LG AN-TP200 Operation manual

[KOREA]
LG Touch Pen User Information
(Model Name: AN-TP200)
목 차
1. LG Touch Pen 의 개요 및 제원
(1) 개 요
(2) 제 원
2. 주의 사항
3. 고객지원
4. User notice
(1) 개 요
이 LG Touch Pen 는 사용자가 가정이나 사무실에서 PDP TV
에 직접 글이나 그림을 나타낼 수 있으며, 2.4GHz 대역의 무
선방식을 LG Pentouch Dongle 과 연동하여 PDP 화면을 제어
하는 송신부 제품입니다.
(2) 제 원
구 분 내 용
모 델 명 AN-TP200
주파수 대역 2402MHz ~ 2480MHz
채 널 79EA
송신 출력 0 dBm
수신 감도 -82dBm
크 기 폭 17 x 두께 18.5 x 길이 196.8
(공차 ± 1mm)
무 게 36.34g
전 원 3.7V
(Lithium ion Battery)
동작 온도 0℃ ~ + 40 ℃
1. LG Touch Pen 의 개요 및 제원

2. 주의 사항
(1) LG Touch Pen 구입 후 제품 사용법에 따라 페어링 후에 사용하세요.
(2) LG Touch Pen 의 밧데리는 교체할 수 없으며, 수시로 USB를 통해 충전하여 사용하세요.
(3) 제품을 분해하거나, 열을 가해서는 안됩니다.
(4) 케이스가 손상될 정도로 극심한 충격을 줘서는 안됩니다.
(5) 제품을 물에 넣어서는 안됩니다.
3. 고객 지원
(1) TV 매뉴얼의 서비스 연락처를 참조하세요.
(2) 보증기간 : 1년
보증 기간 중에 정상적인 사용 중에 기술상의 결함이나 문제가 나타났을 때, 구입처를
방문하세요. 이 보증은 제품을 구매한 그 지역의 구매자에게만 적용됩니다.
(3) KCC 인증 마크 및 인증번호
KCC-CRM-LGE-EBX615087
기자재의 명칭(모델명) : 특정소출력무선 기기
(무선데이터 통신 시스템용 무선기기)/AN-TP200
상호명 : 엘지전자㈜
제조자/제조국가: 엘지전자㈜/대한민국
제조년월: . .

[ENGLISH]
Contents
1. Overview and Specifications of LG Touch Pen
(1) Overview
(2) Specifications
2. Cautions
3. Customer Support
4. User Notice
(1) Overview
The LG Touch Pen allows you to type text or draw a picture directly on the PDP TV at home
or in the office. It is a transmitter that controls the PDP screen by working with the LG Pentouch
Dongle using the 2.4 GHz wireless band.
(2) Specifications
Item Description
Model Name AN-TP200
Frequency band 2402 MHz to 2480 MHz
Channels 79
Tx power 0 dBm
Reception sensitivity
-82 dBm
Size 17 x 18.5 x 196.8
(Tolerance ± 1 mm)
Weight 36.34 g
Power supply 3.7 V
(lithium ion battery)
Operating
temperature
0℃ to +40℃
1. Overview and Specifications of LG Touch Pen

2. Cautions
(1) Start using the LG Touch Pen by first pairing it with the TV, as instructed in the user manual.
(2) The battery of the LG Touch Pen cannot be replaced, but it can be charged through a USB port.
(3) Do not disassemble or heat the product.
(4) Avoid extreme shocks or impacts that can damage the case.
(5) Do not put the product in water.
3. Customer Support
(1) See the service contact in the TV manual.
(2) Warranty period: 1 year
If you find a technical defect or problem in the course of normal use during the warranty
period, please contact your dealer. This warranty applies only to the purchaser in the region where
the product is purchased.

[GERMAN]
Inhalt
1. Überblick und Spezifikationen des LG Touch Pen
(1) Überblick
(2) Spezifikationen
2. Warnhinweise
3. Kundendienst
4. Hinweis für Benutzer
(1) Überblick
Mit dem LG Touch Pen können Sie auf Ihrem PDP-Fernseher zu Hause oder im Büro direkt
Text eingeben oder zeichnen. Es handelt sich um einen Sender, der den PDP-Bildschirm
steuert. Dies geschieht im Zusammenspiel mit dem LG Pentouch Dongle über die
Drahtlosfrequenz 2,4 GHz.
(2) Spezifikationen
Element Beschreibung
Modellname AN-TP200
Frequenzband 2.402 bis 2.480 MHz
Kanäle 79
TX Power 0 dBm
Empfängerempfindlichkeit
-82 dBm
Größe 17 x 18,5 x 196,8
(Toleranz ± 1 mm)
Gewicht 36,34 g
Stromversorgung 3,7 V
(Lithium-Ionen-Akku)
Betriebstemperatur 0℃ bis +40℃
1. Überblick und Spezifikationen des LG Touch Pen

2. Warnhinweise
(1) Wenn Sie den LG Touch Pen zum ersten Mal verwenden, koppeln Sie ihn mit Ihrem Fernsehgerät
wie in der Bedienungsanleitung beschrieben.
(2) Der Akku des LG Touch Pen lässt sich nicht austauschen, kann aber über einen USB-Anschluss
aufgeladen werden.
(3) Bauen Sie das Produkt nicht auseinander, und erhitzen Sie es nicht.
(4) Vermeiden Sie extreme Stöße und Erschütterungen, die das Gehäuse beschädigen können.
(5) Bringen Sie das Produkt nicht mit Wasser in Berührung.
3. Kundendienst
(1) Siehe Service-Kontakt in der Bedienungsanleitung Ihres Fernsehgeräts.
(2) Garantiezeitraum: 1 Jahr
Sollte bei normaler Verwendung während des Garantiezeitraums ein Defekt oder sonstiges
Problem auftreten, wenden Sie sich an Ihren Fachhändler. Diese Garantie gilt nur für den Käufer in
der Region, wo das Produkt gekauft wurde.

[FRENCH]
Sommaire
1. Présentation et spécifications du stylet LG Touch Pen
(1) Présentation
(2) Spécifications
2. Précautions
3. Support technique
4. Avertissement utilisateur
(1) Présentation
Le stylet LG Touch Pen vous permet de saisir un texte ou de dessiner une image directement sur
un téléviseur PDP à la maison ou au bureau. Il s'agit d'un transmetteur qui contrôle l'écran PDP grâce
à une interaction avec le module de sécurité LG Pentouch Dongle via une bande sans fil de 2,4 GHz.
(2) Spécifications
Élément Description
Nom du modèle AN-TP200
Bande de fréquence
De 2 402 à 2 480 MHz
Canaux 79
Puissance
d'émission
0 dBm
Sensibilité de
réception
- 82 dBm
Taille 17 x 18,5 x 196,8
(Tolérance ± 1 mm)
Poids 36,34 g
Alimentation
électrique
3,7 V
(batterie Lithium-ion)
Température de
fonctionnement
De 0℃ à + 40℃
1. Présentation et spécifications du stylet LG Touch Pen

2. Précautions
(1) Utilisez tout d'abord le stylet LG Touch Pen en association avec votre téléviseur en suivant les
instructions du guide de l'utilisateur.
(2) La batterie du stylet LG Touch Pen ne peut être remplacée et doit être chargée via un port USB.
(3) N'essayez pas de désassembler ni de faire chauffer le produit.
(4) Évitez tout choc violent avec le produit. Cela pourrait endommager le boitier.
(5) N'immergez pas le produit dans l'eau.
3. Support technique
(1) Consultez le guide d'utilisation du téléviseur pour connaître les coordonnées du support
technique.
(2) Durée de la garantie : 1 an
Si vous constatez un défaut ou un problème technique lors de l'utilisation normale du produit
et que la garantie est toujours valable, contactez votre revendeur. Cette garantie n'est valable
qu'auprès des revendeurs de la région où le produit a été acheté.

[PORTUGUESE]
Sumário
1. Visão geral e especificações da LG Touch Pen
(1) Visão geral
(2) Especificações
2. Cuidados
3. Apoio ao cliente
4. Aviso aos usuários
(1) Visão geral
A LG Touch Pen permite que você digite ou desenhe diretamente na TV PDP em casa ou no
escritório. É um transmissor que controla a tela PDP trabalhando com o LG Pentouch Dongle
usando a banda de 2,4 GHz sem fio.
(2) Especificações
Item Descrição
Nome do modelo AN-TP200
Banda de freqüência
2402 MHz a 2480 MHz
Canais 79
Tx power 0 dBm
Sensibilidade de
recepção
-82 dBm
Tamanho 17 x 18,5 x 196,8
(± 1 mm de tolerância)
Peso 36,34 g
Fonte de
alimentação
3,7 V
(bateria de íon de lítio)
Temperatura
operacional
0℃ a +40℃
1. Visão geral e especificações da LG Touch Pen

2. Cuidados
(1) Comece a usar a LG Touch Pen emparelhando-a com a TV, como instruído no manual do usuário.
(2) A bateria da LG Touch Pen não pode ser substituída, mas pode ser carregada através de uma
porta USB.
(3) Não desmonte ou aqueça o produto.
(4) Evite choques extremos ou impactos que possam danificar o estojo.
(5) Não molhe o produto.
3. Apoio ao cliente
(1) Veja o contato de serviços no manual da TV.
(2) Período da garantia: 1 ano
Se você encontrar defeitos técnicos ou problemas durante o uso normal dentro do período da
garantia, entre em contato com o revendedor. Essa garantia se aplica somente ao comprador na
região onde o produto foi adquirido.

[SPANISH]
Contenido
1. Información general y especificaciones del LG Touch Pen
(1) Información general
(2) Especificaciones
2. Precauciones
3. Asistencia al cliente
4. Aviso al usuario
(1) Información general
El LG Touch Pen permite escribir texto o dibujar imágenes directamente en el televisor PDP de
casa o de la oficina. Es un transmisor que controla la pantalla PDP junto con el LG Pentouch
Dongle a través de la banda inalámbrica de 2,4 GHz.
(2) Especificaciones
Elemento Descripción
Nombre del modelo
AN-TP200
Banda de frecuencia
De 2402 a 2480 MHz
Canales 79
Potencia de
transmisión
0 dBm
Sensibilidad de
recepción
-82 dBm
Tamaño 17 x 18,5 x 196,8
(tolerancia ± 1 mm)
Peso 36,34 g
Fuente de
alimentación
3,7 V
(batería de iones de litio)
Temperatura de
funcionamiento
De 0℃ a +40℃
1. Información general y especificaciones del LG Touch Pen

2. Precauciones
(1) Para comenzar a utilizar el LG Touch Pen asócielo con el televisor, tal y como se indica en el
manual del usuario.
(2) La batería del LG Touch Pen no se puede sustituir, pero puede cargarse mediante un puerto USB.
(3) No desmonte ni caliente el producto.
(4) Evite los golpes o impactos fuertes que podrían dañar la carcasa.
(5) No sumerja el producto en agua.
3. Asistencia al cliente
(1) Consulte los datos del Servicio de Atención al Cliente en el manual del televisor.
(2) Periodo de garantía: 1 año
Si descubre un defecto o problema técnico durante el uso normal dentro del periodo de
garantía, póngase en contacto con su distribuidor. Esta garantía solo se aplica al comprador en la
región en que se compra el producto.

[RUSSIAN]
Содержание
1. Обзор и технические характеристики LG Touch Pen
(1) Обзор
(2) Технические характеристики
2. Предупреждения
3. Поддержка клиента
4. Примечание для пользователя
(1) Обзор
Сенсорное перо LG Touch Pen позволяет вводить текст и рисовать непосредственно на
экране плазменной панели дома или в офисе. Оно является передатчиком, управляющим
изображением на экране плазменной панели с помощью аппаратного ключа LG Pentouch
Dongle на частоте 2,4 ГГц.
(2) Технические характеристики
Элемент Описание
Модель AN-TP200
Частотный
диапазон
2402–2480 МГц
Каналы 79
Модность
передачи
0 дБм
Чувствительность
приемника
-82 дБм
Размер 17 x 18,5 x 196,8
(допустимая погрешность ± 1
мм)
Вес 36,34 г
Блок питания 3,7 В
(литий-ионный аккумулятор)
Рабочая
температура
от 0℃ до +40℃
1. Обзор и технические характеристики LG Touch Pen

2. Предупреждения
(1) Для использования LG Touch Pen выполните сопряжение пера с телевизором, как описано в
руководстве пользователя.
(2) Аккумулятор пера LG Touch Pen не подлежит замене, но его можно заряжать через USB-
порт.
(3) Не разбирайте и не нагревайте устройство.
(4) Избегайте чрезмерных вибраций или воздействий, которые могут повредить корпус
устройства.
(5) Не помещайте устройство в воду.
3. Поддержка клиента
(1) Контактные данные сервисного центра см. в руководстве к телевизору.
(2) Гарантия: 1 год
При обнаружении технического дефекта или проблемы при нормальном использовании
устройства в течение гарантийного периода обратитесь к дилеру. Данная гарантия
распространяется только на покупателей, проживающих в регионе приобретения устройства.

[ITALIAN]
Sommario
1. Panoramica e specifiche tecniche di LG Touch Pen
(1) Panoramica
(2) Specifiche tecniche
2. Precauzioni
3. Assistenza clienti
4. Avviso utente
(1) Panoramica
LG Touch Pen consente di digitare testo o disegnare figure direttamente sullo schermo
del TV PDP a casa o in ufficio. È un trasmettitore che controlla lo schermo PDP operando
con LG Pentouch Dongle e utilizzando la banda wireless a 2,4 GHz.
(2) Specifiche tecniche
Voce Descrizione
Nome modello AN-TP200
Banda di frequenza
Da 2402 MHz a 2480 MHz
Canali 79
Potenza Tx 0 dBm
Sensibilità di
ricezione
-82 dBm
Dimensioni 17 x 18,5 x 196,8
(Tolleranza ± 1 mm)
Peso 36,34 g
Alimentazione
elettrica
3,7 V
(batteria agli ioni di litio)
Temperatura di
funzionamento
Da 0℃ a +40℃
1. Panoramica e specifiche tecniche di LG Touch Pen

2. Precauzioni
(1) Iniziare a utilizzare LG Touch Pen eseguendone preliminarmente l'associazione con il TV,
attenendosi alle istruzioni fornite nel manuale utente.
(2) La batteria di LG Touch Pen non può essere sostituita, ma può essere ricaricata tramite una porta
USB.
(3) Non disassemblare o riscaldare il prodotto.
(4) Evitare che il prodotto subisca urti o scossoni eccessivi che possono danneggiare l'involucro
esterno.
(5) Non immergere il prodotto in acqua.
3. Assistenza clienti
(1) Vedere le informazioni di contatto per l'assistenza presenti nel manuale del TV.
(2) Periodo di garanzia: 1 anno
Se si nota un difetto tecnico o un problema al prodotto nel corso del normale utilizzo dello
stesso e durante il periodo di garanzia, contattare il rivenditore. La garanzia è valida solo per
l'acquirente del prodotto nel paese in cui il prodotto è stato acquistato.

4. User notice
(1) KCC Statement(Korea)
“제작자 및 설치자는 해당 무선설비가 전파혼신 가능성이 있으므로 인명안전 과 관련된
서비스는 할 수 없음.”
(2) ANATEL Statement(Para Brazil)
Este equipamento opera em caráter secundário, isto é, não tem direito à proteção
contra interferência prejudicial, mesmo de estações do mesmo tipo e não pode
causar interferência a sistemas operando em caráter primário.

(3) Federal Communications Commission(FCC) Statement
You are cautioned that changes or modifications not expressly approved by the part responsible
for compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-. Reorient or relocate the receiving antenna.
-. Increase the separation between the equipment and receiver.
-. Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected
-. Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received, including interference that may
cause undesired operation of the device.
Indoor use only
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20 cm between the radiator & your body.
End users must follow the specific operating instructions for satisfying RF
exposure compliance. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.

(4) Industry Canada(IC) Statement
This device complies with RSS-210 of the Industry Canada Rules.
Operation is subject to the following two conditions:
1) this device may not cause interference and
2) this device must accept any interference. Including interference that
may cause undesired operation of device.
This class B digital apparatus complies with Canadian ICES-003
Avis d'Industrie Canada
Cet appareil est conforme à norme CNR-210 des règlements d'Industrie
Canada. Son fonctionnement est sujet aux deux conditions suivantes:
1) Cet appareil ne doit pas provoquer d'interférences et
2) Cet appareil doit accepter toute les interférences. y compris celles
pouvant entraîner son dys-fonctionnement.
Cet appareil numérique de classe B est conforme à la norme NMB-003
du Canada.
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment.
This equipment should be installed and operated with minimum distance
20 cm between the radiator & your body.
NOTE: THE MANUFACTURERE IS NO T RESPONSIBLE FOR ANY RADIO OR
TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY
TO OPERATE THE EQUIPMENT.
Avis d'Industrie Canada sur I'exposition aux rayonnements
Cet appareil est conforme aux limites d'exposition aux rayonnements
d'Industrie Canaca pour unenvironnement non contrôlé.
II doit être installé de façon à garder une distance minimale de 20
centimètres entre la source de rayonnements et votre corps.
REMARQUE: LE FABRICANT N'EST PAS RESPONSIBLE DES INTERFÉRENCES
RADIOÉLECTRIQUES CAUSÉES PAR DES MODIFICATIONS NON AUTORISÉES
APPORTÉES APPORTÉES À CET APPAREIL. DE TELLES MODIFICATIONS
POURRAIT ANNULER L'AUTORISATION ACCORDÉE À L'UTILISATEUR DE FAIRE
FONCTIONNER L'APPAREIL.

(5) CE Statement
1) CE conformity Notice
LG Electronics hereby declares that this product is in compliance with
the following Directives.
R&TTE Directive 1999/5/EC
LOW VOLTAGE Directive 2006/95/EC
The products described above comply with the essential requirements
of the directives specified.
This device is a 2.4 wideband transmission system, intended for use in
all EU member states and EFTA countries, except in France.
This device may not be used for setting up outdoor radio links in France
and in some areas the RF output power may be limited to 10 mW EIRP
in the frequency range of 2454 – 2483.5 MHz. For detailed information
the end user should contact the national spectrum authority in France.
European representative:
LG Electronics Service Europe B.V. Veluwezoom 15, 1327
AE Almere. The Netherlands
(Tel : [phone])
2) CE Notified Body statement:
This is a Class B product. In a domestic environment, this product may
cause radio interference, in which case the user may be required to take
adequate measures.
Explosive device proximity warning – Do not operate a portable
transmitter (such as a wireless network device) near unshielded blasting
caps or in an explosive environment unless the device has been modified
to be qualified for such use.
This CE marking is valid for EU non-harmonized telecommunications
products R&TTE Directive (1999/5/EC) issued by the Commission of the
European Community.
3) Certification Marking
