Lightolier Lytespan 8610E User manual

1 1/16"
1 1/2"
15/16"
4 9/16"
3
1 7/8"
54
1
2
Lytespan®Accent Lighting System 8610E
Page 1 of 1 LyteJacks Track Power Jack
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • A0206
Features
1. Lytespan Attachment Fitting: Rotates into track.
2. Movable Brass Contact: Extends to connection to 2nd circuit in Advent
Lytespan Track.
3. Plastic Housing: Encloses transformer and plug jack.
4. Plug Jack: Molded high heat resistant polymer. Accepts all
Lytejack fixtures.
5. Polycarbonate Stem Bushing: When using Lytedrops, remove by using a
coin such as a dime.
Electrical
Class 2 electronic transformer operates 12V lamps in luminaires.
Dimming
Use only dimmers specifically designed for use with electronic transformers.
Low voltage fixtures may produce audible sound when dimmed.
Finish
All painted finishes baked enamel.
Labels
UL; CUL
Catalog No. Finishes Mounting Use With
8610EWH Matte White All Lytespan ceiling mounted Track systems Lytedrops or Focal Jack Luminaires
8610EBK Matte Black Does not mount on Pro-Spec track 50 Watt Max
8610EAL Aluminum
8610EWH
8610EBK
8610EAL
