BROSA Ethan 5 Drawer Tall Chest User manual

ASSEMBLY GUIDE
Ethan 5 Drawer Tall Chest
v1.0

Components
Upon unpacking your chest from it’s delivery box, you should have the pieces
shown below. Follow the steps on the next pages to assemble your new unit.
15MIN
Drawer Box Unit
Cross dowel
M8 x 12 x 30mm
Threaded bolt
M8 x 60mm
Flat washer
8.4 x 17 x 1.6mm
Lock washer
8.4 x 2mm
Hex nut
M8 x 13mm
Spanner
Mounting plate
Nylon strap
Flat head screw
4 x 17mm
x 4
x 4
x 4
x 4
x 4
x 1
x 2
x 1
x 2
x 1
x 4
2
1
A
B
D
E
C
F
G
J
H

Step 1
A x 4
1.1 Insert cross dowels (A) into the legs (2) by placing each
dowels (A) into the holes on top of each leg (2). Ensure the
horizontal marking on each dowel is facing down.
1.2 Screw threaded bolts (B) into dowels (A) that are already
concealed in legs (2) as shown. Continue to re-tighten until
threaded bolts (B) are securely fastened.
B x 4
Step 1.1
Step 1.2
Step 1.1
Step 1.1
Step 1.2
Step 1.2

Step 2
C x 4
2.1 Lay drawer box unit (1) on a at surface. Attach each leg (2)
into place by inserting threaded bolt (B) through the pre-drilled
hole of each metal corner bracket as shown.
2.2 Insert in order the at washer (C), lock washer (D), and hex
nut (E) onto threaded bolt (B) on leg (2) as shown. Tigthen hex
nut (E) using spanner (F) as shown until securely fastened.
D x 4
E x 4
F x 4
Step 2.3 & 2.4
Step 2.2
Step 1.2
Step 2.1
Step 1.2
Step 2.2

Step 3 With help of assistant, stand the drawer upright.
Enjoy your new drawers!

Tip Kit Instructions
Notice: To prevent injury and property damage from unexpected tipping of furniture, we
highly recommend installation of the anti-tip kit included with this project.
Attaching furniture to wall with anti-tip kits.
1.
2.
3.
4.
5.
Determine where the piece is to be placed and mark location on the wall for the
mounting bracket screw holes. ey should be place approximately 1” below the
bottom of the back of the piece of furniture.
Drill the hole and use the appropriate wall plug that is suitable for your walls
composition. Warning: before drilling check wall for hidden pipes and cables.
Attach the mounting bracket vertically to the wall using appropriate fastener,
through the holes in the bracket and 2 wall plugs that are suitable to your wall and
then tighten securely.
Next using the short screws attach the 2nd bracket to the back of the piece of
furniture’s top.
Lace the nylon strap through the brackets. Slide the thin end of the strap through the
receiving end of the nylon strap. Pull to tighten the piece of furniture snug against
wall.
Wood Brick or Masonry Cavity Wall
If fixing to
wood make
sure that is isn’t
chipboard as
screws can
easily pull
away from the
core structure.
Use an
appropriate
wall plug
provided when
you are sure
your wall is
sound.
Special toggle
wall plugs are
needed. Seek
expert advice.
