LG GoldStar GSO120HE User manual

ENGLISH FRANÇAIS ESPAÑOL
Ductless-Split Air Conditioners and
Heat Pumps
OWNER'S MANUAL
Please read the operating instructions and safety precautions
carefully and thoroughly before installing and operating your
ductless split system.

##############
2Room Air Conditioner
Room Air Conditioner Owner’s Manual
TABLE OF CONTENTS
FOR YOUR RECORDS
Write the model and serial numbers here:
Model #
Serial #
You can find them on a label on the side of each unit.
Dealer's Name
Date Purchased
■Staple your receipt to this page in the event you need
it to prove date of purchase or for warranty issues.
READ THIS MANUAL
Inside you will find many helpful hints on how to use
and maintain your air conditioner properly. Just a little
preventive care on your part can save you a great deal
of time and money over the life of your air conditioner.
You'll find many answers to common problems in the
chart of troubleshooting tips. If you review our chart of
Troubleshooting Tips first, you may not need to call
for service at all.
PRECAUTIONS
•Contract your contractor or authorized dealer for
service or maintenance of this system.
• The air conditioner is not intended for use by
young children without supervision.
• Young children should be supervised to ensure
that they do not play with the air conditioner.
• Installation work must be performed in
accordance with the all federal, state, provincial,
fire local and municipal codes and ordinances by
qualified and authorized personnel only.
Safety Precautions.........................3
Prior to Operation ..........................9
Introduction ..................................10
Electrical Safety ...........................11
Operating Instructions.................12
Maintenance and Service ............26

Safety Precautions
Owner’s Manual 3
ENGLISH
Safety Precautions
To prevent the injury of the user or other people and property damage, the following instructions must be
followed.
■Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is classified by
the following indications.
This symbol indicates the possibility of death or serious injury.
This symbol indicates the possibility of injury or damage to properties only.
■The meanings of the symbols used in this manual are as shown below.
Be sure not to do.
Be sure to follow the instruction.
■Installation
Do not use damaged power
cords, plugs, or a loose
socket.
•There is risk of fire or electric
shock.
For electrical work, contact
the dealer, seller, a qualified
electrician, or an Authorized
Service Center.
•There is risk of fire or electric
shock.
Always use the power plug
and socket with the ground
terminal.
•There is risk of electric shock.
Do not allow water to run into
electric part.
•There is risk of fire, failure of the
product and/or electric shock.
Do not modify or extend the
power cord.
•There is risk of fire or electric
shock.
Do not install, remove, or re-
install the unit by yourself
(customer).
•There is risk of fire, electric shock,
explosion or injury.

Safety Precautions
4Room Air Conditioner
Be cautious when unpacking
and installing the product.
•Shape edges could cause injury.
Be especially careful of the sharp
edges.
For installation, always
contact the dealer or an
Authorized Service Center.
•There is risk of fire, electric shock,
explosion, or injury.
Do not install the product on
a defective installation stand.
•It may cause injury, accident, or
damage to the product.
Be sure the installation area
does not deteriorate with age.
•If the base collapses, the air
conditioner could fall with it,
causing property damage, product
failure, and personal injury.
Install the indoor unit on the
wall where the height from
the floors more then 8ft(2.4m)
•There are sharp moving parts that
could cause personal injury.
Do not handle the pipe by
yourself(Customer)
•High-Pressure refrigent may cause
personal injury.
Use a dedicated outlet for this
appliance.
•There is risk of fire or electric
shock.
Grasp the plug to remove the
cord from the outlet. Do not
touch it with wet hands.
•There is risk of fire or electric
shock.
Do not allow water to run
into electric part.
•There is risk of fire, failure of
the product, and/or electric
shock.
■Operation
8ft(2.4m)

Safety Precautions
Owner’s Manual 5
ENGLISH
Do not place a heater or other
appliances near the power
cable.
• There is risk of fire, failure of the
product, and/or electric shock.
Do not let the air conditioner
run for a long time when the
humidity is very high and a
door or a window is left open.
•Moisture may condense and wet or
damage furnishings.
Do not store of use
flammable gas or
combustibles near the air
conditioner.
•There is risk of fire or product
failure.
Do not use the product in a
tightly closed space for a
long time.
•Oxygen deficiency could occur.
• Some ventilation by opening window
is necessary for the fresh air
When flammable gas leaks, turn off
the gas and open a window for
ventilation before turning the
product on. Do not use the
telephone or turn switches on or off.
•There is risk of explosion or fire.
Unplug the unit if strange
sounds odors or smoke
comes from it.
• There is risk of fire, Product faiure,
and/or electric shock.
Stop operation and close any
window in storm or hurricane
before the hurricane arrives.
•There is risk of property damage,
failure of product, or electric
shock.
Do not open the inlet grill of
the product during operation.
(Do not touch the
electrostatic filter, if the unit
is so equipped.)
•There is risk of physical injury,
electric shock, or product.
When the product is soaked
(flooded or submerged),
contact an Authorized
Service Center.
•There is risk of electrical shock.
Wax
Thinner

Safety Precautions
6Room Air Conditioner
Install the drain hose to
ensure that water is drained
away properly.
•A bad connection may cause
water leakage.
Keep level even when
installing the product.
•To avoid vibration or water
leakage.
Do not install the product
where the noise or hot air
from the outdoor unit could
damage the neighborhoods.
•It may cause a problem for your
neighbors.
■Installation
Take care to ensure that
nobody could step on or fall
onto the outdoor unit.
•There could result in personal
injury and product damage.
Do not insert hands or other
objects through the air inlet
or outlet while the air
conditioner is plugged in.
•There are sharp and moving parts
that could cause personal injury.
Always check for
gas(refrigerant) leakage after
installation or repair of
product.
•Low refrigerant levels may cause
product failure.
Ventilate the product from
time to time when operating it
together with a stove, etc.
•There is risk of fire or electrical
shock.
Unplug the appliance before
performing cleaning or
maintenance.
•There is risk of electric shock.
When the product is not be
used for a long time
disconnect the power supply
plug or turn off the breaker.
•There is risk of product damage or
failure, or unintended operation.
90˚

Safety Precautions
Owner’s Manual 7
ENGLISH
Use two or more people to lift
and transport the air
conditioner.
•Avoid personal injury.
Do not install the product
where it will be exposed to
sea wind (salt spray) directly.
•It may cause corrosion in the
product. Corrosion, particularly on
the condenser and evaporator fins,
could cause product malfunction
or inefficient operation.
Do not direct airflow at room
occupants.
•This could damage your health.
Do not use the product for
special purposes, such as
preserving foods, works of art,
etc. It is a consumer air
conditioner, not a precision
refrigeration system.
•There is risk of damage or loss of
property.
Do not block the inlet or
outlet of air flow.
•It may cause product failure.
Use a soft cloth to clean.
Do not use harsh detergents,
solvents, etc.
•There is risk of fire, electric shock
or damage to the plastic parts of
the product.
Do not touch the metal parts
of the product when
removing the air filter. They
are very sharp!
•There is risk of personal injury.
Do not step on or put
anything on the product.
(outdoor unit)
•There is risk of personal injury and
failure of product.
Always insert the filter
securely. Clean the filter
every two weeks or more
often if necessary.
•A dirty filter reduces the efficiency
of the air conditioner and could
cause product malfunction or
damage.
■Operation

Safety Precautions
8Room Air Conditioner
Do not drink the water
drained from the unit.
• It is not sanitary and could cause
serious health issues.
Use a firm stool or ladder
when cleaning or maintaining
the air conditioner.
• Be careful and avoid personal
injury.
Replace all the batteries in
the remote.
• There is risk of fire or explosion.
Do not recharge or
disassemble the batteries. Do
not dispose of batteries in a
fire.
• They may burn or explode.
If the liquid from the batteries
gets onto your skin or clothes,
wash it well with clean water.
Do not use the remote if the
batteries have leaked.
• The chemicals in batteries could
cause burns or other health
hazards.
If you eat the liquid from the
batteries, brush your teeth
and see doctor. Do not use
the remote if the batteries
have leaked.
• The chemicals in batteries could
cause burns or other health
hazards.
■Disuse

ENGLISH
Owner’s Manual 9
Prior to operation
Prior To Operation
1. Being exposed to direct airflow for a long time may be hazardous to your health. Do not expose
occupants, pets, or plants to direct airflow for a long time.
2. Ventilate the room when the air conditioner is used with other heating devices. Otherwise the oxygen
supply may be inadequate.
3. Do not use this air conditioner for non-specified special purpose (e.g. preserving precision devices, food,
pets, plants, or art objects). Such use may damage your properties.
1. Do not touch the metal parts of the unit when removing the filter. Injury can occur.
2. Do not use water to clean inside the air conditioner. Exposure to water can destroy the insulation,
leading to electric shock.
3. When cleaning the unit, first make sure that the power and breaker are turned off. The fan rotates at a
very high speed during operation. There is a possibility of injury if the unit power is accidently turned on
while the interior of the unit is being cleaned.
For repair and maintenance, contact your contractor or an authorized dealer.
Usage
Cleaning And Maintenance
Service

10 Room Air Conditioner
Introduction
Introduction
This symbol alerts you to the risk of electric shock.
This symbol alerts you to hazards that may cause harm to the
air conditioner.
This symbol indicates special notes.
NOTICE
Features
Symbols Used In This Manual
(Side) (Rear)
Air outlet
vents
Air intake
vents
Piping
Signal receiver
Front Panel
Air Inlet
Air Filter
Indoor
Outdoor
•This appliance should be installed in accordance with national wiring regulations. This guide acts
as a guide to help to explain product features.
