Life Gear 97930 User manual

MOTION CAPTURE PRO
MOTORIZED TREADMILL
OWNER'S MANUAL
MODEL# 97930
Get active for life
2006, Feb.

1
PAGE OF CONTENTS
ONE YEAR LIMTED WARRANTY
LifeGear Inc. warrants to the original purchaser that this product is free from defects in material and workmanship when used for the purpose
intended, under the conditions that it has been installed and operated in accordance with LifeGear's Owner's Manual. LifeGear's
obligation under this warranty is limited to replacing or repairing, free of charge, any parts which may prove to be defective under normal home
use. This warranty does not include any damage caused by improper operation, misuse or commercial application.
From the date of purchase, the frame is warranted to be free from defects for 1 (one) year. This warranty is extended only to the original owner
and is not transferable. When ordering replacement parts please have the following information ready:
1. Owner's Manual
2. Model Number
3. Description of Parts
4. Part Number
5. Date of Purchase
WARRANTY 1
SAFETY INSTRUCTIONS 2
OVERVIEWDRAWING 4
PARTS LIST 5
HARDWARE PACKING LIST 7
ASSEMBLY INSTRUCTIONS 8
CAUTION 9
FOLDUP&INCLINEADJUSTMENT 10
COMPUTER OPERATION 11
LUBRICATION & RUNNINGBELTADJUSTMENT 14

2
Observe the following prior to use of the treadmill:
DANGER: To reduce the risk of electric shock, please observe the following:
zAlways unplug the treadmill from the electrical outlet immediately after using and before cleaning, assembling, or servicing.
NOTE: Failure to follow these instructions may lead to personal injury and cause damage to the treadmill.
WARNING: To reduce the risk of burns, fire, electric shock please observe the following:
zNever leave the treadmill unattended when plugged in. Disconnect by turning off the master power switch, and unplugging from outlet.
zNever operate this treadmill if it has a damaged cord or plug, is not working properly, if it has been dropped or damaged, or if it has been
exposed to water.
zDo not attempt any maintenance or adjustments other than those described in this manual. Should any problems arise, discontinue use and
consult theAuthorized Service Representative.
zDo not use outdoors.
zDo not operate where aerosol (spray can) products are being used or where oxygen is being administered.
zDo not pull the treadmill by its power cord or use the cord as a handle.
zClose supervision is necessary if this treadmill is used by, or near children, persons with disabilities, or pets.
zKeep Dry-do not operates in a wet or moist condition. Save these instructions.
zDo not operate under a blanket. Excessive heating can occur and cause fire, electrical shock, or injury to
persons.
zKeep electrical cord away from heated surfaces.
zNever insert any object into any opening.
zKeep the treadmill on a solid, level surface with sides at least two feet from any wall. Be sure the area around
the treadmill remains clear during use and has adequate clearance, see illustration below.
WARNING: Connect the treadmill to a properly grounded outlet only.
FRONT
REAR
TOP
VIEW
2 FEET MIN. 2 FEET MIN.
4 FEET MINIMUM
LEFT
SIDE
RIGHT
SIDE
SAFETY INSTRUCTIONS

3
zThis product must be grounded. If it should malfunction or break down, grounding provides a path of least resistance for electric current reducing
the risk of electric shock. * This treadmill is equipped with a cord having equipment grounding connector and a grounding plug. The plug must
be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
DANGER: Improper connection of the treadmill grounding connector can result in the risk of electric shock. Check with a qualified
electrician, if you are in doubt as to whether the product is properly grounded. Do not modify the plug provided with the
treadmill. If it will not fit your outlet, have a properly grounded outlet installed by a qualified electrician.
zThis unit must be plugged into a normal 220 volt 50/60 hz, which has a grounding.
zKeep hands clear of all moving parts. Never place hands, feet under the treadmill.
zDo not use the treadmill on a carpet that is greater than 1/2 inch in height.
zBefore each use, check that the running belt is aligned and centered on the treadmill bed and all visible fasteners on the treadmill are
sufficiently tightened and secure.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM CONSULT YOUR PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR
INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE
USING ANY FITNESS EQUIPMENT. WE ASSUME NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE
SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. DO NOT OPERATE THIS EXERCISE EQUIPMENT WITHOUT
PROPERLY FITTED GUARDS, AS THE MOVING PARTS CAN PRESENT A RISK OF SERIOUS INJURY TO YOUNG CHILDREN.
CAUTION: Read all instructions carefully before operating this product. Retain this Owner’s Manual for future reference.

4
OVERVIEW DRAWING

5
Part # Description Quantity Part # Description Quantity
1 Main Frame 1
2 Stabilizer 1
3 End Cap for Stabilizer 2
4 Adjustable Pad (M8) 2
5 Moving Wheel 2
6 Running Belt 1
7 Running Deck 1
8 Front Roller 1
9 Rear Roller 1
10 Motor 1
11 Motor Bracket 1
12 Bushing (Ø25.4*Ø10*20) 2
13 Axis (Ø10*539) 1
14 Cap Nut (Ø 12.7) 2
15 Belt 5PJ190 1
16 Bracket forDrive Motor 1
17 Power Control Board 1
18 Switch, AC Power (KB97) 1
19 Power Cord (1900mm) 1
20 Fuse Box (10A) 1
21 Wire Cap 1
22 Sensor Cable I (850 mm.) 1
23 Sensor Cable II (1100 mm.) 1
24 Sensor Cable III (600 mm.) 1
25 Foot Pad 2
26 Sensor (7R26-17F) 1
27 Bracket for Sensor 1
28 Incline Beam 1
29 Cover for Incline Beam 2
30 Spacer (Ø18*Ø10.5*15.5mm) 2
31 Deck Bumper 10
32 End Cap ( 25*50) 2
33 Side Rail (1083mm) 2
34R Rear Cap (Right) 1
34L Rear Cap (Left) 1
35 Dust Cover, Upper 1
36 Dust Cover, Lower 1
37R Handlebar Support (Right) 1
37L Handlebar Support (Left) 1
38 Handlebar 1
39 Foam Grip (Ø30*Ø37*410) 2
40 Speed Button W/Wire (Handpulse) 1150mm 2
41 Tapping Screw (ST3*20mm) 4
42 End Cap for Handlebar 2
43 Computer (SD6520-7) 1
44 Safety Tether Key 1
45 Safety Tube A 1
46 Bushing 1
47 Spring Knob 1
48 Safety Tube B 1
49 Square End Cap ( 25.4) 1
50 Square End Cap ( 20) 1
51 Spacer (Ø13.5*Ø8.5*14mm) 2
52 Spring Washer (M8) 16
53 Hex Socket Head Cap Bolt (M8x40mm) 2
54 Nylon Nut (M6) 10
55 Tapping Screw (M4*16mm) 16
56 Bolt (M6*33mm) 10
PARTS LIST

6
57 Bolt (M8*60mm) 2
58 Screw (M3x10mm) 2
59 Hex Socket Button Head
Cap Bolt (M8*40mm) 1
60 Nylon Washer (M8) 2
61 Nylon Nut (M8) 4
62 Bolt (M8*35mm) 1
63 Bolt (M10*40mm) 2
64 Nylon Nut (M10) 4
65 Screw (M4*60mm) 4
66 Bolt (M8*12) 2
67 Bolt (M10*100mm) 2
68 Screw (M4*12) 11
69 Nylon Nut (M4) 7
70 Bolt (M8*16mm) 12
71 Washer (Ø11*Ø21*1.8) 2
72 Washer (Ø8.5*Ø18*1.5) 6
73 Washer (Ø4.2*Ø12*0.8) 4
74 Computer Knob (M5) 4
75 Choke (34MH-40MH) 1
76 Wave Filter (06SS4-2DC1) 1
77 Wire for Fuse Box (CM-125) 2
78 Cable Switch/PCB (CM-90) 2
79 Wire Cap (10A) 1
80 Earth Lead (CM-115) 1
81 Ring for Cable Power (Ø26*13) 1
82 Connecting Wire of Ring
for Cable Power 750mm 2
83 Cylinder 1
Part # Description Quantity Part # Description Quantity
PARTS LIST

7
52 Spring Washer (M8)----------------------------------------------------------------------------------------12
70 Bolt (M8*16mm) ------------------------------------------------------------------------------------12
72 Washer (Ø8.5*Ø18*1.5)-----------------------------------------------------------------------------6
74 Computer Knob (M5)--------------------------------------------------------------------------------4
PLACE WASHER, BOLT’S END, OR
SCREW ON CIRCLE TO CHECK FOR
CORRECT SIZE.
INCHES
MILLIMETERS
Part # Description Quantity
HARDWARE PACKING LIST

8
Step 1
Connect the Sensor Cable II (23) from the Right Handlebar Support (37R) to the Sensor Cable
III (24) from the Stabilizer (2).Attach the Right and Left Handlebar Supports (37R,37L) to the
Stabilizer (2) with six Spring Washers (52) and Bolts (70).
Step 2
Connect the Sensor Cable I (22) from the Handlebar (38) to the Sensor Cable II (23) from the
Right Handlebar Support (37R). Attach the Handlebar (38) to the Right and Left Handlebar
Supports (37R,37L) with six Washers (72), Spring Washers (52), and Bolts (70).
Step 3
Connect the Sensor Cable I (22) and Speed Wires (40) to the wires that come from the
Computer (43). Then attach the Computer (43) onto the Handlebar (38) with four Computer
Knobs (74). Finally, install the Safety Tether Key (44) onto the Computer (43).
ASSEMBLY INSTRUCTIONS
1
2
3

Before beginning a workout session ensure Safety Tether Key is properly installed onto the Computer Console and the
Safety Clip is securely attached to an article of your clothing.
Always begin the treadmill standing on the side rails-not on the running belt. Allow the treadmill to reach a speed of at
least 0.8km before walking on the running belt.
Operating in Quick Start Mode
Ensure this treadmill is plugged into a nominal 220 volt 50/60hz, which has a grounding plug.
Step 1: Power Up
zPress the Master Power Switch that is located at the front of the treadmill to ON position. The LCD console will immediately run a
self diagnostic display. After that it will display current system status.
Step 2: Begin Workout
zPress the START button to begin operation.
zAs the running belt speed reaches 0.8km, you can start walking on the treadmill. Adjust to desired speed using the FAST button.
Press the SLOW button to decrease speed. The LCD console will immediately display when you adjust the speed.
9
CAUTION
