provides general
information for administrators.
The information onthe CD is also
available onthe Lexmark Web site at
www.lexmark.com/publications.
The Quick Reference and Clearing Jams
sheets provide easy access to
information about loading print media,
understanding common printer
messages, and clearing paper jams.
The drivers CD contains all the
necessary files to get your printer up and
running. It may also contain printer
utilities, screen fonts,and additional
documentation.
Visit our Web site at www.lexmark.com
for updated printer drivers, utilities, and
other printer documentation.
Introduction
ix

Step 1: Unpack your printer
CAUTION: The baseprinter weighs80.5 kg(177 Ib)and Remove allitems from the box except the
requires at least four people to lift it safely.Anytime you printer.Make sure you have the following
moveor lift the printer makesure you have enough people items:
to help you. Use the handholds on the side of the printer (1) Printer
whenlifting. (2) Four toner cartridges
Note: Leave the printer in the box until you are ready to (3) Four photodevelopers
8 7
1
place it into position. (4) Fuser oil coating roll
(5) Quick Reference and
9 Clearing Jams sheets
(6) Setup Guide
(7) Publications CD
(8) Drivers CD
(9) Power cord
If any items are missing or damaged,
2 refer to thepublications CD for
information about contacting Lexmark
Customer Support.
Save the carton and packing materials in
case you need to repackthe printer.
6
5
4
3
Unpack your printer
1

Step 2: Select a location for your
printer
Considering
environmental
issues
Note: Adequate ventilation
is important if you expect to
print high volumes of
materials orprint
continuously.
Allowingenough
space
Choosing the correct location for your new Lexmark C912 printer is
vital to ensuring the printer provides you with the quality of service you
expect.
When choosing a place to set up the printer, look for:
• A firm, level surface
• An area that is:
– Well ventilated
– Clean, dry, and free of dust
– Away from direct sunlight
– Free oftemperature or humidity extremes or fluctuations
– Away from the direct airflow of heaters, airconditioners, or
ventilators
When choosing a place to set up your printer, allow enough space for
the printer and any options you mayhave purchased. Allowspace for
proper ventilation around the printer.
Select a location for your printer
2

When selecting a location for the base model, makesure you have at
least the amount of space indicated inthe figure.
660.4 mm
(26 in.)
1498.6 mm
(59 in.) 1181.1 mm
(46.5 in.)
740.6 mm
(29.1 in.)
127 mm
(5 in.) 152.1 mm
(6 in.)
330.2 mm
(13 in.)
Space and clearance requirements change depending on the printer
model. See the table below for the requirements for your model.
Space and clearance requirements
Model Leftside Right side Total height* Total width* Total depth*
Lexmark C912 (base) 330.2 mm
(13 in.) 152.4 mm (6 in.) 740.6 mm (29.1 in.) 1181.1 mm (46.5 in.) 1498.6 mm (59 in.)
Lexmark C912n (network) 152.4 mm
(6 in.) 869.6 mm (34.2 in.) 1181.1 mm (46.5 in.)
Lexmark C912dn (duplex network) 330.2 mm
(13 in.) 869.6 mm (34.2 in.) 1355.4 mm (53.4 in.)
Lexmark C912 with a high
capacity feeder 762 mm (30 in.) 1384.3 mm (54.5 in.) 1787.2 mm (70.4 in.)
*Includes the printer and any standard options for that model.
Select a location for your printer
3

Step 3: Set up the printer and
paper handling options
If you only purchased a base printer with
no options, follow the directions under
“Positioning the printer”on page 6.
Note: Be sure to set up the items in the orderlisted in the Usethefollowingtabletolocate thesetup
table. instructions for your printer and any
paper handling options you may have
purchased.
Topic Go to page...
Installing the printer base or cabinet 5
Installing a 550-sheet drawer 5
Positioning the printer 6
Installing an optional duplex unit 8
Installing an optional high capacity feeder 10
Set up the printer and paper handling options
4

Installing the printer base orcabinet
Installing a 550-sheet drawer
You can purchase an optional printer
cabinet or printer base.
To install the printer cabinet or printer
base:
1 Remove the cabinetor base from
the box.
2 Remove all packing material.
3 Follow the instructions that came
withthe optionto assemble or
prepare the cabinet or base for
installation.
4 Place the cabinet or base in the
location you have chosen for your
printer.
Your printer supports up to three optional
550-sheet drawers.
1 Unpack the 550-sheet drawer and
remove any packing material.
2 Place the 550-sheet drawer in the
location you have chosen, on the
optional printer cabinet, or on the
optional printer base.
Carefully align the positioning
posts on the cabinet or base to the
holes in the 550-sheet drawer.
Set up the printer and paper handling options
5

3 If you have additional 550-sheet
drawers:
Positioning the printer
CAUTION: The baseprinter weighs 80.5 kg (177 Ib)and
requires at least four people to lift it safely.
a
b
c
Align the positioning posts on
the lower drawerwith the holes
in the 550-sheet drawer.
Lower the 550-sheet drawer
into place. Seat it securely on
the other drawer.
Repeat steps a and b for each
additional drawer.
You are ready to position the printer.
1 Have three other people help you
lift the printer.
Use the handholds on the sides of
the printer.
Set up the printer and paper handling options
6

Installing an optional heavy media
tray
2 Have three other people help you
place the printer in the chosen
location.
If you are installing the printer on a
550-sheet drawer,align the
positioningposts onthe drawer
withthe holes in the printer. Seat
the printer securely on the drawer.
3 Remove any tape or packing
material.
Your printer supports an optional heavy
media tray. Touse this tray, simply
remove the standard tray that came with
the printer (Tray 1) and replace it with the
heavy media tray. Store the standard tray
in the boxthe optional tray came in.
Set up the printer and paper handling options
7

Installing an optional duplex unit
Note: Refer to the publications CD for information about
the types and sizes of paper the duplex unit supports.
Your printer supports an optional duplex
unit that provides two-sided printing.
1 Remove the duplexunit from its
packing material.
2 Remove any shipping tape and
additional packing material.
3 Open the duplex unit access door
on the leftside of the printer.
Set up the printer and paper handling options
8

4 Align the duplexunit withthe slots
in the printer.
5 Slide inthe duplexunit.
6 Align the thumbscrews on the
duplexunit with the holes in the
printer.
7 Tighten the thumbscrews.
8 Close the duplexunit door.
Set up the printer and paper handling options
9

Installing an optional high capacity
feeder
Note: You must have an optional printer cabinet with one
optional drawer or an optional printer stand with three
optional drawers in order to install a high capacity feeder.
1 2 3
4 5 6
7 8 9
Your printer supports an optional high
capacity feeder. You can load up to 3,000
sheets of letter or A4 size paperin the
high capacity feeder.
Remove and unpackall items from the
box. Make sure you have the following
items:
(1) High capacity feeder
(2) Docking frame
(3) Guide rail
(4) Interface cable
(5) Power cord
(6) Four docking frame screws
(7) Cable holder
(8) Eight height adjustment spacers
(9) Wrench
If any items are missing or damaged,
refer to thepublications CD for
information about contacting Lexmark
Customer Support.
Make sure the printer power switch is Off.
Set up the printer and paper handling options
10

Attaching the docking frame 1 Remove the two side covers from
the top 550-sheet drawer.
You may need to use a small
flathead screwdriver to pry the
covers up and outward.
2 Insert two screws through the top
screw holes of the docking frame
as shown.
3 Use the wrench to tighten the
screws.
4 Insert two screws through the
bottom screw holes of the docking
frame as shown.
5 Tighten the screws.
6 Place the wrench in the holder on
the high capacity feeder.
Set up the printer and paper handling options
11
