Mocka Kirra User manual

Kirra Desk
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
Hardware Supplied
dowel
x13
bolt
x25
screw
x12
locking nut
x25
small screw
x30
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
A B CD E
NM
LK
J
IHG
F
wedge
x4
scerw
x4
long scerw
x6
nut
x2
bolt
x2
bolt
x3
allen key
x1
Wall Strap
x2
washer
Z
Y
wall
anchor
x1
X
safety
strap x1
WV
screw
x1
wall
screw
x1
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
Phillips & Flathead screwdrivers required.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
screw
x16
O P Q
slide rail
x3
slide rail
x3
slide rail
x3
slide rail
x3

Kirra Desk
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
12
Insert 7x bolts (C) into panel [1]. Tighten with a screwdriver.
1
3
3
Attach 3x slide rails (F) to panel [3] as shown and secure with 9x
screws (E). Flip the panel [3], attach 2x bolts (C) to panel [3] as
shown.
E
F
CL
C
C
C
C
C
C
C
EC
C
C
C
E
E
E
E
E
F
F
F
E
E
E
FLIP

Kirra Desk
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
3 4
Attach panels [3] and [4] to panels [5] with 4x dowels (A) and secure
with 4x locking nuts (D). Tighten with a screwdriver.
4
4
5
5
3
Attach 3x slide rails (G) to panel [4] and secure with 9x small screws (E).
Tighten with a screwdriver.
E
G
CR
C
G
G
G
C
E
E
EE
E
EE
E
E
A
D
D
D
D
A
A
A
D

Kirra Desk
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
6
4
2
3
5
Attach panel [2] to the rest of the unit using 4x dowels (A).
Secure with 6x long screws (M) and tighten with a screwdriver.
Attach the legs [7] to panel [2] as shown using 16x screw (J) .Tighten
with a screwdriver.
A
A
A
M
M
M
M
M
M
J
JJ
J
JJJ
J
J
JJ
J
J
JJ
J
2
7
7
7
7
7
J

Kirra Desk
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
7 8
3
6
6
8
Attach panel [6] to panel [3] with 1x dowel (A) and secure with 2x
locking nuts (D). Tighten with a screwdriver.
Attach panel [8] to panel [6] with 2x bolts (O) and secure with 2x nuts (N).
Tighten with a screwdriver.
N
N
O
O
D
×
3
A

Kirra Desk
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
6
910
1
4
4
3
3
6
8
Slide panel [9] down along the grooves between panels [3] and [4].
Attach 4x dowels (A) to panels [3] and [4] as shown.
Ensure laminated
side of panel is facing
inwards.
Attach panel [1] to panels [3], [4] and [6], secure with 7x locking nuts (D).
Tighten with a screwdriver. Attach panel [1] to panel [8], secure with
3x bolts (P). Tighten with an allen key (Q).
A
A
D
P
P
Q
Q
P
D
D
D
D
A
A
D
D
P
9

Kirra Desk
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
x2
x2
7
12Drawers x311 Drawers x3
15
10
11
12
Insert 4x bolts (C) into panel [10]. Tighten with a screwdriver.
Insert 8x bolts (C) into panels [15]. Tighten with a screwdriver.
Attach panels [11] and [12] to panel [10] and secure with 4x locking
nuts (D). Tighten with a screwdriver. Attach panels [16] and [17] to
panels [15] and secure with 8x locking nuts (D). Tighten with a
screwdriver.
C
C
C
C
10
C
C
C
C
D
DD
D
15
16
17
D
D
D
D

10
10
11
12
11
14
12
13
13
Slide panel [13] down along the grooves between panels [11]
and [12]. Slide panels [13] down along the grooves between
panels [16] and [17].
Kirra Desk
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
8
13 Drawers x3 14 Drawers x3
Attach panels [11], [12] and [14] as shown using 4x screws (B). Tighten with
a screwdriver. Attach panels [16], [17] and [18] as shown using 8x screws (B).
Tighten with a screwdriver.
x2
15 x2
15
16
16
18
17
17
B
B
B
B
B
B
B
B
Ensure laminated
side of panel is facing
inwards.
Ensure laminated
side of panel is facing
inwards.

10
10
11
12
Kirra Desk
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
9
15 Drawers x3 16 Drawers x3
Attach slide rails (I) and slide rails (H) to the underside of the side panels
as shown. Secure with 12x screws (E) and tighten with a screwdriver.
Insert the assembled drawers into the corresponding compartments
as shown. Ensure the drawers slide easily along the rails.
x2
15
15
15
16
17
H
I
H
E
E
E
E
E
E
E
E

Once assembled lift furniture into place, do not drag. Use a drill to create
a small hole lining up with the top of the safety strap (V). Fasten to wall
using 1x washer (Z), 1x wall plug (X) and 1x screw (Y). Ensure unit is
balanced and steady before use. You’re done, enjoy!
K
K
L
L
9
XZ
V
wall
plug
screw
strap
washer
Kirra Desk
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
10
17 18
Attach 4x wedges (K) into the corners of the back of the unit and secure
with 4x screws (L). Tighten with a screwdriver.Attach 1x safety strap (V)
to the top of the back side of the unit as shown using 1x washer (Z) and
1x screw (W). Tighten with a screwdriver.
V
Z
W
V
Z
W
