ProSpec® Track Lighting System 26075
Page 1 of 1 Lytespan to ProSpec Adapter
Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2005 Genlyte Group LLC • 0505
Description
Adapter module that mounts anywhere along the ProSpec track and accepts
most Lytespan luminaires (see luminaire compatibility for exceptions).
Features
1. Adapter Housing: High-temperature impact resistant thermoplastic.
2. Basic Lytespan Track Strip: Die cast aluminum, with high-temperature
impact resistant thermoplastic insulator, supporting electrical contacts.
Accepts Lytespan luminaires.
3. Track Attachment Fitting: High-temperature impact resistant polycarbon-
ate, rotates into track. Adapter module can be flipped 180° to access one or
the other circuit.
4. Clamping Knob: Rotation of clamping knob secures steel clamping toggle
to track.
5. Attachment Lever: Impact resistant polycarbonate. For mechanical/electri-
cal connection to track.
Electrical
Unit is polarized and continuously grounded throughout. 250W load capacity.
Labels
cULus
Ordering Information
Catalog No. Finishes Track Mounting Luminaire Compatibility
26075WH
26075BK
Matte White
Matte Black
Compatible with ProSpec Track Systems.
DO NOT USE with Monopoints.
Compatible with all Lytespan line and low voltage incandescent
luminaires, 250W Max.
Compatible with all Lytespan fluorescent and metal halide
luminaires EXCEPT PowerWash, Lyteflood L39/L40, PowerArc
Modular, SofTech Metal Halide, Lytespot Metal Halide.
DO NOT USE with Power Jack or ProSpec luminaires.
1 1/2
[37.39]
9/16
[15.04]
6 3/8
[162.07]
4 11/16
[118.76]
1 1/2
[38.36]
2 1/16
[51.84]
2 1/16
[51.88]
1
3
5
2
4
