LG LS091HSV3 User manual

SINGLE ZONE HIGH EFFICIENCY, STANDARD,
EXTENDED PIPE, AND MEGA WALL MOUNTED
INSTALLATION MANUAL
Single Zone High Efciency:
LS091HSV3, LS121HSV3, LS181HSV3, LS240HSV3
Single Zone Standard: LS307HV3, LS360HV3
Single Zone Extended Pipe: LS240HLV, LS300HLV, LS360HLV
Single Zone Mega: LS090HEV, LS120HEV, LS180HEV, LS240HEV
Single Zone Mega 115V: LS090HXV, LS120HXV

The instructions included in this manual must be followed to prevent product malfunction, property damage, injury, or death to the user or
other people. Incorrect operation due to ignoring any instructions will cause harm or damage. The level of seriousness is classified by the
symbols described below.
Do not throw away, destroy, or lose this manual.
Please read carefully and store in a safe place for future reference.
Content familiarity required for proper installation.
A summary list of safety precautions begins on page 3.
For more technical materials such as submittals, engineering
databooks, and catalogs, visit www.lghvac.com.
For continual product development, LG Electronics U.S.A., Inc., reserves the right to change specifications without notice.
©LG Electronics U.S.A., Inc.
This document, as well as all reports, illustrations, data, information, and other materials are the property of LG Electronics U.S.A., Inc.
PROPRIETARY DATA NOTICE
This document, as well as all reports, illustrations, data, information, and
other materials are the property of LG Electronics U.S.A., Inc., and are
disclosed by LG Electronics U.S.A., Inc., only in confidence.
This document is for design purposes only.
IM-WallMounted-ALL-08-14

3
Safety Instructions
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
SAFETY INSTRUCTIONS
The instructions below must be followed to prevent product malfunction, property damage, injury or death to the user or other people. Incor-
rect operation due to ignoring any instructions will cause harm or damage. The level of seriousness is classified by the symbols described
below.
INSTALLATION
TABLE OF SYMBOLS
This symbol indicates an imminently hazardous situation which, if not avoided, will result in death or serious
injury.
This symbol indicates a potentially hazardous situation which, if not avoided, could result in death or serious
injury.
This symbol indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
This symbol Indicates situations that may result in equipment or property damage accidents only.
This symbol indicates an action should not be completed.
Do not install, remove, or re-install the unit by yourself
(customer). Ask the dealer or an authorized technician to
install the unit.
Improper installation by the user may result in water leakage, re,
explosion, electric shock, physical injury or death.
For replacement of an installed unit, always contact an
authorized LG service provider.
There is risk of re, electric shock, explosion, and physical injury or death.
The unit is shipped with refrigerant and the service valves
closed. Do not open service valves on the unit until all
non-condensible have been removed from the piping system
and authorization to do so has been obtained from the com-
missioning agent.
There is a risk of equipment damage, refrigerant contamination, refriger-
ant loss, physical injury or death.
Be very careful when transporting the product.
• Do not attempt to carry the product without assistance.
• Some products use polypropylene bands for packaging. Do not use
polypropylene bands to lift the unit.
• Suspend the unit from the base at specified positions.
• Support the unit a minimum of four points to avoid slippage from
rigging apparatus.
Wear protective gloves when handling equipment. Sharp
edges may cause personal injury.
The unit is shipped with refrigerant and service valves
closed. Do not run the compressor with the service valves
closed.
There is a risk of equipment damage, explosion, physical injury, or death.
Dispose the packing materials safely.
• Packing materials, such as nails and other metal or wooden parts,
may cause puncture wounds or other injuries.
• Tear apart and throw away plastic packaging bags so that children
may not play with them and risk suffocation and death.
Install the unit considering the potential for strong winds or
earthquakes.
Improper installation may cause the unit to fall over, resulting in physical
injury or death.
If the air conditioner is installed in a small space, take
measures to prevent the refrigerant concentration from
exceeding safety limits in the event of a refrigerant leak.
Consult the latest edition of ASHRAE (American Society of Heating,
Refrigerating, and Air Conditioning Engineers) Standard 15. If the
refrigerant leaks and safety limits are exceeded, it could result in personal
injuries or death from oxygen depletion.
Install the unit in a safe location where nobody can step on or
fall onto it.
There is risk of unit damage, physical injury or death.
Do not install the unit on a defective stand.
There is a risk of property damage or physical injury.
Install the drain hose to ensure adequate drainage.
There is a risk of water leakage and property damage.

4
Single Zone High Efciency, Standard, Extended Pipe and Mega Wall Mount Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
SAFETY INSTRUCTIONS
Don’t store or use ammable gas / combustibles near the unit.
There is risk of product failure, re, explosion, and physical injury or death.
It may result in an accident that causes product damage or personal injury
or death.
Periodically check that the outdoor frame is not damaged.
There is a risk of equipment damage, explosion, physical injury, or death.
Do not change the settings of the protection devices.
If the pressure switch, thermal switch, or other protection device is
shorted and forced to operate improperly, or parts other than those
specied by LG are used, there is risk of re, electric shock, explosion,
and physical injury or death.
Replace all control box and panel covers.
If cover panels are not installed securely, dust, water and animals may
enter the water source unit, causing re, electric shock, and physical in-
jury or death.
Always check for system refrigerant leaks after the unit has
been installed or serviced.
Low refrigerant levels may cause product failure, and exposure to high
concentration levels of refrigerant gas may lead to illness or death. Keep
the unit upright during installation to avoid vibration or water leakage.
Don’t install the unit where it’s directly exposed to ocean winds.
Ocean winds may cause corrosion, particularly on the condenser and
evaporator ns, which, in turn could cause product malfunction or inef-
cient performance.
When installing the unit in a low-lying area, or a location that
is not level, use a raised concrete pad or concrete blocks to
provide a solid, level foundation.
This may prevent water damage and reduce abnormal vibration.
Properly insulate all cold surfaces to prevent “sweating.”
Cold surfaces such as uninsulated piping can generate condensate that
may drip and cause a slippery oor condition and / or water damage to
walls.
When installing the unit in a hospital, mechanical room, or
similar electromagnetic eld (EMF) sensitive environment,
provide sufcient protection against electrical noise.
Inverter equipment, power generators, high-frequency medical equip-
ment, or radio communication equipment may cause the air conditioner to
operate improperly. The unit may also affect such equipment by creating
electrical noise that disturbs medical treatment or image broadcasting.
Do not use the product for special purposes such as
preserving foods, works of art, wine coolers, or other
precision air conditioning applications. The equipment is
designed to provide comfort cooling and heating.
There is risk of property damage.
Do not make refrigerant substitutions. Use R410A only.
If a different refrigerant is used, or air mixes with original refrigerant, the
unit will malfunction and be damaged.
When connecting refrigerant tubing, remember to allow for
pipe expansion.
Improper piping may cause refrigerant leaks and system malfunction.
Do not install the unit in a noise sensitive area.
Take appropriate actions at the end of HVAC equipment life
to recover, recycle, reclaim or destroy R410A refrigerant
according to applicable U.S. Environmental Protection
Agency (EPA) rules.
INSTALLATION - CONTINUED

5
Safety Instructions
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
SAFETY INSTRUCTIONS
High voltage electricity is required to operate this system.
Adhere to the National Electrical Codes and these
instructions when wiring.
Improper connections and inadequate grounding can cause accidental
injury or death.
Always ground the unit following local, state, and National
Electrical Codes.
Turn the power off at the nearest disconnect before servicing
the equipment.
Electrical shock can cause physical injury or death.
Properly size all circuit breakers or fuses.
There is risk of re, electric shock, explosion, physical injury or death.
The information contained in this manual is intended for use
by an industry-qualied, experienced, certied electrician
familiar with the U.S. National Electric Code (NEC) who is
equipped with the proper tools and test instruments.
Failure to carefully read and follow all instructions in this manual can
result in equipment malfunction, property damage, personal injury or death.
All electric work must be performed by a licensed electrician
and conform to local building codes or, in the absence of
local codes, with the National Electrical Code, and the
instructions given in this manual.
If the power source capacity is inadequate or the electric work is not per-
formed properly, it may result in re, electric shock, physical injury or death.
Refer to local, state, and federal codes, and use power wires
of sufcient current capacity and rating.
Wires that are too small may generate heat and cause a re.
Secure all eld wiring connections with appropriate wire
strain relief.
Improperly securing wires will create undue stress on equipment power
lugs. Inadequate connections may generate heat, cause a re and phys-
ical injury or death.
WIRING

6
Single Zone High Efciency, Standard, Extended Pipe and Mega Wall Mount Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
SAFETY INSTRUCTIONS
Do not provide power to or operate the unit if it is ooded or
submerged.
There is risk of re, electric shock, physical injury or death.
Use a dedicated power source for this product.
There is risk of re, electric shock, physical injury or death.
Do not operate the disconnect switch with wet hands.
There is risk of re, electric shock, physical injury or death.
Periodically verify the equipment mounts have not
deteriorated.
If the base collapses, the unit could fall and cause property damage,
product failure, physical injury or death.
If gas leaks out, ventilate the area before operating the unit.
Leaking gas may cause re, electric shock, explosion, physical injury or
death if the unit is mounted in an enclosed, low-lying, or poorly ventilated
area and the system develops a refrigerant leak.
Do not allow water, dirt, or animals to enter the unit.
There is risk of unit failure, re, electric shock, physical injury or death.
Avoid excessive cooling and periodically perform ventilation
to the unit.
Inadequate ventilation is a health hazard.
Do not touch the refrigerant piping during or after operation.
It can cause burns or frostbite.
Do not operate the unit with the panel(s) or protective
cover(s) removed; keep ngers and clothing away from
moving parts.
The rotating, hot, cold, and high-voltage parts of the unit can cause
physical injury or death.
Periodically, check power cord and plug for damage.
Cord must be replaced by the manufacturer, its service agent, or similar
qualied persons in order to avoid physical injury and / or electric shock.
Do not open the inlet grille of the unit during operation. Do
not operate the unit with the panels or guards removed. Do
not insert hands or other objects through the inlet or outlet
with the unit is plugged in. Do not touch the electrostatic
lter, if the unit includes one.
The unit contains sharp, rotating, hot, and high voltage parts that can
cause personal injury and / or electric shock.
To avoid physical injury, use caution when cleaning or
servicing the air conditioner.
Clean up the site after installation is nished, and check that no metal scraps,
screws, or bits of wiring have been left inside or surrounding the unit.
Do not use this equipment in mission critical or special-
purpose applications such as preserving foods, works of art,
wine coolers or refrigeration. The equipment is designed to
provide comfort cooling and heating.
Oil, steam, sulfuric smoke, etc., can signicantly reduce the performance
of the unit, or damage its parts.
Provide power to the compressor crankcase heaters at least
six (6) hours before operation begins.
Starting operation with a cold compressor sump(s) may result in severe
bearing damage to the compressor(s). Keep the power switch on during
the operational season.
Do not block the inlet or outlet.
Unit may malfunction.
Securely attach the electrical part cover to the indoor unit
and the service panel to the outdoor unit.
Non-secured covers can result in re or electric shock due to dust or water.
OPERATION

7
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
TABLE OF CONTENTS
Safety Instructions................................................................................3
General Data..........................................................................................8
Unit Nomenclature...............................................................................8
Single Zone High Efficiency Unit Specifications..................................9
Single Zone Standard Unit Specifications..........................................11
Single Zone Extended Pipe Unit Specifications................................13
Single Zone Mega Unit Specifications..........................................15-18
Single Zone Mega115V Unit Specifications.......................................19
Electrical............................................................................................21
R410ARefrigerant.............................................................................22
General Installation Guidelines..........................................................23
Location Selection.............................................................................23
OceansideApplications.....................................................................24
Mounting Bolt Location......................................................................25
Required Clearances.........................................................................26
Mounting of Indoor Unit Installation Plate.....................................27-31
Mounting of Indoor Unit.....................................................................32
Piping Preparation.............................................................................33
Piping Materials and Handling......................................................35-39
Piping Support, Elbow Usage............................................................40
Refrigerant Piping System Layout.....................................................41
Refrigerant Piping Connections.........................................................42
Refrigerant Piping System Limitations...............................................42
Installation Overview.........................................................................44
Directional Pipe Formation................................................................45
Drain Hose.........................................................................................46
Outdoor Unit Connections............................................................47-51
Indoor Unit Connections....................................................................52
Indoor Unit Connections - Conduit Bracket Placement.....................53
Bundling and Cutting Line.................................................................54
Refrigerant Piping Insulation........................................................55-57
Air Purging.........................................................................................58
Leak Test/Soap Method Check..........................................................59
Evacuation of Lines...........................................................................60
Finishing Up.......................................................................................60
Remote Controller.............................................................................61
Pump Down, Cooling Only Mode......................................................62
Electrical Wiring..................................................................................63
General Information and Safety Guidelines.......................................63
Power Wiring Specifications and Best Practices...............................64
Controllers.........................................................................................66
Indoor Unit Electrical Connections...............................................67-71
Outdoor Unit Electrical Connections.............................................72-75
Self Diagnosis Functions ..................................................................76
LG SIMS - Self Diagnosis Functions ................................................78
Troubleshooting..................................................................................80
Error Codes .................................................................................80-82
Refrigerant Leaks..............................................................................83
Installation Checklist...........................................................................84

8
Single Zone High Efciency, Standard, Extended Pipe and Mega Wall Mount Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Single Zone Wall Mount Indoor and Outdoor Units
LS N091 HSV 3
Generation
3 = Third
Indoor/Outdoor Product
HSV = High Efficiency
HV = Standard
HLV = Extended Pipe
HEV = Mega
HXV = Mega 115V
Nominal Capacity
(Nominal cooling capacity in Btu/h)
090/091 = 9,000
120/121 = 12,000
180/181 = 18,000
240 = 24,000
300/307 = 30,000
360 = 36,000
Type
N = Indoor Wall Mount Unit
U = Outdoor Heat Pump Unit
Family
LS= High Efficiency Wall Mount / Standard/ / Extended Pipe / Mega
Unit Nomenclature

9
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Single Zone High Efciency Unit Specications
Type Single Zone High Efciency Units
System Model Number (IDU/ODU)
LS091HSV3
(LSN091HSV3/
LSU091HSV3)
LS121HSV3
(LSN121HSV3/
LSU121HSV3)
LS181HSV3
(LSN181HSV3/
LSU181HSV3)
LS240HSV3
(LSN240HSV3/
LSU240HSV3)
Nominal Cooling Capacity (Btu/h) 9,000 11,200 18,200 22,000
Cooling Power Input1(kW) 0.67 0.89 1.4 1.7
Nominal Heating Capacity (Btu/h)110,800 13,300 22,000 27,600
Heating Power Input1(kW) 0.70 1.0 1.7 2.3
COP 4.53 3.90 3.66 3.4
EER 13.3 12.5 12.6 12.5
SEER 21.5 21.5 20.5 20.0
HSPF 11.0 11.0 9.7 10.2
Power Supply (V/Hz/Ø) 208-230/60/1
Outdoor Unit Operating Range2
Cooling (°F DB) 14-118
Heating (°F WB) -4-75
Indoor Unit Operating Range2
Cooling (°F) 64-90
Heating (°F) 60-86
Unit Data
Refrigerant Type3R410A
Refrigerant Control EEV
IDU Sound Pressure4dB(A) (H/M/L) 38/33/24 39/33/24 45/40/35 46/43/39
ODU Sound Pressure4dB(A) 45 45 53 54
Power/Communication Cable5
(No. x AWG) 4 x 18
IDU Net/Shipping Weight (lbs) 23/28 23/28 32/41 36/42
ODU Net/Shipping Weight (lbs) 75/79 75/79 123/131 128/137
Compressor
Compressor Type (Qty) Rotary (1) Rotary (1) Twin Rotary (1) Twin Rotary (1)
Fan
IDU Type (Qty) Cross Flow (1)
ODU Type (Qty) Propeller (1)
Motor/Drive Brushless Digitally Controlled/Direct
Airflow Rate
IDU Max/H/M/L (CFM) 388/335/272/212 423/353/272/212 735/622/509/399 883/742/629/424
ODU Max (CFM) 1,165 1,165 2,119 2,119
Table 1: Single Zone High Efciency Unit Specications
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
1Power Input is rated at high speed.
2Low Ambient Wind Baffle Kit allows operation down to 0°F in cooling mode.
3Take appropriate actions at the end of HVAC equipment life to recover, recycle, reclaim or destroy R410A
refrigerant according to applicable regulations (40 CFR Part 82, Subpart F) under section 608 of CAA.
4Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
5All power/communication cables to be minimum 18 AWG, 4-conductor, stranded, shielded and must
comply with applicable and national code.
Power wiring is field supplied and must comply with the applicable local and national codes.
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level with 24.6 of refrigerant line per indoor unit and a 0 ft level
difference outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet bulb
(WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 59ºF wet bulb
(WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).

10
Single Zone High Efciency, Standard, Extended Pipe and Mega Wall Mount Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Type Single Zone High Efciency Units
System Model Number (IDU/ODU)
LS091HSV3
(LSN091HSV3/
LSU091HSV3)
LS121HSV3
(LSN121HSV3/
LSU121HSV3)
LS181HSV3
(LSN181HSV3/
LSU181HSV3)
LS240HSV3
(LSN240HSV3/
LSU240HSV3)
Piping
Liquid Line (in, OD) 1/4 1/4 3/8 3/8
Vapor Line (in, OD) 3/8 3/8 5/8 5/8
Condensation Line (OD, ID) 27/32, 5/8 27/32, 5/8 27/32, 5/8 27/32, 5/8
Additional Refrigerant Charge (oz/ft) 0.22 0.22 0.38 0.38
Max Pipe Length6(ft) 65.6 65.6 98.4 98.4
Piping Length6(no add’l
refrigerant, ft) 41.0 41.0 24.6 24.6
Max Elevation Difference (ft) 32.8 32.8 49.2 49.2
Table 1: Single Zone High Efciency Unit Specications - Continued
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
6Piping lengths are equivalent.
Power wiring is field supplied and must comply with the applicable local and national codes.
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level with 24.6 of refrigerant line per indoor unit and a 0 ft level
difference outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 59ºF wet
bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
Single Zone High Efciency Unit Specications

11
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Single Zone Standard Unit Specications
Table 2: Single Zone Standard Unit Specications
Type Single Zone Standard Units
System Model Number (IDU/ODU) LS307HV3 (LSN307HV3/LSU307HV3) LS360HV3 (LSN360HV3/LSU360HV3)
Nominal Cooling Capacity (Btu/h) 30,000 33,000
Cooling Power Input1(kW) 3.0 4.0
Nominal Heating Capacity (Btu/h)132,000 35,200
Heating Power Input1(kW) 3.1 3.8
COP 3.0 2.7
EER 10.0 8.2
SEER 18.0 16.1
HSPF 9.5 9.9
Power Supply (V/Hz/Ø) 208-230/60/1 208-230/60/1
Outdoor Unit Operating Range
Cooling (°F DB) 14-118 14-118
Heating (°F WB) -4-75 -4-75
Indoor Unit Operating Range
Cooling (°F) 64-90 64-90
Heating (°F) 60-86 60-86
Unit Data
Refrigerant Type2R410A R410A
Refrigerant Control EEV EEV
IDU Sound Pressure3dB(A) (H/M/L) 49/44/39 49/44/39
ODU Sound Pressure3dB(A) 55 55
Power/Communication Cable4 (No. x
AWG) 4 x 18 4 x 18
IDU Net/Shipping Weight (lbs) 36/42 36/42
ODU Net/Shipping Weight (lbs) 128/137 128/137
Compressor
Compressor Type (Qty) Twin Rotary (1) Twin Rotary (1)
Fan
IDU Type (Qty) Cross Flow Cross Flow
ODU Type (Qty) Propeller Propeller
Motor/Drive Brushless Digitally Controlled/Direct
Airflow Rate
IDU Max/H/M/L (CFM) 883/770/629/424 883/795/629/424
ODU Max (CFM) 2,119 2,119
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
1Power Input is rated at high speed.
2Take appropriate actions at the end of HVAC equipment life to recover, recycle, reclaim or destroy
R410A refrigerant according to applicable regulations (40 CFR Part 82, Subpart F) under section 608
of CAA.
3Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
4All power/communication cables to be minimum 18 AWG, 4-conductor, stranded, shielded and must
comply with applicable and national code.
Power wiring is field supplied and must comply with the applicable local and national codes
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level with 24.6 of refrigerant line per indoor unit and a 0 ft level
difference outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 59ºF wet
bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).

12
Single Zone High Efciency, Standard, Extended Pipe and Mega Wall Mount Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Type Single Zone Standard Units
System Model Number (IDU/ODU) LS307HV3 (LSN307HV3/LSU307HV3) LS360HV3 (LSN360HV3/LSU360HV3)
Piping
Liquid Line (in, OD) 3/8 3/8
Vapor Line (in, OD) 5/8 5/8
Condensation Line (OD/ID) 27/32, 5/8 27/32, 5/8
Additional Refrigerant Charge (oz/ft) 0.38 0.38
Max Pipe Length5(ft) 98.4 98.4
Piping Length5(no add’l
refrigerant, ft) 24.6 24.6
Max Elevation Difference (ft) 49.2 49.2
Table 2: Single Zone Standard Unit Specications - Continued
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
5Piping lengths are equivalent.
Power wiring is field supplied and must comply with the applicable local and national codes
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level with 24.6 of refrigerant line per indoor unit and a 0 ft level
difference outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 59ºF wet
bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
Single Zone Standard Unit Specications

13
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Type Single Zone Extended Pipe Units
System Model Number (IDU/ODU) LS240HLV (LSN240HLV/
LSU240HLV)
LS300HLV (LSN300HLV/
LSU300HLV)
LS360HLV (LSN360HLV/
LSU360HLV)
Nominal Cooling Capacity (Btu/h) 22,000 30,000 33,000
Cooling Power Input1(kW) 1.7 3.0 4.0
Nominal Heating Capacity (Btu/h)127,000 32,000 35,200
Heating Power Input1(kW) 2.3 3.1 3.8
COP 3.32 3.03 2.69
EER 12.5 10.0 8.2
SEER 21.0 18.5 16.5
HSPF 11 10 10
Power Supply (V/Hz/Ø) 208-230/60/1
Outdoor Unit Operating Range
Cooling (°F DB) 14-118
Heating (°F WB) -4-75
Indoor Unit Operating Range
Cooling (°F) 64-90
Heating (°F) 60-86
Unit Data
Refrigerant Type2R410A
Refrigerant Control EEV
IDU Sound Pressure3dB(A) (H/M/L) 49/44/40 49/44/40 49/44/40
ODU Sound Pressure3dB(A) 55 55 55
Power/Communication Cable4 (No. x
AWG) 4 x 18
IDU Net/Shipping Weight (lbs) 40/46 40/46 40/46
ODU Net/Shipping Weight (lbs) 125/133 125/133 125/133
Compressor
Compressor Type (Qty) Twin Rotary (1) Twin Rotary (1) Twin Rotary (1)
Fan
IDU Type (Qty) Cross Flow
ODU Type (Qty) Propeller
Motor/Drive Brushless Digitally Controlled/Direct
Airflow Rate
IDU Max/H/M/L (CFM) 848/706/530/459 848/706/530/459 848/706/530/459
ODU Max (CFM) 2,119 2,119 2,119
Table 3: Single Zone Extended Pipe Unit Specications
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
1Power Input is rated at high speed.
2Take appropriate actions at the end of HVAC equipment life to recover, recycle, reclaim or destroy
R410A refrigerant according to applicable regulations (40 CFR Part 82, Subpart F) under section 608
of CAA.
3Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
4All power/communication cables to be minimum 18 AWG, 4-conductor, stranded, shielded and must
comply with applicable and national code.
Power wiring is field supplied and must comply with the applicable local and national codes
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level with 24.6 of refrigerant line per indoor unit and a 0 ft level
difference outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 59ºF wet
bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
Single Zone Extended Pipe Unit Specications

14
Single Zone High Efciency, Standard, Extended Pipe and Mega Wall Mount Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Type Single Zone Extended Pipe Units
System Model Number (IDU/ODU) LS240HLV (LSN240HLV/
LSU240HLV)
LS300HLV (LSN300HLV/
LSU300HLV)
LS360HLV (LSN360HLV/
LSU360HLV)
Piping
Liquid Line (in, OD) 3/8 3/8 3/8
Vapor Line (in, OD) 5/8 5/8 5/8
Condensation Line (OD, ID) 27/32, 5/8 27/32, 5/8 27/32, 5/8
Additional Refrigerant Charge (oz/ft) 0.38 0.38 0.38
Max Pipe Length5(ft) 164 164 164
Piping Length5(no add’l
refrigerant, ft) 24.6 24.6 24.6
Max Elevation Difference (ft) 98.4 98.4 98.4
Table 3: Single Zone Extended Pipe Unit Specications - Continued
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
5Piping lengths are equivalent.
Power wiring is field supplied and must comply with the applicable local and national codes
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level with 24.6 of refrigerant line per indoor unit and a 0 ft level
difference outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 59ºF wet
bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
Single Zone Extended Pipe Unit Specications

15
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Single Zone Mega Unit Specications
Type Single Zone Mega Inverter
System (Model IDU/ODU) LS090HEV (LSN090HEV/LSU090HEV) LS120HEV (LSN120HEV/LSU120HEV)
Nominal Cooling Capacity (Btu/h) 8,500 12,000
Cooling Power Input1(kW) 0.78 1.17
Nominal Heating Capacity (Btu/h) 9,000 12,000
Heating Power Input1(kW) 0.78 0.98
COP 3.19 3.00
EER 10.90 10.26
SEER 16.3 16.3
HSPF 8.3 8.5
Power Supply (V / Hz / Ø) 208-230/60/1
ODU Operating Range
Cooling (°F DB) 64-118
Heating (°F WB) 23-75
IDU Operating Range
Cooling (°F WB) 64-90
Heating (°F DB) 60-86
Indoor Temperature Setting Range
Cooling (°F) 65-86
Heating (°F) 61-86
Unit Data
Refrigerant Type2R410A
Refrigerant Control Capillary Tube
IDU Sound Pressure3± 3 dB(A) (H/M/L) 39/33/25 39/33/25
ODU Sound Pressure ± 3 dB(A) 47 47
Indoor Unit (Net/Shipping Weight lbs.) 16/21 20/25
Outdoor Unit (Net/Shipping Weight lbs.) 52/56 49/53
Power/Communication Cable4(No. x AWG) 4 x 18
Compressor
Compressor Type (Qty) Single Rotary (1) Single Rotary (1)
Fan
Indoor Type (Qty) Cross Flow (1)
Outdoor Type (Qty) Propeller (1)
Motor/Drive Brushless Digitally Controlled/Direct
Airflow Rate
Indoor - Max/H/M/L (CFM) 318/276/226/177 424/353/272/212
Outdoor - Max (CFM) 953 953
Table 4: Single Zone Mega Unit Specications

16
Single Zone High Efciency, Standard, Extended Pipe and Mega Wall Mount Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
EEV: Electronic Expansion Valve
Power wiring is field supplied and must comply with the applicable local and national codes.
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level, with 24.6 ft of refrigerant line per indoor unit and a 0 ft level difference
between outdoor and indoor units. All capacities are net with a combination ratio between 95-105%.
Cooling capacity rating obtained with air entering the indoor coil at 80ºF dry bulb (DB) and 67ºF wet bulb (WB);
and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 60ºF wet bulb (WB);
and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
1Power Input is rated at high speed.
2Take appropriate actions at the end of HVAC equipment life to recover, recycle, reclaim or
destroy R410A refrigerant according to applicable regulations (40 CFR Part 82, Subpart F)
under section 608 of CAA.
3Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
4All power/communication cable to be minimum 18 AWG, 4-conductor, stranded, shielded
and must comply with applicable and national code.
5Piping lengths are equivalent.
Type Single Zone Mega Inverter
System (Model IDU/ODU) LS090HEV (LSN090HEV/LSU090HEV) LS120HEV (LSN120HEV/LSU120HEV)
Piping
Liquid Line (in, OD) 1/4 1/4
Vapor Line (in, OD) 3/8 3/8
Condensation Line (OD | ID) 27/32 | 5/8 27/32 | 5/8
Additional Refrigerant Charge (oz/ft) 0.22 0.22
Max Pipe Length (ft)549.2 49.2
Piping Length (no add’l refrigerant, ft)524.6 24.6
Max Elevation Difference (ft) 22.9 22.9
Table 4: Single Zone Mega Unit Specications - Continued
Single Zone Mega Unit Specications

17
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Table 4: Single Zone Mega Unit Specications - Continued
Single Zone Mega Unit Specications
Type Single Zone Mega Inverter
System (Model IDU/ODU) LS180HEV (LSN180HEV/LSU180HEV) LS240HEV (LSN240HEV/LSU240HEV)
Nominal Cooling Capacity (Btu/h) 17,000 22,000
Cooling Power Input1(kW) 1.55 2.04
Nominal Heating Capacity (Btu/h) 19,000 22,000
Heating Power Input1(kW) 1.59 1.93
COP 3.19 3.00
EER 10.95 10.75
SEER 17.0 17.0
HSPF 8.7 8.5
Power Supply (V / Hz / Ø) 208-230/60/1
ODU Operating Range
Cooling (°F DB) 64-118
Heating (°F WB) 23-75
IDU Operating Range
Cooling (°F WB) 64-90
Heating (°F DB) 60-86
Indoor Temperature Setting Range
Cooling (°F) 65-86
Heating (°F) 61-86
Unit Data
Refrigerant Type2R410A
Refrigerant Control Capillary Tube
IDU Sound Pressure3± 3 dB(A) (H/M/L) 42/40/35 45/40/35
ODU Sound Pressure ± 3 dB(A) 51 53
Indoor Unit (Net/Shipping Weight lbs.) 28/30 28/34
Outdoor Unit (Net/Shipping Weight lbs.) 72/77 92/104
Power/Communication Cable4(No. x AWG) 4 x 18
Compressor
Compressor Type (Qty) Twin Rotary (1) Twin Rotary (1)
Fan
Indoor Type (Qty) Cross Flow (1)
Outdoor Type (Qty) Propeller (1)
Motor/Drive Brushless Digitally Controlled/Direct
Airflow Rate
Indoor - Max/H/M/L (CFM) 629/512/441/353 689/600/494/388
Outdoor - Max (CFM) 1,342 1,766

18
Single Zone High Efciency, Standard, Extended Pipe and Mega Wall Mount Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Type Single Zone Mega Inverter
System (Model IDU/ODU) LS180HEV (LSN180HEV/LSU180HEV) LS240HEV (LSN240HEV/LSU240HEV)
Piping
Liquid Line (in, OD) 1/4 1/4
Vapor Line (in, OD) 1/2 5/8
Condensation Line (OD | ID) 27/32 | 5/8 27/32 | 5/8
Additional Refrigerant Charge (oz/ft) 0.33 0.33
Max Pipe Length (ft)565.6 65.6
Piping Length (no add’l refrigerant, ft)524.6 24.6
Max Elevation Difference (ft) 32.8 32.8
EEV: Electronic Expansion Valve
Power wiring is field supplied and must comply with the applicable local and national codes.
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level, with 24.6 ft of refrigerant line per indoor unit and a 0 ft level difference
between outdoor and indoor units. All capacities are net with a combination ratio between 95-105%.
Cooling capacity rating obtained with air entering the indoor coil at 80ºF dry bulb (DB) and 67ºF wet bulb (WB);
and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 60ºF wet bulb (WB);
and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
1Power Input is rated at high speed.
2Take appropriate actions at the end of HVAC equipment life to recover, recycle, reclaim or
destroy R410A refrigerant according to applicable regulations (40 CFR Part 82, Subpart F)
under section 608 of CAA.
3Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
4All power/communication cable to be minimum 18 AWG, 4-conductor, stranded, shielded
and must comply with applicable and national code.
5Piping lengths are equivalent.
Table 4: Single Zone Mega Unit Specications - Continued
Single Zone Mega Unit Specications

19
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Single Zone Mega115V Unit Specications
Type Single Zone Mega Inverter
System (Model IDU/ODU) LS090HXV (LSN090HXV/LSU090HXV) LS120HXV (LSN120HXV/LSU120HXV)
Nominal Cooling Capacity (Btu/h) 8,500 12,000
Cooling Power Input1(kW) 0.71 1.14
Nominal Heating Capacity (Btu/h) 10,900 13,000
Heating Power Input1(kW) 0.88 1.09
COP 3.63 3.50
EER 12.01 10.5
SEER 17.0 17.0
HSPF 9.0 9.0
Power Supply (V / Hz / Ø) 115/60/1
ODU Operating Range
Cooling (°F DB) 14-118
Heating (°F WB) 14-75
IDU Operating Range
Cooling (°F WB) 64-90
Heating (°F DB) 60-86
Indoor Temperature Setting Range
Cooling (°F) 65-86
Heating (°F) 61-86
Unit Data
Refrigerant Type2R410A
Refrigerant Control EEV
IDU Sound Pressure3± 3 dB(A) (H/M/L) 39/33/25 39/33/25
ODU Sound Pressure ± 3 dB(A) 47 47
Indoor Unit (Net/Shipping Weight lbs.) 23/26 23/26
Outdoor Unit (Net/Shipping Weight lbs.) 67/79 67/79
Power/Communication Cable4(No. x AWG) 4 x 18
Compressor
Compressor Type (Qty) Single Rotary (1) Single Rotary (1)
Fan
Indoor Type (Qty) Cross Flow (1)
Outdoor Type (Qty) Propeller (1)
Motor/Drive Brushless Digitally Controlled/Direct
Airflow Rate
Indoor - Max/H/M/L (CFM) 335/272/212/124 335/272/212/124
Outdoor - Max (CFM) 1,000 1,000
Table 5: Single Zone Mega 115V Unit Specications

20
Single Zone High Efciency, Standard, Extended Pipe and Mega Wall Mount Installation Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
EEV: Electronic Expansion Valve
Power wiring is field supplied and must comply with the applicable local and national codes.
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level, with 24.6 ft of refrigerant line per indoor unit and a 0 ft level difference
between outdoor and indoor units. All capacities are net with a combination ratio between 95-105%.
Cooling capacity rating obtained with air entering the indoor coil at 80ºF dry bulb (DB) and 67ºF wet bulb (WB);
and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 60ºF wet bulb (WB);
and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
1Power Input is rated at high speed.
2Take appropriate actions at the end of HVAC equipment life to recover, recycle, reclaim or
destroy R410A refrigerant according to applicable regulations (40 CFR Part 82, Subpart F)
under section 608 of CAA.
3Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
4All power/communication cable to be minimum 18 AWG, 4-conductor, stranded, shielded
and must comply with applicable and national code.
5Piping lengths are equivalent.
Type Single Zone Mega Inverter
System (Model IDU/ODU) LS090HXV (LSN090HXV/LSU090HXV) LS120HXV (LSN120HXV/LSU120HXV)
Piping
Liquid Line (in, OD) 1/4 1/4
Vapor Line (in, OD) 3/8 3/8
Condensation Line (OD | ID) 27/32 | 5/8 27/32 | 5/8
Additional Refrigerant Charge (oz/ft) 0.22 0.22
Max Pipe Length (ft)549.2 49.2
Piping Length (no add’l refrigerant, ft)524.6 24.6
Max Elevation Difference (ft) 23 23
Table 5: Single Zone Mega 115V Unit Specications - Continued
