Light Emotion LEDBAR1803 Operator's manual

www.lightemotion.com.au
LEDBAR1803
Outdoor 1m LED Bar 18 x 3W 3-in-1 RGB LEDs
User’s instruction manual
This manual contains important information about the safe installation and use of this product
Please read this instruction manual carefully before installing or operating
Please keep these instructions in a safe place for future reference
V1.00

1
Contents
1. Safety Instructions 2
2. Installation 3
3. Features 3
4. Menu Operation 4
5. DMX Tables 5
5a. 2 Channel Mode 5
5b. 3 Channel Mode 5
5c. 4 Channel Mode 6
5d. 6 Channel Mode 6
5e. 7 Channel Mode 6
5f. 9 Channel Mode 7
5g. 18 Channel Mode 7
5h. 54 Channel Mode 8
5i. 56 Channel Mode 10
6. DMX Connection 12
7. DMX Address Setting 12
8. DMX Terminator 13
9. Cleaning and Maintenance 13
10. Technical Data 13
11. Warranty 14

2
Introduction
Thank you for the purchase of your LEDBAR1803 Outdoor 1m LED bar with 18 x 3w 3-in-1
LEDs by Light Emotion. We are confident you will be satisfied with your purchase and enjoy
many years of use from this Professional Light Emotion product. Please read these instructions
carefully to ensure the product is well look after and used correctly to avoid any potential
problems.
Please note that as part of our ongoing commitment to continuous improvement and product
development, the specifications in this manual are subject to change without notice. Whilst
every care has been taken in the preparation of this manual we reserve the right to change
specifications in the course of product improvement.
What is in the box:
- 1 x LEDBAR1803 Lighting Effect
- 1 x Power Cable
- This user manual and warranty card
1. Safety Instructions:
Please read these instructions carefully. It includes important information about the installation
usage and maintenance of this product.
- Please keep this User Manual for future consultation. If you sell the unit to another user, be
sure that they also receive this instruction booklet.
- Always make sure that you are connecting to the proper voltage and that the line voltage you
are connecting to is not higher than that stated on the sticker of the fixture.
- This is an outdoor water-proof rated unit. In order to ensure the fixture remains water-proof,
do not attempt to disassemble as in doing so the rubber seals and the like that help keep the
product water-proof may be damaged.
- Use only compatible water-proof cables for installation and connection
- Product can be used indoors as well
- Make sure there are no flammable materials close to the unit while operating.
- The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surface. Be sure that no ventilation slots are blocked.
- Always disconnect from power source before servicing.
- Secure fixture to stands, trussing and the like using a safety chain.
- Maximum ambient temperature is 50˚C. Do not operate fixture at temperatures higher than
this.

3
- In the event of serious operating problem, stop using the unit immediately. Never try to repair
the unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction.
Please contact the nearest authorized technical assistance center.
- Make sure power cord is never crimped or damaged.
- Never disconnect power cord by pulling or tugging on the cord.
- Never carry the fixture directly from the cord. Carry by holding the chassis of the unit.
- Avoid direct eye exposure to the light source while it is on.
2. Installation:
Caution: For safe mounting of this product, please read the following carefully.
- When mounting the product, do not stand directly underneath the product.
- When mounting in fixed installation, use the provided brackets. Please ensure the unit is
being attached securely to any surface – consult a professional for the installation if need be.
- For outdoor installations be sure that proper IP rated cables are used compatible with the
connections that come with the product.
- Always use a safety chain when mounting the product on stands, trussing or bars. Make sure
the breaking strain rating of the chain is at least 10 times the weight of the product.
- Product will work in any orientation.
- Make sure there is adequate ventilation around the product.
- Never look directly into the LED light sources of the product.
- Keep out of reach of children.
3. Features
This product is designed as an outdoor professional LED flood lighting effect and is only
intended to be used as such for entertainment, display and architectural applications. Due to
our ongoing commitment to constantly reviewing and improving products, features and
specifications are subject to change without prior notice.
- LEDs: 18 x 3W RGB TRI 3-in-1 LEDs with average 50000 hours lifespan
- Beam angle ： 15º
- Control: DMX or on-board built-in programs
- 10 different DMX modes to suit users’ needs
- DMX Channels: 2/3/4/6/7/9/18/54/56
- Functions: Colour mixing and fading, single colour, patterns, individual pixel control
- Electronic strobe rate: 1-25Hz
- Built in colour macros and programs
- Extruded rugged Aluminium housing
- IP65 rated
- Weight: 7kg
- Packed Dimensions 1060x110x170mm

4
4. Menu Operation
Used for setting up or operating the product without DMX control
Menu: Press each time to access features – see
table below.
UP: Increase setting
DOWN: Decrease setting
Enter: Confirm and save setting.
Menu Table:
No. Show Value Function
1 d001 001- 512 DMX512 starting address
2 R255 000 - 255 Red Dimming 0-100%
3 G255 000 - 255 Green Dimming 0-100%
4 B255 000 - 255 Blue Dimming 0-100%
5 FF99 00 - 99 RGB Strobe, speed from slow to fast
6 1JP0 0 - 9 Jump effect 01,Speed from slow to fast
7 2JP0 0 - 9 Jump effect 02,Speed from slow to fast
8 3JP0 0 - 9 Jump effect 03,Speed from slow to fast
9 4JP0 0 - 9 Jump effect 04,Speed from slow to fast
10 5JP0 0 - 9 Jump effect 05,Speed from slow to fast
11 6JP0 0 - 9 Jump effect 06,Speed from slow to fast
12 7JP0 0 - 9 Jump effect 07,Speed from slow to fast
13 8JP0 0 - 9 Jump effect 08,Speed from slow to fast
14 9JP0 0 - 9 Loops jump effect 01 to 08
15 1dE0 0 - 9 Red shade effect, Speed from slow to fast
16 2dE0 0 - 9 Green shade effect, Speed from slow to fast
17 3dE0 0 - 9 Blue shade effect, Speed from slow to fast
18 4dE0 0 - 9 Pink shade effect, Speed from slow to fast
19 5dE0 0 - 9 Yellow shade effect, Speed from slow to fast
20 6dE0 0 - 9 Loops red to yellow shade effect ,Speed from slow to fast
21 Sud0 0 - 9 Sound active, Speed from slow to fast
22 CH02 02/03/04/06/07/09/18/5
4/56 DMX channel mode / profile set

5
5. DMX Channel Allocation and functions tables.
There are 10 different DMX profiles for this fixture. This allows the user to use simple overall
control over fewer DMX channels or for the user to individually control each individual
feature of the light over many more channels. You must choose the DMX mode/profile prior to
setting up with DMX. When using multiple fixtures, all fixtures should be set to the same
DMX profile for simplicity of control and DMX address allocation.
5a. Two channel DMX mode:
Channel DMX Value Function
CH1
000-005 Null
006-016 Red
017-027 Green
028-038 Blue
039-049 Yellow
050-060 Pink
061-071 Cyan
072-082 White
083-093 Jump effect 01
094-104 Jump effect 02
105-115 Jump effect 03
116-126 Jump effect 04
127-137 Jump effect 05
138-148 Jump effect 06
149-159 Jump effect 07
160-170 Jump effect 08
171-181 Loops jump effect 01 to 08
182-192 Red shade effect
193-203 Green shade effect
204-214 Blue shade effect
215-225 Pink shade effect
226-236 Yellow shade effect
237-247 Loops red to yellow shade effect
248-255 Sound active
CH2 000-255 Speed from slow to fast
5b. Three Channel DMX Mode
Channel DMX Value Function
CH1 000-255 Red Dimming, From dark to light
CH2 000-255 Green Dimming, From dark to light
CH3 000-255 Blue Dimming, From dark to light

6
5c. Four Channel DMX Mode
Channel DMX Value Function
CH1 000-255 RGB Total Dimming, From dark to light
CH2 000-255 Red Dimming, From dark to light
CH3 000-255 Green Dimming, From dark to light
CH4 000-255 Blue Dimming, From dark to light
5d. Six Channel DMX Mode
Channel DMX Value Function
CH1 000-255 1-8# Red Dimming, From dark to light
CH2 000-255 1-8# Green Dimming, From dark to light
CH3 000-255 1-8# Blue Dimming, From dark to light
CH4 000-255 9-18# Red Dimming, From dark to light
CH5 000-255 9-18# Green Dimming, From dark to light
CH6 000-255 9-18# Blue Dimming, From dark to light
5e. Seven channel DMX Mode
Channel DMX Value Function
CH1 000-255 RGB Total Dimming, From dark to light
CH2 000-255 Red Dimming, From dark to light
CH3 000-255 Green Dimming, From dark to light
CH4 000-255 Blue Dimming, From dark to light
CH5 007-255 RGB Strobe,SPEED FROM SLOW TO FAST
CH6
000-005 Null
006-016 Red
017-027 Green
028-038 Blue
039-049 Yellow
050-060 Pink
061-071 Cyan
072-082 White
083-093 Jump effect 01
094-104 Jump effect 02
105-115 Jump effect 03
116-126 Jump effect 04
127-137 Jump effect 05
138-148 Jump effect 06
149-159 Jump effect 07
160-170 Jump effect 08
171-181 Loops jump effect 01 to 08

7
182-192 Red shade effect
193-203 Green shade effect
204-214 Blue shade effect
215-225 Pink shade effect
226-236 Yellow shade effect
237-247 Loops red to yellow shade effect
248-255 Sound active
CH7 000-255 SPEED FROM SLOW TO FAST
5f. Nine Channel DMX Mode
Channel DMX Value Function
CH1 000-255 1-6# Red Dimming, From dark to light
CH2 000-255 1-6# Green Dimming, From dark to light
CH3 000-255 1-6# Blue Dimming, From dark to light
CH4 000-255 7-12# Red Dimming, From dark to light
CH5 000-255 7-12# Green Dimming, From dark to light
CH6 000-255 7-12# Blue Dimming, From dark to light
CH7 000-255 13-18# Red Dimming, From dark to light
CH8 000-255 13-18# Green Dimming, From dark to light
CH9 000-255 13-18# Blue Dimming, From dark to light
5g. 18 Channel DMX Mode
Channel DMX Value Function
CH1 000-255 1-3# Red Dimming, From dark to light
CH2 000-255 1-3# Green Dimming, From dark to light
CH3 000-255 1-3# Blue Dimming, From dark to light
CH4 000-255 4-6# Red Dimming, From dark to light
CH5 000-255 4-6# Green Dimming, From dark to light
CH6 000-255 4-6# Blue Dimming, From dark to light
CH7 000-255 7-9# Red Dimming, From dark to light
CH8 000-255 7-9# Green Dimming, From dark to light
CH9 000-255 7-9# Blue Dimming, From dark to light
CH10 000-255 10-12# Red Dimming, From dark to light
CH11 000-255 10-12# Green Dimming, From dark to light
CH12 000-255 10-12# Blue Dimming, From dark to light

8
CH13 000-255 13-15# Red Dimming, From dark to light
CH14 000-255 13-15# Green Dimming, From dark to light
CH15 000-255 13-15# Blue Dimming, From dark to light
CH16 000-255 16-18# Red Dimming, From dark to light
CH17 000-255 16-18# Green Dimming, From dark to light
CH18 000-255 16-18# Blue Dimming, From dark to light
5h. 54 Channel DMX Mode
Channel DMX Value Function
CH1 000-255 1# Red Dimming, From dark to light
CH2 000-255 1# Green Dimming, From dark to light
CH3 000-255 1# Blue Dimming, From dark to light
CH4 000-255 2# Red Dimming, From dark to light
CH5 000-255 2# Green Dimming, From dark to light
CH6 000-255 2# Blue Dimming, From dark to light
CH7 000-255 3# Red Dimming, From dark to light
CH8 000-255 3# Green Dimming, From dark to light
CH9 000-255 3# Blue Dimming, From dark to light
CH10 000-255 4# Red Dimming, From dark to light
CH11 000-255 4# Green Dimming, From dark to light
CH12 000-255 4# Blue Dimming, From dark to light
CH13 000-255 5# Red Dimming, From dark to light
CH14 000-255 5# Green Dimming, From dark to light
CH15 000-255 5# Blue Dimming, From dark to light
CH16 000-255 6# Red Dimming, From dark to light
CH17 000-255 6# Green Dimming, From dark to light
CH18 000-255 6# Blue Dimming, From dark to light
CH19 000-255 7# Red Dimming, From dark to light
CH20 000-255 7# Green Dimming, From dark to light
CH21 000-255 7# Blue Dimming, From dark to light
CH22 000-255 8# Red Dimming, From dark to light
CH23 000-255 8# Green Dimming, From dark to light
CH24 000-255 8# Blue Dimming, From dark to light
CH25 000-255 9# Red Dimming, From dark to light

9
CH26 000-255 9# Green Dimming, From dark to light
CH27 000-255 9# Blue Dimming, From dark to light
CH28 000-255 10# Red Dimming, From dark to light
CH29 000-255 10# Green Dimming, From dark to light
CH30 000-255 10# Blue Dimming, From dark to light
CH31 000-255 11# Red Dimming, From dark to light
CH32 000-255 11# Green Dimming, From dark to light
CH33 000-255 11# Blue Dimming, From dark to light
CH34 000-255 12# Red Dimming, From dark to light
CH35 000-255 12# Green Dimming, From dark to light
CH36 000-255 12# Blue Dimming, From dark to light
CH37 000-255 13# Red Dimming, From dark to light
CH38 000-255 13# Green Dimming, From dark to light
CH39 000-255 13# Blue Dimming, From dark to light
CH40 000-255 14# Red Dimming, From dark to light
CH41 000-255 14# Green Dimming, From dark to light
CH42 000-255 14# Blue Dimming, From dark to light
CH43 000-255 15# Red Dimming, From dark to light
CH44 000-255 15# Green Dimming, From dark to light
CH45 000-255 15# Blue Dimming, From dark to light
CH46 000-255 16# Red Dimming, From dark to light
CH47 000-255 16# Green Dimming, From dark to light
CH48 000-255 16# Blue Dimming, From dark to light
CH49 000-255 17# Red Dimming, From dark to light
CH50 000-255 17# Green Dimming, From dark to light
CH51 000-255 17# Blue Dimming, From dark to light
CH52 000-255 18# Red Dimming, From dark to light
CH53 000-255 18# Green Dimming, From dark to light
CH54 000-255 18# Blue Dimming, From dark to light

10
5i. 56 Channel DMX Mode
Channel DMX Value Function
CH1 000-255 RGB Total Dimming, From dark to light
CH2 007-255 RGB Strobe, SPEED FROM SLOW TO FAST
CH3 000-255 1# Red Dimming, From dark to light
CH4 000-255 1# Green Dimming, From dark to light
CH5 000-255 1# Blue Dimming, From dark to light
CH6 000-255 2# Red Dimming, From dark to light
CH7 000-255 2# Green Dimming, From dark to light
CH8 000-255 2# Blue Dimming, From dark to light
CH9 000-255 3# Red Dimming, From dark to light
CH10 000-255 3# Green Dimming, From dark to light
CH11 000-255 3# Blue Dimming, From dark to light
CH12 000-255 4# Red Dimming, From dark to light
CH13 000-255 4# Green Dimming, From dark to light
CH14 000-255 4# Blue Dimming, From dark to light
CH15 000-255 5# Red Dimming, From dark to light
CH16 000-255 5# Green Dimming, From dark to light
CH17 000-255 5# Blue Dimming, From dark to light
CH18 000-255 6# Red Dimming, From dark to light
CH19 000-255 6# Green Dimming, From dark to light
CH20 000-255 6# Blue Dimming, From dark to light
CH21 000-255 7# Red Dimming, From dark to light
CH22 000-255 7# Green Dimming, From dark to light
CH23 000-255 7# Blue Dimming, From dark to light
CH24 000-255 8# Red Dimming, From dark to light
CH25 000-255 8# Green Dimming, From dark to light
CH26 000-255 8# Blue Dimming, From dark to light
CH27 000-255 9# Red Dimming, From dark to light
CH28 000-255 9# Green Dimming, From dark to light
CH29 000-255 9# Blue Dimming, From dark to light
CH30 000-255 10# Red Dimming, From dark to light
CH31 000-255 10# Green Dimming, From dark to light

11
CH32 000-255 10# Blue Dimming, From dark to light
CH33 000-255 11# Red Dimming, From dark to light
CH34 000-255 11# Green Dimming, From dark to light
CH35 000-255 11# Blue Dimming, From dark to light
CH36 000-255 12# Red Dimming, From dark to light
CH37 000-255 12# Green Dimming, From dark to light
CH38 000-255 12# Blue Dimming, From dark to light
CH39 000-255 13# Red Dimming, From dark to light
CH40 000-255 13# Green Dimming, From dark to light
CH41 000-255 13# Blue Dimming, From dark to light
CH42 000-255 14# Red Dimming, From dark to light
CH43 000-255 14# Green Dimming, From dark to light
CH44 000-255 14# Blue Dimming, From dark to light
CH45 000-255 15# Red Dimming, From dark to light
CH46 000-255 15# Green Dimming, From dark to light
CH47 000-255 15# Blue Dimming, From dark to light
CH48 000-255 16# Red Dimming, From dark to light
CH49 000-255 16# Green Dimming, From dark to light
CH50 000-255 16# Blue Dimming, From dark to light
CH51 000-255 17# Red Dimming, From dark to light
CH52 000-255 17# Green Dimming, From dark to light
CH53 000-255 17# Blue Dimming, From dark to light
CH54 000-255 18# Red Dimming, From dark to light
CH55 000-255 18# Green Dimming, From dark to light
CH56 000-255 18# Blue Dimming, From dark to light

12
6. DMX-512 Control Connection
Using a 3 pin XLR cable, you can connect the product to a DMX controller and then to
other fixtures with 3 pin XLR inputs and outputs. When not using DMX, multiple
fixtures can be connected together and operate under master/slave control. The signal
cable should have two core with shielded cable, the signal connectors are XLR input
and output connectors. Please refer to the below diagram:
7. DMX Address Setting
When being used in conjunction with a DMX controller, each fixture must be set a specific
starting address. When receiving signal, fixture will receive channel control signals of this
address from the DMX controller.
For simplicity, the user can use the same address for multiple fixtures but this will result in
each fixture providing exactly the same output and fixtures with the same DMX address cannot
be individually controlled.
To control each fixture individually via DMX, each fixture must have its own unique DMX
address. Depending upon which DMX mode this fixture is set in, the individual DMX
addresses must be separated by at least the same number of channels. For example in 9 channel
mode, the DMX addresses must be at least 9 channels apart.
So for example – assuming the first fixture is DMX channel 1 and we are in 9 channel DMX
mode, the second fixture would need to be on channel 10, then the 3
rd
channel 19 and so on.
Some DMX controllers may group fixtures in lots of 16 channels – so in that case, fixture 1 on
channel 1, fixture 2 on channel 17, 3 on 33, and so on. Refer to your DMX controllers’
instruction manual on how best to manage your DMX channel allocation.

13
8. DMX Terminator:
A DMX terminator helps to reduce ‘noise’ on the DMX chain, and makes the light respond to
control more accurately. It should be plugged in to the last fixture in any chain. For Terminator
connections please see below:
9. Cleaning and maintenance
From time to time it is recommended the product is cleaned to ensure maximum light output
and performance. Use a wet cloth to clean the housing as well as the lenses and base. Glass
cleaner is also suitable but alcohol based cleaners and solvents cannot be used as they will
cause damage to the product.
When used in a fixed long term installation such as a venue or club, the unit should be
periodically taken down from the installation and professionally cleaned. Dust build-up within
the unit can cause damage and ultimately failure of components.
10. Technical Data
- Input voltage: 90-240VAC, 50 or 60Hz
- Power consumption: 60W
- LEDs: 18 x 3W RGB TRI 3-in-1 LEDs with average 50000 hours lifespan
- Beam angle: 15º
- Control: DMX or on-board built-in programs
- 10 different DMX modes to suit users’ needs
- DMX Channels: 2/3/4/6/7/9/18/54/56
- Functions: Colour mixing and fading, single colour, patterns, individual pixel control
- Electronic strobe rate: 1-25Hz
- Built in colour macros and programs
- Extruded rugged Aluminium housing
- Cooling via Aluminium housing
- IP65 rated
- Weight: 7kg / 9kg gross
- Packed Dimensions 2060x110x170mm

14
11. Warranty
This product is warranted for 12 months from your purchase date. We are confident that this
product will give many years of trouble-free operation but should an unlikely problem arise,
warranty claims must be via the original place of purchase, together with the original purchase
receipt. Please keep both your original purchase receipt and this instruction manual together
and in a safe place for future reference. Should the product be sold within the warranty period,
be sure to pass on both to the new purchaser so they are able to claim warranty should they
need to. We recommend you register your warranty online at www.industrygear.com.au.
Purchased from:_________________________________________
Contact Details:_________________________________________
Date Purchased:_________________________________________
Invoice/Receipt Number:__________________________________
Copyright Light Emotion 2016. E&OE
Exclusively imported by LSW Imports and Distribution
PO Box 887, Kingsgrove, NSW, 2208
[email protected]
www.lightemotion.com.au
1800 643 111 (within Australia)
[phone] (outside of Australia)
