LG LGC-500W Manual

LGC500W Operator’s Guide
July 8, 1999
Terminal Research Institute Software Development Sector
Jong-sung Park

Terminal Development Center
1
LGIC
Call Status Functions
1.Scratch Pad (Menu Soft Key 1 + 1)
* Function to store a telephone number while calling
lSelect Menu + 1and enter the telephone number to store.
lPress Store (Soft Key 2) key. (Name is not stored)
2.Send Own No. (Menu Soft Key 1 + 2)
* Function to transmit her/his own number while calling
lYou can transmit your own number while calling by pressing menu Soft Key 1 + 2.
3.Volume Control (Soft Key2)
* Function to control the volume while calling
lYou can control the volume by pressing Soft Key 2.
Select the volume using the v(center soft key) or V/#’button or Side Key
4.Mute Feature (the bottom of center soft key)
* Function to mute the speech voice while calling
lIf you press the bottom of center soft key( ç ), the speech tone is muted immediately.
If you want to deactivate this mute function, press the bottom of center soft key again.

Terminal Development Center
2
LGIC
Stand-by Status Menu Set-up and Its Functions
1. PIM [Menu + 1]
* Phone Book / Scheduler / Alarm / Call Reserve / World Time
1.1 Phone Book [Menu +1 + 1 ]
1.1.1 New Entry [Menu +1+1+ 1 ]
1.1.2 Find Entry [Menu +1+1+ 2 ]
1.1.3 Delete Entry [Menu +1+1+ 3 ]
-You can navigate these menus by follow soft_key direction.
1.2 Schedule Management Secretary [Menu +1 + 2 ]
-You can navigate these menus by follow soft_key direction.
¢ÑTime display is not serviced in a ANALOG system and can’t guarantee any functions
with regard to time including above menu.
1.3 Alarm Secretary [Menu +1 + 3 ]
Alarm Time
*User can set an alarm to the desired time.
lSelect Menu + 1+ 3.
lSelect one of ‘OFF / EVERY DAY / ONCE’.
lIf you select ‘OFF’, it becomes the state of stand-by. In case an alarm time was set previously,
that setting time will be deleted.
lWhen ‘EVERYDAY / ONCE’is selected, you just enter the alarm time in the order of hour and
minute.
lIn case the alarm time has been set already, the set alarm time and the soft keys of EDIT/OK are
displayed.
- If you select EDIT here, the soft key 1 of EDIT is displayed in ‘AM’or ‘PM”mode for editing the
input.
l‘AM’and ‘PM’mode can be switched with Soft Key1[AM/PM]
lYou can edit the entered contents using the bottom of center soft key (ç)
lPress OK key to store the entered alarm time.
¢ÑNote: The alarm bell is triggered at the set alarm time with the message of “Alarming Now”
displayed on the display.
¢ÑNote: In case ‘Once’is selected, if the END key is pressed or 1minute is passed, the alarm time is
deleted.

Terminal Development Center
3
LGIC
1.4 Call Reservation Secretary [Menu + 1 + 4 ]
Call Reserve
*Function to originate a call to the reserved number automatically at the reserved time.
lSelect Menu + 1+ 4.
lEnter the reservation time in the order of “Hour :Minute”.
l‘AM’and ’PM’mode can be switched with Soft Key 1[AM/PM].
lPress OK key to store the entered reserved call time.
lEnter the reservation telephone number.[Up to 32 characters acceptable]
lStore the entered telephone number using OK key.
¢ÑNote: Telephone rings at the reserved time with the message of “Reserve Time”on the
display.
¢ÑNote:If the END key is pressed or one minute is passed, the reserved call time is automatically
deleted and stored in the last call list.
1.5 World Time secretary [Menu +1 + 5]
World Time
*Function to confirm the standard time of major cities in the world based on GPC time.
This function is available in CDMA mode only.
lSelect Menu + 1+ 5.
lSelect the city you want to check using ’v(center soft_key)’or ‘V/#’key and press OK key.
Then, the international standard time of the selected city is appeared.
¢ÑCities applicable
ABU DHABI / AMSTERDAM / ANCHORAGE / ATHENS / AZORES / BANGKOK /
BEIJING / BEIRUT / BERLIN / BOSTON / BUENOS AIRES / CAIRO / CARACAS /
CHICAGO / COLOMBO / DACCA / DALLAS / DELHI / DENVER / DETROIT /
GUAM / HANOI / HELSINKI / HONG KONG / HONOLULU / JAKARTA / JEDDA /
KABUL / KUWAIT / LISBON / LONDON / LOS ANGELES / MADRID / MANILA /
MEXICO CITY / MONTREAL / MOSCOW / NEW YORK / OAKLAND / PARIS /
RIO DE JANEIRO / ROME / SEATTLE / SINGAPORE / SYDNEY / TAIPEI / TEHERAN
TOKYO / VIENNA / WASHINGTON

Terminal Development Center
4
LGIC
2.Volume Control [Menu + 2]
* Function to control Ringer /Key Beep /EarPiece
2.1 Ringer control[3step+SILENT]
lSelect Menu + 2+ 1.
lSelect the volume using ’v(center soft_key)’
lOr select the volume you want using V/#keys.
lStore the selected volume using the Soft Key2(SELECT).
2.2 Key Beep Volume Control [3-step +Mute]
lSelect Menu + 2+ 2.
lSelect the volume using ’v(center soft_key)’
lOr select the volume you want using V/#key.
lStore the selected volume using the Soft Key2(SELECT).
2.3 Volume Control [8-step + Low]
lSelect Menu + 2+ 3.
lSelect the volume using ’v(center soft_key).’
lOr select the volume you want using V/#key.
lStore the selected volume using the Soft Key2(SELECT).
3. Bell Selection [Menu +3]
* Function to select the bell type for the incoming call.
3.1 Types of Bell [Ring / Vibration / Vibration + Ring]
lSelect Menu + 3+ 1.
lSelect the bell type using’v(center soft_key)’
lOr select the type of bell you want using V/#key.
lStore the selected status using the Soft Key2(SELECT).
3.2 Bell Selection (12 types)
[Sound 1~12]
lSelect Menu + 3+ 2
lSelect the type of bell using the ’v(center soft_key)’.
lOr select the bell you want using V/#key.
lStore the selected status using the Soft Key2(SELECT)

Terminal Development Center
5
LGIC
4. Call Info [Menu + 4]
* Function to verify the record on the call time
4.1 Last Call Time
*Function to show the last call time
lSelect Menu + 4+ 1.
lPress OK key to return to the stand-by state.
4.2 HomeCalls
*Function to show the total number and time of all calls made while in the home system.
lSelect Menu+4+2
lIf you select OK key , it returns to the stand-by status.
4.3 Roam Calls
*Function to show the total number and time of all calls made while in the roaming
lSelect Menu+4+3
lIf you select OK key , it returns to the stand-by status.
4.4All Calls
*Function to show the number of call and the call time for all calls of receiving and transmitting.
User can verify the total number of calls made and the call time through this function.
lSelect Menu + 4+ 4.
lIf you select OK key , it returns to the stand-by status and if you select CLERkey (Soft Key1), you
can delete the accumulated total call time.
5. Security Function [Menu +5 + Password 4-digit]
*Lock Mode / Restrict / Clear Calls / clear Memory / Emergency # / New Code / Version
5.1. Lock Mode
*Function to restrict the originating and storing functions.
*You can select ‘NEVER / ON POWER UP/ NOW’
lPress Menu + 5+ Password 4-digit + 1
lSelect one of ‘NEVER / ON POWER UP/ NOW’using v(center soft_key)’Or ‘V/#’key and
press the store key.
lIf you select ‘NOW’, the phone falls in the lock mode always, and PIM menu and the calling are
locked.

Terminal Development Center
6
LGIC
-If you try to call in this case, you are prompted for the password and if the entered password is
identified, the call is established. In the lock mode, if you press [UNLOCK] button,
[UNLOCK] button is changed to [SEARCH] button.
-Even in this case, whenever you try to call, the password is required but PIM is released
-If you want the locking release, you should release this setup from the [Menu]+5.
lIf you select ‘ON POWER UP’, the locking function is not immediately executed but when the
phone is switched on, it is automatically set to the lock mode and at the same time, the soft key is
changed to [Menu], [unlock].
¢ÑDefault password is ‘0000’.
5.2.Restrict
*you can only call using the telephone numbers stored in the Phone Book.
lMenu”+5+Password-4digit+2.
lSelect ‘Yes’using v(center soft key) and press the SELECT key.
5.3. clear Calls
*Function to delete all the telephone numbers stored in the last call list.
lSelect Menu + 5 + Password 4-digit + 3
lPress OK key
5.4. Clear Memory
*Function to delete all the contents stored in the memory address 01 ~ 200.
lSelect Menu +5 + Password 4-digit + 3.
lPress OK key
¢ÑDuring the deletion, a message of ‘Please, wait’appears and after the completion of the deletion
it returns to the stand-by status.
5.5. Emergency
*Function used to enter the emergency telephone number [Up to 3 numbers ]
lSelect Menu + 5 + Password 4-digit + 5.
If the telephone number stored in the telephone number 1is appeared empty, a message of
‘Empty’appears.
lSelect the memory address where you want to make input using Soft Key1 (¡å) or ‘V/#’key
lSelect the edit mode by pressing EDIT key.
lEnter the telephone to store and press OK key.

Terminal Development Center
7
LGIC
If you want to terminate the process at this time, press the END key and if you want to enter the
telephone in other memory address, repeat the procedures that follow the step of memory address
selection.
5.6.New Code
*Function to change the password
lSelect Menu + 5 + Password 4-digit + 6.
lEnter a new password of 4-digit and press ‘OK’key.
lFor the reconfirmation, enter the password you entered just before in 4-digit.
lPress OK key. [It is then back to the previous status]
5.7. Software Version Confirm
*Function to confirm the software version of the phone.
lSelect Menu + 5 + Password 4-digit + 7.
.
6.Display
6.1 Backlight
* Function to control the turn off time of the LCD and Keypad backlighting.
lSelect Menu+6+1.
lChoose one of AlwaysOff / On Flip Open / 10Sec / Auto usingv(center soft_key)
lPress ‘SELECT’Key to save
¢Ñ¢ÑFollowing values can be set.
AlwaysOff : Background illumination is always off.
10 Sec :Background illumination is on for 10 seconds.
Auto :It remains in off-state from 08:00 through 17:00, otherwise the background
illumination lights up every 9 seconds.
On Flip Open: Background illumination lights up only when the flip is open.
6.2 key Beep
* Function to control the DTMF TONE length
lMenu+6+2.
lChoose one of Normal/Long using v(center soft_key) and press SAVE key

Terminal Development Center
8
LGIC
¢ÑNormal: Once the key is pressed, DTMF TONE is transmitted for a specific period [200ms]
Long: DTMF TONE is transmitted constantly, while the key is pressed on hold.
6.3 Banner
*Function to display on the top line when the phone powers up and when it is in standby.
lMenu+6+3.
lEnter the contents of logo. [Up to 16charcters].
lPress SELECT Key.
7.Advanced
7.1 Data/Fax In (can’t use now)
lModem Terminating Setup [Only available for a phone with data communication function]
*When you use the data communication function , you can select modem communication or fax
communication.
lSelect ‘Menu + 7 + 1’
lSelect one of ‘Terminating Release / Modem Terminating / Fax Terminating’using v(center
soft_key) and V/# key and press SELECT key.
Modem Communication: You select this mode when you receive the counterpart’s call in the 1 : 1 data
communication mode.
Fax Communication: You select this mode when you receive a fax from your counterpart
7.2 Auto Answer [Menu + 7+2]
*It is used for the setup of functions that are related with the automatic answering function.
¢ÑNote: If you are not in a position to answer a call, you can record the message of the counterpart
by answering the call automatically.
lSelect ‘Menu + 7+2’
lChoose one of Off / 1RING / 3RING using v(center soft_key) and press ‘SELECT’Key.
7.3 Language (can’t use now)
*Function to select language to be displayed in LCD.
lSelect ‘Menu+7+3’.
lChoose one of English /Spanish/French/Portuguese and press ‘SELECT’Key.

Terminal Development Center
9
LGIC
8.Alert [Menu + 8]
* Three types of audible alert are provided.
8.1 Fade Alert
*An alert to notify that it is’t in the service area.
lSelect ‘Menu + 8+ 1’
lSelect ‘ON’of ‘ON/OFF’and press ‘SELECT’key.
8.2 Service Alert
*An alert to notify that the service area has been changed.
lSelect ‘Menu + 8+ 2’
lSelect ‘Setup’of ‘On / Off’and press ‘SELECT’key.
8.3 1 Minute Alert
*An alert that is triggered 10 seconds before every minute as one minute is passed
during the call.
lSelect ‘Menu + 8+ 3’
lSelect ‘Setup’of ‘Setup/Release’and press SELECT’key.
9. System Setup [Menu + 000000]
* This is the function used for the dual mode . You can select the mode in use and
the system.
9.1Prog Mode [ Menu + 0 + 000000 + 1]
*Select NAM#1 ~ NAM#4PARAMETERS.
lSelect ‘Menu + 0 + 000000 + 1’+1~4(NAM#)
NAM#1 ~ NAM#4 PARAMETER => ESN display =>Phone Number [ ] =>Home SID[ ]
=>NAM Name[ ] => Service Code [ ] => System Number [ ] => Country Code[ ]
=>Network Code[ ] => Phone model [ ] => Slot Cycle Index[ ]. ( [ ] mean that it can be edited) ,
lJust after selecting NAM# ( 1~4 ) , you can choose AKEY soft_key2 and can input Akey value
for Authentication process

Terminal Development Center
10
LGIC
9.2Pref Mode [ Menu + 0 + 000000 + 2]
*Select the one of CDMA only , ANALOG pref, ANALOG olnly and CDMA pref using NEXT
soft_key2 and press OK soft_key1 for storing
9.3ER Mode [ Menu + 0 + 000000 + 3]
*Please see your service provider for details and availability .
9.4PRL [ Menu + 0 + 000000 + 4]
*Please see your service provider for details and availability .
10. Advanced ÀÇ System ¼³Á¤
10.1 Field Service [ Menu + 7 + 0 + 000000 + 1 ] ]
*Used for the call test of the PHONE, check of the phone status, verification of the error list and the
deletion of the error list.
10.1.1 Screen [Menu +7+0 + 000000 +1 + 1]
*As the function capable of checking the status of the phone, this performs to verify the status of the
current reception task, RX AGC VALUE, TX GAIN, PN OFFSET and PILOT ACTIVE.
lSelect ‘Menu + 0 + 000000 + 3 + 1’
¢ÑFirst LINE
1 ~ 3 : PN OFFSET / 5 : Status of Reception TASK / 7 ~ 8 : RX AGC VALUE
¢ÑSecond LINE
1 : No meaning / 3 : Status of PILOT ACTIVE / 7 ~ 8 : TX GAIN VALUE
10.1.2 Test Call [Menu +7+ 0 + 000000 + 1 + 2 ]
*It can make test of 8K / 13K Markov and loopback.
lSelect ‘Menu + 7+0 + 000000 + 1 + 2’
lSelect one of OLD8K Markov / NEW8K Markov / 8K loopback / NEW13K Markov / 13K
loopbacks using center soft key and press SAVE key. You can verify the call operation under the
selected status.
10.1.3CDMA Only [Menu+7+0+000000+1+3].

Terminal Development Center
11
LGIC
*Change the mode to use the CDMA only
10.1.4 Clear Errors [ Menu + 7 + 0 + 000000 + 1 + 4]
*Function used to delete the entities stored in the error list.
lSelect ‘Menu +7+ 0 + 000000 + 1 + 4’.
lSelect ‘Yes’of ‘Yes/No’using center soft Key and press SELECT key.
10.1.5Errors [ Menu + 7 + 0 + 000000 + 1 +5]
*Function used to verify the entities stored in the error list.
lSelect ‘Menu +7+ 0 + 000000 + 1 + 5’
lYou can verify 20 lists of error using the next setup key (Soft Key1) or V/# key.
End => It returns to the stand-by status
Del => It returns to the previous state
10.2 Select [Menu + 7 + 0 + 000000 + 2]
*Select the system to be used.
lChoose one of A Only / A Then B / B Only / B Then A / HOME Only / Standard Only
lpress ‘SELECT’Key
10.3 Set NAM [Menu + 7 + 0 +000000+3]
*select one of NAM#1 ~ NAM#4
lselect one of NAM#1 ~ NAM#4
lpress ‘SELECT’Key.
¢ÑBecause NAM#1 ~ NAM#4have different NAM PARAMER value if a selected NAM is not
matched registered number, it is not served
10.4 AUTO NAM [Menu + 7+ 0 + 000000 + 4]
*It is the function to automatically set the NAM that is identified with the subscribed number when
more than one NAM are used.

Terminal Development Center
12
LGIC
lSelect ‘Menu + 0 + 7+ 000000 + 4’.
lSelect ‘ON’of ‘ON/OFF’using center soft key or ‘V/#’key and press ‘SELECT’key.
lEditable PARAMETER LISTS . [ NAM#1 ~ NAN#4]
10.5 Voc Select[Menu+7+0+000000+5]
lEVRC/8K Q /13K Q
lSelect ‘Menu + 7 + 0 + 000000 + 5’
lSelect EVRC/ 8K/13K using center soft Key.
10.6 DM_DATA Set[Menu+7+0+000000+6]
*for programmer ( Can’t use now)
11. SMS
11.1 message - Text
*check the received Text Message
lSelect ‘the surface of center soft key(MSG)’+1+1.
lPress ‘VIEW’Key
11.1.2 Message -Voice
*check the received Voice Message
lselect ‘‘the surface of center soft key(MSG)’+1+2.
lPress ‘VIEW’Key
11.1.3 Delete All
*delete received Text/Voice Message
lSelect ‘the surface of center soft key(MSG)’+ 1 + 3.
lPress ‘SELECT’Key
11.2 Setup
11.2.1 Alert Type
* Function to choose a alert type
l2times / 4 times / Vibration / Silent
l‘the surface of center soft key(MSG)’+ 2 + 1

Terminal Development Center
13
LGIC
lselect Alert type and press ‘SELECT’Key
11.2.2 Display.
l‘the surface of center soft key(MSG)’+ 2 + 2 .
lSelect one of CONTENT/TILE.
lPress ’SELECT’Key to save.
Using Search Menu
1. Latest Call List [Search + 1]
* Used to verify the list of 10 telephone numbers that were connected lately.
lSelect ‘Search + 1’[Latest call list appears]
Call => Originating
End => It returns to the stand-by status
Soft Key1 => It returns to Stand-by status/Previous status
View => It returns to detailed information display status
[Function of Keys of Detailed Information Display]
Call => Originating.
Num => Enter into PREPEND status [Originating only possible, storing disabled]
Soft Key2=> Same as the storing procedure of telephone number
ç=> Returns to the previous status
End => Returns to the stand-by status
2. Phone Book Search [Search + 2]
* Function to search the memorized telephone numbers using the memory address.
-You can navigate these menus by follow soft_key direction.
3. Schedule Search [Search + 3]
*Function to search user’s schedule and its details using the scheduler.
lSelect ‘Search + 3’.
- See the description of the diary function.

Terminal Development Center
14
LGIC
4. Send Own No. [Search + 4]
*Function to verify her/his phone number.
lSelect ‘Search + 4’
Other Function Keys
1. Message Key
-If you press this key in the step of telephone number edit, you can enter ‘manual stand-
by/time stand-by/hyphen’.
2. # Key
-If you press this key on hold for a specific time at any state, you can make a call with one-
touch.
3.* Key
if you press this Key on hold for a specific time at first state , you can make it lock mode
4 Center soft Key
press the bottom of center soft key(ç)for calling , Mute On/Off
