6700S2UEM
Decorative, Circline Fluorescent, 1 Lt. 22W
Page 1 of 3
Job Information Type:
Job Name:
Cat. No.:
Notes:
Ordering Information
Catalog Number Finish Wattage Voltage Lamping
6700S2UEM matte silver 22W 120V/277V Philips Sylvania
FC9T5/* FPC22/*
*Designates manufacturers’ color temperature.
8
14
5
2
3
6
7
9
9 ⅞" (251mm) dia.
8 ¼" (210mm) dia.
1 516"
(33mm)
4"
(102mm)
13 1516" (354mm) dia.ADA Compliant
w/Emergency
Battery Backup

6700S2UEM
Decorative, Circline Fluorescent, 1 Lt. 22W
Page 2 of 3
Job Information Type:
Features
1. Diffuser: Acrylic, injection molded and bonded into one
piece assembly; 0.12" minimum thickness; 70% light
transmission. Lights evenly without discernible hot spots.
Integral tabs provide “twist-lock” installation; no loose
hardware, no tools required.
2. Housing: Polycarbonate, injection molded. Shatter resistant.
Integral bosses retain diffuser without loose hardware.
Tamperproof fastener is optional.
3. Ballast: Electronic; High power factor; Class P.
See Electrical/Ballast.
4. Lamp: 22W, T5, Circline; 2GX13 base (by others).
5. Lamp Socket: Polycarbonate, 4-Pin, 2GX13 base.
6. Lamp Support Clip: .020" thick, spring steel.
7. Test Switch: Single pole.
8. Charge Indicator Light: LED
9. Battery Pack: Provides 90-minute emergency lighting when
AC power fails. Long life nickel cadmium battery; charges
from 120 and 277VAC. Meets National Electric and Life
Safety Code.
Mounting
Ceiling or wall (ADA compliant). Mounts to standard
4" outlet box.
Options
• Shatter resistant polycarbonate diffuser with tamper proof set
screw. Add TPR to end of catalog number.
+ Designates made to order only. Consult factory for lead times.
Electrical/Ballast
22W Lamps
120V 277V
Total Input Watts: 25 25
Max Line Current: .22 .10
Power Factor: >.98 >.98
Ballast Factor: 1.00 1.00
THD: <10% <10%
Min. Starting Temp: 0ºF 0ºF
Emergency/Ballast
Recharge Time Charging Current Lumens
24 hours 280MA 600
Labels
UL Listed. Suitable for dry locations.
8
14
5
2
3
6
7
9
9 ⅞" (251mm) dia.
8 ¼" (210mm) dia.
1 516"
(33mm)
4"
(102mm)
13 1516" (354mm) dia.ADA Compliant
w/Emergency
Battery Backup

6700S2UEM
Decorative, Circline Fluorescent, 1 Lt. 22W
Page 3 of 3
Philips Lightolier
e: [email protected]
t: [phone]
w: www.lightolier.com
6700S2UEM May 31, 2011
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2011.All rights reserved.
Job Information Type:
3 4 5 6 7 8 9 10
10 20 30 40 50 60 70 80 90 100
60
50
40
30
20
10
AREA PER FIXTURE IN SQUARE FEET
Initial Footcandles
CENTER TO CENTER DISTANCE OF FIXTURES IN FEET
Use quick calculator chart to determine the number and spacing
of luminaires for desired level of illumination.
ROOM SURFACE REFLECTANCES
80% Ceiling, 50% Walls, 20% Floor
1800 Lumens Per Lamp
RCR = 1 (60' x 60' x 8.5' room)
RCR = 5 (12' x 12' x 8.5' room)
RCR = 10 (6' x 6' x 8.5' room)
180 150 120
80
90
30
0
300
200
100
ACROSS
45
ALONG
Candlepower summary
Angle Mean CP LMS Angle Mean CP LMS
0 247 90 28
5 246 24 95 25 29
10 243 100 25
15 238 68 105 28 30
20 232 110 32
25 222 103 115 37 37
30 212 120 42
35 199 125 125 48 44
40 185 130 54
45 169 131 135 58 45
50 152 140 61
55 133 120 145 64 40
60 114 150 65
65 94 94 155 65 31
70 76 160 65
75 59 64 165 64 18
80 46 170 59
85 35 40 175 57 6
90 28 180 54
Zonal Lumens and Percentages
Zone Lumens %Lamp %Luminaire
0-30 193 10.76 18.58
0-40 318 17.69 30.57
0-60 568 31.59 54.57
0-90 765 42.52 73.45
40-90 446 24.83 42.89
60-90 196 10.93 18.89
90-180 276 15.37 26.55
0-180 1042 57.89 100.00
**Efficiency = 57.9%**
Coefficients Of Utilization
% Effective Ceiling Cavity Reflectance - Effective Floor Cavity Reflectance = .20
RC 80 70 50 30 10 0
RW 50 30 10 50 30 10 50 30 10 50 30 10 50 30 10 0
1 .57 .54 .52 .54 .52 .50 .49 .47 .45 .44 .42 .41 .39 .38 .37 .35
2 .49 .46 .42 .47 .43 .41 .42 .40 .37 .38 .36 .34 .34 .33 .31 .29
3 .43 .39 .35 .47 .41 .37 .38 .34 .32 .34 .31 .29 .31 .29 .27 .23
4 .39 .34 .30 .43 .37 .34 .32 .33 .30 .30 .27 .25 .27 .25 .23 .21
5 .34 .29 .25 .39 .32 .29 .28 .30 .26 .27 .24 .21 .24 .22 .20 .18
6 .30 .25 .22 .36 .29 .24 .24 .26 .23 .24 .21 .18 .22 .19 .17 .16
7 .27 .22 .19 .33 .26 .21 .22 .24 .20 .22 .18 .16 .20 .17 .15 .14
8 .24 .20 .16 .30 .23 .18 .19 .21 .18 .20 .16 .14 .18 .15 .13 .12
9 .22 .17 .14 .28 .21 .16 .17 .19 .16 .18 .14 .12 .16 .13 .11 .10
10 .20 .15 .12 .26 .19 .14 .15 .18 .14 .16 .13 .11 .15 .12 .10 .09
Room Cavity Ratio
Certified Test Report
No: 1927FR
Computed by LSI Program
**TEST-LITE**
Date: June 25, 2002
Prepared for:
Lightolier
Fall River, MA
Lightolier Surface Utility Fluorescent, Discus with twist lock diffuser, 22W T5 Circline Sylvania
Lamp, Lumen Rating = 1800 LMS, Magnetek Ballast #C2642UNVSE, 120V
Tested according to IES procedures.
Test distance exceeds five times the
greatest luminous opening of luminaire.
8' 8"
9'
9'
8'
8 fc
9 fc
Spacing Ratio = 1.3
Corridor
6700MS22U
6.4 fc. average
0.35W/sf
