Lexmark 34S0109 - E 260dt B/W Laser Printer Service manual

E260, 260d/dn, E360d/dn,
E460dn/dw, X203n MFP, X204n
MFP
Technical Reference
February 2010 www.lexmark.com
Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries.
All other trademarks are the property of their respective owners.
February 2010
All rights reserved.
740 West New Circle Road
Lexington, Kentucky 40550

Edition notice
February 2010
The following paragraph does not apply to any country where such provisions are inconsistent with local law: LEXMARK INTERNATIONAL,
INC., PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,
THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or
implied warranties in certain transactions; therefore, this statement may not apply to you.
This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these
changes will be incorporated in later editions. Improvements or changes in the products or the programs described may be made at any time.
References in this publication to products, programs, or services do not imply that the manufacturer intends to make these available in all countries
in which it operates. Any reference to a product, program, or service is not intended to state or imply that only that product, program, or service
may be used. Any functionally equivalent product, program, or service that does not infringe any existing intellectual property right may be used
instead. Evaluation and verification of operation in conjunction with other products, programs, or services, except those expressly designated by
the manufacturer, are the user’s responsibility.
For Lexmark technical support, visit support.lexmark.com.
For information on supplies and downloads, visit www.lexmark.com.
If you don't have access to the Internet, you can contact Lexmark by mail:
Lexmark International, Inc.
Bldg 004-2/CSC
740 New Circle Road NW
Lexington, KY 40550
USA
February 2010
All rights reserved.
Trademarks
Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries.
PCL® is a registered trademark of the Hewlett-Packard Company.
All other trademarks are the property of their respective owners.
UNITED STATES GOVERNMENT RIGHTS
This software and any accompanying documentation provided under this agreement are commercial computer software and documentation
developed exclusively at private expense.

Contents
Edition notice......................................................................................2
Introduction........................................................................................5
Understanding letters after model numbers...............................................................................................................5
Learning about the printer...............................................................6
Finding information about the printer...........................................................................................................................6
Printer Control Language (PCL) page formatting........................7
Printable areas.........................................................................................................................................................................7
Supported paper and envelope dimensions...............................................................................................................8
Printer Job Language (PJL).............................................................11
PJL commands information.............................................................................................................................................11
PostScript (PS) emulation...............................................................12
Paper sizes supported........................................................................................................................................................12
PostScript paper tray support.........................................................................................................................................13
PostScript envelope size support..................................................................................................................................14
PostScript envelope tray support..................................................................................................................................15
Printer specifications......................................................................17
Airflow requirement...........................................................................................................................................................17
Noise emission levels.........................................................................................................................................................17
Electrical specifications.....................................................................................................................................................18
Power requirements...........................................................................................................................................................18
Physical specifications.......................................................................................................................................................19
Clearance requirements....................................................................................................................................................20
Environmental conditions................................................................................................................................................20
Altitude specifications and atmospheric pressure..................................................................................................21
Appendix A: PCL support.................................................................22
PCL emulation commands...............................................................................................................................................22
GL/2 commands...................................................................................................................................................................28
Contents
3

Appendix B: PJL support.................................................................32
Common variables for both printer languages........................................................................................................32
Printer-unique PJL variables for both printer languages......................................................................................34
Common variables for PCL emulation.........................................................................................................................44
Printer-unique variables for PCL emulation...............................................................................................................44
Common variables for PostScript emulation............................................................................................................45
Printer-unique variables for PostScript emulation..................................................................................................45
Printer-unique LRESOURCE variables...........................................................................................................................46
Status Readback commands...........................................................................................................................................46
USTATUS unsolicited status variables..........................................................................................................................46
PJL messages for auto-continuable conditions........................................................................................................47
PJL messages for attendance conditions....................................................................................................................53
PJL messages for paper handling..................................................................................................................................68
PJL messages for paper jams...........................................................................................................................................70
Service errors.........................................................................................................................................................................77
Device attendance messages..........................................................................................................................................77
Lexmark-unique PJL commands....................................................................................................................................78
File and device protection commands........................................................................................................................79
Appendix C: PostScript support.....................................................80
Supplemental operators...................................................................................................................................................80
Page device parameters....................................................................................................................................................83
User interpreter parameters............................................................................................................................................88
System interpreter parameters.......................................................................................................................................89
Devices supported..............................................................................................................................................................92
Device parameters..............................................................................................................................................................94
PostScript message keys commands.........................................................................................................................104
Index.................................................................................................105
Contents
4

Introduction
Overview
This edition of the Technical Reference contains information about the following printers or multifunction printers
(MFPs):
E260
E260d
E260dn
E360d
E360dn
E460dn
E460dw
X203n MFP
X204n MFP
Understanding letters after model numbers
Some Lexmark printers may have one or more letters after the model name to indicate printer features:
Acronym Meaning
dduplex1
ee-Task (electronic task) touch-screen interface
ffinisher/stapler
hhigh-capacity drawer
mmailbox
nnetwork
tadditional tray2
tt tandem tray module
wwireless
1Duplex printing (two-sided printing) accomplished by means of an optional duplex unit or an internal duplex unit based
on the product.
2The additional tray is part of a drawer.
Introduction
5

Learning about the printer
Finding information about the printer
Setup information
Description Where to find
The Setup information gives you instructions for setting
up the printer. Follow the set of instructions for local,
network, or wireless, depending on what you need.
You can find the Setup information on the inside of the printer
box or on the Lexmark Web site at www.lexmark.com.
Help
Description Where to find
The Help gives you instructions for using the software. While in any Lexmark software program, click Help, Tips >
Help, or Help > Help Topics.
Customer support
Description Where to find (North America) Where to find (rest of world)
Telephone support Call us at
•US: 1-800-332-4120
Monday–Friday (8:00 AM–11:00 PM ET)
Saturday (Noon–6:00 PM ET)
•Canada: 1-800-539-6275
Monday–Friday (8:00 AM–11:00 PM ET)
Saturday (Noon–6:00 PM ET)
•Mexico: 001-888-377-0063
Monday–Friday (8:00 AM–8:00 PM ET)
Note: Telephone numbers and support times
may change without notice. For the most recent
telephone numbers available, see the printed
warranty statement that came with your printer.
Telephone numbers and support hours vary by
country or region.
Visit our Web site at www.lexmark.com. Select
a country or region, and then select the
Customer Support link.
Note: For additional information about
contacting Lexmark, see the printed warranty
that came with your printer.
E-mail support For e-mail support, visit our Web site:
www.lexmark.com.
1Click SUPPORT > Technical Support > your
printer type >your printer model.
2From the Support Tools section, click e-Mail
Support.
3Complete the form, and then click Submit
Request.
E-mail support varies by country or region, and
may not be available in some instances.
Visit our Web site at www.lexmark.com. Select
a country or region, and then select the
Customer Support link.
Note: For additional information about
contacting Lexmark, see the printed warranty
that came with your printer.
Learning about the printer
6

Printer Control Language (PCL) page
formatting
For more information on PCL, refer to the Printer Languages and Interfaces Technical Reference. It contains a complete
listing with descriptions of PCL commands.
To determine which PCL commands your printer supports, see “Appendix A: PCL support” on page 22.
Printable areas
The printable areas and logical pages for PCL emulation (both portrait and landscape orientation) are illustrated
below. See the legend that follows for definitions of areas Athrough I.
Legend:
APortrait physical page width and landscape physical page length
BPortrait physical page length and landscape physical page width
CPortrait logical page width
DLandscape logical page width
EDistance between the side edge of the physical page and the logical page in portrait
FDistance between the side edge of the physical page and the logical page in landscape
GDistance between the top and bottom edge of the physical page and logical page
HDistance between the left and right edge of the physical page and the printable area in portrait, or distance between
the top and bottom edge of the physical page and printable area in landscape
Printer Control Language (PCL) page formatting
7

Legend:
IDistance between the top and bottom edge ofthe physical page and the printable area in portrait, or distance between
the left and right edge of the physical page and the printable area in landscape
Note: The tables that follow in this chapter list the page sizes and dimensions of each area labeled on the preceding
diagram for all paper and envelope sizes your printer supports.
Supported paper and envelope dimensions
The following table lists the page sizes and print area dimensions for all supported paper and envelope sizes. For
more information about the printable areas and logical pages for PCL emulation, see “Printable areas” on page 7.
Selection Paper/envelope
dimensions
Dimensions by area (pels)1
Page
size
param
eters2
Name mm inches A B C D E F G H I
Paper
13, 613 A5 148 x 2
10
5.83 x 8.
27
3496 4960 3196 4720 142 118 0100 100
12, 45,
612
JIS B5
Paper
182 x 2
57
7.2 x 10.
1
4300 6070 4000 5830 150 120 0100 100
26, 626 A4 (198
mm)3
210 x 2
97
8.3 x 11.
7
4960 7014 4676 6778 142 118 080 100
26, 626 A4 (203
mm)3
210 x 2
97
8.3 x 11.
7
4960 7014 4800 6778 80 118 080 100
24 A6 148 x 1
05
5.8 x 4.1 2480 3496 2196 3260 142 118 0100 100
1, 601 Executi
ve
184 x 2
67
7.25 x 1
0.5
4350 6300 4050 6060 150 120 0100 100
2, 602 Letter 216 x 2
79
8.5 x 11 5100 6600 4800 6360 150 120 0100 100
1Pel dimensions are for 600 dpi.
2Page Size Parameters are explained in the Page Control table in the PCL chapter in the Printer Language and Interfaces
Technical Reference.
3The width of the logical page for A4 paper can be changed from the printer control panel or your software application.
4For the Universal paper size, the area dimensions are listed in pel ranges.
5Paper ID 99 will be supported for backward compatibility with other Lexmark printers. Paper ID 99 has the same logical
paper size as ID 100 (compatible with HP LaserJet 5Si/5SiMx) but is 8 pels wider than the Lexmark 4039.
6This dimension applies only to the Lexmark X203n MFP and X204n MFP.
7This dimension applies only to the Lexmark E260, E260d/dn, E360d/dn, and E460dn/dw.
Note: The explanation of the printable area assumes the Print Area menu item is set to Normal. For more information,
see “Print Area Menu Item” in the PCL chapter in the Printer Language and Interfaces Technical Reference.
Printer Control Language (PCL) page formatting
8

Selection Paper/envelope
dimensions
Dimensions by area (pels)1
Page
size
param
eters2
Name mm inches A B C D E F G H I
3, 603 Legal 216 x 3
56
8.5 x 14 5100 8400 4800 8160 150 120 0100 100
4 or 10 Folio 216 x 3
30
8.5 x 13 5100 7800 4800 7560 150 120 0100 100
15 Statem
ent
139.7 x
215.9
5.5 x 8.5 3300 5100 3000 4860 150 120 0100 100
101 Univers
al
216 x 3
56
8.5 x 14 1800-
51004
1800-
85024
1500-
48004
1500-
82624
150 120 0100 100
300 Oficio
(Mexic
o)
216 x 3
40
8.5 x 13.
4
5100 8040 4800 7800 150 120 0100 100
Envelope
90 DL 220 x 1
10
8.66 x 4.
33
2598 5196 2314 4960 142 118 0100 100
91 C5 229 x 1
62
9.02 x 6.
38
3826 5408 3542 5172 142 118 0100 100
995,
100
B5
Envelo
pe
250 x 1
76
9.84 x 6.
93
4156 5904 3872 5668 142 118 0100 100
600 Other
Envelo
pe
216 x 3
56
8.5 x 14 5100 8400 4800 8160 150 120 0100 100
89 9 (Com
9)
225 x 9
8
8.875 x
3.875
23266
/23247
5324 2024 5084 150 120 0100 100
81 10
(Com
10)
241 x 1
05
9.5 x 4.1
25
2474 5700 2174 5460 150 120 0100 100
1Pel dimensions are for 600 dpi.
2Page Size Parameters are explained in the Page Control table in the PCL chapter in the Printer Language and Interfaces
Technical Reference.
3The width of the logical page for A4 paper can be changed from the printer control panel or your software application.
4For the Universal paper size, the area dimensions are listed in pel ranges.
5Paper ID 99 will be supported for backward compatibility with other Lexmark printers. Paper ID 99 has the same logical
paper size as ID 100 (compatible with HP LaserJet 5Si/5SiMx) but is 8 pels wider than the Lexmark 4039.
6This dimension applies only to the Lexmark X203n MFP and X204n MFP.
7This dimension applies only to the Lexmark E260, E260d/dn, E360d/dn, and E460dn/dw.
Note: The explanation of the printable area assumes the Print Area menu item is set to Normal. For more information,
see “Print Area Menu Item” in the PCL chapter in the Printer Language and Interfaces Technical Reference.
Printer Control Language (PCL) page formatting
9

Selection Paper/envelope
dimensions
Dimensions by area (pels)1
Page
size
param
eters2
Name mm inches A B C D E F G H I
80 7 3/4
(Monar
ch)
98 x 19
1
3.875 x
7.5
23266
/23247
4510 2024 4260 150 120 0100 100
1Pel dimensions are for 600 dpi.
2Page Size Parameters are explained in the Page Control table in the PCL chapter in the Printer Language and Interfaces
Technical Reference.
3The width of the logical page for A4 paper can be changed from the printer control panel or your software application.
4For the Universal paper size, the area dimensions are listed in pel ranges.
5Paper ID 99 will be supported for backward compatibility with other Lexmark printers. Paper ID 99 has the same logical
paper size as ID 100 (compatible with HP LaserJet 5Si/5SiMx) but is 8 pels wider than the Lexmark 4039.
6This dimension applies only to the Lexmark X203n MFP and X204n MFP.
7This dimension applies only to the Lexmark E260, E260d/dn, E360d/dn, and E460dn/dw.
Note: The explanation of the printable area assumes the Print Area menu item is set to Normal. For more information,
see “Print Area Menu Item” in the PCL chapter in the Printer Language and Interfaces Technical Reference.
Printer Control Language (PCL) page formatting
10

Printer Job Language (PJL)
PJL commands information
Your printer supports complete PJL commands, including certain commands that cause the printer to enter PCL
emulation, PostScript emulation, and Personal Printer Data Stream (PPDS).
For a complete listing with descriptions of PJL commands, see the Printer Languages and Interfaces Technical
Reference.
To determine which commands your printer supports, see “Appendix B: PJL support” on page 32.
Printer Job Language (PJL)
11

PostScript (PS) emulation
Your printer supports complete PostScript emulation supplemental operators. For full descriptions in detail for these
operators, refer to the PostScript emulation chapter in the Printer Languages and Interfaces Technical Reference.
To determine which commands your printer supports, see “Appendix C: PostScript support” on page 80.
Paper sizes supported
= Supported
X = Not supported
Paper sizes Printer models
Size Literal name Size (mm) Size (inches) Size (points) E260, E260d/
dn, E360d/
dn, E460dn/
dw
X203n MFP,
X204n MFP
Letter letter 215.9 x 279.4 8.5 x 11.0 612 x 792
Legal legal 215.9 x 355.6 8.5 x 14.0 612 x 1008
JIS B5 b5* 182.0 x 257.0 7.2 x 10.1 516 x 729
A4 a4 210.0 x 297.0 8.3 x 11.7 595 x 842
Executive executivepage 184.2 x 266.7 7.25 x 10.5 522 x 756
A5 a5 148.0 x 210.0 5.83 x 8.27 419 x 595
Oficio oficio 215.9 x 340.4 8.5 x 13.4 612 x 965
(Lexmark-unique size)
612 x 972 (official
Postscript size)
Folio folio 215.9 x 330.2 8.5 x 13.0 612 x 936
Statement statement 139.7 x 215.9 5.5 x 8.5 396 x 612
A6 a6 105.0 x 148.0 4.13 x 5.83 297 x 419 X
Universal universal 216 x 356 8.5 x 14 612 x 1008
Custom custom 215.9 x 355.6 8.5 x 14.0 612 x 1020 X X
Custom custom 297 x 431.8 11.7 x 17 842 x 1224 X X
Custom custom 320 x 559 12.6 x 22 908 x 1584 X X
Custom custom 297 x 914 11.7 x 36 842 x 2592 X X
* This is a Japanese Industry Standard (JIS) paper size. The same named designation is used by JIS and International
Standards Organization (ISO) for different paper sizes.
PostScript (PS) emulation
12

PostScript paper tray support
When the printer receives one of the operators listed in “Tray selected with tray operators” on page 13, it performs
the actions listed as follows. This paper tray selection process ends as soon as a suitable paper source is chosen and
paper is fed from this tray.
•The printer checks the value of manualfeed in statusdict and the ManualFeed page device parameter. If either
one is true, the printer sends a message to load the requested size in the manual feed tray or multipurpose feeder.
•The PageSize Policy is set to 2 by means of setpagedevice.
•The printer checks the paper size loaded in the current active source to determine if it matches the requested
size. If the sizes match, the paper is fed from the active source.
Note: The current active tray is the last source that was selected from the printer control panel or by the printer
language.
•If the requested size and the size loaded in the active source do not match, the sources are searched in the order
defined by the Priority array in the InputAttributes dictionary in the pagedevice dictionary.
•If the requested media size is not found by the previous search, the following search order is used:
–Tray 1
–Multipurpose Feeder/Manual Feeder
•If the requested size cannot be located in any automatic source, a configurationerror is issued and the job is
flushed.
For printers that support automatic duplexing:
•Automatic duplexing is not supported for custom-size paper or for envelopes in the multipurpose feeder.
Automatic duplexing is supported from the multipurpose feeder for all other papers.
•If the paper source is changed before the back side of a duplexed page prints, a blank back page prints, the paper
source changes, and the information for the back side of the page is printed on the front side of a page sent from
the new paper source.
When these operators are used, it is equivalent to executing the following PostScript emulation sequence:
<< /PageSize [x y]/ImagingBBox null /Policies << /PageSize 2>> >>
setpagedevice
where x y are the PageSize in points.
Tray selected with tray operators
= Supported
X = Not supported Printer models
Operator Tray selected (corresponding image
size is set)
E260, E260d/dn, E360d/dn,
E460dn/dw
X203n MFP, X204n MFP
a3tray tray with A3-size paper X X
a4tray tray with A4-size paper
a5tray tray with A5-size paper
b4tray tray with B4-size paper X X
b5tray tray with B5-size paper
PostScript (PS) emulation
13

= Supported
X = Not supported Printer models
Operator Tray selected (corresponding image
size is set)
E260, E260d/dn, E360d/dn,
E460dn/dw
X203n MFP, X204n MFP
customtray tray with custom-size paper X X
executivetray tray with executive-size paper
foliotray tray with folio-size paper
ledgertray tray with ledger-size paper X X
legaltray tray with legal-size paper
lettertray tray with letter-size paper
oficiotray tray with oficio-size paper
statementtray tray with statement-size paper
11x17tray tray with 11 x 17-inch paper X X
PostScript envelope size support
The literal names in “Envelope sizes supported” on page 14 are also supported as operators in userdict. These
operators change the image size, but do not change the active paper source. Therefore, when these operators are
used, part of the image may be clipped.
When these literal names are used as operators, it is equivalent to executing the following PostScript emulation
sequence. The following example uses a 3.875 x 7.5 envelope.
<</Policies <</PageSize 7>> /PageSize [279 540]>> >>setpagedevice
Envelope sizes supported
= Supported
X = Not supported
Envelope sizes Printer models
Size name Literal name Size (mm) Size (inches) Size (points) E260,
E260d/dn,
E360d/dn,
E460dn/dw
X203n MFP,
X204n MFP
7 3/4 3.875x7.5envelope 98.4 x 190.5 3.875 x 7.5 279 x 540
Commercial 9 3.875x8.875envelope 98.4 x 225.4 3.875 x 8.875 279 x 639
Commercial 10 4.125x9.5envelope 104.8 x 241.3 4.125 x 9.5 297 x 684
International DL 110x220envelope 110 x 220 4.33 x 8.66 312 x 624
* For other envelopes, the page is formatted to 216 x 356 mm (8.5 x 14 in.) unless a size is specified by your software
program.
PostScript (PS) emulation
14

= Supported
X = Not supported
Envelope sizes Printer models
Size name Literal name Size (mm) Size (inches) Size (points) E260,
E260d/dn,
E360d/dn,
E460dn/dw
X203n MFP,
X204n MFP
International C5 162x229envelope 162 x 229 6.38 x 9.01 459 x 649
International B5 176x250envelope 176 x 250 6.93 x 9.84 499 x 708
Other envelope otherenvelope 296.93 x 427.48 11.69 x 16.83 841 x 842 X X
otherenvelope* Other 229.11 x 355.6 9.02 x 14 612 x 996
* For other envelopes, the page is formatted to 216 x 356 mm (8.5 x 14 in.) unless a size is specified by your software
program.
Literal names supported
= Supported
X = Not Supported
Literal names Printer models
Literal name Compatible literal name E260, E260d/dn, E360d/dn, E460dn/dw X203n MFP, X204n MFP
monarchenvelope 3.875x7.5envelope
com9envelope 4.125x9.5envelope
com10envelope 4.125x9.5envelope
dlenvelope 110x220envelope
c5envelope 162x229envelope
b5envelope 176x250envelope X X
PostScript envelope tray support
If manualfeed in statusdict and the ManualFeed page device parameter are false when the printer receives one of
the envelopetray operators listed in “Envelopetray operator selections” on page 16, then the printer:
•Sets the PageSize Policy to 0.
•Checks the active source to see if it matches the requested envelope size. If the sizes match, the envelope is fed
from the active source.
Note: The active source is the last source selected from the printer control panel or data stream.
•If the requested size and the size loaded in the active source do not match, the sources are searched in the order
defined by the Priority array in the InputAttributes dictionary in the pagedevice dictionary.
PostScript (PS) emulation
15

•If the requested size and type are notavailable from anyautomatic source, you areprompted to load therequested
envelope size and type in the manual feed source.
•If the size is still not available, a configurationerror is issued and the print job is flushed.
If manualfeed or ManualFeed is true, the printer prompts you to load the requested size manually. If no manual feed
exists on the printer, a rangecheck error message is generated
The envelope tray the printer selects when it receives an envelopetray operator is listed in “Envelopetray operator
selections” on page 16. These operators are equivalent to executing the following PostScript emulation sequence:
<</PageSize [x y] /ImagingBBox null /Policies<</PageSize 0>> >>
setpagedevice
where x y is the PageSize in points.
Envelopetray operator selections
= Supported
X = Not supported
Tray operators Printer models
Operator Tray selected (Corresponding
image size is set)
E260, E260d/dn, E360d/
dn, E460dn/dw
X203n MFP, X204n MFP
110x220envelopetray tray with 110 x 220 size envelopes
dlenvelopetray tray with 110 x 220 size envelopes
162x229envelopetray tray with 162 x 229 size envelopes
c5envelopetray tray with 162 x 229 size envelopes
176x250envelopetray tray with 176 x 250 size envelopes
b5envelopetray tray with 176 x 250 size envelopes
3.875x7.5envelopetray tray with 3.875 x 7.5 size envelopes
monarcenvelopetray tray with 3.875 x 7.5 size envelopes
3.875x8.875envelopetray tray with 3.875 x 8.875 size
envelopes
4.125x9.5envelopetray tray with 4.125 x 9.5 size envelopes
com10envelopetray tray with 4.125 x 9.5 size envelopes
otherenvelopetray tray with other size envelopes
PostScript (PS) emulation
16

Printer specifications
This chapter lists printer specifications and information about hardware, environmental conditions, and power
requirements.
Airflow requirement
The room should meet ASHRAE 62—1989 standards.
Noise emission levels
The following measurements were made in accordance with ISO 7779 and reported in conformance with ISO 9296.
Status
1-meter average sound pressure, dBA
E260/E260d/E260dn E360d/E360dn E460dn/E460dw X203n X204n
Printing simplex 53 53 53 51 50
Printing duplex 52 52 52 Inapplicable Inapplicable
Scanning Inapplicable Inapplicable Inapplicable 48 50
Copying Inapplicable Inapplicable Inapplicable 48 50
Quiet Mode printing 48 49 49 47 47
Standby (Idle without Power
Saver)
Inaudible Inaudible Inaudible 23 24
Note: Measurements apply to 300-dpi, 600-dpi, and 1200-dpi printing.
Status
Declared sound power level, Bels
E260/E260d/E260dn E360d/E360dn E460dn/E460dw X203n X204n
Printing (simplex and mono) 6.7 6.8 6.7 6.5 6.4
Idle (Standby mode) Inaudible Inaudible Inaudible 3.9 3.9
Scanning Inapplicable Inapplicable 6.2 6.2 6.5
Copying Inapplicable Inapplicable Inapplicable 6.2 6.4
Quiet Mode printing 6.3 6.3 6.3 6.1 6.1
Note: Measurements apply to 300-dpi, 600-dpi, and 1200-dpi printing.
Printer specifications
17

Electrical specifications
E260, E260d/dn, E360d/E360dn, and E460dn/E460dw
Printer model Electrical specification
Low voltage models1,2 110–127 V at 50–60 Hz (+/- 3), nominal
90–137 V, extreme
High voltage models1,2 220–240 V at 50–60 Hz (+/- 3), nominal (not available in all countries)
198–259 V, extreme
Other voltage models (Japan)1,2 90–110 V at 50–60 Hz (+/-3), nominal
90–110 V, extreme
1Using a 220–110 power converter with a 110–V printer is not recommended.
2Using an inverter (12 V DC to 120 V AC, for example) to power the printer is not recommended.
X203n MFP and X204n MFP
Printer model Electrical specification
Low voltage model* 100–127 V at 50–60 Hz (+/-3), nominal
90–137 V, extreme
High voltage model* 220–240 V at 50–60 Hz (+/-3), nominal
198–259 V, extreme
* Using a 220–110 power converter with 110 V printer is not recommended.
Warning—Potential Damage: Lexmark recommends that you do not use voltage converters with printers.
Power requirements
The following tables list the nominal average power requirements (including fuser power).
Lexmark E260, E360, and E460 models nominal average power requirements
Printing states E260/E260d/E260dn E360d/E360dn/E460dn E460dw
Average power while printing continuously
1-sided (simplex)
2-sided (duplex)
470 W
290 W
500 W
310 W
500 W
310 W
Average power while idle
Power Saver on
Ready mode
11 W
12 W
11 W
12 W
13 W
14 W
Max current while printing
100 V
120 V
230 V
9.1 A
9.1 A
4.5 A
9.5 A
9.5 A
4.5 A
9.5 A
9.5 A
4.5 A
Printer specifications
18

Printing states E260/E260d/E260dn E360d/E360dn/E460dn E460dw
Average current while printing
100 V
120 V
230 V
8.6 A
7.6 A
3.7 A
8.6 A
7.6 A
3.7 A
8.6 A
7.6 A
3.7 A
Lexmark X203n MFP and X204n MFP nominal average power requirements
Printing states X203n and X204n
Off 0 W
Power Saver Mode on <11 W
Standby Mode <55 W
Simplex printing (one-sided printing) < or = 350 W
Copying continuously < or = 305 W
Scanning continuously < or = 65 W
Maximum current while printing
120 V
230 V
<6.2 A RMS
<3.4 A RMS
Physical specifications
Lexmark E260, E260d/dn, E360d/dn, and E460dn/dw dimensions
Physical dimensions Depth Width Height Weight1
All printers2369.5 mm (14.55 in.)3406 mm (15.98 in.) 259.5 mm (10.2 in.)3Refer to the table
below.
250-sheet drawer 367 mm (14.45 in.)4406 mm (15.98 in.) 89 mm (3.5 in.) 2.55 kg (5.6 lb)
550-sheet drawer 387 mm (15.24 in.)4406 mm (15.98 in.) 130.5 mm (5.08 in.) 3.23 kg (7.2 lb)
All printers with
250-sheet drawer
369.5 mm (14.55 in.)3, 4 406 mm (15.98 in.) 347 mm (13.7 in.)3, 5 16.6 kg (36.52 lb)
All printers with
550-sheet drawer
387 mm (15.24 in.)3, 4 406 mm (15.98 in.) 388.5 mm (15.3 in.)3, 5 17.28 kg (38.02 lb)
1Combined weight is based on the heaviest model (E460dw).
2Printer weight includes the print cartridge which ships inside the printer.
3Measured with multipurpose feeder extension and the paper stop in the standard exit binincollapsed or closed positions.
4Measured with the paper size set to Letter.
5Total height of all printers installed on an optional drawer (250 or 550) is 1.5 mm (0.1 in.); this is shorter than the combined
height of the individual items due to the interlocking fit of the printer and drawer.
Printer specifications
19

Printer weight E260/E260d/E260dn E360d/E360dn E460dn E460dw
Without the print
cartridge and
photoconductor unit
shipped with the printer
12.0 kg (26.4 lb) 12.3 kg (27.06 lb) 12.5 kg (27.5 lb) 12.52 kg (27.54 lb)
With the print cartridge
and photoconductor
unit shipped with the
printer
13.53 kg (29.77 lb) 13.83 kg (30.43 lb) 14.03 kg (30.87 lb) 14.05 kg (30.91 lb)
Lexmark X203n MFP and X204n MFP dimensions
Option name Height Width Depth Weight*
X203n MFP 340.6 mm (13.4 in.) 401.2 mm (15.8 in.) 356.7 mm (14 in.) 13.4 kg (29.5 lb)
X204n MFP 384.5 mm (15.1 in.) 401.2 mm (15.8 in.) 356.7 mm (14 in.) 14.6 kg (32.2 lb)
*The weight includes the print cartridge and photoconductor unit which are shipped inside the printer.
Clearance requirements
Model Left side Right side Front Rear Top
E260, 260d/dn, E360d/dn,
E460dn/dw
12.7 mm (0.5 in.) 300 mm (12 in.) 200 mm (8 in.) 300 mm (12 in.) 300 mm (12 in.)
X203n MFP, X204n MFP 152.4 mm (6 in.) 304.8 mm (12 in.) 406.4 mm (16 in.) 152.4 mm (6 in.) 304.8 mm (12 in.)*
Note: When the printer or MFP is installed, allow enough room to access trays, multipurpose feeders, and output bins.
*This amount is needed in addition to the ADF paper support height on the X204n MFP.
Environmental conditions
Note: When shipping or storing printers, always pack the printer supplies (cartridges and photoconductors, for
example) separately.
Air temperature ranges
Printer model Operating value Storage and shipping
value (packed)
Storage and shipping value
(unpacked)
E260, E260d/dn, E360d/dn,
E460dn/dw
15.6–32.2°C (60–90°F) -20–40°C (-4–104°F) 0–40°C (32–104°F)
X203n/X204n 15.6–32.2°C (60–90°F) -40–69°C (-40–140°F) 0–40°C (32–104°F)
Printer specifications
20
