Light Emotion DERBY3 Operator's manual

www.lightemotion.com.au
DERBY3
3-in-1 Entertainment Lighting Effect.
User’s instruction manual
This manual contains important information about the safe installation and use of this product
Please read this instruction manual carefully before installing or operating
Please keep these instructions in a safe place for future reference
V1.01

1
Contents
1. Safety Instructions 2
2. Installation 3
3. Features 3
4. Menu Operation 4
5. IR Remote Control 6
6. DMX Control 7
7. DMX Connections 9
8. DMX Address Setting 9
9. DMX Terminator 10
10. Cleaning and Maintenance 10
11. Technical Data 10
12. Warranty 11

2
Introduction
Thank you for the purchase of your DERBY3 3-in-1 Lighting Effect by Light Emotion. We are confident you will
be satisfied with your purchase and enjoy many years of use from this Professional Light Emotion product. Please
read these instructions carefully to ensure the product is well look after and used correctly to avoid any potential
problems.
Please note that as part of our ongoing commitment to continuous improvement and product development, the
specifications in this manual are subject to change without notice. Whilst every care has been taken in the
preparation of this manual we reserve the right to change specifications in the course of product improvement.
What is in the box:
- 1 x DERBY3 fixture
- Power cable
- Laser safety switch key
- IR remote control
- This user manual
1. Safety Instructions:
Please read these instructions carefully. It includes important information about the installation usage and
maintenance of this product.
- Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also
receive this instruction booklet.
- Always make sure that you are connecting to the proper voltage and that the line voltage you are connecting to is
not higher than that stated on the sticker of the fixture.
- This product is intended for indoor use only. To prevent risk of fire or shock, do not expose fixture to rain or
moisture.
- Make sure there are no flammable materials close to the unit while operating.
- The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surface. Be sure that
no ventilation slots are blocked.
- Always disconnect from power source before servicing.
- Secure fixture to stands, trussing and the like using a safety chain.
- Maximum ambient temperature is 40˚C. Do not operate fixture at temperatures higher than this.
- In the event of serious operating problem, stop using the unit immediately. Never try to repair the unit by yourself.
Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest authorized
technical assistance centre.
- Make sure power cord is never crimped or damaged.
- Never disconnect power cord by pulling or tugging on the cord.
- Never carry the fixture directly from the cord. Carry by holding the unit directly or via the hanging bracket.

3
- Avoid direct eye exposure to the light source while it is on.
2. Installation:
Caution: For safe mounting of this product, please read the following carefully.
- Use a suitable clamp to attach to lighting stand, trussing or bar, together with safety chain.
- When mounting the product, do not stand directly underneath the product
- Always use a safety chain when mounting the product on stands, trussing or bars. Make sure the breaking strain
rating of the chain is at least 10 times the weight of the product.
- Make sure there is adequate ventilation around the product.
- Never look directly into the LED light or laser sources of the product.
- For indoor use only – do not use outdoors.
- To avoid electrical shock, keep away from rain and moisture.
3. Features
This product is designed as entertainment effect lighting fixture and is only intended to be used as an effect for
entertainment and production applications. Due to our ongoing commitment to constantly reviewing and improving
products, features and specifications are subject to change without prior notice.
It features a Derby effect, RGB mini laser which produces patterns and a unique 105 SMD LED panel round flood
area that can be used for patterns, strobing and flood light applications. All three built-in effects can be controlled
independently or used together to create interesting lighting effect shows. Like most lighting effects, the beams of
the Derby in particular are enhanced in an environment where a smoke / fog or haze machine is used, but the use of
an effects machine is not necessary for this light to provide a great and effective light show.
- Derby LED: 2 x 10w RGBW 4-in-1 10W LED
- SMD LED Panel: 105 x 0.2W RGB 30-in-1 SMD LED
- Laser: Red 100mW/650nm + Green 30mW/532nm + Blue 80mW 450nm
- Control: Sound activated, auto, DMX, master/slave, IR remote control
- DMX channels: 2 / 14 ch selectable profile
- Power input: 100-240VAC, 50/60Hz.
- Power consumption: 50W
- DMX connections: 3 pin male and female XLR
- Dimensions: 510 x 290 x 295mm
- Weight: 6.5kg

4
4. Operation
Because this light features a laser, there is the mandatory key operated laser safety switch on the rear of the unit.
This is independent of the power on/off switch. The laser will not operate until the safety switch is placed into the
on position using the included key. All other functions of the product will work regardless, when the power switch
is on.
The four button LED menu control on the rear of the product allows you to access all features of the product
including how it is to be controlled.
LED Four Digit Display:
Menu Up Down Enter
Using the four button LED menu control, press the menu button repeatedly until you reach your desired mode. You
can also scroll though the modes using the up and down buttons. Press enter to access being able to vary the settings
for that mode or feature. Using the up and down buttons, adjust to the desired setting, then press enter again to save
your setting.
The following table shows each of the modes and the settings able to be varied in each mode:

5
Explanation of Menu items.
Addr – DMX address
ChMd – DMX profile 2 or 14 channel mode
ShNd – Built in show selection
SPEE – Speed setting for shows 1-7 if not sound activated
SLMD – Chose between master or slave mode
SoUn – Sound activation on or off
SoSe – Sets sound sensitivity
NodM – Sets what the light does if there is loss of DMX signal
LED – LED display on or off – When you chose off, the LED display will turn itself off after 10
seconds of not being used. Pressing mode turns on the LED display.
Ver – shows the software version of the light
TEST – Test mode.
Notes:
- DMX takes priority over all other mode settings. If there is a DMX lead connected and a DMX
signal received, the light will immediately be controlled by DMX.
- After using the LED menu, hold down the menu button for 2 seconds for the light to resume
normal operation. Otherwise normal operation will resume after 10 seconds (as in light effects
output).
MENU UP/DOWN Default
Value
Function
1 Addr 1-512 1
DMX Address setting
2 ChMd 14Ch 14Ch
14 channel setting
2Ch
2 channel setting
3 ShNd
Sh 1 Sh 7
Show
1 Derby Only
Sh 2
Show
2 SMD LED Panel Only
Sh 3
Show
3 Laser Only
Sh 4
Show
4 Derby and Laser
Sh 5
Show
5 Derby and SMD LED Panel
Sh 6
Show
6 Laser and SMD LED Panel
Sh 7
Show
7 Combined 3 effects
4 SPEE 0-100 90 Sh 1-Sh 7
speed setting
5 SLMD MASt MASt
Master mode
SLAV Slave mode
6 SoUn ON/OFF ON
Sound activation on or off
7 SoSE 0-100 90
Sound sensitivity setting
8 NodM
Prom Prom
If no DMX, use master mode
BLAC
If no DMX, enter standby mode
HoLd
If no DMX, use last show
9 LED ON/OFF ON
LED Display on/off
10 Ver
V10
Version
11 Test
Test mode

6
6
7
11
10
18
19
14
17
16
15
5. Infra Red remote control.
Number
Button Function
1 Stand By Stand by
2 DMX Hold on
3-10 Show 1-Show 8 Show1-Show7 (Show 8 hold on)
11 LED Colour LED colour select
12 LED Random LED colour randomly
13 Sound ON Sound on
14 Laser Colour Laser colour select
15 Laser Random Laser colour randomly
16 Sound OFF Sound off
17 Speed - Show 1 - Show 7 speed down
18 Speed Show 1 - Show 7 speed default
19 Speed+ Show 1 - Show 7 speed up
1
2
5
8
3
4
9
12
13

7
6. DMX Control
Using DMX you can control each of the three effects built into this light individually. You can also
use DMX to call upon built in programs and shows. This fixture has 2 DMX profiles – 2 and 14
channels modes. The 14 channel mode allows individual control of all the effects while the 2
channel mode is a simpler way to control the light by DMX simply calling upon built in programs
and features.
14 Channel DMX chart:
DMX Value Range
Function
CH1
Access to b
uilt-in
shows via DMX
0-9 No function
10-44 Show 1 Derby only
45-79 Show 2 SMD LED panel only
80-114 Show 3 Laser only
115-149 Show 4 Derby and Laser only
150-184 Show 5 SMD LED panel and Derby only
185-219 Show 6 Laser and SMD LED panel only
220-255 Show 7 All three effects together
CH2
RGBW Derby
colour select
(CH1 set 0-9)
0-9 black-out
10-198 Choose colours(15 groups),
13 DMX values for
each colour.
199-225 Colour chase1 (single colour) from slow to fast
226-255 Colour chase2 (multiple colour) from slow to fast
Sound active
on/off(CH1 set
0-9)
0-247 Sound control off for Show 1 -
Show 7 from slow
to fast
248-255 Sound control on for Show 1 - Show 7
CH3 Derby LED
Strobing
0-9 No strobing
10-244 Derby LED strobe speed from slow to fast
245-255 Derby LED strobe by sound
CH4
LED Motor setting
0-127 Derby LED motor position select
128-255 Derby LED motor scan speed from slow to fast
CH5 SMD LED Setting
0-9 SMD LED off
10-255 Strobe, LED chase effect select
CH6 Strobe chase
speed
0-127 No strobe, LED chase speed from slow to fast
127-255 With strobe, LED chase speed from slow to fast
CH7 Laser colour
select
0-9 Laser off
10-127 Laser colour fixed
128-255 Colour chase speed from slow to fast
CH8 Laser pattern
select 0-255 Laser pattern select
CH9 Laser pattern size
0-63 Choose patterns size
64-127 From small to large, speed up rate
128-191 From large to small, speed up rate

8
192-255 Large – small – large, speed up rate
CH10
Laser pattern
rotation
0-127 Rotation angle select
128-191 positive rotation speed
192-255 Inverted rotation speed
CH11
Laser pattern pan
position
0-127 Horizontal position
128-255 Horizontal move, speed up rate
CH12
Laser pattern tilt
position
0-127 Choose vertical position
128-255
Vert
ical move, speed up rate
CH13
Laser scan track
choose 0-255 Track choose
CH14
Laser track scan
speed choose 0-255 Laser track scan speed from slow to fast
Note: In 14 channel mode, channel 1 needs to be set between 0 and 9 to be able to control the
feature of the light individually. When channel 1 is set between 10 and 255, the light will perform
one of the 7 inbuilt shows in accordance to what the DMX setting is on channel 1. Also note that
channel 2, when channel 1 is set between 10 and 255 playing shows, controls sound activation and
the speed of the shows
2 channel DMX Chart:
DMX Value Range Function
CH1 Show mode
0-9 No function
10-44 Show 1 Derby LED only
45-79 Show 2 SMD LED Panel only
80-114 Show 3 Laser only
115-149 Show 4 Derby and Laser only
150-184 Show 5
Derby and SMD LED panel
185-219 Show 6 Laser and SMD LED panel
220-255 Show 7 Three effect combined
CH2
Show
speed/Sound
active
0-247 Show 1-Show 7 speed from slow to
fast
248-255 Show 1-Show 7 Sound active

9
7. DMX-512 Control Connection
Using a 3 pin XLR cable, you can connect the product to a DMX controller and then to other fixtures
with 3 pin XLR inputs and outputs. When not using DMX, multiple fixtures can be connected together
and operate under master/slave control. The signal cable should have two core with shielded cable, the
signal connectors are XLR input and output connectors. Please refer to the below diagram:
8. DMX Address Setting
When being used in conjunction with a DMX controller, each fixture must be set a specific starting
address. When receiving signal, fixture will receive channel control signals of this address from the
DMX controller.
For simplicity, the user can use the same address for multiple fixtures but this will result in each fixture
providing exactly the same output and fixtures with the same DMX address cannot be individually
controlled.
To control each fixture individually via DMX, each fixture must have its own unique DMX address. If
this fixture is in 14 channel DMX mode then each address must be 14 channels apart. For example, if
the first unit is on DMX channel 1, the 2
nd
must be on DMX channel 15, the 3
rd
on channel 29 and so on.
Similarly, for 2 channel DMX mode, the DMX channels would be 1,3,5,7 and so on.
Some DMX controllers may group fixtures in lots of 16 channels – so in that case, fixture 1 on channel 1,
fixture 2 on channel 17, 3 on 33, and so on. Refer to your DMX controllers’ instruction manual on how
best to manage your DMX channel allocation.
DMX Out
1
st
addr 001
2
nd
addr 015 3
rd
addr 029

10
9. DMX-512 connection with DMX terminator
A DMX terminator helps to reduce ‘noise’ on the DMX chain, and makes the light respond to control
more accurately. It should be plugged in to the last fixture in any chain. For Terminator connections
please see below:
10. Cleaning and Maintenance
From time to time it is recommended the product is cleaned to ensure maximum light output and
performance. Use a wet cloth to clean the housing as well as the lenses. Please note that alcohol based
cleaners and solvents cannot be used as they will cause damage to the product.
When used in a fixed long term installation such as a venue or club, the unit should be periodically taken
down from the installation and professionally cleaned. Dust build-up within the unit can cause damage
and ultimately failure of components.
11. Technical Data
- Derby LED: 2 x 10w RGBW 4-in-1 10W LED
- SMD LED Panel: 105 x 0.2W RGB 30-in-1 SMD LED
- Laser: Red 100mW/650nm + Green 30mW/532nm + Blue 80mW 450nm
- Control: Sound activated, auto, DMX, master/slave, IR remote control
- DMX channels: 2 / 14 ch selectable profile
- Power input: 100-240VAC, 50/60Hz.
- Power consumption: 50W
- DMX connections: 3 pin male and female XLR
- Working temperature 10-40 degrees C
- Fuse 5x20mm 250VAC T2A
- Dimensions: 510 x 290 x 295mm
- Weight: 6.5kg

11
12. Warranty
This product is warranted for 2 years from your purchase date. We are confident that this product will
give many years of trouble-free operation but should an unlikely problem arise, warranty claims must be
via the original place of purchase, together with the original purchase receipt. Please keep both your
original purchase receipt and this instruction manual together and in a safe place for future reference.
Should the product be sold within the warranty period, be sure to pass on both to the new purchaser so
they are able to claim warranty should they need to. We recommend you register your warranty online at
www.industrygear.com.au.
Purchased from:_________________________________________
Contact Details:_________________________________________
Date Purchased:_________________________________________
Invoice/Receipt Number:__________________________________
Copyright Light Emotion 2017. E&OE
Exclusively imported by LSW Imports and Distribution
PO Box 887, Kingsgrove, NSW, 2208
www.lightemotion.com.au
1800 643 111 (within Australia)
+612 9718 4900 (outside of Australia)
Table of contents
Other Light Emotion Lighting Equipment manuals

Light Emotion
Light Emotion Phantomrgb1700 User manual

Light Emotion
Light Emotion thunderboltg2 Operator's manual

Light Emotion
Light Emotion VIVID0312 Operator's manual

Light Emotion
Light Emotion FLAT1012 Operator's manual

Light Emotion
Light Emotion DERBY2 Guide

Light Emotion
Light Emotion LX90SPOT User manual

Light Emotion
Light Emotion QUARK2GBC User manual

Light Emotion
Light Emotion QUARK2RBP User manual

Light Emotion
Light Emotion STROBA Operator's manual

Light Emotion
Light Emotion UVLED User manual
