Lightolier Lytecaster 1102TH1R User manual

3 3/4” High
8”
Ceiling Opening 7" Diameter
Lytecaster®Recessed Downlighting 1102TH1R
6 3/4 Aperture Low Profile 2 Light 13W Twin Tube Fluorescent Non-IC Remodeler Frame-in Kit
Features
1. Bracket: #18 ga. galvanized steel. Anchor nails are provided to secure J-box
bracket to ceiling. (3) retaining clips mount reflector trim to ceiling.
2. Thermally Protected Ballast: 2 light electromagnetic, encased and potted,
class "P" normal power factor or high power factor. Insulation must be kept 3"
away from fixture sides and wiring compartment and must not be placed
above fixture as to entrap heat.
3. Socket Housing: #22 ga. galvanized steel; snap-in quick assembly for
precise lamp location.
4. Socket: Two-pin, molded thermoplastic ; prewired with #18 AWM leads to
junction box.
5. Junction Box: #14 ga. 4" x 3 1/2" x 2" galvanized steel. Quick release "L"
shaped cover for access to wiring. Integral cable clamps permit attachment of
nonmetallic Romex®or armored cable without the need for separate
connectors. Rated for min. 75°C supply wire. .
6. Mounting Ring: .048 (#18 ga.) galvanized steel. Accommodates existing
ceilings up to 1 1/2" thick. Attaches securely to any type of ceiling material
without tools using (3) mounting straps provided. Push-in/twist out clips hold
reflector flush to ceiling. Included adhesive backed aperture template..
7. Nail Clips: Secures junction box to ceiling.
Electrical 120V
HPF: Input Watts 32
Amps: 0.28
Options & Accessories
Plaster Ceiling Ring: 1961- 7/8” depth for wet plaster ceilings
Labels
UL (Damp Locations), I.B.E.W.
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Frame-In Kit Reflector Trims — See Individual Reflector Trim Specification Sheets
Open Downlight
Cone Baffles Cross Blade
1102TH1R HPF 120V 1113TGD 1105T 1132T 1126T 1135T
1113TCL 1105TWH 1128T
1178T
Enclosed
Diffusers
Wall
Washer
Romex®is a registered trademark of General Cable Industries Inc.
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • B0506
