Lightolier ProSpec 37121 User manual

37121
ProSpec™277V HID, Cylinder, 39W T6 CMH
Page 1 of 3
Job Information Type:
Job Name:
Cat. No.:
Notes:
7 7/32"
[184 mm] 8 5/8"
[219 mm]
5"
[127 mm]
5 1/2"
[140 mm]
9 9/32"
[235 mm]
1 5/8"
[41 mm]
2 1/2"
[63 mm]
5 9/32"
[134 mm]
n5"
[127 mm]
1
3
2
6
5
4
8
7
11
910
Catalog No. Finish Mounting Lamp Reflectors (Sold Separately)
37121WH
37121BK
White
Black
ProSpec®120V/277V
track systems only.
39W T6 CMH
G12 base
Not included
Spot Reflector: MHT6RS, MHT6RSCCZ
Narrow Flood Reflector: MHT6RNF,
MHT6RNFCCZ
Flood Reflector: MHT6RF, MHT6RFCCZ
Features
1. Track Attachment Fitting: Molded polycarbonate,
rotates into track.
2. Locking Lever: Steel pin locks and detaches unit.
3. Track Adaptor Housing: Die-cast aluminum.
4. Ballast Housing: Extruded aluminum housing with
die-cast aluminum covers.
5. Ballast: Electronic HID.
6. Pivot Mounts: Allows for 350° horizontal and 180°
vertical rotation with tensioned mounts for controlled aim.
7. Housing: 0.04" (1.02mm) aluminum.
8. Lampholder: Bi-pin G12 single-ended base. 5kV pulse
rated porcelain body socket with nickel-plated contacts. 18
AWG silicone leads with fiberglass outer sleeve hidden
inside of housing.
9. Protective Glass: 0.13" (3.18mm) tempered glass.
10. Housing Cover: 0.04" (1.02mm) aluminum.
11. Knobs: Steel painted knurled knob.
Accessories (Holds one accessory only)
Diffusion/ Special Filters: AF4 series
Color Filters: ADF4 series
Louver (Hex Cell): AL4HC
Electrical
Electronic Ballast (Thermally Protected)
Input Voltage: 120V/277V Total Harmonic Distortion: <10%
Power Factor: >0.99 ANSI Code: M 130
Input Power: 44W Do not use on dimming circuit
Max Input Current: 0.37A@120V/0.16A@277V
Finish
All painted finishes are baked powder or enamel.
Markings
UL, cUL

LBeam Length DDistance
W Beam Width AAiming Angle
CDistance to FC Footcandles
center beam
Land Ware the outer points where the candle
power drops to 50% of the maximum. FC are
the initial footcandles at the center of the beam.
Lamp data shown is typical. Consult lamp
manufacturers for availability and performance.
CBCP = Center Beam Candle Power .
Flood Reflector with 39W T-6 Master Color
Ceramic Metal Halide Philips (Clear) Lamp
Lamp
Beam Spread
(To 50% CBCP) CBCP Rated Life (Hrs.)
10,932 12,000
21°
LBeam Length DDistance
W Beam Width AAiming Angle
CDistance to FC Footcandles
center beam
Land Ware the outer points where the candle
power drops to 50% of the maximum. FC are the
initial footcandles at the center of the beam.
Lamp data shown is typical. Consult lamp
manufacturers for availability and performance.
CBCP = Center Beam Candle Power .
Flood Reflector with 39W T-6 Master Color
Ceramic Metal Halide Philips (Clear) Lamp
Lamp
Beam Spread
(To 50% CBCP) CBCP Rated Life (Hrs.)
3,849 9000
39W T-6 to
40° 15,000
Aiming Angle:
0° 30° Horizontal 30° Vertical 45°Vertical
Aiming Angle:
0° 30° Horizontal 30° Vertical 45°Vertical
D C FC L W
6' 3.5' 69 6.1' 5.0'
8' 4.6' 39 8.1' 6.7'
10' 5.8' 25 10.2' 8.4'
12' 6.9' 17 12.2' 10.1'
D C FC L W
2' 3.5' 120 9.7' 2.9'
3' 5.2' 53 14.5' 4.4'
4' 6.9' 30 19.3' 5.8'
5' 8.7' 19 24.2' 7.3'
D C FC L W
3' 3.0' 151 5.0' 3.1'
4' 4.0' 85 6.7' 4.1'
5' 5.0' 54 8.4' 5.1'
6' 6.0' 38 10.1' 6.2'
D FC L W
6' 107 4.4' 4.4'
8' 60 5.8' 5.8'
10' 38 7.3' 7.3'
12' 27 8.7' 8.7'
6' 4.5' 111 4.0' 5.0'
8' 5.8' 71 5.0' 6.7'
10' 6.9' 49 6.0' 8.4'
12' 8.1' 36 7.0' 10.1'
D C FC L W D C FC L W
2' 5.2' 152 5.0' 2.2'
3' 6.9' 85 6.6' 3.0'
4' 8.7' 55 8.3' 3.7'
5' 10.4' 38 9.9' 4.4'
D C FC L W
5' 5.0' 155 3.8' 2.6'
6' 6.0' 107 4.6' 3.1'
7' 7.0' 79 5.4' 3.7'
8' 8.0' 60 6.1' 4.2'
D FC L W
6' 171 3.0' 3.0'
8' 109 3.7' 3.7'
10' 76 4.4' 4.4'
12' 56 5.2' 5.2'
MHT6RS Metal Halide T-6 Reflector Spot
MHT6RF Metal Halide T-6 Reflector Flood
Job Information Type:
37121
ProSpec™277V HID, Cylinder, 39W T6 CMH
Page 2 of 3

LBeam Length DDistance
W Beam Width AAiming Angle
CDistance to FC Footcandles
center beam
Land Ware the outer points where the candle
power drops to 50% of the maximum. FC are the
initial footcandles at the center of the beam.
Lamp data shown is typical. Consult lamp
manufacturers for availability and performance.
CBCP = Center Beam Candle Power .
Flood Reflector with 39W T-6 Master Color
Ceramic Metal Halide Philips (Clear) Lamp
Lamp
Beam Spread
(To 50% CBCP) CBCP Rated Life (Hrs.)
28,105 9,000
39W T6 CMH
10° 12,000
Aiming Angle:
0° 30° Horizontal 30° Vertical 45°Vertical
MHT6RF Metal Halide T-6 Reflector Flood
D C FC L W
6' 4.6' 285 1.9' 1.6'
12' 6.9' 127 2.8' 2.4'
16' 9.2' 71 3.7' 3.2'
20' 11.5' 46 4.7' 4.0'
D C FC L W
4' 6.9' 220 2.9' 1.4'
6' 10.4' 98 4.3' 2.1'
8' 13.9' 55 5.7' 2.8'
10' 17.3' 35 7.2' 3.5'
D C FC L W
6' 6.0' 276 2.1' 1.5'
9' 9.0' 123 3.2' 2.2'
12' 12.0' 69 4.2' 3.0'
15' 15.0' 44 5.3' 3.7'
D FC L W
10' 281 1.7' 1.7'
15' 125 2.6' 2.6'
20' 70 3.5' 3.5'
25' 45 4.4' 4.4'
Philips Lightolier
e: [email protected]
t: [phone]
w: www.lightolier.com
37121 October 11, 2011
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2010.All rights reserved.
Job Information Type:
37121
ProSpec™277V HID, Cylinder, 39W T6 CMH
Page 3 of 3
