Life Gear 97320 User manual

PACE MAKER PRO
OWNER’S MANUAL
MODEL#97320
The specifications of this product may vary from this photo,
subject to change without notice.

PAGE OF
CONTENTS
ONE YEAR
LIMITED
WARRANTY
Warranty 1
Important Safety
Instructions 2
Overview Drawing 4
Parts List 5
Hardware Packing List 7
Assembly Instructions 8
Operation 11
Folding Up and Setting
Down the Treadmill 12
Manual lncline
Adjustment 13
Console Operation 14
Using Your Treadmill 17
Lubrication and Running
Belt Adjustment 19
Fitness Tip 20
LifeGear Inc. warrants to the
original purchaser that this
product is free from defects in
material and workmanship when
used for the purpose intended,
under the conditions that it has
been installed and operated in
accordance with LifeGear's
Owner's Manual. LifeGear's
obligation under this warranty is
limited to replacing or repairing,
free of charge, any parts which
may prove to be defective under
normal home use. This warranty
does not include any damage
caused by improper operation,
misuse or commercial
application.
From the date of purchase, the
frame is warranted to be free
from defects for 1 (one) year.
This warranty is extended only
to the original owner and is not
transferable. When ordering
replacement parts please have
the following information ready:
1. Owner's Manual
2. Model Number
3. Description of Parts
4. Part Number
5. Date of Purchase
1

IMPORTANT SAFETY INSTRUCTIONS
2
Observe the following prior to use of the treadmill:
DANGER: To reduce the risk of electric shock, please observe the following:
zAlways unplug the treadmill from the electrical outlet immediately after using and before cleaning,
assembling, or servicing.
NOTE: Failure to follow these instructions may lead to personal injury and cause damage to the
treadmill.
WARNING: To reduce the risk of burns, fire, electric shock please observe the following:
zNever leaves the treadmill unattended when plugged in. Disconnect by turning off the master power
switch, and unplugging from outlet.
zNever operate this treadmill if it has a damaged cord or plug is not working properly, if it has been
dropped or damaged, or if it has been exposed to water.
zIf the supply cord is damaged, it must be replaced by the manufacture, its service Agent or similarly
qualified person in order to avoid a hazard.
zDo not attempt any maintenance or adjustments other than those described in this manual. Should
any problems arise, discontinue use and consult an Authorized Service Representative.
zDo not use outdoors.
zDo not operate where aerosol (spray can) products are being used or where oxygen is being
administered.
zDo not pull the treadmill by its power cord or use the cord as a
handle.
zNever operate the treadmill with the air openings blocked. Keep air
openings free of lint, hair, and the like.
zClose supervision is necessary if this treadmill is used by, or near
children, people with disabilities, or pets.
zKeep Dry-do not operates in a wet or moist condition. Save these
instructions.
zDo not operate under a blanket. Excessive heating can occur and
cause fire, electrical shock, or injury to people.
zKeep electrical cord away from heated surfaces.
zNever insert any object into any opening.
zKeep the treadmill on a solid, level surface with sides at least two feet
from any wall. Be sure the area around the treadmill remains clear
during use and has adequate clearance, see illustration below.
WARNING: Connect the treadmill to a properly grounded outlet only.
FRONT
REAR
TOP
VIEW
2 FEET MIN. 2 FEET MIN.
4 FEET MINIMUM
LEFT
SIDE RIGHT SIDE

zThis product must be grounded. If it should malfunction or break down, grounding provides a path
of least resistance for electric current - reducing the risk of electric shock. This treadmill is
equipped with a cord having an equipment grounding connector and a grounding plug. The plug
must be plugged into an appropriate outlet that is properly installed and grounded in accordance
with all local codes and ordinances.
DANGER: Improper connection of the treadmill grounding connector can result in the risk of
electric shock. Check with a qualified electrician, if you are in doubt as to whether the
product is properly grounded. Do not modify the plug provided with the treadmill. If it
will not fit your outlet, have a properly grounded outlet installed by a qualified
electrician.
zThis unit must be plugged into a nominal 230 volt 50/60 hz, which has a grounding.
zKeep hands clear of all moving parts. Never place hands, feet under the treadmill.
zDo not use the treadmill on a carpet that is greater than 1/2 inch in height.
zBefore each use, check that the running belt is aligned and centered on the treadmill bed and all
visible fasteners on the treadmill are sufficiently tightened and secure.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM CONSULT YOUR PHYSICIAN. THIS IS
ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PEOPLE WITH PRE-EXISTING
HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. WE
ASSUME NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR
THROUGH THE USE OF THIS PRODUCT.
DO NOT OPERATE THIS EXERCISE EQUIPMENT WITHOUT PROPERLY FITTED GUARDS, AS THE
MOVING PARTS CAN PRESENT A RISK OF SERIOUS INJURY TO YOUNG CHILDREN.
CAUTION: Read all instructions carefully before operating this product. Retain this Owner's Manual
for future reference.
3

OVERVIEW DRAWING
4
23
4
5
6
7
8
8
1
9
10
11
12
13
15
14
14
16
17
18
19
21
20
22
23
24
25
27
28
26
29
30
31
32
34
35
36
37
38
39
40
41
43
42
88
44
45
47
47
46
48
48
49
49
50
55
50
52
53
54
55
56
29
69
55
51
56
58
59
60
61
63
64
65
49
62
62
49
64
66
67
68
70
55
55
71
72
75
75
74
74
73
73
66
33
76
77
78
79
80
26
26
21
26
24
26
82
83
84
85
86
87
81
81
81
81
76
88
57

PARTS LIST
5
Part # Description Quantity Part # Description Quantity
1 Main Frame 1
2 Base Frame 1
3 Adjustable Pad 2
4 End Cap for #2 2
5 Move Wheel 2
6 Wheel 2
7 Rod for Move Wheel 2
8 Screw (M4*10) 4
9 Running Deck 1
10 Front Roller, Drive 1
11 Rear Roller, Tension 1
12 Running Belt 1
13 Motor Base 1
14 Bushing 2
15 Axis 1
16 Drive Motor 1
17 Bracket for Drive Motor 1
18 PCB Motor Controller 1
19 Drive Belt 1
20 Sensor 1
21 Bracket for Sensor 2
22 Switch, AC Power 1
23 Rubber Bumper 8
24 Side Rail 2
25 Bolt (M8*60) 2
26 Screw (M4*16) 13
27 Screw (M6*35) 8
28 Nut (M6) 8
29 Nut (M8) 2
30 End Cap (25*50) 2
31 Dust Cover, Up 1
32 Dust Cover, Lower 1
33 Screw (M4*60) 4
34 L-Handrail 1
35 R-Handrail 1
36 Handlebar 1
37 End Cap for Handlebar 2
38 Computer 1
39 Computer Bracket Cover 1
40 Bolt (M5*10) 4
41 Safety Magnet 1
42 Handlebar Adorner 2
43 Bolt (M8*50) 4
44 End Cap (30*60) 2
45 Foam Grip 2
46 Spacer 2
47 Cap Nut 2
48 Bolt (M10*60) 2
49 Nut (M10) 4
50 Bolt (M8*16) 6
51 Nut 1
52 Safety Tube A 1
53 Safety Tube B 1
54 Bolt (M8*40) 1
55 Spring Washer (M8) 11
56 Nylon Washer 2
57 Spring Knob 1
58 Foot Pad 2
59 L-Rear Cap 1
60 R-Rear Cap 1
61 Incline Beam 1
62 Cover for Incline Beam 2
63 Bolt (M10*40) 2
64 Bushing 2

6
Part # Description Quantity
65 Tapping Screw (ST4*10) 4
66 Handpulse Cover-Upper
W/Wire 2
67 Handpulse Cover-Lower 2
68 Screw (M3*20) 4
69 Bolt (M8*35) 1
70 Screw (M8*12) 2
71 Bolt (M8*45) 2
72 Screw (M4*12) 7
73 Sensor Cable I (850 mm.) 1
74 Sensor Cable II (1100 mm.) 1
75 Sensor Cable III (600 mm.) 1
76 Speed Button W/Wire 1
77 End Cap ( 25) 1
78 End Cap ( 20) 1
79 Fuse Box 1
80 Cable, Power Plug 1
81 Nylon Nut (M4) 7
82 Earth Lead 1
83 Cable Switch/PCB 1
84 Wire for Fuse Box 1
85 Inductance (34MH-40MH) 1
86 Wave Filter (06SS4-2DC1) 1
87 Ring for Cable Power 1
88 Mode Button w/Wire 1

HARDWARE
PACKING LIST
7
Part # Description Quantity
43 Bolt (M8*50) ------------------------------------------------------------------------------------------------4
50 Bolt (M8*16) --------------------------------------------------------------------------------------6
55 Spring Washer (M8)----------------------------------------------------------------------------6
NOTE: 1. Above described parts are all the parts you need to assemble this machine. Before
you start to assemble, please check the hardware packing to make sure they are
included.
2. Please find tools in the hardware pack to help you assemble this machine easier.
PLACE WASHER, BOLT S END OR
SCREW ON CIRCLE TO CHECK FOR
CORRECT SIZE.
INCHES
MILLIMETERS
,

THANK YOU ASSEMBLY
INSTRUCTIONS
Thank you for purchasing your
new exercise product. This
exercise machine will help you
enjoy a lifetime of beneficial
exercise providing a
cardiovas-cular and muscle
toning workout in the
convenience of your own home.
This manual is designed to help
you easily assemble, adjust, and
use this machine. Please read
this manual carefully. For the
sake of familiarizing yourself
with the parts identified in the
instructions, please first study
the overview drawing.
Set all parts in a clear area on
the floor and remove the
packing materials. Refer to the
parts list for help to identify the
parts. To assemble the machine,
see the following pages.
8

STEP 1&2
9
Install Handrails
1. Connect the Sensor Cable I (#73) and Sensor Cable II (#74).
2. Fasten the R-Handrail (#35) to the Base Frame (#2)
with three M8*16 Bolts (#50) and M8 Spring Washers (#55).
Repeat this step to assemble L-Handrail (#34). Careful not
to crimp,pinch or otherwise damage the
cable and cable connections.
Install Handlebar
3. Attach the Handlebar (#36) to the top of the Handrails
(#34 & #35) with two Handlebar Adorners
(#42) and four M8*50 Bolts (#43).
4. Connect the Sensor Cable II (#74) and Sensor Cable III (#75).
Place the connection inside of R-Handrail (#35). Careful
not to crimp, pinch or otherwise damage the cable and cable
connections.
1
4
2
2-1
3-1
4-1
3
73
74
35
2
34
36
43
35
75
74
35
42
55 & 50

STEP 3&4
10
5. Insert the End Caps (#44) into the Handrails (#34 & #35).
Install Computer
6. Remove the Computer Bracket Cover (#39).
7. Connect the Handpulse Wires (#66), Speed Button Wire (#76),
Mode Button Wire (88), and Sensor Cable III (#75) to the
Computer (#38).
8. Assemble the Computer (#38) onto the bracket of the
Handlebar (#36) with four M5*10 Bolts (#40). Place the wire
connections inside the room of the
Handlebar (#36) bracket and cover up the
Computer Bracket Cover (#39).
5
8
6
5-1
7-1
8-1
7
34 44
35
39
36
38
38
75
66
40
36
39

OPERATION
CAUTION:
Before beginning a workout session ensure Safety Tether Key is properly placed onto the
Computer Console and the Safety Clip is securely attached to an article of your clothing.
Always begin the treadmill standing on the side rails-not on the running belt. Allow the
treadmill to reach a speed of at least 0.8 km/h before walking on the running belt.
I: Operation in Quick Start Mode
Ensure this treadmill is plugged into a nominal 230 volt 50/60hz, which has a grounding plug.
Step 1: Power Up
zPress the Master Power Switch located at the front of the treadmill to ON position. The LCD
console will immediately run a self diagnostic display. After that it will display current system
status.
Step 2: Begin Workout
zPress the ON button then press UP button to increase running speed.
zAs the running speed reaches 0.8 km/h you can start walking on the treadmill. To adjust the
desired speed by pressing the UP or DOWN button to increase or decrease running speed.
zDuring exercise press OFF button to stop operation.
11

FOLDING UP AND SETTING DOWN THE TREADMILL
12
Folding Up the Treadmill
Place one hand on the rear end of deck and the other hand to pull the Spring Knob, then lift the
deck up from the rear of treadmill until the Spring Knob "pops" down into the locked position.
(See diagrams A and B.) Check the Spring Knob is "pop" down into the locked position before
moving the treadmill.
Setting Down the Treadmill
Place one hand on the rear end of deck and the other hand to pull the Spring Knob, then lower the
deck down from the rear of treadmill until the Spring Knob "pops" down into the locked position.
(See diagram C.)
TO PREVENT INJURY PLEASE MAKE SURE YOU HAVE A FIRM HOLD WHEN LIFTING UP OR
SETTING DOWN THE DECK.
B
A
C

MANUAL INCLINE ADJUSTMENT
13
Incline adjustment
Place one hand on the rear end of deck. Lift up the rear end of deck and then pull the Incline
Beam to a higher or lower position. Please refer to the diagrams A, B and C.
BC
A

CONSOLE OPERATION
BUTTON FUNCTIONS
ON PRESS ON BUTTON AND THEN PRESS UP BUTTON TO HAVE THE TREADMILL
RUNNING.
OFF TO OFF THE TREADMILL RUNNING.
MODE TO SELECT EACH FUNCTION (TIME, DISTANCE, or CALORIE) FOR TARGET
PRESETTING.
SET TO SET EACH FUNCTION (TIME, DISTANCE, or CALORIE) FOR TARGET PRESETTING.
UP SPEED UP ADJUSTMENT DURING EXERCISE.
DOWN SPEED DOWN ADJUSTMENT DURING EXERCISE.
COMPUTER FUNCTIONS
TIME ACCUMULATES TOTAL RUNNING TIME UP TO 99:59.
SPEED DISPLAYS CURRENT RUNNING SPEED FROM THE MINIMUM 0.8KPH TO THE
MAX.12 KPH.
DISTANCE ACCUMULATES TOTAL RUNNING DISTANCE UP TO 99.99KM.
CALORIE ACCUMULATES CALORIES CONSUPMTION DURING EXERCISE. (THIS DATA IS A ROUGH
GUIDE FOR COMPARISON OF DIFFERENT EXERCISE SESSIONS WHICH CAN NOT BE
USED IN MEDICAL TREATMENT).
PULSE THE MONITOR WILL DISPLAY YOUR CURRENT HEART RATE IN 5 SECONDS AFTER
HOLD ON GRIPS WITH BOTH HANDS DURING EXERCISE. TO HAVE THE HEART RATE
FIGURES MORE ACCURATE AND STEADY, WE WOULD SUGGEST YOU TO HOLD BOTH
HANDS ON GRIPS TO INSTEAD OF ONE HAND ONLY.
14

NOTE
THE MONITOR WILL STAND-BY FOR 4 MINUTES IF YOU STOP RUNNING OR PRESSING ANY
BUTTON. AFTER 4 MINUTES, ALL DISPLAYS WILL SHUT OFF AUTOMATICALLY.
COMPUTER OPERATION
1. AFTER AC POWER ON, THE TREADMILL IS STOPPED. PLEASE MAKE SURE THE SAFE-KEY IS
INSTALL ONTO THE CONSOLE BEFORE THE TREADMILL RUNNING. IT IS FOR SAFE REASON
CONSIDERATION.
2. PRESS THE BUTTON "ON", THEN PRESS "UP" TO HAVE THE TREADMILL RUNNING.
3. YOU MAY ADJUST RUNNING SPEED BY PRESSING THE BUTTONS: UP or DOWN. UPFORWARD
ADJUSTING - EACH SHORT PRESSING TO HAVE SPEED UP WITH PRESET MINIMUM
INCREMENT SLOWLY, OR HOLD ON PRESSING TO ACCELERATE ADJUSTMENT. BACKWARD
ADJUSTING - EACH SHORT PRESSING TO HAVE SPEED DOWN WITH PRESET MINIMUM
DECREMENT SLOWLY, OR HOLD ON PRESSING TO ACCELERATE ADJUSTMENT DOWN TO
MINIMUM SPEED.
4. WHEN YOU WOULD LIKE TO STOP THE TREADMILL RUNNING, YOU MAY PRESS "OFF" BUTTON
OR YOU MAY ALSO PULL UP THE SAFE-KEY TO STOP.
15

Error codes description
The error codes "E1" or "E2" display on the electronic console which indicate the malfunction of
the motor controller during workout session and will have a series of continuous audible "beeps"
from the electronic console.
ERROR CODE DESCRIPTION
E1 Speed error (The treadmill running speed is 3.2 kph faster than the displayed
speed). The treadmill will stop immediately when the console detects this error.
E2 Speed error (The treadmill running speed is 3.2 kph slower than the displayed
speed). The treadmill will stop 16 seconds later after the console detects this
error.
Troubleshooting / Resetting error codes
In the rare event of the treadmill displaying an error code ("E" followed by a number), simply reset
the computer by:
1. Step off the treadmill. Ensure that you are clear of the running belt.
2. Turn the treadmill off at the master power switch located near the motor housing.
WARNING: Ensure nothing is positioned near or under running belt which may possibly block
it's normal operation.
3. Turn the treadmill on at the master power switch.
4. Ensure that the Safety Tether Key is securely and properly installed onto the console or just
reinstalling the Safety Tether Key can also reset the display.
If the above does not clear the error code, please contact the nearest Dealer/Service Center.
16

USING YOUR TREADMILL
Observe the following to get the most from using and interacting with your treadmill:
zAlways stretch your muscles prior to and following any exercise program. Warm up slowly by
walking at a slow speed. Increase workout intensity gradually until you reach your desired
workout pace. Before completing an exercise session, slow your pace gradually to an easy walk,
allowing your heart rate to decrease to normal.
zWhen starting the treadmill, always stand with both feet on the side landing areas. When
finished allow the running belt to slow and come to a complete stop before stepping off.
zAlways use the handrail when stepping on or off the treadmill and when changing incline or
speed.
zWear comfortable, nonrestrictive clothing when using the treadmill. Never wear anything loose,
such as baggy sweat pants, neckties, loose socks; or jewelry. Never drape towels on or around
the treadmill during use.
zThis treadmill is equipped with a safety tether key. Always clip the cord attached to the safety
tether key to a part of your clothing so the key will properly detach from the computer console,
therefore stopping the treadmill, as necessary.
zWear running or walking shoes with high-traction soles. To avoid injury and unnecessary wear
on your treadmill, be sure your shoes are free of any debris such as gravel and small rocks.
CAUTION: If you experience dizziness, nausea, chest pain, or other abnormal symptoms, stop
immediately. Consult a physician before continuing.
Before completing an exercise session always:
zAllow time to slow your pace, cool down, reducing your heart rate to a normal level before
completing your workout.
zGrasp the handlebars and press the DOWN button; Slow your pace to an easy walk.
zEnsure the running belt has come to a complete stop before exiting the treadmill.
17

At the end of every exercise session always:
zRemove the Safety Tether Key from the Computer Console.
zUse the main power switch to turn the treadmill off. The main power switch is located at the
front of the treadmill next to the electrical cord.
zAlways position and store the electrical cord where it is clear from all pathways.
zUnplug the electrical cord from the electrical outlet. This is especially important if you are not
going to use your treadmill for extended periods.
zWipe all treadmill surfaces with a dry cloth or towel-especially perspiration on the handlebars,
control panel, running belt or other treadmill components.
CAUTION: Turn off and unplug the treadmill before proceeding with any maintenance or
visual inspections. Failure to do so may result in serious injury.
Note: Failure to perform the required periodic and preventative maintenance can void your
warranty.
18

LUBRICATION AND RUNNING BELT ADJUSTMENT
19
Lubrication
The treadmills have already been spread with "Silicone Oil" in advance
before leaving the manufacturing plant. Silicone oil is without volatility
and has gradually permeated through the running belt. There will be no
need to re-spread the oil in normal circumstances.
To maintain the running belt, we have included a small bottle of
"Silicone Oil". "Silicone Oil" may be re-spread once the resistance has
been increased and the running belt starts rubbing against the running
deck. To hold open the running belt from two sides, apply the silicone oil with an even motion on
the center of the running deck. Allow the silicone oil to 'set' for one minute before using the
treadmill.
Attention: Only use "Silicone Oil" lubricants for this equipment. In addition, do not add any other
oil ingredient; otherwise the treadmill will bedamaged. Do not over-lubricate the walking
board. Excess lubricant should be wiped off with a clean towel.
Running Belt Adjustment:
The running belt is adjusted at the factory; it may come loose during
transportation and from use. After prolong use of running, the belt will
stretch out. If the running belt is shifting to the left, turn on the main
power switch of treadmill and let the running belt run at the speed of
2~3 km/h. Using the hex key provided, turn the left rear roller
adjustment bolt 1/4 turn in the clockwise direction. You should see the
belt start to correct itself by moving back toward the center. Repeat the
above procedure until the running belt is centered. If the running belt is shifting to the right, turn
on the main power switch of treadmill and let the running belt run at the speed of 2~3 km/h.
Using the hex key provided, turn the right rear roller adjustment bolt 1/4 turn in the clockwise
direction. You should see the belt start to correct itself by moving back toward the center. Repeat
the above procedure until the running belt is centered. If the running belt is slipping during use,
turn off and unplugged the treadmill. Using the hex key provided, turn both left and right rear
roller adjustment bolts 1/4 turn in the clockwise direction for the same distance, turn on the main
power switch of treadmill and let the running belt run at the speed of 2~3 km/h. You should now
walk on to the running belt to determine if the running belt is still slipping. Repeat the above
procedure until the running belt is not slipping.
