ENGINEERING MANUAL
Art Cool Premier Wall Mounted
3/4 and 1 Ton
ART COOL PREMIER WALL MOUNTED

EM-SZ-ArtCoolPremier-ALL-09-14
For continual product development, LG Electronics U.S.A., Inc., reserves the right to change specifications without notice.
©LG Electronics U.S.A., Inc.
PROPRIETARY DATA NOTICE
This document, as well as all reports, illustrations, data, information, and
other materials is the property of LG Electronics U.S.A., Inc., and are
disclosed by LG Electronics U.S.A., Inc., only in confidence.
This document is for design purposes only.

Due to our policy of continuous product innovation, some specications may change without notication. 3
Introduction
About LG Electronics
LG Electronics is a global leader and technology innovator
in consumer electronics, mobile communications, and home
appliances. LG Electronics comprises five business units—Home
Entertainment, Mobile Communications, Air Conditioning, Business
Solutions, and Home Appliance. LG is one of the world’s leading
producers of flat panel televisions, audio and video products, mobile
handsets, air conditioners, and washing machines. LG’s commercial
air conditioning business unit was established in 1968 and has built
its lineup of residential and commercial products to include VRF,
Flex-Multi, duct-free split systems, packaged terminal air condition-
ers (PTACs), and room air conditioners. In 2011, the air conditioning
and energy solutions business unit grew to include LED lighting and
solar products. For more information, visit www.lg.com.
Duct Free Split Systems
LG HVAC systems offer a range of solutions that are cost efficient,
quiet and attractive. Duct Free Split systems are “split” into
indoor and outdoor units, and provide a smart alternative to both
central HVAC and window-mounted air conditioners. These inverter
heat pump systems are available in a variety of configurations to suit
different cooling and heating situations. Installation by a qualified
HVAC contractor is safe and easy – little to no duct work or sheet
metal is required.
Inverter Systems
LG Single Zone Inverter Wall Mount air-source systems offer the
opportunity to minimize ductwork in the same configuration. The
system offers zoning without the need for zone damper systems.
The LG Single Zone Inverter Wall Mount system’s advanced controls
provide exceptional building dehumidification and temperature
control, and can rapidly adapt system operating parameters to the
ever changing building load. The LG Single Zone Inverter Wall Mount
system is easy to design, install, and maintain. The modular design
allows occupants to control their environmental condition, providing
individualized control of the set-point temperature and allowing oc-
cupants to condition only the occupied zones.
Quality Commitment
LG is committed to the success of Duct Free Split projects. We
provide industry leading technical support during installation and
commissioning. LG offers a variety of classes designed for installers
and servicers to ensure that every system installation is completed
successfully.
Classes are conducted at LG’s training centers and in field locations
at various times throughout the year and upon special request.

4
Art Cool Premier Wall Mounted Engineering Manual
TABLE OF CONTENTS
INTRODUCTION.................................................................................5
Architectural Appeal..........................................................................6
PRODUCT DATA ................................................................................7
Product Features and Benets ........................................................8
Unit Nomenclature.............................................................................9
General Data ....................................................................................10
Art Cool Premier Pairing Table ......................................................10
Art Cool Premier Specications..................................................... 11
General and Electrical Data............................................................12
Functions, Controls, Options.........................................................13
Outdoor Unit Dimensions...............................................................14
Indoor Unit Dimensions..................................................................15
Acoustic Data...................................................................................16
Refrigerant Flow Diagram...............................................................18
Wiring Diagram...........................................................................19-20
Accessories ................................................................................21-24
PERFORMANCE DATA....................................................................25
Cooling Capacity ...........................................................................26
Heating Capacity ...........................................................................27
Air Flow and Temperature Distributions Graphs .......................28-29
APPLICATION GUIDELINES ...........................................................31
Equipment Selection Procedure ....................................................32
Building Ventilation Design Guide............................................33-34
Placement Considerations ........................................................35-38
REFRIGERANT PIPING DESIGN & LAYOUT
BEST PRACTICES ...........................................................................39
Refrigerant Piping Design .........................................................40-41
Installation & Layout Best Practices ........................................42-46
Electrical Connections....................................................................47
Mechanical Specications..............................................................48
Acronyms.........................................................................................49
TABLE OF SYMBOLS
This symbol indicates an imminently hazardous situation which, if not avoided, will result in death or serious
injury.
This symbol indicates a potentially hazardous situation which, if not avoided, could result in death or serious
injury.
This symbol indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
This symbol Indicates situations that may result in equipment or property damage accidents only.
This symbol indicates an action should not be completed.
DANGER

INTRODUCTION
“Architectural Appeal” on page 6

6|INTRODUCTION
Art Cool Premier Wall Mounted Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
Benefits of Single Zone
Art Cool Premier Wall Mount System
•Inverter technology
•Available in 9,000 and 12,000 Btu/h capacities
•All-season use - heat pump models for both
cooling and heating capabilities
•Operating ranges for Outdoor units of 14°F to
118°F (DB) for cooling; -13°F to 65°F (WB) for
heating
•Operating ranges for Indoor Units of 53°F to
75°F (WB) for cooling; 60°F to 86°F (DB) for
heating
•Quiet operation inside and outside
•Duct Free Split system
Convergence of Technological Innovation with Flexibility and Style
Single Zone Inverter
Wall Mount
Choosing an LG Single Zone Wall Mount
product provides a system designer an
edge to engineer a system with indi-
vidual control, and design flexibility with
advanced controls. The Art Cool Premier
Outdoor and Indoor units are available
in a nominal capacity range of 3/4 to 1
ton. These are best suited for applica-
tions with zones that require heating or
cooling, such as residential, and small
business office buildings.
Single Zone Wall Mount Outdoor
and Indoor units are available in
208–230V/60Hz/1Ph.
Adaptable and
Flexible
The Single Zone Wall Mount System
allows cooling or heating for the entire
residence or just a single room without
the need for evasive duct work. There is
minimal renovation needed.
Long refrigerant piping lengths allow
for extra design flexibility in indoor unit
installation.
These units may be used for a number of
residential or commercial environments
such as:
•Older homes
•New home construction
•Office buildings
•Restaurants
•Hospitals / Medical facilities
•Schools
•Nursing homes
•Retail establishments
•Houses of worship
Inverter Technology
Inverter variable-speed Duct Free Split
Systems are measurably quieter and
consume less energy than conventional
air conditioners. The Inverter compressor
ramps up or down to match the required
room capacity and maintain the comfort
level. When the selected temperature
is reached, the inverter compressor
operates at low speed to maintain that
comfort level, thereby using less energy.
ARCHITECTURAL APPEAL

“Product Features and Benefits” on page 8
“Unit Nomenclature” on page 9
“General Data” on page 10
“Electrical Data” on page 12
“Outdoor Unit Dimensions” on page 14
“Indoor Unit Dimensions” on page 15
“Acoustic Data” on page 16
“Refrigerant Flow Diagram” on page 18
“Wiring Diagram” on page 19
“Accessories” on page 21
PRODUCT DATA

8|PRODUCT DATA
Art Cool Premier Wall Mounted Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
Single Zone Art Cool
Premier Wall Mount
Single Zone Art Cool Premier Wall Mount
units are equipped with inverter components
that offer superior load matching and long
piping installation. The product works for
optimizing power consumption in residential
and small office buildings. Utilizing multiple
indoor wall mount units each with custom
temperature controls allow for precise
temperature settings in each zone of the
building. Art Cool Premier allows flexibility in
interior design and complements any decor.
Low Sound Levels
When outdoor units operate fully loaded, they
have one of the quietest sound levels. To
promote a quiet, comfortable environment, the
LG Single Zone Art Cool Premier indoor units
operate at sound levels as low as 25 dB(A)
(17dB(A) in sleep mode) and the outdoor
units as low as 45 dB(A) at full load.
All rotating components are soft-started by
the controller using digitally controlled invert-
ers, which reduce undesirable noise caused
by fans and compressors cycling on and off.
Comfort Control at Its
Best
Unlike traditional air conditioning control
systems, which use thermostatic controls
to maintain room temperatures, LG Single
Zone Inverter controls continuously vary the
indoor unit fan speed and refrigerant flow, in-
directly providing lower and more consistent
humidity levels in the conditioned space.
LG Single Zone one-to-one systems con-
tinuously measure the room temperatures
and adjust system operation accordingly to
maintain set temperature. The outdoor unit
adjusts operation by varying the compressor
speed and outdoor fan motors as needed
to maintain system operating pressure. As
a result, the Single Zone Art Cool Premier
Wall Mount system delivers targeted space
temperature control.
Inverter Driven
The twin-rotary compressor is optimized to
maximize compressor efficiency, which re-
duces power consumption and monthly utility
bills. This latest inverter technology allows
the LG Single Zone Art Cool Premier Wall
Mount outdoor unit to vary the compressor
motor shaft speed to deliver an appropriate
amount of cooling to the indoor unit. Precise
refrigerant volume delivery translates into
long periods with coil surface temperatures
below dew point and minimizes compressor
and fan component run time which may lead
to lower utility usage.
Simplified Installation
Cooling and heating systems that use the
LG Single Zone Art Cool Premier Wall Mount
product simplify and reduce the mechani-
cal and control system design time. The
designer no longer has to be concerned
with interconnecting chilled and condenser
water piping, air-distribution duct systems,
matching and selecting chillers, towers,
pumps, coils, fans, air handlers, or Variable
Air Volume (VAV) boxes.
Operating Range
The Single Zone Art Cool Premier Wall
Mount product has a nominal capacity range
of 3/4 to 1 ton (depending on outdoor/indoor
units).Operating ranges include:
Art Cool Premier Outdoor Units
Cooling: 14°F DB to 118°F DB
Heating: -13°F WB to 65°F WB
Compact Size
Single Zone Art Cool Premier Wall Mount
units are available in 3/4 to 1 tons. The out-
door units have a footprint of (WxHxD)
30 5/16 x 21 1/2 x 11 5/16.
Heat Transfer Efficiency
Fin Design with GoldFin™ Coating
All Single Zone Art Cool Premier Wall Mount
outdoor units are provided with large surface
coils made of copper tubes with louvered
aluminum fins designed to maximize unit
operating efficiency over a wide range of
ambient conditions.
Standard from the factory, every LG Single
Zone Art Cool Premier Wall Mount outdoor
coil fin surface is coated with LG’s exclusive
GoldFin™ anti-corrosive coating designed
to prevent natural surface corrosion of the
aluminum fins. This maintains heat transfer
properties of the coil for an extended time.
A hydrophilic coating is applied to the
outdoor unit coil fin surface over the GoldFin
coating. This coating enhances the develop-
ment of heavier water droplets gathering on
the fin surface. As a result, the droplets roll
off the fin surfaces, delaying the point when
frost forms on the coil surface during heat-
ing operation. This coating also makes it
possible to easily clean the outdoor unit coil
using a mild soap.
Other Features
•Inverter Variable Speed Compressor
•Jet Cool/Jet Heat
•Dehumidifying Mode
•Chaos Wind
•Auto restart
•Auto operation
•Self-cleaning indoor coil
•Smaller Footprint
•Precision Load Matching
•Follows AHRI 210/240
PRODUCT FEATURES AND BENEFITS

PRODUCT DATA | 9
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
Single Zone Wall Mount Indoor and Outdoor Units
LA N090 HYV 2
Generation
2 = Second
3 = Third
Indoor/Outdoor Product
HEV = Mega
HXV = Mega 115V
HYV = Art Cool Premier
HVP = Art Cool Gallery
HSV3 = High Efficiency
HSV2 = Art Cool Mirror
HV = Standard
HLV = Extended Pipe
Nominal Capacity
(Nominal cooling capacity in Btu/h)
090/091 = 9,000
120/121 = 12,000
180/181 = 18,000
240 = 24,000
307 = 30,000
360 = 36,000
Type
N = Indoor Wall Mount Unit
U = Outdoor Heat Pump Unit
Family
LA= Art Cool Premier/ Gallery / Mirror
LS= High Efficiency Wall Mount / Standard/ Mega
UNIT NOMENCLATURE

10 |PRODUCT DATA
Art Cool Premier Wall Mounted Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
GENERAL DATA
Art Cool Premier Pairing Table
The following table shows the available outdoor and indoor unit, along with the factory provided remote controller.
Table 1: Single Zone Art Cool Premier Pairing Table
Outdoor Unit Model/Btu/h Indoor Unit Model/Btu/h Controller
LAU090HYV / 9,000
LAU120HYV / 12,000
LAN090HYV / 9,000
LAN120HYV / 12,000
AKB73835312

PRODUCT DATA | 11
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
GENERAL DATA

Table 2: Unit General Data
Type Art Cool Premier Art Cool Premier
System (Model) LA090HYV (LAN090HYV/LAU090HYV) LA120HYV (LAN120HYV/LAU120HYV)
Cooling Capacity (Min/Rated/Max) (Btu/h) 1,023~9,000~12,966 1,023~12,000~13,785
Cooling Power Input1(kW) 0.56 0.85
Heating Capacity (Min/Rated/Max) (Btu/h) 1,023~11,000~20,472 1,023~13,600~22,178
Heating Power Input1(kW) 0.70 0.86
COP 4.6 4.63
Maximum Heating Capacity (Btu/h)
Outdoor 17 °F (WB)/Indoor 70 °F (DB) 11,935 (109%) 14,650 (108%)
Outdoor 5°F (WB)/Indoor 70 °F (DB) 11,220 (102%) 13,720 (101%)
Outdoor -13 °F (WB)/Indoor 70 °F (DB) 7,920 (72%) 9,520 (70%)
EER 16.01 14.12
SEER 27.5 25.5
HSPF 11.8 11.5
Power Supply (V / Hz / Ø) 208-230/60/1
ODU Operating Range
Cooling (°F DB) 14-118
Heating (°F WB) (-13)-65
IDU Operating Range
Cooling (°F WB) 53-75
Heating (°F DB) 60-86
Indoor Temperature Setting Range
Cooling (°F) 65-86
Heating (°F) 61-86
Unit Data
Refrigerant Type2R410A
Refrigerant Control EEV
IDU Sound Pressure3dB(A) (H/M/L/Sleep) 42/36/25/17
ODU Sound Pressure dB(A) 45
Unit Weight (lbs)
Indoor Unit (Net/Shipping) 25/29
Outdoor Unit (Net/Shipping) 73/78
Power/Communication Cable4(No. x AWG) 4 x 18
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
Power wiring is field supplied and must comply with the applicable local and national codes.
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level, with 24.6 ft of refrigerant line per indoor unit and a 0 ft level
difference between outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor coil at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB); and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 60ºF wet
bulb (WB); and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
1Power Input is rated at high speed.
2Take appropriate actions at the end of HVAC equipment life to recover, recycle, reclaim or destroy
R410A refrigerant according to applicable regulations (40 CFR Part 82, Subpart F) under section 608
of CAA.
3Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
4All power/communication cables to be minimum 18 AWG, 4-conductor, stranded, shielded and must
comply with applicable local and national code.

12 |PRODUCT DATA
Art Cool Premier Wall Mounted Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
Unit Model Nos. Nom.
Tons
Compressor
Qty
Compressor(A)
Cool/Heat Fan Qty ODU Fan(A) IDU Fan(A) MCA(A) MOP(A)
Art Cool Premier
LAU090HYV 3/4 1 8.3/8.3 1 0.40 0.40 11.2 15
LAU120HYV 1 1 8.3/8.3 1 0.40 0.40 11.2 15
LAU090HYV, LAU120HYV
GENERAL AND ELECTRICAL DATA
For component model nos.
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity
ODU Fan = Outdoor Unit Fan Motor
IDU Fan = Indoor Unit Fan Motor
Maximum Overcurrent Protection (MOP) is calculated as follows:
(Largest motor FLA x 2.25) + (Sum of other motor FLA) rounded down
to the nearest standard fuse size.
Table 3: 208-230V, 60Hz, 1-Phase Single Zone Art Cool Premier Electrical Data Table
Type Art Cool Premier Art Cool Premier
System (Model) LA090HYV (LAN090HYV/LAU090HYV) LA120HYV (LAN120HYV/LAU120HYV)
Fan
Indoor Type (Qty) Cross Flow (1)
Outdoor Type (Qty) Propeller (1)
Motor/Drive Brushless Digitally Controlled/Direct
Airflow Rate
Indoor - Max/H/M/L (CFM) 547/494/417/283
Outdoor - Max (CFM) 1,165
Piping
Liquid Line (in, OD) 1/4
Vapor Line (in, OD) 3/8
Condensation Line (OD | ID) 27/32 | 5/8
Additional Refrigerant Charge (oz/ft) 0.22
Pipe Length (Minimum/Maximum) (ft)56.6/65.6
Piping Length (no add’l refrigerant, ft)541.0
Max Elevation Difference (ft) 32.8
Table 2: Unit General Data (Continued)
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
Power wiring is field supplied and must comply with the applicable local and national codes.
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level, with 24.6 ft of refrigerant line per indoor unit and a 0 ft level
difference between outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor coil at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB); and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 60ºF wet
bulb (WB); and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
5Piping lengths are equivalent.

PRODUCT DATA | 13
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
LAN090HYV, LAN120HYV
FUNCTIONS, CONTROLS, OPTIONS
Table 4: Indoor Units—Functions, Controls and Options
Indoor Unit Type
Art Cool™
Premier Wall
Mounted
(LAN090HYV/
LAN120HYV)
Airow
Air supply outlet 1
Airflow direction (left/right) Auto
Airflow direction (up/down) Auto
Auto swing (left/right) √
Auto swing (up/down) √
Airflow steps (fan/cool/heat) 6 / 6 / 6
Auto Swing √
Natural wind (Auto wind) √
Jet-cool/heat √/√
Swirl wind X
Air Purifying
Washable anti-fungal1√
Deodorizing filter X
Plasma2X
Allergy safe filter X
3M Simple HAF filter2√
Functions
Drain pump X
E.S.P. control X
Electric heater X
High ceiling X
Defrost √
Low ambient √
Hot start √
Self diagnostics √
Soft Dry (dehumidification) √
Auto changeover √
Auto clean (coil dry) √
Auto restart √
Child lock X
Forced operation √
Sleep mode √
Timer (24hr on/off) √
Weekly timer X
Two thermistor control X
Indoor Unit Type
Art Cool™
Premier Wall
Mounted
(LAN090HYV/
LAN120HYV)
Controllers
Wireless Remote Controller √
Simple Controller with
Mode Selection o
Simple Controller without
Mode Selection o
LG Programmable
Thermostat o
Dry contact o
Central control (LGAP) X
PI 485 X
Special Function Kit
Zone control X
CTIE X
Electro thermostat X
WLAN capability √
Water level sensor connection
(for optional AG-9300-LG) √
Wind baffle kit X
Other
Thermistor X
1Primary washable filters.
2Secondary filters.
√=Standardfeature
o = Optional accessory (must be purchased separately)
X = Not available
When Dry Contact Mode is active, WLAN function can not be used.
•WhenchangingfromWLANmodetodrycontactmode,normaloperation
resumes in approximately 3 minutes.

14 |PRODUCT DATA
Art Cool Premier Wall Mounted Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
OUTDOOR UNIT DIMENSIONS
LAU090HYV, LAU120HYV
30-5/16
22 4-3/16
13-29/32
6-3/32
2-3/32
10 -29/32
1
20-29/32
21-1/2
10-1/2
9-11/32
19 -31/32
2-13/16 8-3/32
4
3
2
5
11- 5/16
5-23/32
Ø18- 5/16
[Unit: inch]
Center of Gravity
Discharge Air Grille

PRODUCT DATA | 15
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
INDOOR UNIT DIMENSIONS
LAN090HYV, LAN120HYV
Ø 2-
9/16
Ø 2-
9/16
4-13/16
6-11/16
Right rear piping
Left rear piping
Installation Plate
Place a level on raised tab
Unit Outline
8-17/32
6-29/32
17 17-5/16
5
9-1/4
11-5/8
1-31/32
34-7/16
1-31/32
2-5/32
2-5/32
3
2
14
[Unit : inch]
Return Air Grille

16 |PRODUCT DATA
Art Cool Premier Wall Mounted Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
ACOUSTIC DATA
Figure 1: Art Cool Premier Sound Pressure Level

Octave Band Sound Pressure Level (dB re 20µPa )
Octave Band Center Frequency (Hz)
10
20
30
40
50
60
70
80
63 125 250 500 1000 2000 4000 8000
NC-15
NC-20
NC-25
NC-30
NC-35
NC-40
NC-45
NC-50
NC-55
NC-60
NC-65
Approximate
Hearing
Threshold
LAU090HYV/LAU120HYV
3.28 ft
Center of
Outdoor Unit
Model Sound Levels dB(A)
H
LAU090HYV 45
LAU120HYV 45
Table 5: Outdoor Unit - Sound Level

PRODUCT DATA | 17
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
ACOUSTIC DATA
Figure 2: Art Cool Premier Sound Pressure Level

Octave Band Sound Pressure Level (dB re 20µPa )
Octave Band Center Frequency (Hz)
10
20
30
40
50
60
70
80
63 125 250 500 1000 2000 4000 8000
LAN090HYV/ LAN120HYV
Model Sound Levels dB(A)
H M L
LAN090HYV 42 36 25
LAN120HYV 42 36 25
Table 6: Indoor Unit - Sound Level
2.62 ft
3.28 ft
Microphone
Indoor Unit

18 |PRODUCT DATA
Art Cool Premier Wall Mounted Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
REFRIGERANT FLOW DIAGRAM
LAN090HYV, LAN120HYV
LAU090HYV, LAU120HYV
LOC. Description PCB Connector
Th1 Indoor air temperature thermistor CN-TH1(Indoor)
Th3 Water level sensor (Option) CN-TH2 (Indoor)
Th4 Evaporating middle temperature thermistor CN-TH3 (Indoor)
Th5 Discharge pipe temperature thermistor CN-TH2 (OUTDOOR)
Th6 Heat exchanger temperature thermistor CN-TH1(OUTDOOR)
Th7 Outdoor air temperature thermistor CN-TH1(OUTDOOR)
EEV : Electronic Expansion Valve
Indoor Unit Outdoor Unit
Heat
Exchanger
(Evaporator )
Heat
Exchanger
(Condenser )
Compressor
Accumulator
Gas Side
3-Way Valve
2-Way Valve
Liquid Side
Coolin g
Heatin g
Reversing Valve
Th1
Th6
Th3
Th7
Th4
Th5
FIELD PIPING
(Ø 1/4” Copper
Tubing)
FIELD PIPING
(Ø 3/8” Copper
Tubing )
EEV

PRODUCT DATA | 19
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
WIRING DIAGRAM
LAN090HYV, LAN120HYV

20 |PRODUCT DATA
Art Cool Premier Wall Mounted Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
WIRING DIAGRAM
LAU090HYV, LAU120HYV
