FBP100FE
450 LUMEN LINEAR FLUORESCENT EM. BALLAST
Page 1 of 2
Job Information Type:
Job Name:
Cat. No.:
Notes:
Features
Illumination: The FBP100FE
provides 90 minutes of
emergency illumination by
utilizing existing fluorescent
lighting, and produces 350-450
lumens initial emergency light
output. The FBP100FE can be
used with most 17 to 40 W
(2’-4’) T8, T10, or T12
fluorescent lamps without
integral starters, including
U-shaped, HO, VHO, circline,
energy saving, and 4-pin
compacts. It is also compatible
with most 1-, 2-, 3-, and 4-lamp
electronic, standard, energy
saving and dimming AC ballasts.
See lamp operation for specific
lamp types.
Housing: Housing is
constructed of 20 gauge steel
with a high temperature
powder coat paint finish. Slim
housing allows for wireway
channel mounting on most
lighting fixtures.
Operating Temperature
Range:
32°F (0°C) to 131°F (55°C)
Electronics: 120/277 VAC
dual voltage input with surge
protected, solid-state charging
circuitry provides for a reliable
charging system. Charging
system is complete with AC
indicator lamp and test switch.
Electrical Specifications:
Input Power
3.5 W max.
Battery
Maintenance free, sealed nickel
cadmium battery. Supplies 90
minutes of emergency power.
Estimated service life of 10
years.
Lamp Operation1: Operates
the following lamp types2:
T8 linear fluorescent
T12 linear fluorescent
T9 circline
T12 U-bent
T5 long compact fluorescent
Notes:
1) Consult factory for compatibility
and performance of product with lamp
types not listed.
2) See Table 1 for specific lamp
performance and operation.
Code Compliance
UL 924 listed. NFPA 70, NFPA
101, NEC, BOCA, OSHA and
IBC illumination standards.
Suitable for use in sealed and
gasketed luminaires.
Warranty
One year full electronics
warranty. One year full battery
warranty.
FBP100FE
9.4"
(23.9 cm)
1.5"
(3.8 cm)
2.4"
(6.1 cm)

FBP100FE
450 LUMEN LINEAR FLUORESCENT EM. BALLAST
Page 2 of 2
Philips Lightolier
e: [email protected]
t: [phone]
w: www.lightolier.com
FBP100FE August 28, 2012
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2012.All rights reserved.
Job Information Type:
Ordering Information
Series
FBP100FE = 450 Lumen Max. Output
Fluorescent Emergency Ballast for One
Lamp Operation
FBP100FE
LAMP
TYPE
F20T12
F30T12
F40T12
F48T10
F17T8
F25T8
F32T8
F40T8
FC6T9
FC8T9
FC12T9
FC16T9
F39/36BX
F40/30BX
WATT.
20
30
40
110
17
25
32
40
20
22
32
40
39
40
BASE TYPE
G13/Med Bi-Pin
G13/Med Bi-Pin
G13/Med Bi-Pin
R17D/Recessed
G13/Med Bi-Pin
G13/Med Bi-Pin
G13/Med Bi-Pin
G13/Med Bi-Pin
G10Q/4-Pin
G10Q/4-Pin
G10Q/4-Pin
G10Q/4-Pin
2G11/4-Pin
2G11/4-Pin
NON-EMERGENCY
MAX. LUMEN OUTPUT
1275
2350
2650
6200
1350
2150
2950
3725
800
1100
1950
2700
2850
3150
NOTES
1) Maximum non-emergency lumen output can vary based on lamp manufacturer, ambient operating temperature,
and ballast manufacturer.
2) Maximum emergency lumen output is based on total output of one or two lamps, and can vary based on lamp
manufacturer and ambient operating temperature.
3) Consult factory for compatibility, operation, and performance of lamp types not listed.
O
ptions
EX1= Special Input Transformer
(specify voltage and frequency)
Lamp Operation and Performance
Table 1
Accessories (order as a separate item)
CCAPS = Wire Cover Kit for External Mounting
RTS = Remote Test Plate
RTS2 = Remote Test Switch & Pilot Light Kit (includes plate)
EMERGENCY OP.
MAX. LUMEN OUTPUT
350-450
350-450
350-450
350-450
350-450
350-450
350-450
350-450
350-450
350-450
350-450
350-450
350-450
350-450
EMERGENCY
LAMP OPERATION
One
One
One
One
One
One
One
One
One
One
One
One
One
One
Note
1) Some option combinations may impact UL listing. Consult factory for specifics.
