LG L6104-DP User manual

L6104-DN / L6104-DP

2
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead symbol
within an equilateral triangle is intended to alert
the user to the presence of uninsulated danger-
ous voltage within the product’s enclosure that
may be of sucient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the pres-
ence of important operating and maintenance
(servicing) instructions in the literature accom-
panying the product.
FCC WARNING: This equipment may generate or use radio
frequency energy. Changes or modications to this equip-
ment may cause harmful interference unless the modica-
tions are expressly approved in the instruction manual. The
user could lose the authority to operate this equipment if an
unauthorized change or modication is made.
Regulatory Notices For U.S.A
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own
expense.
• A suitable conduit entries, knock-outs or glands shall be
provided in the cable entries of this product in the end
user.

3
• Caution: Danger of explosion if battery is incorrectly re
placed. Replaced only with the same or equivalent type
recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions.
• Holes in metal, through which insulated wires pass,
shall have smooth well rounded surfaces or shall be
provided with brushings.
Warning: Do not install this equipment in a conned space
such as a bookcase or similar unit.
Warning: Wiring methods shall be in accordance with the
National Electric Code, ANSI/NFPA 70.
Warning: This is a class A product. In a domestic
environment this product may cause radio interference in
which case the user may be required to take adequate meas-
ures.
Warning: To reduce a risk of re or electric shock, do not
expose this product to rain or moisture.
Caution: This installation should be made by a qualied
service person and should conform to all local codes.
Caution: To avoid electrical shock, do not open the cabinet.
Refer servicing to qualied personnel only.
Caution: The apparatus should not be exposed to water
(dripping or splashing) and no objects lled with liquids, such
as vases, should be placed on the apparatus.

4
Disposal of your old appliance
1. When this crossed-out wheeled bin
symbol is attached to a product it means the
product is covered by the European Directive
2002/96/EC.
2. All electrical and electronic products
should be disposed of separately from the
municipal waste stream via designated
collection facilities appointed by the govern-
ment or the local authorities.
3. The correct disposal of your old appli-
ance will help prevent potential negative
consequences for the environment and
human health.
4. For more detailed information about
disposal of your old appliance, please con-
tact your city oce, waste disposal service or
the shop where you purchased the product.
LG Electronics hereby declares that this/
these product(s) is/are in compliance with
the essential
requirements and other relevant provisions
of Directive 2004/108/EC, 2006/95/EC, and
2009/125/EC.
European representative :
LG Electronics Service Europe B.V.
Veluwezoom 15, 1327 AE Almere,
The Netherlands (Tel : [phone])

5
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accord
ance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not t into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specied by the manufacturer, or sold with the ap-
paratus. When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury from
tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been dam-
aged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally,
or has been dropped.

6
Cautions for Safe Operation
Power Supply
This camera must always be operated at DC 12V
Certified/Listed, class 2 power supply only.
Handling of the unit
Be careful not to spill water or other liquids on the unit. Be
cautions not to get combustible or metallic material inside
the body. If used with foreign matter inside, the camera is
liable to fail or to get cause of fire or electric shock.
• Remove dust or dirt on the surface of the lens with a
blower.
• Use a dry soft cloth to clean the body. If it is very dirty,
use a cloth dampened with a small quantity of neutral
detergent then wipe dry.
• Avoid the use of volatile solvents such as thinners,
alcohol, benzene and insecticides. They may damage the
surface nish and/or impair the oper ation of the camera.
Operating and storage location
Avoid viewing a very bright object (such as light ttings) dur -
ing an extended period. Avoid operating or storing the unit in
the following locations.
• Extremely hot or cold places (operating temperature
-10 °C to 50 °C, however, we recommend that the unit be
used within a temperature range of 0 °C to 45 °C)
• Damp or dust place
• Places exposed to rain
• Places subject to strong vibration
• Close to generators of powerful electromagnetic radia
tion such as radio or TV transmitters.

7
Contents
Features .......................................................................................... 8
Part Names and Functions ................................................ 9
Connections ................................................................................ 10
Installation ................................................................................... 11
Installing the camera on a ceiling or wall ......................... 11
Adjustment .................................................................................... 13
Lens Focus Adjustment .......................................................... 14
Menu Operation ......................................................................... 15
OSD Menu Overview .............................................................. 16
General Operation .................................................................. 18
............................................................. 19
Exposure Settings
BRIGHTNESS setting
...................................................... 20
AGC (Automatic Gain Control) setting ...................... 21
SHUTTER (Shutter Speed) setting ............................... 21
White Balance settings ......................................................... 22
.................................................................. 19
Day/Night Setting ............................................................... 24
Privacy Setting ....................................................................... 25
Special Menu Settings ...................................................... 26
............................................. 26
................................................. 26
.......................................... 26
................................................. 26
Setting the SHARPNESS 
....................................................................... 31
............................................................................... 32
BLC/LSC setting
Setting the MONITOR
Setting the GAMMA effect
Setting MIRROR effect
Setting USER TITLE
DPC Setting
LANGUAGE Setting
Reset Setting
........................................................ 27
.................................................................. 28
...................................................... 28

8
This Color Video Camera is designed for installation in an
indoor video surveillance system.
This manual contains instructions on how to install and man-
age the Color Video Camera in your video surveillance system.
Should you require any technical assistance, please contact
authorized service center.
•
•
•
•
•
•
•
•
•
•
•
Accessories
DOME CAMERA
SCREW
& "L" Wrench
TEMPLATE
INSTALLATION
MANUAL
Features
OPTION:
WIRED REMOTE
CONTROLLER

9
Part Names and Functions

10
OPTIONAL
WIRED REMOTE
CONTROLLER
FOR OSD
OSD Adjustment
OSD controller is optional item.
Please use OSD wired remote controller if you need camera configuration.
Connections

11
Tapping Type(Supplied)
3.0x25mmx3ea
Installation
Installing the camera on a ceiling
①. Affix the mounting template(supplied) to the mounting surface and .
Along to the inside circle line please drill a hole
②. Secure the camera mounting bracket to the position where the camera should be mounted with the supplied screws.
The bottom case is in the ceiling.
(Please leave a good position of cable not to interrupt the surveillance area with it when installing.)

1
22
③.
AAdjust the camerdjust the camera lens ta lens to faco face the are the area tea to be monito be monitorored and fix theed and fix the
main body and the dome cmain body and the dome coovverer
* (LG logo) at upper body case: It's subject to change depending on the direction of
your installation.
Installation
by rotating to clockwise.

13
TILT +/-60˚
PAN 360˚ R OTATE 360˚
Rotate angle : 360˚
Panning angle : 360˚
Tilting angle : +/-60˚
(Viewable operation tilt angle +/- 60˚ at the middle)
(Viewable operation
tilt angle +/- 60˚ at the middle)
Installation
You can adjust the angle of ball mount to put it down a little.

14
Lens Focus Adjustment
The lens is focused far from 1M when ex-factory.
Therefore please keep the lens focus as is.
Installation

:SET
15
Menu Operation
This camera utilizes an on-screen user MENU.
To set items on the menu, use the following switch. UP
Used to move upper direction on the menu screen. Use
this button to select an item or adjust the parameters.
DOWN
Used to move lower direction on the menu screen. Use this
button to select an item or adjust the parameters.
RIGHT
Moves the cursor to the right. Used to increment the value
selected in the menu. The parameter changes each time
this button is pressed.
LEFT
Moves the cursor to the left. Used to decrement the value
selected in the menu. The parameter changes each time
this button is pressed.
SET
Executes selections and displays a submenu for an item
with the .mark.

16
OSD M enu O verview
The following table shows the list of menu items and options.
You can adapt the camera to your requirements by setting up the
respective items in these menus.
Main M enu Sub M enu Contents
EXPOSURE ELC
ELC
ATW
AWB
MANUAL
PUSH
AUTO
SHUTTER
R-Y GAIN
B-Y GAIN
MANUAL R
MANUAL B
BURST
DAY > NIGHT
NIGHT > DAY
DELAYTIME
BLC / LSC
HSBLC
LSC
BLC
WIDE BLC
BRIGHTNESS
AGC
SHUTTER
0~99
OFF
LOW
MIDDLE
HIGH
AUTO
1/120FLK
1/250
1/500
1/1000
1/2000
1/4000
1/10000
1/100000
0~255
0~255
0~255
0~255
ON/OFF
0~255
0~255
3~12
Main M enu Sub M enu Contents
EXPOSURE
WHITE BAL
DAY&NIGHT
Menu Operation

17
Main M enu Sub M enu Contents Main M enu Sub M enu Contents
DAY&NIGHT COLOR
B&W
OFF
SET WINDOW
ALL SET
ALL CLEAR
SENSITIVITY 0~200
OFF
ICON
TRACE
HOLD TIME 1~15
OFF
MASK NUMBER 1~4
DISPLAY ON/OFF
GRAY
BLACK
WHITE
HEIGHT 1~99
WIDTH 1~99
MOVE Y 1~99
MOVE X 1~99
MOTION DET ON
ALARM
TRACE
PRIVACY ON
COLOR
OFF
SHARPNESS 1~49
CRT
LCD
USER
0.45
0.6
1
ON
OFF
ON
OFF
WHITE THR
LUMA LIMIT
ENG
한국어
RESET FACTORY
DPC SET
LANGUAGE
SPECIAL ON
MONITOR
GAMMA
MIRROR
USER TITLE
Menu Operation
ON/OFF

18
OSD MENU OSD(SCREEN CONTROL)-SETTING
1.Press OSD key down at wired remote controller
The setup menu screen appears on the monitor.
2.Press OSD key to upside or downside to select an option then
Press OSD key down. Submenu appears on the monitor.
3.Press OSD key to upside or downside to select a Submenu option.
4.Use OSD key to left or right to select a value.
5.Select [EXIT] and click the OSD key. Then OSD is setup.
RET: Return to the previous menu .
TOP: Return to the CAMERA SETTING menu screen.
END: Exit the setup menu.
CAMERA SETTING
EXPOSURE
WHITE BAL
DAY & NIGHT
MOTION DET
PRIVACY
SPECIAL
RESET
EXIT
ELC
ATW
AUTO
OFF
OFF
Menu Operation

19
OSD MENU-Exposure Settings
You can set the exposure options using the EXPOSURE menu. Use WIDE BLC option to view the object clearly in strong
backlight conditions.
1.Select [WIDE BLC]] option.
2.Use OSD key to left or right to select a mode then press[SET].
Select[EXPOSURE]option on the[CAMERA SETTING]menu.
Press OSD key down and the EXPOSURE menu appears.
To see [ELC]] and press down to click it.
this function is for clear image even if backlight condition.
Select [BLC], [WIDE BLC], [LSC]or[ HSBLC]
OSD MENU-Exposure Settings(BLC / LSC)
CAMERA SETTING
EXPOSURE
WHITE BAL
DAY & NIGHT
MOTION DET
PRIVACY
SPECIAL
RESET
EXIT
ELC
ATW
AUTO
OFF
OFF
EXPOSURE-ELC
BLC/LSC
BRIGHTNESS
AGC
SHUTTER
EXIT
BLC
40
MIDDLE
AUTO
RET
[BLC]-After click [BLC], you can move OSD key left/right
[BLC]-[ON]or[OFF], its level.
Then press down [RET] for BLC setting.
-WIDE BLC : Use for adjusting brightness of the subject and
background image to view the both of object clearly at the
same time in backlight condition.
-INDOOR: WIDE BLC ON
-OFF
Menu Operation

20
BLC : Use for adjusting brightness of the subject to view the
object clearly in backlight condition. Set to select [on] or [off]
HSBLC : Use for masking brightness of the specific area to
view the subject more clearly.
The HSBLC mode is automatically activated only in low
illumination scene.
Push OSD key to left or right to select a ON or OFF.
Press[SET] to exit the Area setting menu.
-ON: It has powerful back light compensation performance.
The function suppress highlight then it will make the objects
very clean and obvious.
-OFF: Not used.
LSC: It can compensate the shading correction curve on
each corners of the views.
CAMERA SETTING
EXPOSURE
WHITE BAL
DAY & NIGHT
MOTION DET
PRIVACY
SPECIAL
RESET
EXIT
ELC
ATW
AUTO
OFF
OFF
EXPOSURE-ELC
BLC/LSC
BRIGHTNESS
AGC
SHUTTER
EXIT
BLC
40
MIDDLE
AUTO
RET
1.Select [BRIGHTNESS]
/ [AGC] / [SHUTTER]
option.
2.Use OSD key to left
or right to select a mode
then press[SET].
OSD MENU-Exposure Settings
BRIGHTNESS : You can set the brightness level. (0-100)
AGC : If the images are too dark, change the maximum [AGC]
value to make the images lighter.
SHUTTER : (AUTO→1/120FLK→1/250 󰾝 1/100000)
Menu Operation
