Lightmybricks 10273 User manual

Light My Bricks: LEGO Haunted House 10273
Lighting Kit
The following page is the instructions for the Light My Bricks LEGO Haunted House 00273) LED light
kit.
Ifyou run into any issues, please refer to the online troubleshooting guide.
To ensure a trouble-free installation of your light kit, please read and follow each step carefully
Please note: This page lists instructions for the LED light kit only
Package Contents:
• 4 x White 30cm Bit Lights
• 4 x White 15cm Bit Lights
• 4 x White 30cm Micro Bit Lights
• 12 x White 15cm Micro Bit Lights
• 2 x Warm White Strip Lights

• 6 x Green Strip Lights
• 3 x 6-Port Expansion Board
• 1 x 8-Port Expansion Board
• 3 x Micro 2-4 Port Expansion Boards
• 1 x Micro 2-8 Port Expansion Board
• 3 x Flicker Effects Boards
• 2 x Scary Flicker Effects Boards
• 10 x 5cm Connecting Cable
• 2 x 15cm Connecting Cables
• 6 x 30cm Connecting Cables
• 1 x 50cm Connecting Cable
• USB power cable
• I x Flat Battery Pack (Aequires 2x CA2032 Batteries)
• 4 x Adhesive Squares
LEGO Pieces:
• 2 x Trans Dark Blue Round Plate IXI
• 2 x Black IXI Modified Plate Rounded with Handle
• 1 x Black Round Plate with open stud IXI
• 1 x Black Arm Skeleton, Bent with Clips (Horizontal Grip)
Important things to note:
Laying cables in between and underneath bricks
Cables can fit in between and underneath LEGO@ bricks, plates, and tiles providing they are laid
correctly between the LEGO@ studs. Do NOT forcefully join LECO@ together around cables; instead
ensure they are laying comfortably in between each stud.

CAUTION: Forcing LEGO@ to connect over a cable can result in damaging the cable and light.
Connecting cable connectors to Expansion Boards
Take extra care when inserting connectors to ports of Expansion Boards. Connectors can be inserted
only one way. With the expansion board facing up, look for the soldered symbol on the left side of
the port. The connector side with the wires exposed should be facing toward the soldered symbol
as you insert into the port. If a plug won't fit easily into a port connector, do not force it.
Incorrectly inserting the connector can can result in bent pins inside the port or possible
overheating of the expansion board when connected.
Connecting cable connectors to Strip Lights
Take extra care when inserting connectors to ports on the Strip Lights. Connectors can be inserted only
one way. With the Strip Light facing up, ensure the side of the connector with the wires exposed is facing
down. If a plug won't fit easily into a port connector, don't force it. Doing so will damage the plug and the
connector.

Connecting Micro Cable connectors to Micro Expansion
Board Ports
Take extre care when inserting the micro connectors to micro ports of Micro Expansion Boards.
Connecting Micro Bit Lights to Micro Expansion Boards is similar to connecting lights and cables
to
Strip Lights. With the expansion board facing up, ensure the side of the cannector with the wires exposed
is facing down. If a plug won't fit easily into a port connector, do not fdrce it. Use your fingernail to push
the plastic part of the connector to the micro port.
Installing Bit Lights under LEGO@ bricks and plates.
When installing Bit Lights under LECO@ pieces, ensure they are placed the correct way up (Yellow LED
component exposed). You can either place them directly on top of LEGO@ studs or in between.

OK, Let's Begin!
