Lightolier SL110B User manual

Features
Stand-Off Unit: 2-3/4" overall height, meets ADA requirements.
Channel: 1" x 1" brushed and anodized extruded aluminum ballast channel.
Provided with KO’s and threaded holes to accept all mounting accessories.
Cover: Brushed and anodized aluminum ballast cover. Press-fit installation.
No visible hardware.
Multi-fonction bloc (2): Retains lampholder to the ballast channel. Also
functions as a wireway for continuous rows and patterns. Brushed and anodized
aluminum finish.
Lampholder Stem: Small 5/16" diameter aluminum wireway stem for lampholder,
suitable distance to permit the installation of the shielding options. Hold in place
by ball plungers to ease relamping.
Lampholder Housing (2): 1" square brushed and anodized aluminum with turret
style locking socket.
Mounting
Direct Mount: Square canopies or invisible feed suitable for plaster ceiling, exposed
ceiling or T-Bar ceilings mounts. See details on page 2.
Suspended Mount: Single stem or aircraft cable with round canopy suitable for mounting
on a standard outlet box for plaster ceiling, exposed installation or T-Bar ceilings mounts.
Stem and cable mounts can both be used on the same fixture.
Wall Mount: can be wall mounted vertically or horizontally.
KUBIK 1.0 SL110B
Page 1 of 5 Bare Lamp Stand-Off Unit
1-28W T5 Linear
Dimensions
Louver accessories
Lightolier www.lightolier.com

We reserve the right to change details of design, materials and finish.
SL110B.pdf
Canlyte www.canlyte.com

Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Accessories/Options
Cat. No. Description Finish
SL002ALG Spiral Louver Textured light grey (paint)
SL002C Orbit Louver Semi-diffused aluminum anodized
SPR: Add to unit. The
Spiral louver produces
refined, effective lengthwise
shielding to minimize
add to direct view of
the light source.
ORB: Add to unit. The
Orbit louver displays perfect
balance as it rotates into
any number of positions
from uplight to downlight
to wall washing.

46-3/16"
(1173mm)
2-3/4"
(70mm)
1"
(25mm)
44-1/2"

2"

43-1/2"
 1-3/8"

3-1/2"

Spiral Louver
Orbit Louver (1 part)
Labels
cULus Certified. Suitable for damp locations.
Electrical
Ballast: Electronic rapid start extra slim profile 1 lamp 28W T5 linear ballast. Not available
in universal voltage.
120V: 0.25 amps
277V: 0.11 amps
Lampholder: G5 plug-on base, miniature Bi-pin.
Finish
Natural brushed and anodized aluminum. All suspension parts and Spiral louver painted
with powder coat paint process.
Ordering guide (complete luminaire consist of unit & power feed)
Cat. No. Lamp Volts Description Finish
SL110A28IA1 120V 4 ft Bare Lamp Flush unit Brushed and Anodized Aluminum
SL110A28IA2 1 -28W T 5 277V
Lightolier is a Philips group brand

KUBIK 1.0 SL110B
Page 2 of 5 Bare Lamp Stand-Off Unit
1-28W T5 Linear
Accessories/Options
Job Information Type:
Lightolier www.lightolier.com

We reserve the right to change details of design, materials and finish.
SL110B.pdf
Canlyte www.canlyte.com

Cat. No. Finish Feed Canopy Kit
SL003JLG
SL003JWH
Textured Light Grey
White
Mounts to end or middle of the channel for power feed from
3" (76mm) or 4" (102mm) octagonal outlet box. Kit includes
one 0.05" (1.3mm) thick, 4-1/2" (114mm) grounded square steel
plate. Comes with 4 wires 18 AWG, 10 Amps max.
4-1/2"

Square
Cat. No. Finish Invisible Feed Kit
SL003K Corrosion Protected Accepts conduit or cable with 3/8" (10mm) or 1/2" (13mm)
electrical connector (by others). Kit includes one 0.06" (1.5mm)
thick wall by 1/2" (13mm) dia. seamless steel stem and,
one 0.09" (2.3mm) thick by 5/8" (16mm) by 15/16" (24mm) dia.
aluminum connector. (20 Amps max.)
Cat. No. Finish Power Feed Stem Kit
SLO03M18LG
SLO03M36LG
SLO03M48LG
SLO03M72LG
SLO03M18WH
SLO03M36WH
SL003M48WH
SLO03M72WH
18" Textured Light Grey
36" Textured Light Grey
48" Textured Light Grey
72" Textured Light Grey
18" White
36" White
48" White
72" White
Mounts to a 3" (76mm) or 4" (102mm) octagonal outlet box
Kit includes one 0.024" (0 6mm) thick, 5" (127mm) round steel
canopy, and one 0.06" (1.5mm) thick, 1/2" (13mm) dia. seamless
steel stem, available in 4 different lengths and two decorative
cylinder head screws. Complete installation of Power Feed
Stem Kit. Field cuttable, re-thread stem 1/4-18 NPS. Comes
with 5 pre-assembled wires. 10 Amps max.
Cat. No. Finish Stem Mounting Kit (non-electrical)
SLO04M18LG
SLO04M36LG
SLO04M48LG
SLO04M72LG
SLO04M18WH
SLO04M36WH
SLO04M48WH
SLO04M72WH
18" Textured Light Grey
36" Textured Light Grey
48" Textured Light Grey
72" Textured Light Grey
18" White
36" White
48" White
72" White
Mounts to a 3" (76mm) or 4" (102mm) octagonal outlet box
Kit includes one 0.024" (0 6mm) thick, 5" (127mm) round steel
canopy, and one 0.06" (1.5mm) thick, 1/2" (13mm) dia. seamless
steel stem, available in 4 different lengths and two decorative
cylinder head screws. Complete installation of Power Feed
Stem Kit. Field cuttable, re-thread stem 1/4-18 NPS.
Cat. No. Finish Grid Ceiling Feed Kit
SL003LLG
SL003LWH
Textured Light Grey
White
Mounts along runner or at the intersection of runners. Kit
Includes one 2-1/8" (54mm) deep by 4" (102mm) grounded
octagonal outlet box, one 0.05" (1.3mm) thick universal
crossbar, one 4-1/2” (114mm) white plastic square, and two
t-bar clips 5/32" (4mm) thick spacer, one 0.04" (1 mm) thick
aluminum canopy and two t-bar wrap around clips. Comes
with 4 wires 18 AWG, 10 Amps max.
Lightolier is a Philips group brand

KUBIK 1.0 SL110B
Page 3 of 5 Bare Lamp Stand-Off Unit
1-28W T5 Linear
Job Information Type:
Lightolier www.lightolier.com

We reserve the right to change details of design, materials and finish.
SL110B.pdf
Canlyte www.canlyte.com

Cat. No. Finish Power Feed Cable Kit
SL003NLG
SL003NWH
Textured Light Grey
White
Mounts to a 3" (76mm) or 4" (102mm) octogonal outlet box.
Kit includes one 0.024" (0.6mm) thick, 5" (127mm) round steel
canopy, one 0.05" (1.3mm) thick grounded crossbar threaded
stud, one 0.046" (1.2mm), 96" (2438mm) long aircraft galvanized
cable with zinc plated hanger adjusting glider hardware,
two white plastic cable stay and one 18 AWG (AWM), 10 feet
(3048mm) long white cord, 10 Amps max.
Cat. No. Finish Extension Blank (4')
SL003F4 Brushed Aluminum Permits power feed between two 1" x 1" (25mm x 25mm)
brushed and anodized units in a straight run with supplied
extra wires 18 AWG, 10 Amps max, and wire connectors
to energize them. Includes one 46-3/16" (1173mm) long
extruded aluminum channel and cover, two solid aluminum
multi-function blocks as a wireway, plug inserts and wire
connectors.
46-3/16"

Cat. No. Finish Invisible Coupler
SL003G Zinc plated Invisible coupler for joining two Kubik 1.0 units together
mechanically or/and electrically. Recommended for direct
surface mounting. Comes with 4 wires 18 AWG, 10 Amps max.
Cat. No. Finish 5 Face Connector
SL003H Brushed Aluminum Kubik 1.0 units coupled with exclusive solid brushed and
anodized aluminum 5-face connectors and power feed can
satisfy virtually any layout requirement. The connector permits
you to create square, rectangular, continuous rows, L, T,
X configurations. Includes four threaded couples, plug insert
(3), four wires 18 AWG and wire connectors, 10 Amps max.
Kubik 1.0
1"

Cat. No. Finish Cable Mounting Kit (non-electrical)
SL004NLG
SL004NWH
Textured Light Grey
White
Mounts to a 3" (76mm) or 4" (10mm) octagonal outlet box.
Kit includes one 0.024" (0.6mm) thick, 5" (127mm) round steel
canopy, one 0.05" (1 3mm) thick grounded crossbar, threaded
stud, one 0.046" (1.2mm), 96' (2438mm) long galvanized
aircraft galvanized cable with zinc plated hanger and
adjusting glider hardware. Can be used with either Cable
or Stem Power Feed Kit.
Lightolier is a Philips group brand

Job Information Type:
Lightolier www.lightolier.com

We reserve the right to change details of design, materials and finish.
SL110B.pdf
Canlyte www.canlyte.com

KUBIK 1.0 SL110B
Page 4 of 5 Bare Lamp Stand-Off Unit
1-28W T5 Linear
ZONE
DEG
ALONG 22.5 45 67.5 ACROSS
0 312 312 312 312 312
     
     
     
     
45 120 141 203 265 308
     
65 33 52 145 232 287
75 22 34 120 218 278
85 13 27 102 203 265
     
     
     
115 0 11 75 187 252
     
135 0 0 0 5 27
145 0 0 0 0 0
155 0 0 0 0 0
165 0 0 0 0 0
175 0 0 0 0 0
180 0 0 0 0 0
ZONE
DEG
ALONG 22.5 45 67.5 ACROSS
0 537 537 537 537 537
5 536 533 538 544 535
     
     
35 362 387 446 502 526
45 274 310 380 447 480
     
65 116 163 242 301 344
     
     
     
     
     
     
125 0 15 21 33 47
135 0 7 22 35 41
145 0 5 20 30 38
155 0 0 12 25 28
     
175 3 1 2 1 0
180 2 2 2 2 2
COEFFICIENTS OF UTILIZATION
ZONAL CAVITY METHOD * EFFECTIVE FLOOR CAVITY REFLECTANCE = .20
80 70 50
Wall Reflectance
70 50 30 10 70 50 30 10 50 30 10
DETERMINED IN ACCORDANCE WITH CURRENT IES PUBLISHED PROCEDURES
LUMINAIRE INPUT WATTS = 33.2
COEFFICIENTS OF UTILIZATION
ZONAL CAVITY METHOD * EFFECTIVE FLOOR CAVITY REFLECTANCE = .20
80 70 50
Wall Reflectance
70 50 30 10 70 50 30 10 50 30 10
DETERMINED IN ACCORDANCE WITH CURRENT IES PUBLISHED PROCEDURES
LUMINAIRE INPUT WATTS = 26.5
Room Cavity RatioRoom Cavity Ratio
ZONE LUMENS % LAMP % LUMINAIRE
   
0-40 383 14.75 25.55
   
   
   
   
   
   
ZONE LUMENS % LAMP % LUMINAIRE
0-30 428 16.41 23.66
   
0-60 1271 48.72 70.24
   
   
   
   
   
DISTRIBUTION
DISTRIBUTION
CANDLEPOWER CURVE
CANDLEPOWER CURVE
Performance
CANDLEPOWER
CANDLEPOWER

CAT. NO: SL110B281A/SL002ALG
1 x 28W T5 at 2610 Lumens
Efficiency: 57.7 %
Candela at Nadir: 312cd

CAT. NO: SL110B281A/SL002C
1 x 28W T5 at 2610 Lumens

Candela at Nadir: 537cd
400
300
200
600
500
400
0 .65 .65 .65 .65 .62 .62 .62 .62 .56 .56 .56
            
            
            
4 .43 .36 .31 .27 .41 .34 .30 .26 .31 .27 .24
            
            
7 .33 .25 .20 .17 .32 .24 .20 .16 .22 .18 .15
            
            
           
            
            
2 .68 .62 .57 .53 .66 .60 .56 .52 .57 .54 .51
            
4 .57 .48 .42 .38 .55 .47 .42 .37 .45 .40 .36
5 .52 .43 .36 .32 .50 .41 .36 .31 .40 .34 .31
6 .47 .38 .32 .27 .46 .37 .31 .27 .35 .30 .26
7 .44 .34 .28 .24 .42 .33 .28 .23 .32 .27 .23
            
            
           
Lightolier is a Philips group brand

Job Information Type:
Lightolier www.lightolier.com

We reserve the right to change details of design, materials and finish.
SL110B.pdf
Canlyte www.canlyte.com

KUBIK 1.0 SL110B
Page 5 of 5 Bare Lamp Stand-Off Unit
1-28W T5 Linear
Pattern
SL110A281A
SL110A281A
SL110A281A
SL110A281A
SL110A281A
SL110A281A
SL110A281A
SL110A281A
SL110A281A
SL110A281A
SL110A281A
SL110A281A
SL003G
SL003G
SL003GSL003F4 SL110A281A
SL003K
SL003J
SL003M
SL003H
SL003H
SL003H
SL004N
SL003H SL004N
SL003J
SL003J
