LG ARNU093TNC2 User manual

Date:
JobName/Location:
PONo.:
Architect:
Engr:
GC:
Rep:
For: File
A
pp
roval
Mech:
Resubmit
Other
(Company) (ProjectManager)
Tag#:
ARNU093TNC2
MultiV™4‐WayCeilingCassette
Performance:
CoolingNominalTestConditions: HeatingNominalTestConditions:
Indoor: 80°FDB/67°FWB
Outdoor: 95°FDB
Indoor: 70°FDB
Outdoor: 47°FDB/43°FWB
HeatingCapacity(Btu/h)10,900
Electrical:
PowerSupply(V/Hz/Ø) 208‐230/60/1
RatedAmps(A)0.56
Pi
p
in
g
:
Refrigerant:
LiquidLine(in,OD) 3/8Flare
VaporLine(in,OD) 5/8Flare
Condensate:
StandardFeatures:
•LimitedWarrantywithLGCerfiedInstallaon
•TwoYearFunctionalPartsWarranty
•CornerAccessPanels
ControlsFeatures:
•Autochangeover
(HeatRecoveryOnly)
•Autooperaon
•Autorestart
•Childlock
•Dualthermistorcontrol
•Forcedoperaon
•Groupcontrol
•Highceiling
•Hotstart
•Selfdiagnoscs
•Sleepmode
•Timer(on/off)
•Weeklyschedule
•Sodry(dehumidificaon)
•Autodirecon/swing(up/down)
•Fanspeedcontrol
•Chaoswind(randomfanspeed)
•Swirlwind(alternangvanes)
•Jetcool(fastcooling)
Fan:
Type Turbo
Quantity 1
Motor/Drive BrushlessDigitallyControlled/Direct
AirflowRateH/M/L(CFM) 484/424/364
O
p
tionalAccessories:
Notes:
1.ThePowerInputisratedathighspeed.
2.Maximumliis27infromboomofunit.
3.SeeEngineeringManualforsensibleandlatentcapacies.
4.SoundPressurelevelsaretestedinananechoicchamberunderISOStandard1996.
5.Allcommunicaoncabletobeminimum18AWG,2‐conductor,stranded,shieldedandmust
complywithapplicablelocalandnationalcode.
6.Powerwiringcablesizemustcomplywiththeapplicablelocalandnaonalcode.
7.Thisunitcomeswithadrynitrogencharge.
8.Thisdataisrated0abovesealevel,with25ofrefrigerantlineperindoorunitanda0
leveldifferencebetweenoutdoorandindoorunits.Allcapacitiesarenetwithacombinationratio
between95–105%.
9.MustfollowinstallaoninstruconsintheapplicableLGinstallaonmanual.
Re
q
uiredAccessories:
GrilleKit(PT‐UMC)
UnitData:
RefrigerantType R410A
RefrigerantControl EEV
NetUnitWeight(lbs) 52
ShippingWeight(lbs) 59
PrimaryFilter WashablePre‐filter
SecondaryFilter Plasma
EnteringMixedAir:
HeatingMin(°FDB) 59
GrilleWeight(lbs) 10
CondensateLine(in,OD) 1
PowerInput¹(W) 144
WirelessHandheldRemoteController(PQWRHDF0)
7‐DayProgrammableController(PQRCUSA)
SimpleControllerwithMode(PQRCUCS0C)
SimpleControllerwithoutMode(PQRCFCS0C)
DryContactUnit(PQDSB1,PQDSBC)
TotalCoolingCapacity(Btu/h) 9,600
FactoryInstalledPump² Yes
VentilationKit(PTVK410+PTVK420)
AutoElevationKit(PTEGM0)
9,600
CoolingMax³(°FWB) 76
SoundPressure⁴dB(A)(H/M/L) 30/26/22
Btu/hIndoorUnit
GrilleShippingWeight(lbs) 13
WallMountedTemperatureSensor(PQRSTA0)
Page1of2
LGElectronicsUSA,Inc.1000SylvanAve,EnglewoodCliffs,NJ07632/www.lg‐vrf.com
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice. VRF‐SB‐DE‐012‐US011H03

ARNU093TNC2
MultiV™4‐WayCeilingCassette
JobName/Location:
Tag#:
Date:
PONo.:
9,600 Btu/hIndoorUnit
Page2of2
LGElectronicsUSA,Inc.1000SylvanAve,EnglewoodCliffs,NJ07632/www.lg‐vrf.com
Forcontinualproductdevelopment,LGreservestherighttochangespecificationswithoutnotice. VRF‐SB‐DE‐012‐US011H03
33-1/16" 9-11/16" 33-1/16" 6-11/16"
3-1/8"
7-11/16"
6-1/2"
3/4"
6-1/2"
3-11/16" 3-15/16"
6-5/8"
4-3/16"
3-15/16"
5-7/16"
1"
37-3/8" 37-3/8" 1-1/16"
30-15/16"
3-1/16"
26-7/16"
1-1/16"
30-15/16"
4-1/8"
W
H D
L1 L2 L3 L4 L5 L6 L7 L8 L9
L10 L11 L12 L13 L14 L15
M1 M2 M3 M4 M5 M6 M7
Note‐Alldimensionshavea
toleranceof±0.25in.
3-1/16"
26-15/16"
M8 M9
