Internal Use Only

Service Manual

LG-E510

Date: September, 2011 / Issue 1.0

Only for training and service purposes

LGE Internal Use Only

Table Of Contents

1. INTRODUCTION..................................................................... 3

1.1 Purpose ........................................................................................................3

1.2 Regulatory Information.........................................................................3

1.3 Abbreviations.............................................................................................5

2. PERFORMANCE...................................................................... 7

2.1 Product Name............................................................................................7

2.2 Supporting Standard..............................................................................7

2.3 Main Parts : GSM Solution.....................................................................7

2.4 HW Features ...............................................................................................8

2.5 SW Features............................................................................................. 10

2.6 HW SPEC. ................................................................................................. 13

3. TECHNICAL BRIEF................................................................ 19

3.1 GENERAL DESCRIPTION...................................................................... 19

3.2 GSM MODE .............................................................................................. 21

3.3 UMTS MODE............................................................................................ 23

3.4 GPS RECEIVER.......................................................................................... 26

3.5 LO GENERATION and DISTRIBUTION CIRCUIT............................ 26

3.6 OFF-CHIP RF COMPONENTS............................................................. 27

3.7 Digital Baseband(DBB/MSM7227T)............................................... 31

3.8 Hardware Architecture........................................................................ 32

3.9 Subsystem (MSM7227T)..................................................................... 34

3.10 Power Block........................................................................................... 37

3.11 External memory interface............................................................. 42

3.12 H/W Sub System.................................................................................. 44

3.13 Audio and sound ................................................................................ 51

3.14 Display..................................................................................................... 57

3.15 Camera Interface (5M Auto Focus).............................................. 59

3.16 Compass Sensor.................................................................................. 60

3.17 Motion Sensor...................................................................................... 61

3.18 Proximity Sensor................................................................................. 62

3.19 Vibrators (DC Motor).......................................................................... 63

3.20 Main Features....................................................................................... 64

4. TROUBLE SHOOTING .......................................................... 68

4.1 RF Component....................................................................................... 68

4.2 SIGNAL PATH ........................................................................................... 69

4.3 Checking TCXO Block........................................................................... 72

4.4 Checking FEM Block............................................................................. 74

4.5 Checking WCDMA Block .................................................................... 76

4.6 Checking GSM Block............................................................................ 87

4.7 GPS/WIFI/BT RF Component ............................................................ 95

4.8 GPS/WIFI/BT SIGNAL PATH ................................................................ 97

4.9 GPS/WIFI/BT Trouble shooting ........................................................ 98

4.10 Power ONTrouble Shooting.........................................................103

4.11 Charging Trouble shooting...........................................................106

4.12 3M AF Camera Trouble Shooting...............................................108

4.13 Main LCD Trouble Shooting .........................................................112

4.14 Proximity Sensor on/oﬀ Trouble Shooting.............................114

4.15 Motion Sensor on/oﬀTrouble Shooting.................................116

4.16 Compass Sensor on/oﬀ Trouble Shooting .............................118

4.17 DC Motor Trouble Shooting.........................................................120

4.18 Audio Troble........................................................................................122

5. DOWNLOAD.......................................................................136

6. BLOCK DIAGRAM...............................................................155

7. CIRCUIT DIAGRAM ............................................................162

8. BGA PIN MAP ....................................................................171

9. PCB LAYOUT.......................................................................175

10. CALIBRATION...................................................................178

10.1 General Description.........................................................................178

10.2 Requirement.......................................................................................178

10.3 Setup for RF calibration..................................................................179

10.4 Tachyon Software Installation .....................................................179

10.5 Tachyon Start......................................................................................180

10.6 Overview of RF Calibration...........................................................185

11. HIDDEN MENU.................................................................189

12. EXPLODED VIEW & REPLACEMENT PART LIST .............195

12.1 EXPLODED VIEW................................................................................195

12.2 Replacement Parts...........................................................................196

12.3 Accessory.............................................................................................218

Only for training and service purposes

LGE Internal Use Only

1. INTRODUCTION

snlGpG|GvG

1. INTRODUCTION

1.1 Purpose

This manual provides the information necessary to repair, calibration, description and download the features

of this model.

1.2 Regulatory Information

A. Security

Toll fraud, the unauthorized use of telecommunications system by an unauthorized part (for example,

persons other than your company’s employees, agents, subcontractors, or person working on your

company’s behalf) can result in substantial additional charges for your telecommunications services.

System users are responsible for the security of own system. There are may be risks of toll fraud associated

with your telecommunications system. System users are responsible for programming and configuring the

equipment to prevent unauthorized use. The manufacturer does not warrant that this product is immune

from the above case but will prevent unauthorized use of common carrier telecommunication service of

facilities accessed through or connected to it. The manufacturer will not be responsible for any charges that

result from such unauthorized use.

B. Incidence of Harm

If a telephone company determines that the equipment provided to customer is faulty and possibly causing

harm or interruption in service to the telephone network, it should disconnect telephone service until repair

can be done. A telephone company may temporarily disconnect service as long as repair is not done.

C. Changes in Service

A local telephone company may make changes in its communications facilities or procedure. If these

changes could reasonably be expected to affect the use of the phones or compatibility with the net work, the

telephone company is required to give advanced written notice to the user, allowing the user to take

appropriate steps to maintain telephone service.

D. Maintenance Limitations

Maintenance limitations on the phones must be performed only by the manufacturer or its authorized agent.

The user may not make any changes and/or repairs expect as specifically noted in this manual. Therefore,

note that unauthorized alternations or repair may affect the regulatory status of the system and may void

any remaining warranty.

1. INTRODUCTION

Only for training and service purposes

LGE Internal Use Only

1. INTRODUCTION

snlGpG|GvG

E. Notice of Radiated Emissions

This model complies with rules regarding radiation and radio frequency emission as defined by local

regulatory agencies. In accordance with these agencies, you may be required to provide information such as

the following to the end user.

F. Pictures

The pictures in this manual are for illustrative purposes only; your actual hardware may look slightly different.

G. Interference and Attenuation

A phone may interfere with sensitive laboratory equipment, medical equipment, etc. Interference from

unsuppressed engines or electric motors may cause problems.

H. Electrostatic Sensitive Devices

ATTENTION

Boards, which contain Electrostatic Sensitive Device (ESD), are indicated by the sign.

Following information is ESD handling:

• Service personnel should ground themselves by using a wrist strap when exchange system boards. • When

repairs are made to a system board, they should spread the floor with anti-static mat which is also grounded.

• Use a suitable, grounded soldering iron. • Keep sensitive parts in these protective packages until these are

used.

• When returning system boards or parts like EEPROM to the factory, use the protective package as described.

Only for training and service purposes

LGE Internal Use Only

1. INTRODUCTION

ʹΠΡΪΣΚΘΙΥι ͽ͸ͶΝΖΔΥΣΠΟΚΔΤͺΟΔͲΝΝΣΚΘΙΥΣΖΤΖΣΧΖΕ

΀ΟΝΪΗΠΣΥΣΒΚΟΚΟΘΒΟΕΤΖΣΧΚΔΖΡΦΣΡΠΤΖΤ

ͽ͸ͶͺΟΥΖΣΟΒΝΆΤΖ΀ΟΝΪ 6/140

1.3 Abbreviations

For the purposes of this manual, following abbreviations apply:

Offset Phase Locked LoopOPLL

Light Emitting DiodeLED

Low Drop OutputLDO

Liquid Crystal DisplayLCD

Intermediate FrequencyIF

International Portable User IdentityIPUI

Global System for Mobile CommunicationsGSM

General Purpose Interface BusGPIB

Gaussian Minimum Shift KeyingGMSK

Flexible Printed Circuit BoardFPCB

Electrostatic DischargeESD

Electrical Erasable Programmable Read-Only MemoryEEPROM

Digital Signal ProcessingDSP

dB relative to 1 milli wattdBm

Digital Communication SystemDCS

Digital to Analog ConverterDAC

Constant Current – Constant VoltageCC-CV

Bit Error RatioBER

BasebandBB

Automatic Power ControlAPC

1. INTRODUCTION

Only for training and service purposes

LGE Internal Use Only

1. INTRODUCTION

ʹΠΡΪΣΚΘΙΥι ͽ͸ͶΝΖΔΥΣΠΟΚΔΤͺΟΔͲΝΝΣΚΘΙΥΣΖΤΖΣΧΖΕ

΀ΟΝΪΗΠΣΥΣΒΚΟΚΟΘΒΟΕΤΖΣΧΚΔΖΡΦΣΡΠΤΖΤ

ͽ͸ͶͺΟΥΖΣΟΒΝΆΤΖ΀ΟΝΪ 7/140

Wireless Application Protocol

WAP

Voltage Control Temperature Compensated Crystal OscillatorVCTCXO

Voltage Controlled OscillatorVCO

Universal Asynchronous Receiver/TransmitterUART

Time Division Multiple AccessTDMA

Time Division DuplexTDD

Travel AdapterTA

Side Tone Masking RatingSTMR

Pseudo SRAMPSRAM

Static Random Access MemorySRAM

Sending Loudness RatingSLR

Subscriber Identity ModuleSIM

Surface Acoustic WaveSAW

Real Time ClockRTC

Root Mean SquareRMS

Receiving Loudness RatingRLR

Radio FrequencyRF

Public Switched Telephone NetworkPSTN

Phase Locked LoopPLL

Programmable Gain AmplifierPGA

Printed Circuit BoardPCB

Power Amplifier ModulePAM

1. INTRODUCTION

2. PERFORMANCE

Only for training and service purposes

LGE Internal Use Only

2. PERFORMANCE

snlGpG|GvG

2.1 Product Name

E510f : WCDMA850/2100+EGSM/GSM850/DCS/PCS

(HSDPA 3.6Mbps GPRS Class 12 / EDGE Class 12)

2.2 Supporting Standard

Item Feature Comment

Supporting Standard WCDMA(FDD1,5)/EGSM/GSM850/DCS1800/PCS1900

with seamless handover

Phase 2+(include AMR)

SIM Toolkit: Class 1, 2, 3, C-E

Frequency Range WCDMA(FDD1) TX : 1920 – 1980 MHz

WCDMA(FDD1) RX : 2110 – 2170 MHz

WCDMA(FDD5) TX : 824 – 849 MHz

WCDMA(FDD5) RX : 869 – 894 MHz

EGSM TX: 880 – 915 MHz

EGSM RX: 925 – 960 MHz

GSM850 TX: 824 – 849 MHz

GSM850 RX: 869 – 894 MHz

DCS1800 TX : 1710 – 1785 MHz

DCS1800 RX: 1805 – 1880 MHz

PCS1900 TX: 1850 – 1910 MHz

PCS1900 RX: 1930 – 1990 MHz

Application Standard WAP 2.0 G

2.3 Main Parts : GSM Solution

Item Part Name Comment

Digital Baseband MSM7227T : Qualcomm G

Analog Baseband PM7540 : Qualcomm G

RF Chip RTR6285 : Qualcomm G

E510 : WCDMA900

WCDMA(FDD8) TX : 880~915 MHz

WCDMA(FDD8) RX : 925~960 MHz

2. PERFORMANCE

Only for training and service purposes

LGE Internal Use Only

snlGpG|GvG

2.4 HW Features

Item Feature Comment

Form Factor DOP type G

1) Capacity

Standard : Li-Ion , 1500mAh G

Battery

2) Packing Type : Soft Pack G

Size Standard :

113.4 x 60.8 x 11.9mm G

Weight 124g GWith Battery

Volume 76cc G

PCB L1F1 type, 8 Layers , 0.8t G

Stand by time 2G Up to 580 hrs

3G Up to 510 hrs

@ Paging Period 9 (2G)

@ DRX 8 (3G)

Charging time 3 hrs @ Power Off / 1500mAh

Talk time 2G Up to 450mins

3G Up to 420mins

@ Power Level 10 (2G)

@ Tx = 0dBm (3G)

RX sensitivity

WCDMA(FDD1) : -106.7 dBm

WCDMA(FDD5) : -104.7 dBm

EGSM : -105 dBm

GSM850 : -105 dBm

DCS 1800 : -105 dBm

PCS 1900 : -105 dBm

WCDMA/

GSM/

GPRS

WCDMA : 24dBm/3.84MHz,+1/-3dBm

EGSM : 33dBm

GSM850 : 33 dBm

DCS 1800 : 30 dBm

PCS 1900 : 30 dBm

Class3(WCDMA)

Class4 (EGSM)

Class4 (GSM850)

Class1 (PCS)

Class1 (DCS)

output

power

EDGE

GSM 900 : 27 dBm

DCS 1800 : 26 dBm

PCS 1900 : 26 dBm

E2 (GSM900)

E2 (PCS)

E2 (DCS)

GPRS compatibility GPRS Class 12 G

EDGE compatibility EDGE Class 12 G

SIM card type Plug-In SIM

3V /1.8V G

2. PERFORMANCE

Only for training and service purposes

LGE Internal Use Only

snlGpG|GvG

Display Main LCD

TFT Main LCD(3.5’, 320 x 480) G

Built-in Camera 5M AF CMOS Camera G

Status Indicator No G

Keypad

Function key : 1

Side Key : 2

Power key : 1

Function Key:

Home, Back, Menu,

Side Key :

Volume up/down

ANT Main : Internal Fixed Type G

System connector 5 Pin G

Ear Phone Jack 3.5Phi, 4 Pole, Stereo G

PC synchronization Yes G

Memory NAND Flash : 4Gbit

SDRAM : 4Gbit G

Speech coding FR, EFR, HR,AMR G

Data & Fax Built in Data & Fax support G

Vibrator Built in Vibrator G

Blue Tooth V3.0 G

MIDI(for Buzzer Function) SW Decoded 72Poly G

Music Player MP3/ WMA/AAC/HE-AAC/EAAC+ G

Video Player MPEG4, H.263, H.264 G

Camcorder MPEG4, H.263, H.264 G

Voice Recording Yes G

Speaker Phone mode

Support Yes G

Travel Adapter Yes G

CDROM No G

Stereo Headset Yes G

Data Cable Yes G

T-Flash

(External Memory) Yes G

2. PERFORMANCE

Only for training and service purposes

LGE Internal Use Only

snlGpG|GvG

2.5 SW Features

Item Feature Comment

RSSI 0 ~ 4 Levels G

Battery Charging 0 ~ 6 Levels G

Key Volume 0 ~ 7 Level G

Audio Volume 1 ~ 15 Level G

Time / Date Display Yes G

Multi-Language Yes English/French/German/Spanish/Italia

n/Danish/Dutch/Korean

Quick Access Mode Dialing/ Contact / Menu / Message /

Camera G

PC Sync No G

Speed Dial No Voice mail center -> 1 key

Profile Yes not same with feature phone setting

CLIP / CLIR Yes G

Phone Book

Name / Number / Email / Chat Id/

Website/Postal

addresses/Organizations/Groups/

BirthdayNotes / Ringtone

There is no limitation on the number

of items.

It depends on

available memory amount.

Last Dial Number Yes

Last Dial Numbers, Last Received

Numbers and Last Missed Numbers

can store up to a total of 500.

Last Received

Number Yes

Last Dial Numbers, Last Received

Numbers and Last Missed Numbers

can store up to a total of 500.

Last Missed Number Yes

Last Dial Numbers, Last Received

Numbers and Last Missed Numbers

can store up to a total of 500.

Search by Number

/ Name Name G

Group Yes

There is no limitation on the number

of items. It depends on

available memory amount.

Fixed Dial Number Yes G

2. PERFORMANCE

Only for training and service purposes

LGE Internal Use Only

snlGpG|GvG

Service Dial Number No G

Own Number Yes

Read only

(add/edit/delete are not

supported)

Voice Memo Yes G

Call Reminder No G

Network Selection Automatic G

Mute Yes G

Call Divert Yes G

Call Barring Yes G

Call Charge (AoC) Yes G

Call Duration Yes G

SMS (EMS)

There is no limitation on the

number of items. It depends on

available memory

amount.

EMS does not support.

SMS Over GPRS No G

EMS Melody / Picture No G

Send / Receive / Save No G

MMS MPEG4

Send / Receive / Save Yes G

Long Message MAX 459 characters SMS 3pages

Cell Broadcast Yes G

Download Over the Web G

Game Yes G

Calendar Yes G

Memo Yes

There is no limitation on the number

of items.

It depends on available memory

amount.

World Clock No G

Unit Convert No G

Stop Watch No G

Wall Paper Yes G

2. PERFORMANCE

Only for training and service purposes

LGE Internal Use Only

snlGpG|GvG

WAP Browser No

Support only web browser based on

webkit. WAP stack and wml are not

supported.

Download Melody /

Wallpaper Yes Over web browser

SIM Lock Yes Operator Dependent

SIM Toolkit Class 1, 2, 3, C G

MMS Yes Google MMS Client

EONS Yes G

CPHS Yes V4.2

ENS No G

Camera Yes 5M AF /

Digital Zoom : x4

JAVA Yes CLDC V1.1 / MIDP V2.1

Download Over Web

Voice Dial No G

IrDa No G

Bluetooth Yes Ver. 3.0

(HSP,HFP,A2DP,AVRCP)

FM radio Yes G

GPRS Yes Class 12

EDGE Yes Class 12

Hold / Retrieve Yes G

Conference Call Yes Max. 6

DTMF Yes G

Memo pad No G

TTY No G

AMR Yes G

SyncML Yes G

IM Yes G

Email Yes G

2. PERFORMANCE

Only for training and service purposes

LGE Internal Use Only

snlGpG|GvG

2.6 HW SPEC.

1) GSM transceiver specification

Item Specification

Phase Error Rms : 5°

Peak : 20 °

Frequency Error GSM : 0.1 ppm

DCS/PCS : 0.1 ppm

EMC(Radiated Spurious Emission

Disturbance) GSM/DCS : < -28dBm

Transmitter Output power and Burst

Timing

GSM : 5dBm – 33dBm ± 3dB

DCS/PCS : 0dBm – 30dBm ± 3dB

Burst Timing <3.69us

Spectrum due to modulation out to

less than 1800kHz offset

200kHz : -36dBm

600kHz : -51dBm/-56dBm

Spectrum due to modulation out to

larger than 1800kHz offset to the

edge of the transmit band

GSM :

1800-3000kHz :< -63dBc(-46dBm)

3000kHz-6000kHz : <-65dBc(-46dBm)

6000kHz < : < -71dBc(-46dBm)

DCS :

1800-3000kHz :< -65dBc(-51dBm)

6000kHz < : < -73dBc(-51dBm)

Spectrum due to switching transient 400kHz : -19dBm/-22dBm(5/0), -23dBm

600kHz : -21dBm/-24dBm(5/0), -26dBm

Reference Sensitivity – TCH/FS Class II(RBER) : -105dBm(2.439%)

Usable receiver input level range 0.012(-15 - -40dBm)

Intermodulation rejection – Speech

channels

± 800kHz, ± 1600kHz

: -98dBm/-96dBm (2.439%)

AM Suppression

TGSM : -31dBm

- DCS : -29dBm

-98dBm/-96dBm (2.439%)

Timing Advance ± 0.5T

2. PERFORMANCE

Only for training and service purposes

LGE Internal Use Only

snlGpG|GvG

2) WCDMA transmitter specification

Item Specification

Transmit Frequency Band1 : 1920 MHz ~ 1980 MHz

Band5 : 824MHz ~ 849MHz

Maximum Output Power +24 dBm / 3.84 MHz, +1 / -3 dB

Frequency Error within ±0.1 PPM

Open Loop Power Control Normal Conditions : within ±9 dB,

Extreme Conditions : within ±12 dB

Minimum Transmit Power < -50 dBm /3.84 MHz

Occupied Bandwidth < 5 MHz at 3.84 Mcps (99% of power)

Adjacent Channel Leakage

Power Ratio (ACLR)

> 33 dB @ ±5 MHz,

> 43 dB @ ±10 MHz

Spurious Emissions

|f-fc| > 12.5 MHz

< -36 dBm / 1 kHz RW @ 9 kHz ≤ f < 150 kHz

< -36 dBm / 10 kHz RW @ 150 KHz ≤ f < 30 MHz

< -36 dBm / 100 kHz RW @ 30 MHz ≤ f < 1 GHz

< -30 dBm / 1 MHz RW @ 1 GHz ≤ f < 12.75 GHz

< -60 dBm / 3.84 MHz RW @ 869 MHz ≤ f ≤ 894 MHz

< -60 dBm / 3.84 MHz RW @ 1930 MHz ≤ f ≤ 1900 MHz

< -60 dBm / 3.84 MHz RW @ 2110 MHz ≤ f ≤ 2155 MHz

< -67 dBm / 100 kHz RW @ 925 MHz ≤ f ≤ 935 MHz

< -79 dBm / 100 kHz RW @ 935 MHz < f ≤ 960 GHz

< -71 dBm / 100 kHz RW @ 1805 MHz ≤ f ≤ 1880 MHz

< -41 dBm / 300 kHz RW @ 1884.5 MHz < f < 1919.6 MHz

Transmit Intermodulation < -31 dBc @ 5 MHz & < -41 dBc @ 10 MHz

when Interference CW Signal Level = -40 dBc

Error Vector Magnitude < 17.5 %, when Pout ≥ -20 dBm

Peak Code Domain Error < -15 dB at Pout t-20 dBm

Band8 : 880MHz ~ 915MHz

2. PERFORMANCE

Only for training and service purposes

LGE Internal Use Only

snlGpG|GvG

3) WCDMA receiver specification

Item Specification

Receive Frequency Band1 : 2110 ~ 2170 MHz

Band5 : 869 ~ 894 MHz

Reference Sensitivity Level Band1 : BER < 0.001 when Îor = -106.7 dBm / 3.84 MHz

Band5 : BER < 0.001 when Îor = -104.7 dBm / 3.84 MHz

Maximum Input Level BER < 0.001 when Îor = -25 dBm / 3.84 MHz

Adjacent Channel Selectivity

(ACS)

ACS > 33 dB where BER < 0.001 when

Îor = -92.7 dBm / 3.84 MHz

& Ioac = –52 dBm / 3.84 MHz @ ±5 MHz

Blocking Characteristic BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz

& Iblocking = -56 dBm / 3.84 MHz @ Fuw(offset) = ±10 MHz

or Iblocking = -44 dBm / 3.84 MHz @ Fuw(offset) = ±15 MHz

Spurious Response BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz

& Iblocking = -44 dBm

Intermodulation BER < 0.001 when Îor= -103.7 dBm / 3.84 MHz

& Iouw1 = -46 dBm @ Fuw1(offset) = ±10 MHz

& Iouw2 = -46 dBm / 3.84 MHz @ Fuw2(offset) = ±20 MHz

Spurious Emissions < -57 dBm / 100 kHz BW @ 9 kHz ≤ f < 1 GHz

< -47 dBm / 1 MHz BW @ 1 GHz ≤ f ≤ 12.75 GHz

Inner Loop Power Control

In Uplink

Adjust output(TPC command)

cmd 1dB 2dB 3dB

+1 +0.5/1.5 +1/3 +1.5/4

0 -0.5/+0.5 -0.5/+0.5 -0.5/+0.5

-1 -0.5/-1.5 -1/-3 -1.5/-4

group(10equal command group)

+1 +8/+12 +16/+24

Band8 : 925~960MHz

Band8 : BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz

ACS > 33 dB where BER < 0.001 when

Îor = -92.7dBm / 3.84 MHz & Ioac = –52 dBm / 3.84 MHz @ ±5 MHz(Band1)

Îor = -89.7dBm / 3.84 MHz & Ioac = –52 dBm / 3.84 MHz @ ±5 MHz(Band8)

BER < 0.001 when Îor= -103.7 dBm / 3.84 MHz, Îor = -100.7 dBm/ 3.84 MHz(Band8)

& Iouw1 = -46 dBm @ Fuw1(oﬀset) = ±10 MHz

& Iouw2 = -46 dBm / 3.84 MHz @ Fuw2(oﬀset) = ±20 MHz

2. PERFORMANCE

Only for training and service purposes

LGE Internal Use Only

snlGpG|GvG

4) HSDPA transmitter specification

Item Specification

Transmit Frequency Band1 : 1920 MHz ~ 1980 MHz

Band5 : 824 MHz ~ 849 MHz

Maximum Output Power Sub-Test

1=1/15, 2=12/15 21~25dBm / 3.84 MHz

3=13/15 4=15/8 20~25dBm / 3.84 MHz

5=15/7 6=15/0 19~25dBm / 3.84 MHz

HS-DPCCH

Sub-test

in table

C.10.1.4

Power

step

Power step slot

boundary

Power

step size,

P [dB]

Transmitter power step

tolerance [dB]

1 Start of

Ack/Nack

6 +/- 2.3

2 Start of CQI 1 +/- 0.6

3 Middle of CQI 0 +/- 0.6

4 End of CQI 5 +/- 2.3

Spectrum Emission Mask

Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0

Frequency offset

from carrier ୞f Minimum requirement Measurement Bandwidth

2.5 ~ 3.5 MHz -35-15×(୞f-2.5)dBc 30 kHz

3.5 ~ 7.5 MHz -35-1×(୞f-3.5)dBc 1 MHz

7.5 ~ 8.5 MHz -35-10×(୞f-7.5)dBc 1 MHz

8.5 ~ 12.5 MHz -49dBc 1 MHz

Adjacent Channel Leakage

Power Ratio (ACLR)

Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0

> 33 dB @ ±5 MHz

> 43 dB @ ±10 MHz

Error Vector Magnitude < 17.5 %, when Pout ≥ -20 dBm

Band8 : 880MHz ~ 915MHz

2. PERFORMANCE

Only for training and service purposes

LGE Internal Use Only

snlGpG|GvG

5) HSDPA receiver specification

Item Specification

Receive Frequency

Band1 : 2110 MHz ~ 2170 MHz

Band5 : 869 MHz ~ 894 MHz

Maximum Input Level

(BLER or R), 16QAM Only

Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0

BLER < 10% or R >= 700kbps

6) WLAN 802.11b transceiver specification

Item Specification

Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )

Tx Power Level ≤ 20dBm under (Europe), ≤ 30dBm under (USA)

Frequency Tolerance within ±25 PPM

Chip clock Frequency

Tolerance

within ±25 PPM

Spectrum Mask ≤ -30 @ fc-22MHz< f <fc-11MHz and fc+11MHz< f <fc+22MHz

≤ -50 @ f < fc-22MHz and f > fc+22MHz

Power ramp on/off time ≤ 2us

Carrier Suppression ≤ -15dB

Modulation Accuracy

(Peak EVM)

≤ 35%

Spurious Emissions < -36 dBm @ 30MHz ~ 1GHz

< -30 dBm above @ 1GHz ~ 12.75GHz

< -47 dBm @ 1.8GHz ~ 1.9GHz

< -47 dBm @ 5.15GHz ~ 5.3GHz

Rx Min input Sensitivity ≤ -76dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%

Rx Max input Sensitivity ≥ -10dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%

Rx Adjacent Channel

Rejection

≥ 35dB @FER ≤ 8%,

interference input signal -70dBm@fc±25MHz(11Mbps)

Band8 : 925 MHz ~ 960 MHz

2. PERFORMANCE

Only for training and service purposes

LGE Internal Use Only

snlGpG|GvG

7) WLAN 802.11g transceiver specification

Item Specification

Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )

Tx Power Level ≤ 20dBm under (Europe), ≤ 30dBm under (USA)

Frequency Tolerance within ±25 PPM

Chip clock Frequency

Tolerance

within ±25 PPM

Spectrum Mask ≤ -20 @ ±11MHz offset (9Mhz ~ 11MHz)

≤ -28 @ ±20MHz offset (11MHz ~ 20Mhz)

≤ -40 @ ±30MHz offset (20MHz ~ 30Mhz)

Transmitter constellation error

(rms EVM)

≤ -5dB

Spurious Emissions < -36 dBm @ 30MHz ~ 1GHz

< -30 dBm above @ 1GHz ~ 12.75GHz

< -47 dBm @ 1.8GHz ~ 1.9GHz

< -47 dBm @ 5.15GHz ~ 5.3GHz

Rx Min input Sensitivity PER ≤ 10%

-82dBm@6Mbps, -81dBm@9Mbps, -79dBm@12Mbps

-77dBm@18Mbps, -74dBm@24Mbps, -70dBm@36Mbps

-66dBm@48Mbps, -65dBm@54Mbps

Rx Max input Sensitivity ≥ -20dBm(6,9,12,18,24,36,48,54Mbps) @ PER ≤ 10%

Rx Adjacent Channel

Rejection

PER ≤ 10%,

ACR ≥ 16dB@6Mbps, ACR ≥ 15dB@9Mbps,

ACR ≥ 13dB@12Mbps, ACR ≥ 11dB@18Mbps,

ACR ≥ 8dB@24Mbps, ACR ≥ 4dB@36Mbps

ACR ≥ 0dB@48Mbps, ACR ≥ -1dB@54Mbps

୔ACR shall be measured by setting the desired signal's strength 3 dB

above the rate-dependent

sensitivity specified in min input sensitivity

8) GPS receiver specification

Item Specification

Receive Frequency 1574.42 MHz ~ 1576.42 MHz

Minimum Sensitivity 1 satellite ≥-142dBm, 7 satellites ≥ -147dBm at coarse time aiding

3. TECHNICAL BRIEF

Only for training and service purposes

LGE Internal Use Only

3. TECHNICAL BRIEF

snlGpG|GvG

3.1 GENERAL DESCRIPTION

The E510f supports UMTS-850, UMTS-2100, GSM-850, GSM-850, GSM-900, GSM-1800, and GSM-1900 based

GSM/GPRS/EDGE/UMTS. All receivers and the UMTS transmitter use the radioOne1 Zero-IF architecture to

eliminate intermediate frequencies, directly converting signals between RF and baseband. The quad-band

GSM transmitters use a baseband-to-IF upconversion followed by an offset phase-locked loop that translates

the GMSK-modulated or 8-PSK-modulated signal to RF.

[Figure 1-1] Block diagram of RF part

}j{jv

X` Yto

{yr sv hkq

tzt^YY^{

kTm

wt^\[W

oiymv|{Z

Yto

W2100

W900

Dual

PAM

W2100

DUPLEXER

~jkthG

{Gzh~

nwpv XW\

{jv lu

{yr



hkq

{jv pu

i|mmly |ziwozzjsr

m



y{y]Y_\

wypw

wypu

{jv

siymv|{Y

{iphz

~wysiw

wy xw

ppwjoW

pptjoW

x pw joW

wkl{pu

W900

DUPLEXER

~jkthG

{Gzh~

nwpv



XW\

{jv



zzip {jv

{jvv|{

{jv



j

kypw

kypu

~wysiw

~wysiu

~wyzlY

wy



wyxu

kyxw

kyxu



joW

xptjoW

ppwjoX

pptjoX

xpwjoX

xptjoX

~wyzlYv|{

mlt

k\WX^ {xw

{xu

si ym v|{X

khj



pylm

nwzpu

{pw

{pu

khj



ylm

pv|{w

pv|{u

xv|{w

xv|{u

yGzh~ suh

nwzsuhlu

~YXWW

yG

WB_MX_INP

WB_MX_INM

nzt`WWG

njlsspuw

njlsspuu

lnztpuw

oiymv|{X



v|{X

ymvu



zik{ nwpv\`

{vu



~jkth_\WvuGGGGGGGGGGGGwhvuX

~jkth YXWW vu wh vuW

nzt_\W

kjzX_WWG

wjzX`WW

ynzt_\W

y nzt `WW

PAM

lnztpuu

kjzpuw

kjzpuu

nwjzpuw

nwjzpuu

~wyzlXpu

}kkh

nwpvXW]

nwpv\^

~jkth



YXWW



GGGGGGGGGG



vuW

nwpv^`

nwpv_W

whw~yj{s

y



nzt



`WW

ykjz

ywjz

hGzG

WSXSYSZ nwpv^Ya^\

nztwhluSGnztwhihuk

nztwhyhtw

E510

900

3. TECHNICAL BRIEF

Only for training and service purposes

LGE Internal Use Only

snlGpG|GvG

A generic, high-level functional block diagram of E510f is shown in Figure 1-1. One antenna collects base

station forward link signals and radiates handset reverse link signals. The antenna connects with receive and

transmit paths through a FSM(Front-End-Module).

The UMTS receive paths each include an LNA, an RF band-pass filter, and a downconverter that translate the

signal directly from RF-to-baseband using radioOne ZIF techniques. The RFIC’s Rx analog baseband outputs,

for the receive chains, connect to the MSM IC. The UMTS and GSM Rx baseband outputs share the same

inputs to the MSM IC.

For the transmit chains, the RTR6285 IC directly translates the Tx baseband signals (from the MSM device) to

an RF signal using an internal LO generated by integrated onchip PLL and VCO. The RTR6285 IC outputs

deliver fairly high-level RF signals that are first filtered by Tx SAWs and then amplified by their respective

UMTS PAs. In the GSM receive path, the received RF signals are applied through their band-pass filters and

down-converted directly to baseband in the RTR6285 transceiver IC. These baseband outputs are shared with

the UMTS receiver and routed to the MSM IC for further signal processing.

The GSM/EDGE transmit path employs one stage of up-conversion and, in order to improve efficiency, is

divided into phase and amplitude components to produce an open-loop Polar topology:

1. The on-chip quadrature up-converter translates the GMSK-modulated signal or 8-PSK modulated signal, to

a constant envelope phase signal at RF;

2. The amplitude-modulated (AM) component is applied to the ramping control pin of Polar power amplifier

from a DAC within the MSM. E510f power supply voltages are managed and regulated by the PM7540 Power

Management IC. This versatile device integrates all wireless handset power management, general

housekeeping, and user interface support functions into a single mixed signal IC.

It monitors and controls the external power source and coordinates battery recharging while maintaining the

handset supply voltages using low dropout, programmable regulators.

The device’s general housekeeping functions include an ADC and analog multiplexer circuit for monitoring

on-chip voltage sources, charging status, and current flow, as well as user-defined off-chip variables such as

temperature, RF output power, and battery ID.

Various oscillator, clock, and counter circuits support IC and higher-level handset functions. Key parameters

such as under-voltage lockout and crystal oscillator signal presence are monitored to protect against

detrimental conditions.

E510

Other manuals for LG-E510

Table of contents

Popular Cell Phone manuals by other brands

Swatch

Swatch Cordless II Comfort Quick reference guide

Samsung

Samsung SM-F7070 user manual

Zte

Zte BLADE A110 Upgrade guide

SoftBank

SoftBank 812SH s II Supplementary manual

HTC

HTC Sensation XE quick guide

SoftBank

SoftBank 830SH manual

Zte

Zte F866 user guide

Olympia

Olympia Vox Colour operating instructions

NEC

NEC N8605 user manual

Nokia

Nokia 7610 - Smartphone 8 MB user guide

Samsung

Samsung Galaxy S9 Enterprise Edition user manual

switel

switel S 50 D SKY operating instructions

Samsung

Samsung E630 - SGH Cell Phone owner's manual

Sanyo

Sanyo SCP-4920 user guide

ZTC

ZTC ZT688 user manual

Sony

Sony Xperia Z1 troubleshooting guide

Sanyo

Sanyo SCP-8200 operating guide

Samsung

Samsung SCH-A815 Quick reference card

LG LG-E510 User manual

Popular Cell Phone manuals by other brands
