Calculite® Matrix®Open Downlight 4X4
Page 1 of 2 4 1/2" X 4 1/2" Square Aperture (1) 26/32W Triple Tube
5
5 1/2"
4 1/2"
5 3/4"
7
1
2
4 3 6
1 1/4" Max.
Ceiling Thickness
4 1/2"
5 3/4"
9 5/8"
10"
5 7/8"
7 1/8"
5"
Top View
Features
1. Reflector Trim: Pre-finished aluminum with low iridescence clear finish. 55°
visual and reflected cutoff. Overlap flange accommodates different ceiling
types. Precision mitered flange corners.
2. Upper Reflector: High efficiency, 97%, Specular Clear.
3. Housing: 22 ga. galvanized formed steel. Centerline notches and holes
for consistent alignment of multiple fixtures. Accommodates ceilings up to
1 1/4" thick.
4. Ballast Assembly: Door-mounted for easy service, allows replacement from
inside of fixture.
5. Torsiontite Springs: Precision-tooled steel springs secure reflector trim
to housing for quick tool-less installation. Positive tension holds flange tight
against ceiling.
6. J-Box: 14 ga. galvanized steel. Accessible from inside and outside of the
fixture. Outside J-box door is hinged for easy access.
7. Mounting Brackets: 16 ga. steel. Adjustable from inside fixture. Utilize 3/4"
or 1 1/2" lathing channel, 1/2" EMT, or optional mounting bars.
Options & Accessories
Chicago Plenum with Fuse (slow blow): Add LCF suffix to Frame-In Kit,
consult factory for specifications.
Mounting Bars / T-Bar Anchor Clips: See specification sheet “MBA”.
Electrical
UL Listed for through circuit wiring with max of (8) No. 12 AWG, 90°C supply
conductors.
Note: For complete ballast data and lamp/ballast compatibility refer to
“Ballast” specification sheet.
General
UL listed for damp locations, I.B.E.W. Union Made.
Specular Clear nish (CL) reector trims meet IES RP-1 practice.
Ceiling Cutout: 5 1/8" L X 5 1/8" W
Trim Kits Frame-In Kits
Reflector
Trims Finish / Flange Frame-In Kits Type Ballast Input Voltage
Triple Tube
Wattage Length Width Height
4X4CLW Specular Clear / White 4X4132HU Non-IC Electronic 120/277V 26/32W 10" 9 1/2" 5 3/4"
4X4CLP Specular Clear / Polished 4X4132HUEM4E Non-IC Electronic - Emergency 120/277V 26/32W 10" 11" 5 3/4"
4X4CCLW Comfort Clear / White 4X4132HCU3 Non-IC PowerSpec®HDF Dimming 120/277V 26/32W 10" 9" 5 3/4"
4X4CCLP Comfort Clear / Polished 4X4132HJUM7 Non-IC Mark 7®Dimming 120/277V 26/32W 10" 9 1/4" 5 3/4"
4X4CCDW Comfort Clear Diff. / White 4X4132HJ1MX Non-IC Mark 10®Dimming 120V 26/32W 10" 9 1/4" 5 3/4"
4X4CCDP Comfort Clear Diff. / Polished 4X4132HJ2MX Non-IC Mark 10®Dimming 277V 26/32W 10" 9 1/4" 5 3/4"
4X4CCGP Clear Corrugated / Self Flange
4X4WHW White / White

631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • A0409
Calculite® Matrix®Open Downlight 4X4
Page 2 of 2 4 1/2" X 4 1/2" Square Aperture (1) 26/32W Triple Tube
Job Information Type:
20% Floor Cavity Reectance
1 .60 .59 .58 .59 .58 .57 .57 .56 .55 .55 .54 .53 .53 .52 .52 .51
2 .56 .54 .52 .55 .53 .52 .53 .52 .50 .52 .51 .49 .50 .49 .48 .47
3 .52 .49 .47 .51 .49 .47 .50 .48 .46 .49 .47 .45 .47 .46 .45 .44
4 .48 .45 .43 .48 .45 .43 .47 .44 .42 .45 .43 .42 .44 .43 .41 .40
5 .45 .41 .39 .44 .41 .39 .43 .41 .38 .42 .40 .38 .42 .40 .38 .37
6 .42 .38 .36 .41 .38 .35 .40 .37 .35 .39 .37 .35 .39 .36 .35 .34
7 .38 .35 .32 .38 .34 .32 .37 .34 .32 .36 .34 .32 .36 .33 .31 .31
8 .35 .32 .29 .35 .31 .29 .34 .31 .29 .34 .31 .29 .33 .31 .29 .28
9 .32 .29 .26 .32 .29 .26 .31 .28 .26 .31 .28 .26 .30 .28 .26 .25
10 .30 .26 .24 .29 .26 .24 .29 .26 .24 .28 .25 .23 .28 .25 .23 .23
32W Triple Tube, Specular Clear Reflector Trim
One Philips lamp, 2400 lumens
ZONAL LUMENS AND PERCENTAGES
Zone Lumens % Lamp % Luminaire
0-30 628 26.18 47.89
0-40 1002 41.77 76.42
0-60 1309 54.56 99.82
0-90 1311 54.66 100.00
0 712 712 712 712 712
5 721 735 761 772 773 72
10 710 745 803 840 828
15 685 727 808 835 812 220
20 629 678 765 849 855
25 557 611 745 853 844 336
30 485 560 724 834 823
35 408 493 629 718 732 374
40 313 392 500 574 636
45 220 258 297 404 472 252
50 123 136 141 199 224
55 18 31 47 53 38 55
60 2 3 7 5 4
65 1 2 1 2 2 2
70 1 1 1 1 1
75 0 0 0 0 0 0
80 0 0 0 0 0
85 0 0 0 0 0 0
90 0 0 0 0 0 0
Test Report 1710FR Apr. 4, 2002
Angle Along 22.5 45 67.5 Across Lumens
CANDLEPOWER SUMMARY
EFFICIENCY = 54.7% Spacing Criterion: Along = 1.1 Across = 1.5
% Effective Ceiling Cavity Reectance
1 .60 .59 .58 .59 .58 .57 .57 56 .55 55 .54 .54 .53 .53 .52 .51
2 .56 .54 .52 .55 .53 .52 .53 .52 .51 .52 .51 .49 .50 .49 .48 .48
3 .52 .50 .47 .51 .49 .47 .50 .48 .46 .49 .47 .46 .48 .46 .45 .44
4 .49 .46 .43 .48 .45 .43 .47 .44 .43 .46 .44 .42 .45 .43 .42 .41
5 .45 .42 .39 .45 .42 .39 .44 .41 .39 .43 .40 .39 .42 .40 .38 .37
6 .42 .39 .36 .41 .38 .36 .41 .38 .36 .40 .37 .35 .39 .37 .35 .34
7 .39 .35 .33 .38 .35 .33 .38 .35 .33 .37 .34 .32 .36 .34 .32 .31
8 .36 .32 .30 .35 .32 .30 .35 .32 .30 .34 .31 .29 .34 .31 .29 .29
9 .33 .29 .27 .33 .29 .27 .32 .29 .27 .32 .29 .27 .31 .28 .27 .26
10 .30 .27 .24 .30 .27 .24 .30 26 .24 .29 .26 24 .29 .26 .24 .23
ROOM CAVITY RATIO
cu
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10 0
80 70 50 30 10 0
26W Triple Tube, Specular Clear Reflector Trim
One Philips lamp, 1800 lumens
ZONAL LUMENS AND PERCENTAGES
Zone Lumens % Lamp % Luminaire
0-30 491 27.29 50.06
0-40 768 42.69 78.31
0-60 980 54.47 99.91
0-90 981 54.52 100.00
0 546 546 546 546 546
5 569 576 577 573 572 55
10 580 592 616 644 631
15 552 575 659 651 623 173
20 492 540 623 663 635
25 428 486 588 676 647 263
30 373 428 567 642 584
35 320 370 472 515 508 277
40 254 299 342 407 456
45 179 198 189 272 302 176
50 95 107 98 116 123
55 14 23 32 29 20 36
60 2 2 4 2 2
65 1 0 0 1 1 1
70 0 0 0 0 0
75 0 0 0 0 0 0
80 0 0 0 0 0
85 0 0 0 0 0 0
90 0 0 0 0 0
Test Report 1763FR Apr.5, 2002
Angle Along 22.5 45 67.5 Across Lumens
CANDLEPOWER SUMMARY
EFFICIENCY = 54.5% Spacing Criterion: Along = 1.1 Across = 1.4
% Effective Ceiling Cavity Reectance
ROOM CAVITY RATIO
cu
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10 0
80 70 50 30 10 0
20% Floor Cavity Reectance
Based on specular clear (CL) finish. To estimate other finishes, multiply candelas
and CU values by 0.95 for CCL, by 0.90 for CCD.
