BARRON Exitronix NFT Series User manual

IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations
if applicable.
• Do not mount near gas or electrical heaters.
• Do not use outdoors.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering
by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• Allow battery to charge for 24 hours before first use.
• For use with metal enclosed wiring systems.
SAVE THESE INSTRUCTIONS!
NFT Series
Installation Instructions
10070187 REV 4 - 07/19 1 800-533-3948 www.barronltg.com
Technical Support ■ [phone] ■ [email protected]


NFT Series
Installation Instructions
10070187 REV 4 - 07/19 2 800-533-3948 www.barronltg.com
Wall/Ceiling Mount - Back Power Feed
1. Insert a flat blade screwdriver into the two slots to remove front cover
from backplate. (Fig 1).
2. Remove knockout from center of backplate and route wires through the
hole.
3. Remove appropriate knockouts on backplate and mount to junction box.
4. Connect the fixture wires to the power supply wires using the wire nuts
provided. Connections should be made inside junction box. Connect the
white wire to neutral and black wire to the hot lead. Refer to Wiring
Diagram section.
5. Connect remote lamp wires if fixture is remote capable. Refer to Remote
Lamp Connection section.
6. Connect battery to PCB.
7. Snap the front cover on the backplate.
8. Restore power and then test fixture by pressing test button. LED heads
will turn on.
9. Adjust the direction of lamp heads for optimal lighting coverage.
Wall Mount - Top Power Feed
1. Insert a flat blade screwdriver into the two slots to remove front cover
from backplate.
2. Remove top knockout on the top flange of fixture for the flexible conduit
access hole.
3. Secure flexible conduit to access hole and route wires through conduit
to junction box. (Fig. 3)
4. Remove appropriate knockouts from backplate and mount to wall.
5. Connect the fixture wires to the power supply wires using the wire nuts
provided. Connections should be made inside junction box.
Connect the white wire to neutral and black wire to the hot lead.
Refer to Wiring Diagram section.
6. Connect remote lamp wires if fixture is remote capable.
Refer to Remote Lamp Connection section.
7. Connect battery to PCB.
8. Snap the front cover on the backplate.
9. Restore power and then test fixture by pressing test button.
LED heads will turn on.
10. Adjust the direction of lamp heads for optimal lighting coverage.
Open Fixture
Use Screwdriver
to Pry Open
Mounting
Screws
Backplate
Battery
Connector
Front
Cover
Wall Mount - Back Power Feed
Fig. 2
Fig. 1
Wall Mount - Top Power Feed
Fig. 3
Flexible
Conduit
Junction Box
Wire Nuts
Mounting
Screws

NFT Series
Installation Instructions
10070187 REV 4 - 07/19 3 800-533-3948 www.barronltg.com
Remote Lamp Connection - 9V, 5.4W Max (Option)
1. Remove ground male connector from the female connector.
2. Plug the remote male connector into the female connector.
3. Connect extended remote head wires to the remote wires using wire nut.
Yellow positive (+)
Purple negative (-)
Fig. 4
Female Connector
Ground
Male Connector
Fig. 5
Extended
Remote Wires
Remote Wire
Wire Nut
Female Connector
Remote Male Connector
AC INPUT
White Neutral
Black 120-277VAC
Integral
LED Head
Remote Heads
(Option)
Battery

NFT Series
Installation Instructions
10070187 REV 4 - 07/19 4 800-533-3948 www.barronltg.com
Self-test/Self-diagnostics Option
1. When AC power is supplied to fixture, the unit will automatically initiate a Self-test/Self-diagnostic as follows:
• Verifies battery disconnection, charger board failure, lamps failure and transformer failure at every 5 seconds.
• 3 Minute Self-testing every month.
• 90 Minutes Self-testing on the 12th month of the year after installation.
2. Dual color LED lamp indicator shows the following status:
• Green color: ON/ Ready
Blinking: Testing
• Red color (Service Alert)
• Service Alert LED Code (Red color LED lamp indicator)
CAUTION:
After solving the fault of emergency equipment, please press test button for 2 seconds without releasing to reset.
LED indicator will show green.
3. For manual test, press test button as follows:
One blink ON/pause for 4 seconds Battery is not connected
Two blinks ON/pause for 4 seconds Battery is shorted or battery voltage drops below acceptable level
Three blinks ON/pause for 4 seconds Charger board circuit fault
Four blinks ON/pause for 4 seconds Transfer fault
Five blinks ON/pause for 4 seconds Emergency lamp fault
Six blinks ON/pause for 4 seconds Remote head's emergency lamp fault (if installed)
Press test button once within 2 seconds 30
Second test
Press test button twice within 2 seconds 3 Minute test
Press test button 3 times within 2 seconds 30 Minute test
Press test button 4 times within 2 seconds 90 Minute test
