LG LWHD1006R User manual

COMBO TRAINING
LWHD1006R
Air Conditioner
LWHD1006R

p4
The serial number is
unique to each product.
It is required to be paid
for warranty service and
to get the correct part in
the event a running
production change was
made.
Some models may have
four (4) letters instead of
two (2) for the product
code number. The third
and fourth letters are
significant only to the
manufacturing facility.
LWHD1006R
Serial Number

For temperature
readings,
DB = dry bulb and
WB = wet bulb.
There are types of
thermometers used in
conjunction with
hygrometers in
determining actual and
absolute temperature
and humidity readings.
p5
LWHD1006R
Specifications

The LWHD1006R is a 115-volt window air conditioner. This product is a
consumer comfort appliance, not a precision climate control system.
p6
LWHD1006R
Introduction

The power cord is equipped with a 3-prong grounding plug. It also
incorporates an AFCI (Arc Fault Current Interrupter) as an integral part of
the power cord. If the TEST button does not trip or the RESET button does
not restore power, unplug the air conditioner and call an Authorized
Service Technician.
DO NOT tamper with or attempt to defeat or repair this device.
A faulty socket or bad connection can cause this device to trip.
p6
LWHD1006R
Grounding

The model and serial numbers are
on a sticker on the right side of the cabinet as you face the air conditioner
inside the house.
p7
These are always visible
if the air conditioner is
installed correctly.
LWHD1006R
Product Identification

There is another sticker on the left side showing other important
information about the air conditioner, including refrigerant type and charge.
p7
LWHD1006R
Product Identification

This air conditioner is designed to operate with approximately ½” of water
in the base pan. The condenser (outdoor) fan is made with a ring around
the edge of the blades. This slinger fan runs in the condensate collected in
the pan and expels it through the condenser, which causes a slight
increase in efficiency.
There is no need to add water if the pan is dry.
p9
LWHD1006R
Maintenance

The air conditioner is designed to be installed in a double- or single-hung
window with an actual opening width of 25 ~ 36 inches (not through a hole
in a wall or other structural modification) and plugged into a single-outlet,
dedicated 15-amp circuit without using an extension cord.
All applicable clearances
should be maintained.
All side louvers on the
cabinet must remain exposed
on the outside of the structure.
p9
LWHD1006R
Installation

Abbreviated installation instructions are included in the event the installer
must remove the air conditioner or replace it in the window.
p10
LWHD1006R
Installation

Titles
•Be sure the air conditioner is installed securely and firmly.
•Install the air conditioner so the back (outside) is slightly lower than the
front. This will force water to the drain at the back of the base pan.
•Install the air conditioner
so it is between
30 and 60 inches
above the floor.
p10
LWHD1006R
Installation

•If excess water collects in the base pan or the fan makes undesirable
noise running in the water, remove the rubber plug and install the drain
pipe.
•You can connect a hose
to the pipe and route
the overflow to a
convenient drain place.
p10
Drain plug (removed).
LWHD1006R
Installation

•Plug the air conditioner into a single-outlet 15-amp circuit.
•Be sure furniture and draperies do not block the air inlet and outlet.
p10
LWHD1006R
Installation

p10
LWHD1006R
Dimensions

The installation kit includes all the parts necessary to install the air
conditioner. The panels (1) are different for the left and right sides.
Refer to the chart to identify parts .
Kit is Part # 3127A10015B.
p11
LWHD1006R
Installation

•Refer to the parts list to ensure all parts are included.
•Sort the screws by size, shape, and quantity to determine which is which.
•The foam strip
(PE = poly-ethylene)
with adhesive is to be
applied under the
upper guide before
it is attached to the cabinet.
p10
LWHD1006R
Installation

•Remove the screws at the
back and the sides
of the cabinet.
•Grip the base pan handle
at the front and pull the
chassis out while holding
the cabinet.
•Remove the packing
material taped to the
dryer inside the air
conditioner and discard it.
p10
LWHD1006R
Installation

Attach the adhesive foam strip (11) to
the bottom of the upper guide (10).
p12
LWHD1006R
Installation

p12
Attach the upper guide (10) to
the cabinet using three screws
(Type A).
Note that the screws are inserted
into the guide from inside the
cabinet into the upper guide,
not through the guide into the
cabinet on the top.
LWHD1006R
Installation

Insert the frame guides in the
bottom of the cabinet. Place
the rounded part in the
center track and the tabs into
the rectangular slots. Press
the clip down toward the front
of the cabinet until the tabs
click into place.
p12
LWHD1006R
Installation
