LG 32SE3D Quick start guide

P/No: MFL70040102 (1704-REV01)
LG Digital Signage
(MONITOR SIGNAGE)
ENGLISH Easy Setup Guide
Please read this manual carefully before operating your set and retain it for future reference.
32SE3D 43SE3D 49SE3D 55SE3D 65SE3D
32SE3KD 43SE3KD 49SE3KD 55SE3KD 65SE3KD
AAA

12 0
English
Dimensions
(Width x
Height x Depth)
/ Weight
32SE3D Head 729.4 mm x 428.9 mm x 55.5 mm / 5.2 kg
(28.7 inches x 16.8 inches x 2.1 inches / 11.4 lbs)
Head + Stand 729.4 mm x 481 mm x 154.2 mm / 6 kg
(28.7 inches x 18.9 inches x 6.0 inches / 13.2 lbs)
Head + Speaker 729.4 mm x 428.9 mm x 95.7 mm / 5.7 kg
(28.7 inches x 16.8 inches x 3.7 inches / 12.5 lbs)
Head + Speaker + Stand 729.4 mm x 481 mm x 154.2 mm / 6.5 kg
(28.7 inches x 18.9 inches x 6.0 inches / 14.3 lbs)
43SE3D Head 969.6 mm x 563.9 mm x 38.6 mm / 9.6 kg
(38.1 inches x 22.2 inches x 1.5 inches / 21.1 lbs)
Head + Stand 969.6 mm x 622.2 mm x 193 mm / 12.1 kg
(38.1 inches x 24.4 inches x 7.5 inches / 26.6 lbs)
Head + Speaker 969.6 mm x 563.9 mm x 67.9 mm / 10.1 kg
(38.1 inches x 22.2 inches x 2.6 inches / 22.2 lbs)
Head + Speaker + Stand 969.6 mm x 622.2 mm x 193 mm / 12.6 kg
(38.1 inches x 24.4 inches x 7.5 inches / 27.7 lbs)
49SE3D Head 1102.2 mm x 638.5 mm x 38.6 mm / 13.9 kg
(43.3 inches x 25.1 inches x 1.5 inches / 30.6 lbs)
Head + Stand 1102.2 mm x 696.8 mm x 219.6 mm / 17.2 kg
(43.3 inches x 27.4 inches x 8.6 inches / 37.9 lbs)
Head + Speaker 1102.2 mm x 638.5 mm x 67.9 mm / 14.4 kg
(43.3 inches x 25.1 inches x 2.6 inches / 31.7 lbs)
Head + Speaker + Stand 1102.2 mm x 696.8 mm x 219.6 mm / 17.7 kg
(43.3 inches x 27.4 inches x 8.6 inches / 39.0 lbs)
55SE3D Head 1238 mm x 714.9 mm x 38.6 mm / 17.1 kg
(48.7 inches x 28.1 inches x 1.5 inches / 37.6 lbs)
Head + Stand 1238 mm x 773.4 mm x 219.6 mm / 20.4 kg
(48.7 inches x 30.4 inches x 8.6 inches / 44.9 lbs)
Head + Speaker 1238 mm x 714.9 mm x 67.9 mm / 17.6 kg
(48.7 inches x 28.1 inches x 2.6 inches / 38.8 lbs)
Head + Speaker + Stand 1238 mm x 773.4 mm x 219.6 mm / 19.9 kg
(48.7 inches x 30.4 inches x 8.6 inches / 43.8 lbs)
65SE3D Head 1456.9 mm x 838 mm x 41.1 mm / 27.7 kg
(57.3 inches x 32.9 inches x 1.6 inches / 61.0 lbs)
Head + Stand 1456.9 mm x 898.1 mm x 293.7 mm / 32.9 kg
(57.3 inches x 35.3 inches x 11.5 inches / 72.5 lbs)
Head + Speaker 1456.9 mm x 838 mm x 70.4 mm / 28.2 kg
(57.3 inches x 32.9 inches x 2.7 inches / 62.1 lbs)
Head + Speaker + Stand 1456.9 mm x 898.1 mm x 293.7 mm / 33.4 kg
(57.3 inches x 35.3 inches x 11.5 inches / 73.6 lbs)
WARNING: This product contains chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm. Wash hands after handling.

Dimensions
(Width x
Height x Depth)
/ Weight
32SE3KD Head 729.4 mm x 428.9 mm x 55.5 mm / 5.4 kg
(28.7 inches x 16.8 inches x 2.1 inches / 11.9 lbs)
Head + Stand 729.4 mm x 481 mm x 154.2 mm / 6.2 kg
(28.7 inches x 18.9 inches x 6.0 inches / 13.6 lbs)
43SE3KD Head 969.6 mm x 563.9 mm x 54 mm / 10.0 kg
(38.1 inches x 22.2 inches x 2.1 inches / 22.0 lbs)
Head + Stand 969.6 mm x 622.2 mm x 193 mm / 12.5 kg
(38.1 inches x 24.4 inches x 7.5 inches / 27.5 lbs)
49SE3KD Head 1102.2 mm x 638.5 mm x 54 mm / 14.3 kg
(43.3 inches x 25.1 inches x 2.1 inches / 31.5 lbs)
Head + Stand 1102.2 mm x 696.8 mm x 219.6 mm / 17.6 kg
(43.3 inches x 27.4 inches x 8.6 inches / 38.8 lbs)
55SE3KD Head 1238 mm x 714.9 mm x 54 mm / 17.5 kg
(48.7 inches x 28.1 inches x 2.1 inches / 38.5 lbs)
Head + Stand 1238 mm x 773.4 mm x 219.6 mm / 20.8 kg
(48.7 inches x 30.4 inches x 8.6 inches / 45.8 lbs)
65SE3KD Head 1456.9 mm x 838 mm x 56.5 mm / 27.9 kg
(57.3 inches x 32.9 inches x 2.2 inches / 61.5 lbs)
Head + Stand 1456.9 mm x 898.1 mm x 293.7 mm / 33.1 kg
(57.3 inches x 35.3 inches x 11.5 inches / 72.9 lbs)

32SE3D 43SE3D 49SE3D 55SE3D
32SE3KD 43SE3KD 49SE3KD 55SE3KD
32/43/49/55SE3D
RS-232C
IN

RS-232C
IN

65SE3D 65SE3KD
65SE3D
RS-232C
IN

RS-232C
IN

1
3
2
4
2

P/NO : MFL69040901 (1603-REV04)
(INFORMACION REGULATIVA)
REGULATORY
INFORMATION

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules.These limits are designed
to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
Caution: Any changes or modifications in construction of this device are not
expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
Information for Environmental
Preservation
ENGLISH
Information for Environmental Preservation
LGE. announced the 'LG Declaration for a Cleaner Environment' in 1994, and this
ideal has served as a guiding managerial principle ever since.The Declaration
is a foundation that has allowed us to undertake environmentally friendly
activities in careful consideration of economic, environmental, and social
aspects.
We promote activities for environmental preservation, and we specifically
develop our products to embrace the concept of environment-friendly. We
minimize the hazardous materials contained in our products. For example,
there is no cadmium to be found in our product.
Information for recycling
This product may contain parts which could be hazardous to the environment.
It is important that this product be recycled after use.
LGE. handles all waste product through an environmentally acceptable
recycling method.There are several take-back and recycling systems currently
in operation worldwide. Many parts will be reused and recycled, while harmful
substances and heavy metals are treated by an environmentally friendly
method.
If you want to find out more information about our recycling program, please
contact your local LG vendor or a corporate representative of LG.
We set our vision and policies on a cleaner world by selecting the issue of
the global environment as a task for corporate improvement. Please visit our
website for more information about our‘green’policies.
Removal of waste batteries and accumulators
(Product with embedded battery ONLY)
In case this product contains a battery incorporated within the product which
cannot be readily removed by end-users, LG recommends that only qualified
professionals remove the battery, either for replacement or for recycling at the
end of this product’s working life.To prevent damage to the product, and for
their own safety, users should not attempt to remove the battery and shold
contact LG Service Helpline, or other independent service providers for advice.
Removal of the battery will involve dismantling of the product case,
disconnection of the electrical cables/contacts, and careful extraction of the
battery cell using specialized tools.
WEEE
Disposal of your old appliance
1 This crossed-out wheeled bin symbol indicates that waste
electrical and electronic products (WEEE) should be disposed of
separately from the municipal waste stream.
2 Old electrical products can contain hazardous substances so correct
disposal of your old appliance will help prevent potential negative
consequences for the environment and human health.Your old
appliance may contain reusable parts that could be used to repair
other products, and other valuable materials that can be recycled
to conserve limited resources.
3 You can take your appliance either to the shop where you
purchased the product, or contact your local government waste
office for details of your nearest authorisedWEEE collection point.
BATTERY
Pb
Disposal of waste batteries/accumulators
This symbol may be combined with chemical symbols for
mercury(Hg), cadmium(Cd) or lead(Pb) if the battery Contains more
that 0.0005% of mercury, 0.002% of cadmium or 0.004% of lead. All
batteries/accumulators should be disposed separately from the
municipal waste stream via designated collection facilities appointed
by the government or the local authorities.
The correct disposal ofYour old batteries/accumulators will help to
prevent potential negative consequences for the environment, animal
and human health.
For more detailed information about disposal ofYour old batteries/
accumulators, please contactYour city office, waste disposal service or
the shop whereYou purchased the product.
