LG LS-C1863R User manual

Room Air Conditioner
SVC MANUAL(Exploded View)
MODEL :
CAUTION
Before Servicing the unit, read the safety precautions in General SVC manual.
Only for authorized service personnel.
Internal Use Only
http://biz.lgservice.com
LS-C1863R/W/B/D/M/CM0
LS-H1863R/W/B/D/M/CM0
LS-C2463R/W/B/D/M/CM0
LS-H2463R/W/B/D/M/CM0
LS-C1823R/W/B/D/M/CM0
LS-C1823R/W/B/D/M/CM2
LS-H1823R/W/B/D/M/CM0
LS-C2423R/W/B/D/M/CM0
LS-H2423R/W/B/D/M/CM0
AS-H2463R/D/M/WM1
AS-H1863B/M/R/WM0
AS-H2463R/D/M/WM1
LS-C2463B/C/D/M/RM1
LS-C1823RM1
LS-H1863B/D/M/R/WM1
AS-H1863*M3
AS-H2463*M3
LS-H1863*M3
LS-C2463*M3
LS-H2463*M3
LS-C1863*M3
LS-C2463*M4

- 2 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Air Conditioner Service Manual
TABLE OF CONTENTS
LG Model Name...............................................................................................................................................3
Safety Precautions..........................................................................................................................................4
Dimensions......................................................................................................................................................8
Symbols used in this Manual......................................................................................................................8
Indoor Unit.................................................................................................................................................8
Outdoor Unit...............................................................................................................................................9
Installation.....................................................................................................................................................12
Select the best Location ..........................................................................................................................12
Piping Length and Elevation.....................................................................................................................13
Fixing Installation Plate ............................................................................................................................14
Drill a Hole in the Wall..............................................................................................................................14
Flaring Work.............................................................................................................................................15
Connecting the Piping..............................................................................................................................16
Connecting the Cables to the Indoor Unit ................................................................................................22
Connecting the Cables to the Outdoor Unit..............................................................................................23
Checking the Drainage.............................................................................................................................23
Forming the Piping...................................................................................................................................24
Air Purging ...............................................................................................................................................25
Air Purging with Vacuum Pump................................................................................................................25
Test Running ............................................................................................................................................27
Operation.......................................................................................................................................................28
Function of Controls.................................................................................................................................28
Display Function ......................................................................................................................................35
Self-diagnosis Function............................................................................................................................36
Remote Control Operations......................................................................................................................37
Disassembly ..................................................................................................................................................38
Indoor Unit................................................................................................................................................38
Troubleshooting Guide.................................................................................................................................41
Refrigeration Cycle Diagram....................................................................................................................41
2-way, 3-way Valve .................................................................................................................................42
Cycle Parts...............................................................................................................................................47
Electronic Parts........................................................................................................................................48
Schematic Diagram.......................................................................................................................................55
Electric Control Device.............................................................................................................................55
Wiring Diagram.........................................................................................................................................56
Components Location ..............................................................................................................................58
Product Specifications.................................................................................................................................60
Exploded View...............................................................................................................................................62

- 3 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
LG Model Name
LG Model Name
12 -345678910
Code Type Code of Model Meaning
1 Producing Center, A~Z L: Chang-won R22 N: India
Refrigerant A: Chang-won R410A Z: Brazil
C: Chang-won R407C D: Indonesia
T: China X: Mexico
K: Turkey R22 V: Vietnam
U: China R410A
E: Turkey R410A S: Out Sourcing
H: Thailand
2 Product Type A~Z S: Split Type Air Conditioner
3 Cooling/Heating/Inverter A~Z C: Cooling only
H: Heat pump
X: C/O + E/Heater
Z: H/P + E/Heater
V: AC Inverter C/O
N: AC Inverter H/P
Q: DC Inverter C/O
W: DC Inverter H/P
4, 5 Capacity 0~9 Cooling/Heating Capacity
Ex. "09" →9,000 Btu/h
6 Electric Range 1~9 1: 115V/60Hz, A: 220V, 50Hz, 3Phase
A~Z 2: 220V/60Hz B: 208~230V, 60Hz, 3Phase
3: 208-230V/60Hz C: 575V, 50Hz, 3Phase
5: 200-220V/50Hz D: 440~460, 60Hz, 3Phase
6: 220-240V/50Hz E: 265V, 60Hz
7: 110V, 50/60Hz F: 200V, 50/60Hz
8: 380-415V/50Hz
9: 380-415V/60Hz
7 Chassis 1~9 Name of Chassis of Unit
Ex. 3 → S3 Chassis
8 Look A~Z Look,
Color (Artcool Model)
9 Function A~Z
10 Serial No. 1~9 LG Model De
* ARTCOOL COLOR
velopment Serial No.
Basic A
Basic+4Way B
Plasma Filter C
Plasma Filter+4 Way D
Tele+LCD E
Tele+LCD+Nano plasma+4Way F
Nano Plasma F+(A/changeover)+A/clean+Low A G
Nano Plasma F+(A/changeover)+A/clean+4way+Low A H
Tele+LED+4way I
Internet J
Plasma F+4Way+Oxy generator K
Nano Plasma F+(A/changeover)+A/clean L
Nano Plasma F+(A/changeover)+A/clean+4way M
Nano Plasma F+(A/changeover)+A/clean+PTC N
Nano Plasma F+(A/changeover)+Autoclean+4way+PTC P
Nano Plasma F+(A/changeover)+A/clean+4way+Low A+PTC Q
Negative ION+A/Clean R
(Nano)Plasma+Negative ION+A/Clean S
4way+(Nano)Plasma F+Negative ION+Healthy dehumidification+A/Clean T
Nano Plasma F+4Way+(A/changeover)+A/clean+Oxy generator U
4way+(Nano)Plasma F+Negative ION+Healthy dehumidification+A/Clean+Oxy generator V
Dry Contact W
Wired Remocon 8
R Mirror
W White Wood
B Blue
D Wood
M Metal
C Cherry
N Walnut
A Gogh
S Sisley
Q Quran
K Mecca
2004

- 4 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Safety Precautions
Safety Precautions
To prevent injury to the user or other people and property damage, the following instructions must
be followed.
■Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is
classified by the following indications.
■Meanings of symbols used in this manual are as shown below.
This symbol indicates the possibility of death or serious injury.
This symbol indicates the possibility of injury or damage to properties only.
Be sure not to do.
Be sure to follow the instruction.
Always perform grounding. Don’t use a power cord, a plug
or a loose socket which is
damaged.
For installation of the product,
always contact the service center or
a professional installation agency.
• Otherwise, it may cause electrical
shock. • Otherwise, it may cause a fire or electrical shock. • Otherwise, it may cause a fire, elec- trical shock, explosion or injury.
Securely attach the electrical
part cover to the indoor unit
and the service panel to the
outdoor unit.
Always install an air leakage
breaker and a dedicated
switching board.
Do not keep or use flammable
gases or combustibles near
the air conditioner.
• If the electrical part cover of the
indoor unit and the service panel of
the outdoor unit are not attached
securely, it could result in a fire or
electric shock due to dust, water, etc.
• No installation may cause a fire and
electrical shock. • Otherwise, it may cause a fire or the failure of product.
■Installation
Wax
Thinner

- 5 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Safety Precautions
■Operation
Do not modify or extend the
power cord randomly. Take care so that the power cord may not be pulled during
operation.
Unplug the unit if strange
sounds, smell, or smoke
comes from it.
• Otherwise, it may cause a fire or
electrical shock. • Otherwise, it may cause a fire or electrical shock. • Otherwise, it may cause electrical shock or a fire.
• Sharp edges may cause injury. • It will cause an electric shock or a
fire due to heat generation. • Otherwise, it may cause a fire or electrical shock.
Use caution when unpacking
and installing. Do not share the outlet with other appliances. Do not use the damaged power cord.
Ensure that an installation
frame of the outdoor unit is
not damaged due to use for a
long time.
Do not disassemble or repair
the product randomly. Do not install the product at a place that ther is concern of
falling down.
• It may cause injury or an accident. • It will cause a fire or electrical shock. • Otherwise, it may result in personal
injury.

- 6 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Safety Precautions
Keep the flames away.
Take the power plug out if neces-
sary, holding the head of the plug
and do not touch it with wet hands.
Do not use the power cord
near the heating tools.
• Otherwise, it may cause a fire. • Otherwise, it may cause a fire or
electrical shock. • Otherwise, it may cause a fire and electrical shock.
Do not open the suction inlet
of the indoor/outdoor unit dur-
ing operation.
Do not allow water to run into
electrical parts. Never touch the metal parts of the unit when removing the fil-
ter.
• Otherwise, it may electrical shock
and failure. • Otherwise, it may cause the failure of machine or electrical shock. • They are sharp and may cause injury.
Do not step on the indoor/outdoor unit and do
not put anything on it. Do not place a heavy object on the power cord.
• It may cause an injury through dropping of the unit or
falling down. • Otherwise, it may cause a fire or electrical shock.
When the product is submerged into water,
always contact the service center.
Take care so that children may not step on the
outdoor unit.
• Otherwise, it may cause a fire or electrical shock. • Otherwise, children may be seriously injured due to
falling down.

- 7 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Safety Precautions
■Installation
Install the drain hose to
ensure that drain can be
securely done.
Install the product so that the
noise or hot wind from the
outdoor unit may not cause
any damage to the neighbors.
Always inspect gas leakage
after the installation and repair
of product.
• Otherwise, it may cause water leak-
age.
• Otherwise, it may cause dispute with
the neighbors.
• Otherwise, it may cause the failure of
product.
Wax
Thinner
Keep level parallel in installing the product. Avoid excessive cooling and perform ventila-
tion sometimes.
• Otherwise, it may cause vibration or water leakage. • Otherwise, it may do harm to your health.
Use a soft cloth to clean. Do not use wax, thin-
ner, or a strong detergent. When gas leaks, open the window for ventila- tion before operating the unit.
• The appearance of the air conditioner may deteriorate,
change color, or develop surface flaws. • Otherwise, it may cause explosion, and a fire.
■Operation

- 8 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Dimensions
Dimensions
Installation plate
D
H
W
W mm 1170
H mm 315
D mm 173
Model
Dimension
INDOOR UNIT
Indoor Unit
This symbol alerts you to the risk of electric shock.
This symbol alerts you to hazards that may cause harm to the
air conditioner.
This symbol indicates special notes.
NOTICE
Symbols used in this Manual

- 9 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
W mm 870 870
H mm 655 800
D mm 320 320
L1 mm 370 370
L2 mm 340 340
L3 mm 25 25
L4 mm 630 775
L5 mm 25 25
L6 mm 546 546
L7 mm 162 162
L8 mm 162 162
L9 mm 54 54
L10 mm 74.5 74.5
L11 mm 79 79
LS-C1863R/W/B/D/M/CM0, LS-H1863R/W/B/D/M/CM0
LS-C2463R/W/B/D/M/CM0, LS-H2463R/W/B/D/M/CM0
LS-H2423R/W/B/D/M/CM0, AS-H1863B/M/R/WM0
AS-H2463B/M/R/WM0, LS-C2463B/C/D/M/RM1
LS-C1823RM1, LS-H1863B/D/M/R/WM1
LS-H1863*M3, LS-C2463*M3, LS-H2463*M3
LS-C1863*M3, LS-C2463*M4
AS-H2463R/D/M/WM1
Outdoor Unit
Dimensions
W
L7 L6 L8 L9
D
L1
L2
L3
L10L11
L4L5
H
Gas side
Liquid side
MODEL
DIM

- 10 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Dimensions
WL2
L3
L1
D
H
L4
L5
Gas side
(3-way valve)
Liquid side
(2-way valve)
MODEL
DIM unit
W mm 840
H mm 577
D mm 276
L1 mm 287
L2 mm 64
L3 mm 518
L4 mm 10
L5 mm 100
LS-C1823R/W/B/D/M/CM2, AS-H1863*M3
LS-C2423R/W/B/D/M/CM0, AS-H2463*M3

- 11 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Dimensions
W
D
L1
L2
H
L3
L4
L5L6 L7 L8
L9 L10
Liquid side
2-way valve
Gas side
3-way valve
MODEL
DIM unit
W mm 801
H mm 555
D mm 262
L1 mm 339
L2 mm 37
L3 mm 543.6
L4 mm 11.4
L5 mm 591
L6 mm 105
L7 mm 105
L8 mm 72.5
L9 mm 86.4
L10 mm 77
LS-C1823R/W/B/D/M/CM0
LS-H1823R/W/B/D/M/CM0

- 12 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Installation
Installation
Indoor unit
1. Do not have any heat or steam near the unit.
2. Select a place where there are no obstacles in front
of the unit.
3. Make sure that condensation drainage can be conve-
niently routed away.
4. Do not install near a doorway.
5. Ensure that the interval between a wall and the left
(or right) of the unit is more than 50cm. The unit
should be installed as high as possible on the wall,
allowing a minimum of 10cm from ceiling.
6. Use a stud finder to locate studs to prevent unneces-
sary damage to the wall.
Outdoor unit
1. If an awning is built over the unit to prevent direct
sunlight or rain exposure, make sure that heat radia-
tion from the condenser is not restricted.
2. Ensure that the space around the back and sides is
more than 10cm. The front of the unit should have
more than 70cm of space.
3. Do not place animals and plants in the path of the
warm air.
4. Take the weight of the air conditioner into account
and select a place where noise and vibration are min-
imum.
5. Select a place where the warm air and noise from the
air conditioner do not disturb neighbors.
Select the best Location
More than 10cm
More than
5cm
More than 2.3m
More than
5cm
CAUTION: Install the indoor unit on the wall where the height from the
floor is more than 2 meters.
More than 10cm More than 10cm
More
than 60cm
More than 60cm
More than 70cm

- 13 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Installation
Piping Length and Elevation
Outdoor unit
Indoor unit
A
B
Outdoor unit
Indoor unit
A
B
A
Oil trap
Outdoor unit
Indoor unit
B
If piping length is more than 5m
CAUTION: Capacity is based on standard length and maximum allowance length is
on the basis of reliability.
Oil trap should be installed every 5~7 meters.
Pipe Size
Capacity
(Btu/h) GAS LIQUID
Max.
Length
A (m)
Additional
Refrigerant
(g/m)
Max.
Elevation
B(m)
Standard
Length
(m)
5k~14k 3/8"(Ø9.52) 1/4"(Ø6.35) 4 or 7.5 20
1/2"(Ø12.7) 1/4"(Ø6.35) 4 or 7.5 20
20
1/2"(Ø12.7) 1/4"(Ø6.35) 4 or 7.5
18k~28k 5/8"(Ø15.88) 1/4"(Ø6.35) 4 or 7.5
5/8"(Ø15.88) 3/8"(Ø9.52) 4 or 7.5
30k~38k 5/8"(Ø15.88) 3/8"(Ø9.52) 7.5
3/4"(Ø19.05) 3/8"(Ø9.52) 7.5 50
30
30
20
15
30
15
30
30
30
30
7
15
7
15
15
15
15

- 14 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Installation
The wall you select should be strong and solid
enough to prevent vibration
1. Mount the installation plate on the wall with
type "A" screws. If mounting the unit on a con-
crete wall, use anchor bolts.
•Mount the installation plate horizontally by aligning
the centerline using a level.
2. Measure the wall and mark the centerline. It is
also important to use caution concerning the
location of the installation plate-routing of the
wiring to power outlets is through the walls typi-
cally. Drilling the hole through the wall for piping
connections must be done safely.
Fixing Installation Plate
Installation Plate
Type "A" screw
Installation plate
Ø70mm
Left rear piping Right rear piping
C
D
B
AØ70mm
Left rear piping Right rear piping
B
A
D
C
Right rear piping
B
A
D
C
Installation plate
(SU)
(SZ)
(S3)
Installation plate
•Drill the piping hole with a ø70mm hole core drill.
Drill the piping hole at either the right or the left
with the hole slightly slanted to the outdoor side.
Drill a Hole in the Wall
5-7mm
(3/16"~5/16")
Indoor WALL Outdoor
ABCD
SZ 35 33 156 33
(7k~9k)
SU 92 44 67 44
(11k~14k)
S3 58 3 292 3
(18k~26k)
CHASSIS
(Grade)
Distance (mm)
•For S3 chassis, the center of the unit is different
from that of the Installation plate.

- 15 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Installation
Flaring Work
Main cause for gas leakage is due to defect in flaring work. Carry out correct flaring work in the following procedure.
Cut the pipes and the cable.
1. Use the piping kit accessory or the pipes purchased
locally.
2. Measure the distance between the indoor and the
outdoor unit.
3. Cut the pipes a little longer than measured distance.
4. Cut the cable 1.5m longer than the pipe length.
Burrs removal
1. Completely remove all burrs from the cut cross sec-
tion of pipe/tube.
2. Put the end of the copper tube/pipe in a downward
direction as you remove burrs in order to avoid drop-
ping burrs into the tubing.
Putting nut on
•Remove flare nuts attached to indoor and outdoor unit,
then put them on pipe/tube having completed burr
removal.
(not possible to put them on after flaring work)
Flaring work
1. Firmly hold copper pipe in a die in the dimension
shown in the table below.
2. Carry out flaring work with the flaring tool.
Copper
pipe
90°Slanted Uneven Rough
Pipe Reamer
Point down
Flare nut
Copper tube
mm inch mm
Ø6.35 1/4 0~0.5
Ø9.52 3/8 0~0.5
Ø12.7 1/2 0~0.5
Ø15.88 5/8 0~1.0
Ø19.05 3/4 1.0~1.3
Outside diameter A
Bar
Copper pipe
Clamp handle Red arrow mark
Cone
Yoke
Handle
Bar
"A"

- 16 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Installation
Check
1. Compare the flared work with the figure by.
2. If a flared section is defective, cut it off and do flar-
ing work again.
Indoor
1. Prepare the indoor unit's piping and drain hose for installation through the wall.
2. Remove the plastic tubing retainer(see the illustra-
tion by) and pull the tubing and drain hose away
from chassis.
3. Replace only the plastic tubing holder 1, not the
holder 2 in the original position.
1. Route the indoor tubing and the drain hose in the
direction of rear right.
2.
Insert the connecting cable into the indoor unit from
the outdoor unit through the piping hole.
•Do not connect the cable to the indoor unit.
•Make a small loop with the cable for easy connec-
tion later.
3. Tape the tubing, drain hose, and the connecting
cable. Be sure that the drain hose is located at the
lowest side of the bundle. Locating at the uper side
can cause drain pan to overflow inside the unit.
CAUTION: If the drain hose is routed inside
the room, insulate the hose with an insula-
tion material* so that dripping from "sweat-
ing"(condensation) will not damage furniture
or floors.
*Foamed polyethylene or equivalent is rec-
ommended.
Inclined
Inside is shiny without scratches
Smooth all round
Even length
all round
Surface
damaged Cracked Uneven thickness
= Improper flaring =
Connecting the Piping
For right rear piping
Drain hose
Connecting
pipe
Connecting cable
Tape
Drain hose
Tubing holder 1
Tubing holder 2

- 17 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Installation
4. Indoor unit installation
Hook the indoor unit onto the upper portion of the
installation plate.(Engage the two hooks of the rear
top of the indoor unit with the upper edge of the
installation plate.) Ensure that the hooks are prop-
erly seated on the installation plate by moving it left
and right.
Press the lower left and right sides of the unit
against the installation plate until the hooks engage
into their slots(clicking sound).
Connecting the piping to the indoor unit and drain
hose to drain pipe.
1. Align the center of the pipes and sufficiently tighten
the flare nut by hand.
2. Tighten the flare nut with a wrench.
3. When extending the drain hose at the indoor unit,
install the drain pipe.
Wrap the insulation material around the connect-
ing portion.
1. Overlap the connection pipe insulation material and
the indoor unit pipe insulation material. Bind them
together with vinyl tape so that there may be no
gap.
2. Wrap the area which accommodates the rear piping
housing section with vinyl tape.
3. Bundle the piping and drain hose together by wrap-
ping them with vinyl tape for enough to cover where
they fit into the rear piping housing section.
Drain hose
Connecting
cable
Indoor unit tubing Flare nut Pipes
Wrench
Indoor unit tubing
Open-end wrench (fixed)
Connection pipe
Flare nut
mm inch kg.m
Ø6.35 1/4 1.8
Ø9.52 3/8 4.2
Ø12.7 1/2 5.5
Ø15.88 5/8 6.6
Outside diameter Torque
Vinyl tape(narrow)
Adhesive
Drain pipe
Indoor unit drain hose
Plastic bands Insulation material
Vinyl tape(narrow)
Connection pipe
Connecting cable
Vinyl tape (wide) Wrap with vinyl tape
Indoor unit pipe
Pipe
Wrap with vinyl tape
Drain hose
Pipe
Vinyl tape(wide)

- 18 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Installation
1. Route the indoor tubing and the drain hose to the
required piping hole position.
2. Insert the piping, drain hose, and the connecting
cable into the piping hole.
3.
Insert the connecting cable into the indoor unit.
•Don't connect the cable to the indoor unit.
•Make a small loop with the cable for easy connec-
tion later.
4. Tape the drain hose and the connecting cables.
5. Indoor unit installation
•Hang the indoor unit from the hooks at the top of
the installation plate.
•Insert the spacer etc. between the indoor unit and
the installation plate and separate the bottom of
the indoor unit from the wall.
Connecting the piping to the indoor unit and the
drain hose to drain pipe.
1. Align the center of the pipes and sufficiently tighten
the flare nut by hand.
2. Tighten the flare nut with a wrench.
3. When extending the drain hose at the indoor unit,
install the drain pipe.
For left rear piping
Drain pipe
Connecting
cable
1 2
Installation plate
Spacer
Indoor unit
8cm
Indoor unit tubing Flare nut Pipes
Wrench
Indoor unit tubing
Connection pipe
Flare nut
Open-end wrench (fixed)
Vinyl tape
Adhesive
Drain hose
Indoor unit drain hose
(narrow)
mm inch kg.m
Ø6.35 1/4 1.8
Ø9.52 3/8 4.2
Ø12.7 1/2 5.5
Ø15.88 5/8 6.6
Outside diameter Torque

- 19 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Installation
Wrap the insulation material around the connect-
ing portion.
1. Overlap the connection pipe heat insulation and the
indoor unit pipe heat insulation material. Bind them
together with vinyl tape so that there may be no
gap.
2. Wrap the area which accommodates the rear piping
housing section with vinyl tape.
3. Bundle the piping and drain hose together by wrap-
ping them with cloth tape over the range within
which they fit into the rear piping housing section.
Reroute the pipings and the drain hose across the
back of the chassis.
Indoor unit installation
1. Remove the spacer.
2. Ensure that the hooks are properly seated on the
installation plate by moving it left and right.
3. Press the lower left and right sides of the unit
against the installation plate until the hooks engage
into their slots(clicking sound).
Plastic bands Insulation material
Vinyl tape(narrow)
Connection
pipe
Connecting cable
Indoor
unit piping
Pipe
Vinyl tape
(wide) Wrap with vinyl tape
Drain hose Vinyl tape(narrow)
Pipe
Wrap with
vinyl tape(wide)
Piping for
passage through
piping hole
Drain hose
Connecting
cable

- 20 -
Copyright ©2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes LGE Internal Use Only
Installation
CAUTION: Installation Information
For left piping. Follow the instruction below.
Good case
•Press on the upper side of clamp and unfold the tubing to downward slowly.
Bad case
•Following bending type from right to left may cause damage to the tubing.
